L7 Networks L7-NR2000 User manual

L7 Wireless N Router – L7-NR2000
Wireless NRouter
L7-NR2000

Product Overview
• Package Content
• Hardware Overview
• Features of L7-NR2000/TM
• Factory Default Settings
Agenda
Setting up of Devices
• Quick Setup Wizard (Easy)
• Setup Internet
• Setup Wireless
Page 2

Agenda
Setting up of Devices
• Setup SharePort Network USB Utility
Troubleshooting
Questions and Answers
Questions and Answers
Page 3

L7-NR2000 Overview
•Faster Wireless Networking
– The L7-NR2000 provides up to 300Mbps wireless connection with other 802.11n
wireless clients.
•Compatible with 802.11b and 802.11g Devices
– The L7-NR2000 is still fully compatible with the IEEE 802.11b and IEEE 802.11g
standard.
•Advanced Firewall Features
– Content Filtering & DHCP Reserved
– Filter Scheduling
– Secure Multiple/Concurrent Sessions (IPSec/PPTP)
•User-friendly GUI
– Through its easy-to-use Web-based user interface, the L7-NR2000 lets you control
what information is accessible to those on the wireless network
Page 4

L7-NR2000 Package Content
• 1 D-Link L7-
NR2000 Wireless
Router
• 1 Power adapter
• 1 QIG
• 3 Ethernet Cable
(Red, Yellow & Blue)
• 1 Manual CD
• 1 Warranty Card
Page 5
• 1 Error Check List

Hardware Overview
• The L7-NR2000 creates a
wireless network using
802.11n technology with
multiple antennas to maximize
wireless speed and range, and
share Internet access with
computers, game consoles,
computers, game consoles,
and media players.
Page 6

6
Hardware Overview – Front View
1 2 3 4 5 7
Page 7
No LED Color Status Description
1 Power Green Off No Power Supply
On Power on Properly
2 Internet Green Off PPP Not connected
On PPP Connected
3 WAN Green
Off WAN Cable Disconnected
On WAN Cable Connected
Blinking WAN Data transmitting

Hardware Overview – Front View
No LED Color Status Description
Off
Wireless Off (Default)
61 2 3 4 5 7
Page 8
4 Wireless Green
Off
Wireless Off (Default)
On Wireless On
Blinking Wireless is transmitting
5 LAN Green
Off Cable disconnected
On Cable Connected
Blinking Data is transmitting
6 WPS Blue
Off WPS not in progress
Blinking WPS in Progress (Ma 120 Seconds)
On WPS session success (Steady 5 Seconds)
7 USB None None USB Share Port

Hardware Overview – Rear View
1 2 3 4 5
No.
Description
Usage
6
Page 9
No.
Description
Usage
1 IPTV Port - (Red) Connect the Red Ethernet cable to the Set-Top-Bo (STB)
2High Speed Internet
(HSI) Ports - (Blue) Connect the Blue Ethernet cables to Ethernet devices
3 WAN Port – (Yellow) Connect the Yellow Ethernet cable for VDSL/Fiber Home connection
4 Power Connector Receptor for power adapter
5 Reset Button Press to restore to factory default settings
6 USB Share Port To share multi-function printers, scanners or storage device through the network

Features of L7-NR2000
• 4 LAN ports + 1 WAN port (10/100Mbps)
• 1 USB SharePort
• 2 5dBi Detachable Omni-Directional antennas
• 2.4GHz wireless b/g/n (1~13) channels
• Wireless speed of 300Mbps
• WEP/WPA/WPA2 - Personal
• WPS support
• Supports Multiple SSIDs
Page 10

Features of L7-NR2000 – cont’d
• Firewall/NAT/DMZ
• Parental Control
• Virtual Server/Port forwarding/Port triggering
• TR-069, TR-111 ready
• Network/Website filtering
• WAN management
• DDNS
Page 11

Factory Default Settings
• IP address: 192.168.0.1
• DHCP Server: Enabled
• Login User Name: admin
• Login Password: *blank*
• Wireless SSID: TMHSBB (default not enabled)
• Wireless Auto Channel: On
• Firewall: default Disabled
• Remote Management: default Disabled
Page 12

Hardware Connections E ample
Power Adapter
Laptop (Wireless)
Page 13
Telephone Wall
Socket
Power
Ethernet Cable
(Yellow )
Ethernet Cable
(Blue)
Ethernet Cable
(Red)
Telephone Cable
Broadband
Termination Unit
Desktop (Wired)
Set-Top-Box (STB)

Quick Setup Wizard
Page 14

1
2
Quick Setup of L7-NR2000
Page 15
2

Quick Setup of L7-NR2000
3
Page 16

Quick Setup of L7-NR2000
Page 17
5
4

Quick Setup of L7-NR2000 – Dynamic IP
6
*9
Page 18
7
8
username@unifi
password
password
10

Quick Setup of L7-NR2000 – Static IP
6
8
202.111.222.1
255.255.255.248/252
7
*11
Page 19
9
10
username@unifi
password
password
12
8
202.111.222.2
202.111.222.6/2

Quick Setup of L7-NR2000
13
Page 20
14
