Kuppersbusch FKF8800.1i Operation manual

BEDIENUNGSANWEISUNG
mit Montageanweisungen
INSTRUCTIONS FOR USE
and installation
Lesen Sie unbedingt die Gebrauchsanleitung
und den Montageplan vor Aufstellung,
Installation sowie Inbetriebnahme.
Please read the users and installation
instructions carefully before installation
of the appliance and before starting to use it.
Service und Kundendienst
Telefon: 0209 – 401 631
Email: [email protected]
FKF8800.1i
EN PT ES

CONTENTS
Safety information 2
Safety instructions 4
Installation 6
Control Panel 8
Daily use 10
Hints and tips 11
Care and cleaning 14
Troubleshooting 14
Noises 18
Technical data 18
Information for test institutes 19
Subject to change without notice.
VISIT OUR WEBSITE TO:
Get usage advice, brochures, trouble shooter, service and repair
information:
www.kueppersbusch-home.com
SAFETY INFORMATION
Before the installation and use of the appliance, carefully
read the supplied instructions. The manufacturer is not
responsible for any injuries or damage that are the result of
incorrect installation or usage. Always keep the instructions
in a safe and accessible location for future reference.
Children and vulnerable people safety
•This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
the use of the appliance in a safe way and understand the
hazards involved.
•Children aged from 3 to 8 years are allowed to load and
unload the appliance provided that they have been
properly instructed.
•This appliance may be used by persons with very
extensive and complex disabilities provided that they have
been properly instructed.
•Children of less than 3 years of age should be kept away
from the appliance unless continuously supervised.
•Do not let children play with the appliance.
2

•Children shall not carry out cleaning and user maintenance
of the appliance without supervision.
•Keep all packaging away from children and dispose of it
appropriately.
General Safety
•This appliance is intended to be used in household and
similar applications such as:
–Farm houses; staff kitchen areas in shops, offices and
other working environments;
–By clients in hotels, motels, bed and breakfast and other
residential type environments.
•To avoid contamination of food respect the following
instructions:
–do not open the door for long periods;
–clean regularly surfaces that can come in contact with
food and accessible drainage systems;
–store raw meat and fish in suitable containers in the
refrigerator, so that it is not in contact with or drip onto
other food.
•WARNING: Keep ventilation openings, in the appliance
enclosure or in the built-in structure, clear of obstruction.
•WARNING: Do not use mechanical devices or other
means to accelerate the defrosting process, other than
those recommended by the manufacturer.
•WARNING: Do not damage the refrigerant circuit.
•WARNING: Do not use electrical appliances inside the
food storage compartments of the appliance, unless they
are of the type recommended by the manufacturer.
•Do not use water spray and steam to clean the appliance.
•Clean the appliance with a moist soft cloth. Only use
neutral detergents. Do not use abrasive products, abrasive
cleaning pads, solvents or metal objects.
•When the appliance is empty for long period, switch it off,
defrost, clean, dry and leave the door open to prevent
mould from developing within the appliance.
3

•Do not store explosive substances such as aerosol cans
with a flammable propellant in this appliance.
•If the supply cord is damaged, it must be replaced by the
manufacturer, its Authorised Service Centre or similarly
qualified persons in order to avoid a hazard.
SAFETY INSTRUCTIONS
Installation
WARNING! Only a qualified
person must install this
appliance.
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Do not use the appliance before
installing it in the built-in structure due
to safety manner.
• Follow the installation instructions
supplied with the appliance.
• Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.
• Make sure the air can circulate around
the appliance.
• At first installation or after reversing the
door wait at least 4 hours before
connecting the appliance to the power
supply. This is to allow the oil to flow
back in the compressor.
• Before carrying out any operations on
the appliance (e.g. reversing the door),
remove the plug from the power socket.
• Do not install the appliance close to
radiators or cookers, ovens or hobs.
• Do not expose the appliance to the
rain.
• Do not install the appliance where there
is direct sunlight.
• Do not install this appliance in areas
that are too humid or too cold.
• When you move the appliance, lift it by
the front edge to avoid scratching the
floor.
• The appliance contains a bag of
desiccant. This is not a toy. This is not
food. Please dispose of it immediately.
Electrical connection
WARNING! Risk of fire and
electric shock.
WARNING! When positioning
the appliance, ensure the
supply cord is not trapped or
damaged.
WARNING! Do not use multi-
plug adapters and extension
cables.
• The appliance must be earthed.
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• Always use a correctly installed
shockproof socket.
• Make sure not to cause damage to the
electrical components (e.g. mains plug,
mains cable, compressor). Contact the
Authorised Service Centre or an
electrician to change the electrical
components.
• The mains cable must stay below the
level of the mains plug.
• Connect the mains plug to the mains
socket only at the end of the
installation. Make sure that there is
access to the mains plug after the
installation.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
Use
WARNING! Risk of injury,
burns, electric shock or fire.
4

The appliance contains flammable
gas, isobutane (R600a), a natural gas with
a high level of environmental compatibility.
Be careful not to cause damage to the
refrigerant circuit containing isobutane.
• Do not change the specification of this
appliance.
• Do not put electrical appliances (e.g.
ice cream makers) in the appliance
unless they are stated applicable by the
manufacturer.
• If damage occurs to the refrigerant
circuit, make sure that there are no
flames and sources of ignition in the
room. Ventilate the room.
• Do not let hot items to touch the plastic
parts of the appliance.
• Do not store flammable gas and liquid
in the appliance.
• Do not put flammable products or items
that are wet with flammable products
in, near or on the appliance.
• Do not touch the compressor or the
condenser. They are hot.
Internal lighting
WARNING! Risk of electric
shock.
• The type of lamp used for this
appliance is for household appliances
only. Do not use it for house lighting.
Care and cleaning
WARNING! Risk of injury or
damage to the appliance.
• Before maintenance, deactivate the
appliance and disconnect the mains
plug from the mains socket.
• This appliance contains hydrocarbons
in the cooling unit. Only a qualified
person must do the maintenance and
the recharging of the unit.
• Regularly examine the drain of the
appliance and if necessary, clean it. If
the drain is blocked, defrosted water
collects in the bottom of the appliance.
Service
• To repair the appliance contact the
Authorised Service Centre. Use original
spare parts only.
• Please note that self-repair or non-
professional repair can have safety
consequences and might void the
guarantee.
• The following spare parts will be
available for 7 years after the model
has been discontinued: thermostats,
temperature sensors, printed circuit
boards, light sources, door handles,
door hinges, trays and baskets. Please
note that some of these spare parts are
only available to professional repairers,
and that not all spare parts are relevant
for all models.
• Door gaskets will be available for 10
years after the model has been
discontinued.
Disposal
WARNING! Risk of injury or
suffocation.
• Disconnect the appliance from the
mains supply.
• Cut off the mains cable and discard it.
• Remove the door to prevent children
and pets to be closed inside of the
appliance.
• The refrigerant circuit and the insulation
materials of this appliance are ozone-
friendly.
• The insulation foam contains
flammable gas. Contact your municipal
authority for information on how to
discard the appliance correctly.
• Do not cause damage to the part of the
cooling unit that is near the heat
exchanger.
5

INSTALLATION
WARNING! Refer to Safety
chapters.
WARNING! Refer to
installation instruction
document to install your
appliance.
WARNING! Fix the appliance
in accordance with installation
instruction document to avoid a
risk of instability of the
appliance.
Dimensions
B
A
H1
W1
D1
W2
D2
W3
D3
Overall dimensions
1)
H1 mm 1769
W1 mm 556
6

Overall dimensions
1)
D1 mm 549
1) the height, width and depth of the appliance without
the handle and feet
Space required in use
1)
H2 (A+B) mm 1816
W2 mm 560
D2 mm 552
A mm 1780
B mm 36
1) the height, width and depth of the appliance includ‐
ing the handle, plus the space necessary for free circu‐
lation of the cooling air
Overall space required in use
1)
H3 (A+B) mm 1816
W3 mm 780
D3 mm 1085
1) the height, width and depth of the appliance includ‐
ing the handle, plus the space necessary for free circu‐
lation of the cooling air, plus the space necessary to
allow door opening to the minimum angle permitting
removal of all internal equipment
Location
To ensure appliance's best functionality,
you should not install the appliance in the
nearby of the heat source (oven, stoves,
radiators, cookers or hobs) or in a place
with direct sunlight. Make sure that air can
circulate freely around the back of the
cabinet.
Positioning
This appliance should be installed in a dry,
well ventilated indoor position.
This appliance is intended to be used at
ambient temperature ranging from 10°C to
38°C.
If you have any doubts
regarding where to install the
appliance, please turn to the
vendor, to our customer service
or to the nearest Authorised
Service Centre.
It must be possible to
disconnect the appliance from
the mains power supply. The
plug must therefore be easily
accessible after installation.
Electrical connection
• Before plugging in, ensure that the
voltage and frequency shown on the
rating plate correspond to your
domestic power supply.
• The appliance must be earthed. The
power supply cable plug is provided
with a contact for this purpose. If the
domestic power supply socket is not
earthed, connect the appliance to a
separate earth in compliance with
current regulations, consulting a
qualified electrician.
• The manufacturer declines all
responsibility if the above safety
precautions are not observed.
• This appliance complies with the E.E.C.
Directives.
Ventilation requirements
The airflow behind the appliance must be
sufficient.
5 cm min.
200 cm2
min.
200 cm2
7

CAUTION! Refer to the
installation instructions for the
installation.
Door reversibility
Please refer to the separate document
with instructions on installation and door
reversal.
CAUTION! At every stage of
reversing the door protect the
floor from scratching with a
durable material.
CONTROL PANEL
Functions
32 45
6
1
1Display
2Temperature warmer button
3Temperature colder button
4OK
5Functions
6ON/OFF
It is possible to change predefined sound
of buttons by pressing together Functions
and temperature colder button for a few
seconds. Change is reversible.
Display
Off
min
A B C D
EFG
A. Timer indicator
B. Shopping function
C. NaturaFresh function
D. Temperature indicator
E. Alarm indicator
F. ChildLock function
G. DrinksChill function
Switching on
1. Connect the mains plug to the power
socket.
2. Press the appliance ON/OFF if the
display is off. The temperature
indicators show the set default
temperature.
To select a different set temperature refer
to "Temperature regulation".
If "dEMo" appears on the display, refer to
"Troubleshooting" .
Switching off
1. Press the appliance ON/OFF for 3
seconds.
The display switches off.
8

2. Disconnect the mains plug from the
power socket.
Temperature regulation
Set the temperature of the appliance by
pressing the temperature regulators.
Default recommended set temperature is:
• +4°C for the fridge
The temperature range may vary between
2°C and 8°C for fridge.
The temperature indicators show the set
temperature.
The set temperature will be
reached within 24 hours.
After a power failure the set
temperature remains stored.
Shopping function
If you need to insert in the fridge
compartment a large amount of warm
food, for example after doing the grocery
shopping, we suggest activating the
Shopping function to chill the products
more rapidly and to avoid warming the
other food which is already in the
refrigerator.
1. Press the Functions until the
corresponding icon appears.
The Shopping indicator flashes.
2. Press the OK to confirm.
The Shopping indicator is shown.
This function stops automatically after
approximately 6 hours.
You can deactivate the Shopping function
before its automatic end by repeating the
procedure or by selecting a different fridge
set temperature.
NaturaFresh compartment
setting
The storage temperature and the relative
humidity in NaturaFresh compartment
provide optimal conditions for the storage
of various kinds of fresh food (like fish,
meat, seafood, etc.) as it preserves its
high nutritional values, as well as high
humidity level much longer than regular
refrigerator.
1. Press Functions until the
corresponding icon appears.
The display shows 3. This is the default
setting that ensures the most effective
performance.
The possible settings can vary from 1 (the
coldest) to 5 (the warmest).
Settings from 1 to 3 are suitable for fish
and meat.
Settings 4 and 5 are suitable for
vegetables and fruits. In these settings the
compartment works similarly to the fridge
compartment.
2. Press the temperature buttons on the
control panel to select the required
setting.
3. Press OK to confirm the setting.
The indicator returns to the fridge
temperature setting in a few seconds.
ChildLock function
Activate the ChildLock function to lock the
buttons from unintentional operation.
1. Press Functions until the
corresponding icon appears.
The ChildLock indicator flashes.
2. Press OK to confirm.
The ChildLock indicator is shown.
To deactivate the ChildLock function,
repeat the procedure until the ChildLock
indicator goes off.
DrinksChill function
The DrinksChill function is to be used to
set an acoustic alarm at the preferred
time, useful for example when a recipe
requires to cool down food products for a
certain period of time.
1. Press Functions until the
corresponding icon appears.
The DrinksChill indicator flashes.
The Timer shows the set value (30
minutes) for a few seconds.
2. Press the Timer regulator to change
the Timer set value from 1 to 90
minutes.
3. Press OK to confirm.
The DrinksChill indicator is shown.
The Timer starts to flash (min).
9

At the end of the countdown the "0 min"
indicator flashes and an audible alarm
sounds. Press OK to switch off the sound
and terminate the function.
To switch off the function repeat the
procedure until the DrinksChill goes off.
It is possible to change the time
at any time during the
countdown and at the end by
pressing the Temperature
colder button and the
Temperature warmer button.
Door open alarm
If the fridge door is left open for
approximately 5 minutes, the sound is on
and alarm indicator flashes.
The alarm stops after closing the door.
During the alarm, the sound can be muted
by pressing any button.
If you do not press any button,
the sound switches off
automatically after around one
hour to avoid disturbing.
DAILY USE
Positioning the door shelves
To permit storage of food packages of
various sizes, the door shelves can be
placed at different heights.
1. Gradually pull the shelf up until it
comes free.
2. Reposition as required.
Movable shelves
The walls of the refrigerator are equipped
with a series of runners so that the
shelves can be positioned as desired.
This appliance is also equipped with a
shelf consisting of two parts. The front half
of the shelf can be placed under the
second half to make better use of space.
To fold the shelf:
1. Take out the front half gently.
2. Slide it into the lower rail and under the
second half.
1
2
Do not move the glass shelf
above the vegetable drawer to
ensure correct air circulation.
NaturaFresh compartment
The storage temperature and the relative
humidity in this compartment provide
optimal conditions for the storage of
various kinds of food.
10

To learn about the temperature settings in
the NaturaFresh compartment please refer
to the “NaturaFresh compartment setting”
section.
NaturaFresh compartment is suitable for
the storage of a variety of fresh food (like
fish, meat, seafood, etc.) as it preserves
its high nutritional values as well as high
humidity level much longer in comparison
to the regular refrigerator.
Humidity control
The NaturaFresh compartment has stops
that prevent the drawers from falling out
when fully extended. To remove the
drawer:
1. Pull the drawer to the maximum.
2. Lift and pull out the drawer.
The drawers marked with water drop
symbols: and can be used
according to the desired storage
conditions independently of each other
with lower or higher humidity.
Regulation for each drawer is separate
and is controlled using the slide valve at
the front of the drawer.
• “Dry”: low relative humidity.
This humidity level is reached when
both sliders are set into this position
and the ventilation openings are wide
open.
• “Humid”: high relative humidity.
This humidity level is reached when
both sliders are set in this position
and the ventilation openings are
closed. Humidity is kept and can not
escape.
DYNAMICAIR
The refrigerator compartment is equipped
with a device that allows rapid cooling of
foods and keeps more uniform
temperature in the compartment.
This device activates automatically when
needed.
The fan operates only when the
door is closed.
HINTS AND TIPS
Hints for energy saving
• Most efficient use of energy is ensured
in the configuration with the drawers in
the bottom part of the appliance and
shelves evenly distributed. Position of
the door bins does not affect energy
consumption.
• Do not open the door frequently or
leave it open longer than necessary.
• Do not set too high temperature to save
energy unless it is required by the
characteristics of the food.
• Ensure a good ventilation. Do not cover
the ventilation grilles or holes.
• Make sure that food products inside the
appliance allow air circulation through
dedicated holes in the rear interior of
the appliance.
11

Hints for fresh food refrigeration
• Good temperature setting that ensures
preservation of fresh food is a
temperature less than or equal to +4°C.
Higher temperature setting inside the
appliance may lead to shorter shelf life
of food.
• Cover the food with packaging to
preserve its freshness and aroma.
• Always use closed containers for
liquids and for food, to avoid flavours or
odours in the compartment.
• To avoid the cross-contamination
between cooked and raw food, cover
the cooked food and separate it from
the raw one.
• It is recommended to defrost the food
inside the fridge.
• Do not insert hot food inside the
appliance. Make sure it has cooled
down at room temperature before
inserting it.
• To prevent food waste the new stock of
food should always be placed behind
the old one.
Hints for food refrigeration
• Meat (all types): wrap in a suitable
packaging and place it on the glass
shelf above the vegetable drawer.
Store meat for at most 1-2 days.
• Fruit and vegetables: clean thoroughly
(eliminate the soil) and place in a
special drawer (vegetable drawer).
• It is advisable not to keep the exotic
fruits like bananas, mangos, papayas
etc. in the refrigerator.
• Vegetables like tomatoes, potatoes,
onions, and garlic should not be kept in
the refrigerator.
• Butter and cheese: place in an airtight
container or wrap in an aluminium foil
or a polythene bag to exclude as much
air as possible.
• Bottles: close them with a cap and
place them on the door bottle shelf, or
(if available) on the bottle rack.
• Always refer to the expiry date of the
products to know how long to keep
them.
Hints for fresh food storage in NaturaFresh compartment
Type of food Air humidity adjustment Storage time
Butter “dry” up to 1 month
Beef, venison, small meat
cuts, poultry “dry” up to 7 days
Tomato sauce “dry” up to 4 days
Fish, shellfish, cooked meat
products “dry” up to 3 days
Cooked seafood “dry” up to 2 days
Salad, vegetables
Carrots, herbs, brussels
sprouts, celery
“humid” up to 1 month
Artichokes, cauliflower,
chicory, iceberg lettuce, en‐
dive, lamb’s lettuce, lettuce,
leeks, radicchio
“humid” up to 21 days
12

Type of food Air humidity adjustment Storage time
Broccoli, Chinese leaves,
kale, cabbage, radishes,
Savoy cabbage
“humid” up to 14 days
Peas, kohlrabi “humid” up to 10 days
Spring onions, radishes, as‐
paragus, spinach “humid” up to 7 days
Fruit
Pears, dates (fresh), straw‐
berries, peaches
“humid” up to 1 month
Plums
rhubarb, gooseberries “humid” up to 21 days
Apples (not sensitive to
cold), quinces “humid” up to 20 days
Apricots, cherries “humid” up to 14 days
Damsons, grapes “humid” up to 10 days
Blackberries, currants “humid” up to 8 days
Figs (fresh) “humid” up to 7 days
Blueberries, raspberries “humid” up to 5 days
Cakes containing cream and other kinds
of pastry products can be stored in the
NaturaFresh compartment for 2 or 3 days.
Not to be placed in the NaturaFresh
compartment:
• Cold sensitive fruit which have to be
stored at cellar or room temperature
like pineapple, bananas, grapefruit,
melons, mango, papaya, oranges,
lemons, kiwi fruit.
• Vegetables which have to be stored at
room temperature like tomatoes,
potatoes, onions, and garlic.
• The types of food not mentioned above
should be stored in the refrigerator
compartment (e.g. all sorts of cheese,
cold cuts, etc.).
The level of air humidity in the
drawers depends on the
content of humidity in the
stored food, vegetable and fruit
and on the frequency of door
opening.
The NaturaFresh compartment is also
suitable for slow thawing of food. In this
case the thawed food can be stored in the
NaturaFresh compartment for up to two
days.
• Pay attention to the freshness of the
food, especially on the expiry date.
Quality and freshness influence the
storage time.
• The whole storage cycle time will
depend on the preservation conditions
made prior to the final storage in the
fridge.
13

• Any type of food, fruit, vegetable or
animal food shall always be packed or
wrapped up before storage.
• Food rich in proteins will go bad
quicker. This means seafood will spoil
before fish which in turn will spoil
before meat. While storing food in a
NaturaFresh compartment storage time
for that kind of food can be increased
by up to three times as well without
loss on quality.
• All food stored in a NaturaFresh
compartment should be taken out of
the drawers roughly 15 - 30 min before
consumption, particularly fruit and
vegetables to be consumed without any
additional cooking process. Allowing
fruit and vegetables to return to room
temperature will improve the texture
and flavour.
CARE AND CLEANING
WARNING! Refer to Safety
chapters.
Cleaning the interior
Before using the appliance for the first
time, the interior and all internal
accessories should be washed with
lukewarm water and some neutral soap to
remove the typical smell of a brand-new
product, then dried thoroughly.
CAUTION! Do not use
detergents, abrasive powders,
chlorine or oil-based cleaners
as they will damage the finish.
CAUTION! The accessories
and parts of the appliance are
not suitable for washing in a
dishwasher.
Periodic cleaning
The equipment has to be cleaned
regularly:
1. Clean the inside and accessories with
lukewarm water and some neutral
soap.
2. Regularly check the door seals and
wipe them clean to ensure they are
clean and free from debris.
3. Rinse and dry thoroughly.
Defrosting of the refrigerator
Defrosting of the fridge compartment is
automatic. The water that condenses
flows into a recipient on the compressor
and evaporates. The recipient cannot be
removed.
Period of non-operation
When the appliance is not in use for long
period, take the following precautions:
1. Disconnect the appliance from
electricity supply.
2. Remove all food.
3. Clean the appliance and all
accessories.
4. Leave the door open to prevent
unpleasant smells.
TROUBLESHOOTING
WARNING! Refer to Safety
chapters.
14

What to do if...
Problem Possible cause Solution
The appliance does not op‐
erate.
The appliance is switched
off.
Switch on the appliance.
The mains plug is not con‐
nected to the mains socket
correctly.
Connect the mains plug to
the mains socket correctly.
There is no voltage in the
mains socket.
Connect a different electrical
appliance to the mains sock‐
et. Contact a qualified elec‐
trician.
The appliance is noisy. The appliance is not suppor‐
ted properly.
Check if the appliance
stands stable.
Acoustic or visual alarm is
on.
The cabinet has been re‐
cently switched on.
Refer to "Door Open Alarm"
or "High Temperature
Alarm".
The temperature in the ap‐
pliance is too high.
Refer to "Door Open Alarm"
or "High Temperature
Alarm".
The door is left open. Close the door.
The compressor operates
continually.
Temperature is set incor‐
rectly.
Refer to "Control Panel"
chapter.
Many food products were
put in at the same time.
Wait a few hours and then
check the temperature
again.
The room temperature is too
high.
Refer to "Installation" chap‐
ter.
Food products placed in the
appliance were too warm.
Allow food products to cool
to room temperature before
storing.
The door is not closed cor‐
rectly.
Refer to "Closing the door"
section.
The Shopping function is
switched on.
Refer to "Shopping function"
section.
The compressor does not
start immediately after
pressing the "Shopping", or
after changing the tempera‐
ture.
The compressor starts after
a period of time.
This is normal, no error has
occurred.
15

Problem Possible cause Solution
Door is misaligned or inter‐
feres with ventilation grill.
The appliance is not level‐
led.
Refer to installation instruc‐
tions.
Door does not open easily. You attempted to re-open
the door immediately after
closing.
Wait a few seconds between
closing and re-opening of
the door.
The lamp does not work. The lamp is in stand-by
mode.
Close and open the door.
The lamp is defective. Contact the nearest Author‐
ized Service Centre.
There is too much frost and
ice.
The door is not closed cor‐
rectly.
Refer to "Closing the door"
section.
The gasket is deformed or
dirty.
Refer to "Closing the door"
section.
Food products are not wrap‐
ped properly.
Wrap the food products bet‐
ter.
Temperature is set incor‐
rectly.
Refer to "Control Panel"
chapter.
Appliance is fully loaded and
is set to the lowest tempera‐
ture.
Set a higher temperature.
Refer to "Control Panel"
chapter.
Temperature set in the ap‐
pliance is too low and the
ambient temperature is too
high.
Set a higher temperature.
Refer to "Control Panel"
chapter.
Water flows on the rear plate
of the refrigerator.
During the automatic de‐
frosting process, frost melts
on the rear plate.
This is correct.
There is too much con‐
densed water on the rear
wall of the refrigerator.
Door was opened too fre‐
quently.
Open the door only when
necessary.
Door was not closed com‐
pletely.
Make sure the door is
closed completely.
Stored food was not wrap‐
ped.
Wrap food in suitable pack‐
aging before storing it in the
appliance.
Water flows on the floor. The melting water outlet is
not connected to the evapo‐
rative tray above the com‐
pressor.
Attach the melting water out‐
let to the evaporative tray.
16

Problem Possible cause Solution
Temperature cannot be set. The "Shopping function" is
switched on.
Switch off "Shopping func‐
tion" manually, or wait until
the function deactivates au‐
tomatically to set the tem‐
perature. Refer to "Shopping
function" section.
The temperature in the ap‐
pliance is too low/too high.
The temperature is not set
correctly.
Set a higher/lower tempera‐
ture.
The door is not closed cor‐
rectly.
Refer to "Closing the door"
section.
The food products' tempera‐
ture is too high.
Let the food products tem‐
perature decrease to room
temperature before storage.
Many food products are
stored at the same time.
Store less food products at
the same time.
The door has been opened
often.
Open the door only if neces‐
sary.
The Shopping function is
switched on.
Refer to "Shopping function"
section.
There is no cold air circula‐
tion in the appliance.
Make sure that there is cold
air circulation in the appli‐
ance. Refer to "Hints and
Tips" chapter.
Some specific surfaces in‐
side the fridge compartment
are warmer at some times.
This is a normal state.
DEMO appears on the dis‐
play.
The appliance is in demon‐
stration mode.
Keep the OK key pressed
for approximately 10 sec‐
onds until a long sound is
heard and the display turns
off for a short time.
A or or symbol is
shown instead of numbers
on the temperature display.
Temperature sensor prob‐
lem.
Contact the nearest Author‐
ized Service Centre (the
cooling system will continue
to keep food products cold,
but temperature adjustment
will not be possible).
If the advice does not lead to
the desired result, call the
nearest Authorized Service
Centre.
Replacing the lamp
The appliance is equipped with a longlife
LED interior light.
17

Only service is allowed to replace the
lighting device. Contact your Authorised
Service Centre.
Closing the door
1. Clean the door gaskets.
2. If necessary, adjust the door. Refer to
installation instructions.
3. If necessary, replace the defective
door gaskets. Contact the Authorised
Service Centre.
NOISES
SSSRRR!
CLICK!
HISSS!
BRRR!
BLUBB!
TECHNICAL DATA
The technical information is situated in the
rating plate on the internal side of the
appliance and on the energy label.
The QR code on the energy label supplied
with the appliance provides a web link to
the information related to the performance
of the appliance in the EU EPREL
database. Keep the energy label for
reference together with the user manual
and all other documents provided with this
appliance.
It is also possible to find the same
information in EPREL using the link
https://eprel.ec.europa.eu and the model
name and product number that you find on
the rating plate of the appliance.
See the link www.theenergylabel.eu for
detailed information about the energy
label.
18

INFORMATION FOR TEST INSTITUTES
Installation and preparation of the
appliance for any EcoDesign verification
shall be compliant with EN 62552.
Ventilation requirements, recess
dimensions and minimum rear clearances
shall be as stated in this User Manual at
Chapter 3. Please contact the
manufacturer for any other further
information, including loading plans.
ENVIRONMENTAL CONCERNS
Recycle materials with the symbol . Put
the packaging in relevant containers to
recycle it. Help protect the environment
and human health by recycling waste of
electrical and electronic appliances. Do
not dispose of appliances marked with the
symbol with the household waste.
Return the product to your local recycling
facility or contact your municipal office.
19

ÍNDICE
Informações de segurança 20
Instruções de segurança 22
Instalação 24
Painel de comandos 27
Utilização diária 29
Sugestões e dicas 30
Manutenção e limpeza 33
Resolução de problemas 34
Ruídos 38
Dados técnicos 38
Informação para testes 38
Sujeito a alterações sem aviso prévio.
VISITE O NOSSO WEBSITE PARA:
Resolver problemas e obter conselhos de utilização, catálogos e
informações sobre assistência e reparações:
www.kueppersbusch-home.com
INFORMAÇÕES DE SEGURANÇA
Leia atentamente as instruções fornecidas antes de instalar
e utilizar o aparelho. O fabricante não poderá ser
responsabilizado por ferimentos ou danos resultantes de
instalação incorreta ou utilização incorreta. Guarde sempre
as instruções num sítio seguro e acessível para consultar no
futuro.
Segurança para crianças e pessoas vulneráveis
•Este aparelho pode ser utilizado por crianças de 8 ou mais
anos de idade e por pessoas com capacidades físicas,
sensoriais ou mentais reduzidas ou com pouca
experiência e conhecimento se tiverem recebido
supervisão ou instruções relativas à utilização do aparelho
de forma segura e compreenderem os perigos envolvidos.
•Crianças com idades entre os 3 e os 8 anos estão
autorizadas a carregar e descarregar o aparelho desde
que tenham sido devidamente instruídas.
•Este aparelho pode ser utilizado por pessoas com
incapacidades muitos extensas e complexas desde que
devidamente instruídas.
•É necessário manter as crianças com menos de 3 anos de
idade afastadas do aparelho, a menos que
constantemente vigiadas.
20
