Kzyee KM301 Assembly instructions

OBDII /CAN SCAN TOOL
- 1 -

OBD & Battery Analysis Scanner
Table of Contents
Specifications............................................. 1
Setup - Before Use.................................... 2
Operating Instructions............................... 4
Connect Scan Tool....................................4
Battery Test................................................ 5
Battery Test..........................................6
Battery Test Result............................. 8
Cranking Test.....................................10
Charging System and Ripple Test.11
Charging Test Result.........................12
Quick Test.......................................... 13
Review Data.......................................14
Print Data........................................... 14
OBD Overview........................................ 17
Vehicle Coverage....................................17
Definitions.................................................18
Control Modules...................................... 18
I/M Monitors..............................................19
Diagnostic Test Modes...........................20
Diagnostic Trouble Code....................... 21
Setup......................................................... 22
I/M Readiness Quick-Check.................. 26
Diagnostic Test Modes........................... 27
Read Trouble Codes...............................28
DTC Lookup............................................. 29
Erase Codes............................................ 30
View Live PID Data................................. 31
Record Live PID Data.............................33
Playback Live PID Data......................... 36
View Freeze Frame Data....................... 37
I/M Readiness.......................................... 37
02 Monitor Test........................................38
On-Board Monitor Test...........................39
Component Test...................................... 40
Mode $09 Vehicle Information.............. 41
Modules Present......................................42
Print Data..................................................43
Update.......................................................44
WARNING SYMBOLS AND DEFINITIONS
This is the safety alert symbol. It is used to alert you to
potential personal injury hazards. Obey all safety messages
that follow this symbol to avoid possible injury or death.
Indicates a hazardous situation which, if not avoided,
will result in death or serious injury.
Indicates a hazardous situation which, if not avoided,
could result in death or serious injury.
Indicates a hazardous situation which, if not avoided,
could result in minor or moderate injury.
Addresses practices not related to personal injury.

OBD & Battery Analysis Scanner
- 1 -
Important Safety Information
To prevent personal injury or damage to vehicles and/or the Scan Tool, read this
instruction manual first and observe the following safety precautions, at a minimum,
whenever working on a vehicle:
1. Always perform automotive testing in a safe environment.
2. Wear safety eye protection.
3. Keep clothing, hair, hands, tools, test equipment, etc. away from all moving or hot
engine parts.
4. Operate the vehicle in a well ventilated work area. Exhaust gases are poisonous.
5. Put blocks in front of the drive wheels and never leave the vehicle unattended while
running tests.
6. Use extreme caution when working around the ignition coil, distributor cap, ignition
wires and spark plugs. These components create hazardous voltages when the engine
is running.
7. Put the transmission in PARK (for automatic transmission) or NEUTRAL (for manual
transmission) and make sure the parking brake is engaged.
8. Keep a fire extinguisher suitable for gasoline/ chemical/ electrical fires nearby.
9. Don't connect or disconnect any test equipment while the ignition is on or the engine
is running.
10. Keep the Scan Tool dry, clean, free from oil, water or grease. Use a mild detergent on
a clean cloth to clean the outside of the Scan Tool, when necessary.
Specifications
Service
There are no user serviceable parts. Scan Tool service must be performed only by qualified
repair personnel.
Display Screen
TFT Color (320 x 240)
Operating Temperature
32°F to 140°F
Storage Temperature
-4°F to 158°F
Power
8V to 30V power provided by vehicle battery

OBD & Battery Analysis Scanner
- 2 -
Setup - Before Use:
Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the
beginning of this document including all text under subheadings therein
before set up or use.
Functions
Figure 1

OBD & Battery Analysis Scanner
- 3 -
1. OBD II Cable
Connects the Scan Toolto the vehicle’s
DLC.
2. LCD Screen
3. Red LED
Indicates there is a problem in one
or more of the vehicle's systems.
The RED LED is also used to show
that DTCs are present. DTCs are
shown on the Scan Tool's display.
In this case, the MIL on the
vehicle's instrument panel will light
steady on.
4. Yellow LED
Indicates there is a possible
problem. A “Pending” DTC is
present and/or some of the
vehicle's emission monitors have
not run their diagnostic testing.
5. Green LED
Indicates that engine systems are
running normally (The number of
monitors on the vehicle which are
active and performing their
diagnostic testing is in the allowed
limit, and no DTCs are present).
6. Cancel/Go
Cancels a selection from a menu or
returns to the previous screen.
7. Left Button
Moves to previous screen if
information covers more than one
screen.
8. Help Button ?
View detailed information, if available.
9. USB Connector
Connects the Scan Tool to a PC for
updating software and printing.
10. I/M Button
Quick-checks emissions test
readiness and Drive Cycle
verification.
11. Up Button
Moves up through menu and
submenu items in menu mode. When
more than one screen of data is
retrieved, moves up through the
current screen to the previous
screens for additional data.
12. Select Button OK
Confirms a selection.
13. Right Button
Moves to next screen if
information covers more than one
screen.
14. Down Button
Moves down through menu
and submenu items in menu mode.
When more than one screen of data
is retrieved, moves down through the
current screen to next screens for
additional data.
!
!
√

OBD & Battery Analysis Scanner
- 4 -
Operating Instructions
Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the
beginning of this document including all text under subheadings therein
before set up or use of this product.
TO PREVENT SERIOUS INJURY AND DEATH:
Exhaust gases are poisonous. Operate the vehicle in a well ventilated work area.
Wear ANSI-approved safety goggles during use.
Connect Scan Tool
CAUTION: Do not connect or
disconnect the Scan Tool while the
ignition
is on or the engine is running.
Note: The Scan Tool is powered by the
vehicle’s battery.
1. Turn the engine and ignition OFF.
2. Connect the OBD II Cable to the
Scan Tool.
3. Connect the other end of the
Cable to the 16-cavity DLC.
The DLC is normally located under
the dashboard on the driver’s side.
(Refer to vehicle’s owner’s manual
for location of DLC.)
Figure 2: DLC
4. Turn the vehicle’s ignition ON with the
engine OFF.
Note: If Linking Error! message displays:
• Press the ESC button
• Verify the ignition is ON
• Verify the vehicle is OBD
II compliant
5. If the message does not go away,
have the Scan Tool inspected by a
qualified technician.
Note: To quick-check Emissions Test
Readiness, see page 26.
Note: To read Diagnostic Trouble Codes,
see page 27.

OBD & Battery Analysis Scanner
- 5 -
Battery Test
Notes：
1. This product is a testing tool for 12V battery vehicles. The working DC
voltage range of this product is 8 to 30 volts.
2. The battery voltage will be slightly higher than the normal value when it
is just fully charged. Please turn on the headlamp for 2-3 minutes, and
then measure it when the voltage drops back to the normal value.
3. Do not store or use this product in direct sunlight, or expose it to high
temperature and humidity, otherwise it may cause deformation or
damage.
4. Available battery standards:
1) Cold start rating (ampere) range:
Measure Standard
Measure Range
CCA
100-2000
BCI
100-2000
CA
100-2000
MCA
100-2000
JIS
26A17--245H52
DIN
100-1400
IEC
100-1400
EN
100-2000
SAE
100-2000
GB
100-2000
Figure3
2) Voltage Test Range：8-30V DC

OBD & Battery Analysis Scanner
6
Battery Test
Battery Test can determine battery
status, including voltage, CCA, electronic
resistance, rated CCA, charge value,
health and test results. According to the
battery label, input AH value - battery
rated capacity to start test.
1. From main menu, use the
Up/Down/Left/Right button to select
Battery Test, then press OK.
Figure4
2. From main menu, use the
Up/Down button to select Battery
Test, then press OK.
Main Menu 1/4
1.Battery Test
2.Quick Test Ah
3.Review Data
4.Print Data
Figure5
3. Use Up/Down button to select
Battery Test, then press OK.
Battery Test 1/3
1.Battery Test
2.Cranking Test
3.Charging Test
Figure6
4. The screen automatically displays
the following information, follow the
prompts:
1) If battery just completes charging,
please turn on vehicle headlights;
2) Keep the headlights on for 30
seconds.
3) Turn off the headlights.
4) Press OK to start testing.
Battery Test
1.Check surface charge, turn light on.
2.Take headlight on about 30 seconds.
3.Turn light off.
4.Press OK to start.
Figure7
5. Use Up/Down button to select
Battery Type, then press OK.
Battery Test Select 1/5
1.Regular Flooded
2.AGM Flat Plate
3.AGM Spiral
4.GEL
5.EFB
Figure8

OBD & Battery Analysis Scanner
- 7 -
6. Use the Up/Down button to go to
previous or next screen, select
Battery Test Standard, then press
OK.
Selection Test Standard
CCA
1/10
Figure9
7. Use the Up/Down/Left/Right button
（to increase/ decrease）to input AH
value, then press OK.
Setting Rate
500A CCA
Figure10
8. If the battery power is low, the screen
will automatically prompt [battery
power is low, continue?], press OK to
continue; if the battery power is
normal, the screen will directly
display Testing**.
Battery power is low.
Continue?
Figure11
9. Screen auto prompt Testing**
Please wait for about 3 seconds.
Battery Test
Testing**
Figure12
10. Screen displays battery test result
as follows. Press ESC to exit.
Battery Test
Healthy: 88% 521A(CCA)
Charge: 0% 11.98V
Internal R= 5.19mΩ
Rated: 500A
GOOD,RECHARGE
Figure13

OBD & Battery Analysis Scanner
- 8 -
Battery Test Result
Includes 5 types as following:
1. Good Battery
Battery Test
Healthy: 96% 490CCA
Charge: 98% 12.64V
Internal R= 6.1mΩ
Rated: 500A
GOOD
Figure14
The battery is without any problem,
please be relaxed to use!
2. Good, Recharge
Battery Test
Healthy: 78% 440CCA
Charge: 30% 12.20V
Internal R= 7.2mΩ
Rated: 500A
GOOD,RECHARGE
Figure15
Good battery but low current, recharge
before using.
3.
Replace
Battery Test
Healthy: 46% 490CCA
Charge: 80% 12.68V
Internal R= 18.1mΩ
Rated: 500A
REPLACE
Figure16
The battery is near to or already reached
the end of the using life, replace battery,
otherwise, bigger danger will be followed.
4. Bad Cell, Replace
Battery Test
Healthy: 0% 0CCA
Charge: 80% 10.64V
Internal R= 45.2mΩ
Rated: 500A
BAD CELL,REPLACE
Figure17
Battery interior damaged, bad cell or
short circuit, replace battery.
5. Charge, Retest
Battery Test
Healthy: 39% 310CCA
Charge: 20% 12.08V
Internal R= 30.1mΩ
Rated: 500A
CHARGE,RETEST
Figure18
Unstable battery shall be recharged and
retested to avoid error. If same test
result appears after recharge and retest,
the battery is regarded as damaged,
replace the battery.

OBD & Battery Analysis Scanner
- 9 -
Battery System Standard and Rating
The battery test will test each battery according to the selected system and rating.
Use UP/DOWN key to select according to the actual system standard and rating marked
on the battery. See in the below picture, the arrow indicates location.
Figure19
CCA: Cold Cranking Amps, specified by SAE&BCI, most frequently used value for starting
battery at 0°F (-18°C). BCI: Battery Council International standard
CA：Cranking Amps standard, effective starting current value at 0°C.
MCA: Marine Cranking Amps standard, effective starting current value at 0°C.
JIS：Japan Industrial Standard, displayed on the battery as combination of the numbers
and letters, e.g. 55D23,80D26.
DIN：German Auto Industry Committee Standard
IEC：Internal Electro technical Commission Standard
EN：European Automobile Industry Association Standard
SAE: Society of Automotive Engineers Standard
GB: China National Standard

OBD & Battery Analysis Scanner
- 10 -
Cranking Test
1. Connect the clamp to the battery
before the engine starts. Red clip
connects positive (+) terminal and
black clip connects negative (-).
2. From main menu of battery test,
use the Up/Down button to select
Battery Test, then press OK.
Main Menu 1/4
1.Battery Test
2.Quick Test Ah
3.Review Data
4.Print Data
Figure20
3. Use the Up/Down button to select
Cranking Test, then press OK.
Battery Test 2/3
1.Battery Test
2.Cranking Test
3.Charging Test
Figure21
4. Starting the engine as prompted,
tester will automatically complete
the cranking test and display the
result.
Cranking Test
Start Engine
Figure22
Cranking Test
RPM Detected
Figure23
5. Normally, cranking voltage value
lower than 9.6V is regarded as
abnormal and it is ENTER if it is
higher than 9.6V. Test result of the
tester includes actual cranking
voltage and actual cranking time.
Cranking Test
TIME 780ms
CRANKING NORMAL
10.13V
Figure24
6. When cranking test is abnormal,
battery test result will also be
displayed at the same time.
Cranking Test
TIME 780ms
CRANKING LOW
10.13V
Figure25
7. This is for the convenience of the
maintenance personnel to quickly
know the whole state of the starting
system according to the data. After
testing finished, do not shut down
the engine, press OK to enter
Charging Test.

OBD & Battery Analysis Scanner
- 11 -
Charging System and Ripple Test
1. Connect the clamp to the battery
after the engine starts. Red clip
connects positive (+) terminal and
black clip connects negative (-).
2. Use the Up/Down button to select
Charging Test, then press OK.
Battery Test 3/3
1.Battery Test
2.Cranking Test
3.Charging Test
Figure26
NOTE: Do not shut down the engine
during the test. All electrical appliance
and device are in OFF state. Turn on/off
any electrical appliance in the vehicle
during the test will affect the accuracy of
the test result.
Tester will do the following tests in a
sequence:
3. Ripple Test：
Ripple Test
_______________________
0mV 11.97V
Figure27
For ripple test, tester will display the real
time ripple and meanwhile, shows ripple
volt and charging volt values at the
bottom line. It takes approx. 6 seconds
for the rippletest.
4. After the ripple test, tester will
automatically start the loaded
voltage test. It takes 3 seconds.
Charging Test
Loaded Testing
***
Figure28
5. Operate accordingly ：
1) Increase the engine rotating
speed to 2500turns;
2) Keep for 5 seconds.
3) Press OK to continue.
Charging Test
1.Increasing RMP to 2500 r/min.
2.And keep it 5 seconds.
3.Press OK to continue.
Figure29
6. The instrument will automatically
start unloaded test.
Charging Test
Unloaded Testing
***
Figure30

OBD & Battery Analysis Scanner
- 12 -
7. After the test finished, tester displays
the effective charging volts, ripple
test result and charging test
result.Press ESC to exit.
Charging Test
Loaded: 12.27V
Unloaded: 12.27V
Ripple: 4mV
NO-OUTPUT
Figure31
NOTE: If no increase rev detected, it shall be the fault of generator regulator or connection
with battery failed. Testerwill try 3 times to further detect, if still failed, it will skip the increase
rev detect and the test result displays "No Volt Output". See below:
Check the connection between generator and battery, then retest.
Charging Test Result
1. Charging Volt: Normal
Charging system shows the generator
output is normal, and no problem is
detected.
2. Charging Volt: Low
Charging volt of the charging system is
low.
Check drive belt of the generator
whether it is slipping or running off.
Check the connection between
generator and battery is normal or not. If
both of the drive belt and the connection
are in good condition, follow the
manufacturer's suggestion to eliminate
generator fault.
3. Charging Volt: High
Generator output volt is high.
Since most of the vehicle generators are
using internal regulator, the generator
assembly has to be replaced.(Some old
style cars are using external regulator,
then directly replace the regulator.)
The normal high volt of the voltage
regulator is maximum 14.7±0.5V.If
charging volt is too high, it will
overcharge the battery. Therefore the
battery life will be shortened and troubles
will be caused.
4. No Volt Output:
No generator volt output is detected.
Check the generator connection cable
and the belt whether they are normal.
5. Diode Test:
Through the test of charging current
ripple, tester will find out whether the
diode is normal or not. When ripple volt
is too high, it proves at least one diode is
damaged. Check and replace the diode.
Till now, all tests have been done.

OBD & Battery Analysis Scanner
- 13 -
Quick Test
1. From main menu of battery test,
press UP/DOWN key to select the
Quick Test Ah, then press OK to
confirm.
Main Menu 2/4
1.Battery Test
2.Quick Test Ah
3.Review Data
4.Print Data
Figure32
2. Use Up/Dowm/Left/Right button to
input the rated battery capacity—xx
AH, then press OK.
Input Ah Value
50Ah
Please input the A-HR value in the
lable of the battery
Figure33
3. If the battery power is low, the screen
will automatically prompt [Battery
power is low. Continue?], then
press OK to continue.
Battery power is low.
Continue?
Figure34
4. Screen auto prompt Testing**
Please wait for about 3 seconds.
Battery Test
Testing
Figure35
5. Screen displays battery test result
as follows.Press ESC to exit.
Battery Test
Healthy: 85% 410A(CCA)
Charge: 0% 11.97V
Internal R= 6.61mΩ
Rated: 400A
GOOD,RECHARGE
Figure36

OBD & Battery Analysis Scanner
- 14 -
Review Data
1. From main menu of battery test,
use Up/Down button to select
Review Data, then press OK.
Main Menu 3/4
1.Battery Test
2.Quick Test Ah
3.Review Data
4.Print Data
Figure37
2. Screen displays battery test result
as follows. Press ESC to exit.
Battery Test
Healthy: 77% 489A(CA)
Charge: 0% 12.24V
Internal R= 7.61mΩ
Rated: 500A
GOOD,RECHARGE
Figure38
Print Data
1. Download the driver from the internet:
1) Go to www.kzyee.com
2) Search for KM301
3) Download Installsoftware
4) Download KM301-BatteryTestPrint
2. Connect the tool to the computer via the USB cable.
3. Install the KM301-BatteryTestPrint.exe and select default.
4. After installation, open the KM301-BatteryTestPrint on the desktop.
5. Select print.
If there are some data history in print
software, please kindly press the Clean
button in the upper right corner to clear
the data.
6. From main menu of battery test,
use Up/Down button to select Print
Data, then press OK.
Main Menu 4/4
1.Battery Test
2.Quick Test Ah
3.Review Data
4.Print Data
Figure39

OBD & Battery Analysis Scanner
- 15 -
7. Printing data.
Print Data
Printing
Figure40
8. Once the data is transferred to the
computer, the print software will
show data to be print.
Battery Test
Healthy: 85% 410A(CCA)
Charge: 0% 11.97V
Internal R= 6.61mΩ
Rated: 400A
GOOD,RECHARGE
Figure41

OBD & Battery Analysis Scanner
- 16 -

OBD & Battery Analysis Scanner
- 17 -
Overview
OBD II On-Board Diagnostics
The first generation of On-Board
Diagnostics (called OBDI) was developed
by the California Air Resources Board
(ARB) and implemented in 1988 to monitor
some of the emission control components
on vehicles. As technology evolved and the
desire to improve the On-Board Diagnostic
system increased, a new generation of
On-Board Diagnostic system was
developed. This second generation of
On-Board Diagnostic regulations is called
"OBD II".
The OBD II system is designed to monitor
emission control systems and key engine
components by performing either
continuous or periodic tests of specific
components and vehicle conditions.
Vehicle Coverage
This Scan Tool is designed to work with
all OBD II compliant vehicles, including
those equipped with a CAN bus.
OBD II was installed in some 1994 and
1995 model year gasoline vehicles.
When a problem is detected, the OBD II
system turns on a warning lamp (MIL) on the
vehicle instrument panel to alert the driver
typically by the phrase of “Check Engine” or
“Service Engine Soon”.
The system will also store important
information about the detected malfunction
so that a technician can accurately find and
fix the problem. Here are three examples:
1. Whether the Malfunction Indicator
Light (MIL) is commanded 'on' or 'off';
2. Which, if any, Diagnostic Trouble
Codes (DTCs) are stored;
3. Readiness Monitor status.
To verify if a 1994 or 1995 vehicle is OBD II
compliant, check the Vehicle Emissions
Control Information label, which is located in
the engine compartment.

OBD & Battery Analysis Scanner
- 18 -
Definitions
• EOBD: European On-Board
Diagnostics
Essentially the same as OBD II, with
the same Data Link Connector and
Communication Protocols.
• Communication Protocol: Allows
different systems and sensors in a
vehicle to communicate.
There are currently five Protocols:
CAN Bus
J1850 VPW
ISO 9141-2
J1850 PWM
ISO 14230 KWP
• CAN: Controller Area Network
Message-based Communication
Protocol serial bus.
• CAN Vehicle
2008 and newer.
• Pre-CAN Vehicle
2007 and older.
• DLC: Data Link Connector
The 16-cavity connector on the vehicle
that allows communication between the
computer system and the Scan Tool.
Control Modules
•Drive Cycle
A set of driving procedures that,
when met, provide the Enabling
Criteria for the I/M Monitors to run
and complete their diagnostic tests.
•Enabling Criteria
Operating conditions that must
occur during a Drive Cycle to
cause the I/M Monitors to run and
complete their diagnostic tests.
•MIL: Malfunction Indicator Lamp
The vehicle’s “Check Engine”
warning light that activates
when a DTC is stored.
•DTC: Diagnostic Trouble Code A
code stored in the computer
system’s memory, which helps to
identify the fault condition that is
causing the MIL to activate.
•Freeze Frame Data Operating
conditions that are stored
when a DTC is stored.
•PID - Parameter Identification Data
Data returned by the vehicle’s
Control Modules to the Scan Tool.
Control Modules are individual computers that operate and monitor different systems in
the vehicle. Control Modules vary depending on manufacturer.
ID codes are assigned to each Control Module, which are defined by the vehicle’s
Communication Protocol.
For example, a vehicle may use ID code $7E8 for the PCM and $7E9 for the TCM.
Control Module
Control Module Definition
PCM/ECU
Powertrain Control Module/Engine Control Unit
TCM
Transmission Control Module
Figure 49: Common Control Modules
