La Crosse Technology 616-1412v2 Operating and maintenance manual

Projection Alarm Clock
Model: 616-1412v2
Instructional Manual
DC: 070516
http://bit.ly/LaxTechTalk
For online video support:
LCD Features .......................................................................
Buttons ..............................................................................
Display Date Two Ways .........................................................
Setup .................................................................................
Set Time, Date, etc. .............................................................
Projection Rotation | Focus ....................................................
Set Alarm ...........................................................................
Deactivate | Activate ............................................................
Snooze ...............................................................................
Backlight ............................................................................
Reset Button .......................................................................
Specications ......................................................................
Visit Us on Social Media ........................................................
Warranty and Support ..........................................................
Care and Maintenance ..........................................................
FCC Statement ....................................................................
Canada Statement ...............................................................
Table of Contents
1
1
1
1
2
3
4
4
4
5
5
5
5
6
6
7
7

LCD Features
Time
Alarm
Indoor Temperature/Humidity
Weekday
Month/Date
AM/PM
Setup
Page 1 www.lacrossetechnology.com/support 616-1412v2
6
5
4
3
2
1
1. Insert the 4.5-volt AC adapter into 120V AC wall outlet, and then
plug the AC jack to the back of the unit.
2. Optional: Insert two AAA batteries (not included) to provide backup
power to the clock.
Buttons
3
2
1
6
5
4
AAA
AAA
4.5 V AC adapter
Display Date Two Ways
Press and release the SET button to toggle between:
• Full weekday/temperature/humidity
• Weekday/Month/Date/temperature/humidity

616-1412v2 www.lacrossetechnology.com/support Page 2
Set Time, Date, Etc.
• Hold then release the SET button to enter time set mode.
• Press and release the +or -buttons to adjust the values. Hold to
adjust quickly.
• Press and release the SET button to conrm and move to the next
item.
Time set order:
1. 12/24 hour time format
2. Hour
3. Minutes
4. Year
5. Month
6. Date
7. Fahrenheit/Celsius
Note: Only press one button at a time when setting.
1. 12/24 hour time 2. Hour
To begin: Hold the SET button 3 seconds to enter the settings:
3. Minutes 4. Year
5. Month 6. Date

Page 3 www.lacrossetechnology.com/support 616-1412v2
Projection Rotation | Focus
Rotate Projection:
• The projected image can be rotated in 90 degree increments.
• Press and release the PROJECTION button to rotate the image.
Focus Projection:
• Use the Focus Wheel on the back of the projection arm to provide a
clear projection image.
7. Fahrenheit | Celsius
Tip: The AC adapter must be plugged in for the projection to work.
Focus Projection
Rotate Projection
Note: Weekday will set automatically when year, month and date
are set. If weekday is incorrect, check the year setting.

616-1412v2 www.lacrossetechnology.com/support Page 4
Set Alarm
• Hold then release the ALARM button to enter time set mode.
• Press and release the +or -buttons to adjust the values. Hold to
adjust quickly.
• Press and release the ALARM button to conrm and move to the
next item.
To begin: Hold the ALARM button to enter the settings:
1. Alarm Hour 2. Alarm Minutes
The alarm will be active after setting. The alarm icon (clock) will show.
• From normal time display, press and release the ALARM button to
deactivate or activate the alarm.
Deactivate | Activate the Alarm
Snooze
When alarm is sounding, press SNOOZE LIGHT button to silence the
alarm for 10 minutes.
• The snooze icon Zz will ash.
• Press any button except SNOOZE/LIGHT to silence the alarm for
24 hours.
• This is a crescendo alarm. It will sound for 2 minutes then shut off if
no buttons are pressed.
Active Alarm Active Snooze

Page 5 www.lacrossetechnology.com/support 616-1412v2
Specications
Temperature Range: 32 F to 122 F (0C to 50C)
Humidity Range: 10%-99%RH
Power Clock: AC6 GPU280450150WAOO 4.5V AC adapter
Optional: 2-AAA batteries (not included)
Battery life Clock: over 12 months with reputable batteries
Dimensions Clock: 5.9” L x 2.3” W x 4.4” H inch
(14.98 x 5.84 x 11.17cm)
Visit Us on Social Media
http://bit.ly/LaxTech_Facebook
http://bit.ly/LaxTech__Twitter
http://bit.ly/LaxTech_YouTube
http://bit.ly/LaxTech_Pinterest
For personalized interaction
Join the conversation
Latest video content
Pin and share
Reset button
• If the clock display appears distorted or is not responding to buttons,
use a pen or paper clip to press and release the RESET button one
time.
• This will reset the clock to default settings.
Backlight
• AC adapter: Backlight and projection are on constantly.
• Batteries only: Press the SNOOZE/LIGHT button for a 3 second
backlight and projection.

616-1412v2 www.lacrossetechnology.com/support Page 6
• Do not mix old and new batteries
• Do not mix Alkaline, Standard, Lithium, or Rechargeable Batteries
• Always purchase the correct size and grade of battery most suitable
for intended use.
• Replace all batteries of a set at the same time.
• Clean the battery contacts and also those of the device prior to
battery installation.
• Ensure the batteries are installed with correct polarity (+ and -).
• Remove batteries from equipment when it is not to be used for an
extended period of time.
• Promptly remove expired batteries.
Care and Maintenance
Warranty and Support
La Crosse Technology, Ltd. provides a 1-year limited time warranty (from date
of purchase) on this product relating to manufacturing
defects in materials & workmanship.
Before returning a product, please contact our friendly
customer support with questions or visit our online help:
Phone: [phone]
Online Product Support:
www.lacrossetechnology.com/support
Product Registration:
www.lacrossetechnology.com/support/register
View full warranty details online at:
www.lacrossetechnology.com/warranty_info.pdf
Warranty Address:
La Crosse Technology, Ltd
2830 S. 26th St.
La Crosse, WI 54601

Page 7 www.lacrossetechnology.com/support 616-1412v2
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy, and if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
This device must not be co-located or operating in conjunction with any other
antenna or transmitter.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference
that may cause undesired operation.
Caution!
The manufacturer is not responsible for any radio or TV interference caused
by unauthorized changes or modications to this equipment. Such changes or
modications could void the user authority to operate the equipment.
All rights reserved. This manual may not be reproduced in any form, even in
part, or duplicated or processed using electronic, mechanical or chemical
process without the written permission of the publisher. This booklet may
contain errors or misprints. The information it contains is regularly checked
and corrections are included in subsequent editions. We disclaim any
responsibility for any technical error or printing error, or their consequences.
All trademarks and patents are recognized.
Canada Statement
This device complies with CNR Industry Canada license -exempt devices.
Operation is subject to the following two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including interference that may
cause undesired operation of the device.
FCC Statement
