Model: 308-1425B www.lacrossetechnology.com/support Page | 1
Model: 308-1425B
Instruction Manual
DC: 100814
WIRELESS COLOR WEATHER STATION
WWVB Time
Calendar +
Alarm
Color
Animated
Forecast +
Tendency
Outdoor
Humidity
with Trend
Indoor
Temperature
with Trend
Indoor/Outdoor
Temperature
Alerts + Indoor
Humidity with
Trend
OUTDOOR
SENSOR
TX141TH-Bv2
Outdoor
Temperature
with Trend
Sensor
Battery
Cover
Sensor Battery
Compartment
2 “AA”
Battery
Compartment
3 “AAA”
AC Power
Jack
DC 5.0V
GPU280500150WD00
Base
Stand
24 Hour
Pressure
History Graph
with Trend
SIDE BUTTONS
Moon Phase
LED
TX
BACK
VIEW
FRONT BUTTONS
Wall
Hanging
Holes
FRONT
VIEW

Model: 308-1425B www.lacrossetechnology.com/support Page | 2
Quick Setup
Step 1: Insert the 5 volt AC cord (included) into the wall outlet then into the weather
station.
Step 2: Insert the 3 new AAA Alkaline batteries (not included) into the weather station.
Observe the correct polarity.
Step 3: Insert the 2 new AA batteries (not included) into the TX141TH-Bv2 outdoor
sensor. Observe the correct polarity. The red LED will flash during transmission.
Restart: If the outdoor temperature is not displayed after 3 minutes, unplug the AC
adapter and remove batteries from the weather station & sensor and press any button
20 times. After 15 minutes return to Step 1 above.
Table of Contents
WIRELESS COLOR WEATHER STATION ............................................................................................1
Quick Setup .................................................................................................................................................2
Table of Contents......................................................................................................................................2
Introduction................................................................................................................................................4
Features........................................................................................................................................................4
Detailed Setup: Weather Station and Outdoor Sensor..............................................................4
Button Functions.......................................................................................................................................5
▼(Down) Button..........................................................................................................................................5
TIME SET Button........................................................................................................................................... 5
SNOOZE/LIGHT (HI-LOW-OFF) Button ....................................................................................................5
HEAT/DEW/SENSOR SEARCH button .......................................................................................................5
▲(UP) Button ............................................................................................................................................... 6
ALERT Button................................................................................................................................................. 6
ALARM Button ...............................................................................................................................................6
Set Time, Date, Temperature Unit .....................................................................................................6
WWVB Reception ON/OFF...........................................................................................................................7
Time Zone ......................................................................................................................................................7
Daylight Saving Time Indicator .................................................................................................................7
12-hour or 24-hour Time Format..............................................................................................................7
Set Time ......................................................................................................................................................... 7
Set Calendar ..................................................................................................................................................8
Fahrenheit/Celsius........................................................................................................................................8
Temperature Alerts.................................................................................................................................. 8
Arm/Disarm Temperature Alerts ...............................................................................................................8
Temperature Alert Sounds..........................................................................................................................9

Model: 308-1425B www.lacrossetechnology.com/support Page | 3
Time Alarm Set ..........................................................................................................................................9
Deactivate Alarm ..........................................................................................................................................9
Snooze ............................................................................................................................................................9
Adjust Backlight (HI-LOW-OFF) .........................................................................................................9
Heat Index/Dew Point .........................................................................................................................10
Heat Index ...................................................................................................................................................10
Dew Point Temperature.............................................................................................................................10
Temperature/Humidity Trend indicators......................................................................................10
Search for Outdoor Sensor .................................................................................................................10
MIN/MAX (View, Reset) ...................................................................................................................... 11
Animated Color Forecast Icons......................................................................................................... 11
Forecast Tendency Indicators (Up, Right, Down Arrows) .....................................................12
Manual WWVB Time Signal Search..................................................................................................13
Outdoor Positioning and Use .............................................................................................................13
Low Battery icon .....................................................................................................................................13
Care and Maintenance ..........................................................................................................................13
Specifications ...........................................................................................................................................14
Warranty Information ..........................................................................................................................15
FCC Statement .........................................................................................................................................15

Model: 308-1425B www.lacrossetechnology.com/support Page | 4
Introduction
La Crosse Technology® introduces a Wireless Color Weather Station with precise, real-
time backyard weather. Animated color forecasts with trends react to changing
barometric pressure. 24 hour pressure history graph and moon phase for a complete
weather experience. Monitor in/out temperature trends with high and low alert settings.
Measure in/out temperature and humidity with daily min/max records -- all on one easy-
to-read color display with adjustable brightness.
Features
12/24 hr. atomic time (manual setting)
Signal strength icon for sensor transmission
Outdoor humidity (%RH) with trend indicator
IN / OUT outdoor temperature (°F / °C) with trend
Animated forecast icons
Forecast tendency indicator
Customize IN / OUT temp. alerts (low / high) for weather station and outdoor sensor
Perpetual calendar (day / month / date / year)
Indoor humidity (%RH) with trend indicator
Indoor temperature (°F / °C) with trend
Back light control (high / low / off)
Time alarm
Heat index and dew point
Min. / max. temperature and humidity
24 hour pressure history graph
Moon phase
Station and sensor low battery icon
Atomic reception indicator
Snooze / alarm icon
Detailed Setup: Weather Station and Outdoor Sensor
STEP 1:
Insert the 5-volt A/C power adapter into the designated area
on the back of the Weather station.
Plug the A/C power adapter into a wall outlet for continuous
backlight (ON/OFF), and dimmer feature.
STEP 2: (optional battery operation)
Slide tab to down and pull out to remove the battery cover.
Insert three new AAA Alkaline batteries into the back of the weather
station. Observe the correct polarity (see marking inside the battery
compartment).
The weather station will light up and show indoor temperature, humidity and
time.
(Backlight will illuminate for 8 seconds when using only battery power with a
press/release of the SNOOZE/LIGHT button)

Model: 308-1425B www.lacrossetechnology.com/support Page | 5
STEP 3:
Ensure that the transmitter is within 10 feet of the weather station.
Remove battery cover from transmitter. Slide the battery cover down
and lift off the front.
Insert two new AA batteries into the TX141TH-Bv2 transmitter.
Observe the correct polarity.
Within three minutes, the Weather station will show readings in the
outdoor temperature area on the LCD.
Note: Use Alkaline batteries (or Lithium for temperatures below -20°F/-
28.8°C).
Button Functions
▼(Down) Button
Setting-
Press to decrease values during setting.
Hold 2 seconds to quickly adjust values.
Default Time Display-
Press to display minimum temperature/humidity.
Hold 2 seconds to clear minimum temperature/humidity memory.
Temperature Alert-
Press to disarm alerts
TIME SET Button
Default Time Display-
Press to start or stop a WWVB time signal search
Hold for 3 seconds to set time/calendar, etc.
SNOOZE/LIGHT (HI-LOW-OFF) Button
Default Time Display-
Press to change the LCD backlight brightness. HI/LOW/OFF
Press to activate backlight for 10 seconds.(without adaptor)
Time Alarm-
Press to activate the snooze function when alarming
HEAT/DEW/SENSOR SEARCH button
Default Time Display-
Press once to view Heat Index.
Press twice to view Dew Point.
Hold to search for Outdoor sensor.
The weather station has 5 buttons across the top and 2
on the front.

Model: 308-1425B www.lacrossetechnology.com/support Page | 6
▲(UP) Button
Setting-
Press to increase the values during setting.
Hold 2 seconds to quickly adjust values.
Default Time Display-
Press to view maximum temperature/humidity.
Hold 2 seconds to clear maximum temperature/humidity memory.
Temperature Alert-
Press to arm alerts
ALERT Button
Default Time Display-
Press to toggle between Outdoor High Alert, Outdoor Low Alert, Indoor High Alert and
Indoor Low Alert.
Hold to enter Alert setting
ALARM Button
Default Time Display-
Press once to show alarm time
Hold for 2 seconds enter alarm setting mode
Alarm Mode-
Press to activate or deactivate time alarm.
Set Time, Date, Temperature Unit
Hold the TIME SET button to enter time set mode.
1. Press the ▼or ▲buttons to adjust the values.
2. Press the TIME SET button to confirm adjustments and move
to the next item.
Time Set Order:
1. WWVB time signal (On/Off)
2. Time Zone - 7 time zones
3. DST (Daylight Saving Time On/Off)
4. 12/24 hour time format
5. Hour
6. Minutes
7. Year
8. Month
9. Date
10.Fahrenheit/Celsius
Press the TIME SET button to exit, or wait 20 seconds without pressing buttons to
return to the normal time display.

Model: 308-1425B www.lacrossetechnology.com/support Page | 7
WWVB Reception ON/OFF
The WWVB atomic time reception defaults to ON.
To turn the WWVB reception OFF:
1. Hold the TIME SET button for 5 seconds.
2. WWVB and ON will flash.
3. Press and release the ▼or ▲buttons to turn this OFF if you do not
want to receive the WWVB time signal.
4. Confirm with the TIME SET button and move to the Time Zone.
Time Zone
This station offers seven time zones listed in letter format (default is EST):
AST Atlantic Time
EST Eastern Time
CST Central Time
MST Mountain Time
PST Pacific Time
AKT Alaskan Time
HAT Hawaiian Time
1. EST will flash above the date.
2. Press and release the ▼or ▲buttons to select a different Time Zone.
3. Confirm with the TIME SET button and move to Daylight Saving Indicator.
Daylight Saving Time Indicator
DST will default to the ON position as most of the country observes the DST change. If
you live in an area does not observe the DST change, switch this to the OFF position.
1. DST and ON will flash above the date.
2. Press and release the ▼or ▲buttons to turn DST to OFF.
3. Confirm with the TIME SET button and move to 12/24 hour time format.
12-hour or 24-hour Time Format
The Time may be displayed in 12-hour or 24-hour format. Default is 12-hour time.
Note: When in 12-hour format AM or PM will show in front of the hour.
1. 12H will flash in the time display.
2. Press and release the ▼or ▲buttons to select 24-hour time.
3. Confirm with the TIME SET button and move to Set Time.
Set Time
To set the time manually:
1. The hour digit will flash.
2. Press and release the ▼or ▲buttons to select the hour.
3. Press and release the TIME SET button to set the minutes.
4. The minute’s digit will flash.
5. Press and release the ▼or ▲buttons to select the minutes.
6. Confirm with the TIME SET button and move to Set Calendar.
ON
WWVB
EST
ON
DST
12H

Model: 308-1425B www.lacrossetechnology.com/support Page | 8
Set Calendar
The date default of the weather station is 1. 1. 2014.
To set the calendar:
1. The year will flash.
2. Press and release the ▼or ▲buttons to set the year (between years 2000-2039).
3. Press the TIME SET button again to confirm and to enter the month setting.
4. The month will flash.
5. Press and release the ▼or ▲buttons to set the month.
6. Press the TIME SET button again to confirm and enter the date setting.
7. The date will flash.
8. Press and release the ▼or ▲buttons to set the date.
9. Confirm all calendar settings with the TIME SET button to confirm and move to select
Fahrenheit/Celsius.
Note: The day of the week will set automatically once the year, month and date are set.
Fahrenheit/Celsius
1. °F will flash.
2. Press and release the ▼or ▲buttons to select Fahrenheit or Celsius.
3. Confirm with the TIME SET button and exit the program menu.
Temperature Alerts
The weather station offers individual, programmable high and low
temperature alerts.
Hold the ALERT button for five seconds, until the weather station beeps, to
select and set temperature alert values. Each alert value will flash
separately during alert set mode.
OUTDOOR HIGH alert will flash. Press the ▼or ▲buttons to set the alert value, and
press the ALERT button to confirm. Then press the ALERT button again switch to
OUTDOOR LOW setting.
OUTDOOR LOW alert will flash. Press the ▼or ▲buttons to set the alert value, and
press the ALERT button to confirm. Then press the ALERT button again switch to
INDOOR HIGH setting.
INDOOR HIGH alert will flash. Press the ▼or ▲buttons to set the alert value, and
press the ALERT button to confirm. Then press the ALERT button again switch to
INDOOR LOW setting.
INDOOR LOW alert will flash. Press the ▼or ▲buttons to choose the value, and
press the ALERT button to confirm and exit.
Note: After selecting temperature alert values use the next step to turn individual alerts
ON or OFF.
Arm/Disarm Temperature Alerts
In normal time mode, press and release the ALERT button to toggle between:
oOutdoor HI
oOutdoor Lo
°F

Model: 308-1425B www.lacrossetechnology.com/support Page | 9
oIndoor HI
oIndoor LO
Press the ▲button to arm the selected alert.
The alert bell appears when each alarm is activated.
Press the ▼button to disarm the selected alert.
OFF will show in the Alerts area if no alert is active.
Temperature Alert Sounds
When temperature alert sounds, the corresponding alert bell will flash.
The alert beeps once every minute, until the temperature is out of alert range.
Press any button to stop alert. The alert bell will still show.
Disarm Alert: In normal mode, hold and release the ALERT button to select the alert
to disarm. With HI or LO alert selected, press the ▼button disarm alert.
Time Alarm Set
Hold the ALARM button for 5 seconds to enter the alarm time set mode.
1. The alarm hour digit will flash in the time display.
2. Press and release the ▼or ▲buttons to select the hour.
3. Press and release the ALARM button to set the minutes. The minute
digits will flash.
4. Press and release the ▼or ▲buttons to select the minutes.
5. Confirm with the ALARM button and exit.
6. The bell icon will show indicating the alarm is active.
7. The bell icon will flash when the alarm is sounding.
Deactivate Alarm
1. Press and release the ALARM button once to show alarm time.
2. Press and release the ALARM button to deactivate the Alarm.
3. The bell icon will disappear indicating the alarm is no longer active.
Snooze
1. When the alarm sounds, press the SNOOZE/LIGHT button to trigger snooze alarm
for 10 minutes. The snooze icon Zz will flash by the weekday when the snooze
feature is active.
2. To stop alarm for one day, press ALARM button, while in snooze mode. The bell icon
will remain solid.
Note: When the alarm sounds, it continues for 2 minutes and then shuts off
completely.
Adjust Backlight (HI-LOW-OFF)
When using A/C power:
Press the HI/LOW/OFF button to adjust the backlight:
When using Battery power only:
Press the HI/LOW/OFF button for 10 second backlight.

Model: 308-1425B www.lacrossetechnology.com/support Page | 10
Heat Index/Dew Point
The HEAT/DEW button toggles between Heat Index, Dew Point, and Mold Risk.
Each feature will display for 10 seconds then return to default display if the button
is not pressed again.
Heat Index
Heat Index combines the effects of heat and humidity. It is the apparent temperature of
how hot it feels to a human being. As humidity increases, the body is unable to cool
effectively; therefore, the temperature will feel warmer.
View Heat Index: From a normal display, press the HEAT/DEW button once and Heat
Index will show in place of the outdoor temperature.
Note: Heat index will be the same number as the temperature until the outdoor
temperature is above 80 °F (26.7°C).
Dew Point Temperature
Dew Point Temperature is the saturation point of the air, or the temperature to which the
air has to cool in order to create condensation. The higher the dew points, the higher the
moisture content of the air at a given temperature.
View Dew Point Temperature: From a normal display, press the HEAT/DEW button
twice and Dew Point will show place of the outdoor temperature.
Note: Dew Point is lower than the actual temperature.
Temperature/Humidity Trend indicators
The indoor and outdoor temperature/humidity trend indicators will update every 30
minutes or less. These trends represent temperature changes over the past three hours.
Example: At 1:00pm, the arrow indicates the change in temperature since 10:00am. At
1:30pm, the arrow will indicate the temperature change since 10:30am.
Temperature has risen in the past 3 hours.
Humidity has risen in the past 3 hours.
Temperature has not changed in the past 3 hours.
Humidity has not changed in the past 3 hours.
Temperature has fallen in the past 3 hours.
Humidity has fallen in the past 3 hours.
Search for Outdoor Sensor
Hold the HEAT/DEW button to search for the outdoor sensor.
The strength signal icon will animate until the sensor signal is received or for
3 minutes if no signal available.

Model: 308-1425B www.lacrossetechnology.com/support Page | 11
MIN/MAX (View, Reset)
The Weather station provides the daily minimum and maximum temperatures each day
starting at midnight (12:00 AM). The Weather station automatically resets the min/max
temperatures at midnight (12:00 AM).
View MIN data: Press and release the ▼button to view the minimum
Indoor and Outdoor Temperatures.
Reset MIN data: Hold the ▼button for five seconds and the Indoor and
Outdoor Minimum Temperatures will be reset.
View MAX data: Press and release the ▲button to view the maximum Indoor and
Outdoor Temperatures.
Reset MAX data: Hold the ▲button for five seconds and the Indoor and all Outdoor
Maximum Temperatures will be reset.
Note: The temperature areas will show dashes briefly then return to current
temperatures.
Animated Color Forecast Icons
Animated forecast icons use changing atmospheric pressure to predict weather
conditions for the next 12-hours with 70-75% accuracy.
INTELLIGENT WEATHER FORECAST
This station learns; please allow 3 to 4 weeks for barometric calibration. This will ensure
an accurate personal forecast for your location.
The Weather station samples the barometric pressure every twelve minutes.
These samples are averaged hourly and daily then stored in nonvolatile memory.
The three hour pressure icon change is based off of the last four average hourly
readings.
IMPORTANT: As the Weather station builds memory, it will compare the current
average pressure to the past forty day average pressure for increased accuracy. The
longer the Weather station operates in one location, the more accurate the forecast icons
will be.
The icons forecast the weather in terms of getting better or worse and not necessarily
sunny or rainy as each icon indicates.

Model: 308-1425B www.lacrossetechnology.com/support Page | 12
Forecast Tendency Indicators (Up, Right, Down Arrows)
Working with the forecast icons, the tendency indicators let you know if the weather is
improving, steady or worsening.
Rising Pressure Weather
is Expected to Improve
Steady Pressure Weather
is Expected to Stay the
Same
Falling Pressure Weather
is Expected to Worsen
24 Hour Pressure History Graph/Tendency Arrows
The bar chart indicates the air pressure history trend over
the last 24 hours.
The columns represent the pressure change (”InHg” or “hPa”)
readings at specific times.
The “0” is equal to the current pressure and each bar
represents how past pressure was compared to the current
pressure.
Read the graph from left to right. If the bars are rising, it
means that the weather is getting better due to the increase
of air pressure.
If the bars go down, it means the air pressure has dropped and the weather is
expected to get worse from the present time.
Moon Phase (based on lunar calendar)
New Moon occurs when the moon is between the earth and sun so the illuminated
portion of the moon is on the back side facing the sun and we cannot see it. After a
new moon, the illuminated (visible) portion will increase or wax until the full moon
occurs.
Full Moon occurs when the earth, moon and sun are in approximate alignment, with
the moon and the sun on opposite sides of the earth. The illuminated portion of the
moon faces the earth, giving us complete visibility of one side of the entire moon.
After a full moon, the illuminated portion will decrease or wane until the new moon
occurs.

Model: 308-1425B www.lacrossetechnology.com/support Page | 13
First Quarter and Last Quarter moons occur when the moon is at a 90 degree
angle to the earth and sun. So we see half of the moon illuminated and half is in
shadow.
Waxing means growing or expanding illumination and happens after a new moon.
Waning means decreasing illumination and occurs after a full moon.
Crescent refers to the moon being less than half illuminated. Crescents can be
waning or waxing.
Gibbous describes a moon phase when more than half is illuminated. Gibbous can be
waxing or waning.
Manual WWVB Time Signal Search
Press the TIME SET button to start or stop a manual signal search. The WWVB Icon
flashes during signal search.
For information about WWVB visit:
www.nist.gov/pml/div688/grp40/wwvb.cfm
Outdoor Positioning and Use
Mount the Outdoor Sensor on a north-facing wall or in any well shaded area. Under
an eave or deck rail is preferred.
The maximum wireless transmission range to the weather station is over 300 feet (91
meters) in open air, not including walls or floors.
Be sure the outdoor sensor is mounted vertically.
Low Battery icon
Low battery icon indicates low battery for station or sensor.
If the icon is displayed in the Outdoor Humidity section, replace batteries in
the outdoor sensor.
If the icon is displayed in the Indoor Temperature section, replace batteries
in the forecast station.
Care and Maintenance
Do not mix old and new batteries
Do not mix Alkaline, Standard, Lithium or Rechargeable Batteries
Always purchase the correct size and grade of battery most suitable for the intended
use.
Replace all batteries of a set at the same time.
Clean the battery contacts and also those of the device prior to battery installation.
Ensure the batteries are installed correctly with regard to polarity (+and -).
Remove batteries from equipment with is not to be used for an extended period.
Remove used batteries promptly.
Do not expose to extreme temperature, vibration or shock.
Clean with a soft damp cloth. Do not use solvents or scouring agents.
The product is not a toy. Keep it out of reach of children.
The product is not to be used for medical purpose or for public information. It is
intended for home use only.
The specs of this product may change without prior notice.
Improper use or unauthorized opening of housing voids warranty.
WWVB
ATOMIC
ICON
Low
Battery
Icon

Model: 308-1425B www.lacrossetechnology.com/support Page | 14
If the product is not working properly, change the batteries and/or check the AC cord
connection.
Specifications
Indoor
Temperature Range:
+32°F to +122°F (0°C to 50°C)
Humidity Range:
1%-99% (RH)
Outdoor
Temperature Range:
-40°F to 140°F (-40°C to 60°C)
Alkaline Batteries:
-20°F to 140°F (-29°C to 60°C)
Lithium Batteries:
-40°F to -20°F (-40°C to -29°C)
NOTE:
Temperatures below - 20°F (-29°C) require
Lithium batteries in the outdoor sensor
Humidity Range:
1%-99% (RH)
Distance:
Over 300 ft. (91 meters)
RF 433MHz (open air)
Power
Forecast Station
Primary AC Power:
AC#: GPU280500150WD00
5-volt AC power adapter (included)
Optional/Battery Backup
Optional 3-AAA, IEC, LR3 batteries (not included)
TX141TH-Bv2 Outdoor Sensor:
2-AA, IEC, LR6 batteries (not included)
Battery Life
Forecast Station
Battery Backup:
Battery life is over 36 months when using the AC
adapter for primary power
TX141TH-Bv2 Outdoor Sensor:
Battery life is over 24 months when using
reputable battery brands for both Alkaline and
Lithium batteries
Dimensions
Forecast Station:
6.16” W x 9.65” H x 0.925” D
(156.5 x 245.1 x 23.5 mm)
TX141TH-Bv2 Outdoor Sensor:
1.57"L x 0.79"W x 5.12"H
(40 x 20 x 130mm)

Model: 308-1425B www.lacrossetechnology.com/support Page | 15
Warranty Information
La Crosse Technology, Ltd. provides a 1-year limited time warranty (from date of purchase) on this product
relating to manufacturing defects in materials & workmanship.
Before returning a product, please contact our friendly customer support with questions or visit our
online help (manuals and FAQS):
Phone: [phone] Online Product Support: www.lacrossetechnology.com/support
Product Registration: View full warranty details online at:
www.lacrossetechnology.com/support/register www.lacrossetechnology.com/warranty_info.pdf
Warranty Address: Protected under U.S. Patents:
La Crosse Technology, Ltd 5,978,738 | 6,076,044 |RE43903
2830 S. 26th St.
La Crosse, WI 54601
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
This device must not be co-located or operating in conjunction with any other antenna or transmitter. Operation
is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired
operation.
Caution!
The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to
this equipment. Such modifications could void the user authority to operate the equipment.
All rights reserved. This manual may not be reproduced in any form, even in part, or duplicated or processed
using electronic, mechanical or chemical process without the written permission of the publisher.
This booklet may contain errors or misprints. The information it contains is regularly checked and corrections are
included in subsequent editions. We disclaim any responsibility for any technical error or printing error, or their
consequences.
All trademarks and patents are recognized.
