FILE: 09-133
DATE: 05-08-00
INSTRUCTION MANUAL
418 MHZ TRANSMITTER
and RECEIVER
A Radio Frequency Control Link That Permits
Operating Electrical Devices In A Building From
A Transmitter In A Vehicle
MODEL# 091-133
INPUT, RECEIVER: 120VOLTS, 50/60 Hz AC
TRANSMITTER: 12 VOLTS DC
OUTPUT: RELAY CONTACT CLOSURE. N.O., 2 AMPS
3 YEAR WARRANTY
INTRODUCTION
ANY CHANGE MADE BY THE USER TO
THIS EQUIPMENT WITHOUT THE WRITTEN
APPROVAL OF KUSSMAUL ELECTRONICS CO INC
COULD VOID THE USERS AUTHORITY TO
OPERATE THIS EQUIPMENT
CAUTION:

The Model 091-133 418 MHz Transmitter/Receiver is a remote control system
between a vehicle and a building. It is intended to operate various electrical
devices in the building when signaled to do so from the vehicle. The Transmitter
is installed in the vehicle above the dash and near the windshield. The receiver
is installed on a shelf or on a wall, away from large metallic surfaces. The
transmitter and receiver have four proprietary channels; channels 6, 7,8, & 9.
Channel 9 is dedicated to automatically producing a 1 second closed contact at
the receiver channel 9 output upon the ignition switch being turned on. This is
intended to actuate the Fan Controller in the building. The other three channels
could be used to open the door, close the door, or stop door movement. The
other three channels are operated by momentary push button switch mounted on
the dashboard by the installer.
Each Transmitter and Receiver can be coded using a DIP switch mounted on
each unit. In this way any number of proprietary channels can be implemented.
The Transmitter is of such low power that a license is not required to
operate it, and it has a range of 150 feet to the receiver. For single receiver
systems; each truck can have a transmitter which will communicate with
the single receiver. For multiple Receiver systems each Receiver will be
assigned a code. A given Transmitter will only communicate with a
receiver if it has the code as that receiver. Dip switches on the Receiver
and Transmitter code the Transmitter and Receiver. Thirty-two different
codes are possible.
INSTALLATION & WIRING
Mount the transmitter on the top of the dash, facing the windshield with the
antenna vertical.
Mount the receiver at a convenient location in the firehouse. It may be shelf
mounted on its base or wall mounted using a bracket. The antenna shall be
vertical. Be sure that there are not any metallic barriers between each
transmitter and the receiver.
Make the connections shown in Figure 1.
Figure 2 shows the mounting dimensions for each unit.
SETTING THE CODE

Each Transmitter and Receiver has a dip switch, the setting of which determines
the code sent and received.
The dip switch in the Transmitter and it’s corresponding receiver
must be set to the same code
The units are normally coded OFF, OFF, OFF, OFF, OFF for single Receiver
systems. For multiple Receiver systems, each receiver is given a separate code.
The corresponding transmitters must be set to the same code.
To change the code, remove the Transmitter and Receiver top covers and
change the dip switches.
INSTALLATION EXAMPLES
Figures 3 and 4 show possible installation examples for the Model 091-133
Transmitter and Receiver. There are many other possible installations. Consult
Kussmaul Electronics Co. Inc. Engineering Dept.
to discuss your particular problem.
ON
12345

SPECIFICATION AND OUTLINE
Operating Frequency: 418 MHz
Transmitter Main Input Power: 12 volts D.C. battery.
Transmitter Current Draw: Less than 15 milliamperes D.C..
Number of Transmitter independent (or proprietary) Channels:4
Number of possible Transmitter Codes: 32
Receiver Main Input Power: 115 volts, 60 Hertz
Receiver AC Current Draw: 15 milliamperes AC
Number of Receiver independent (or proprietary) Channels:4
Number of Possible Receiver Codes: 32
Range of Transmission (between Transmitter & Receiver):150 feet typical
Temperature Environment: 0 to 50 deg C.
Outline Drawing: Refer to Figure 2
INSTALLATION RECORD & WARRANTY

Date Installed________________________________________
Installed By___________________________________________
Vehicle Identification_________________________________
Vehicle Owner________________________________________
WARRANTY
All products of Kussmaul Electronics Company Inc. are warranted to be free of
defects of material or workmanship. Liability is limited to repairing or replacing at
our factory, without charge, any material or defects which become apparent in
normal use within 3 years from the date the equipment was shipped. Equipment
is to be returned, shipping charges prepaid and will be returned, after repair,
shipping charges paid.
Kussmaul Electronics Company, Inc. shall have no liability for damages of any
kind to associated equipment arising from the installation and /or use of the
Kussmaul Electronics Company, Inc. products. The purchaser, by the
acceptance of the equipment, assumes all liability for any damages which may
result from its installation, use or misuse, by the purchaser, his or its employees
or others.
