La Crosse Technology T85647v2 Operating and maintenance manual

Wireless Color Weather Station
Welcome!
--------------
Congratulations on your new Wireless Color Weather Station and welcome to the
La Crosse Technology family! This product was designed with you in mind by our
hometown team of weather enthusiasts based in La Crosse, Wisconsin.
Instructional Manual
Model: T85647v2
DC: 092218
Wireless Color Weather Station

Page | 2
Wireless Color Weather Station
Table of Contents
Step 1: Power Up
Step 2: Mounting Basics
Step 3: Set Time, Date, etc.
Setting Menu
Your Weather Station Features
WWVB Atomic Time
Backlight HI-LOW-OFF
Alarm Time
Deactivate/Activate Alarm
Snooze
Set Temperature Alerts
Arm/Disarm Temperature Alerts
MIN/MAX Temperatures
Temperature/Humidity Trend Arrows
Sensor Search
Heat Index | Dew Point| Mold Risk
Forecast
Forecast Trend Arrows
Low Battery
Restart
Help Us, Help You!
Let’s Be Social!
Care and Maintenance
Warranty and Support
Specifications
FCC Statement
Canada Statement
3
3
3
4
5
6
6
6
6
6
7
7
8
8
8
9
9
10
10
10
10
10
11
11
12
13
13

Page | 3
Wireless Color Weather Station
Insert batteries (in any order):
• 2-AA batteries into thermo-hygro sensor
• 5 volt power cord (required) into T85647v2 station
*3-AAA batteries for optional backup of your time and date
STEP 1: Power Up
STEP 2: Mounting Basics
Wait until your sensor information should be displayed on your station.
Here are a few quick tips for mounting your sensor:
• Keep out of direct sunlight & ensure the sensor is well-ventilated.
• We recommend mounting under a deck or eave facing north.
• Insert the mounting screw through the front of the sensor and into the wall.
• Tighten the screw to snug (do not over tighten).
• Be sure the outdoor sensor is mounted vertically to drain moisture.
• The maximum wireless transmission range is over 330 feet (100 meters) in open air, not including walls or
floors.
AAA
AAA
AAA
AA
AA
AA
AA
You can manually adjust your station’s settings:
1. Hold the TIME SET button for 3 seconds to enter settings menu.
2. Press and release the ARROW buttons to adjust the flashing values. Hold to adjust quickly.
3. Press and release the TIME SET button to confirm and move to the next item.
STEP 3: Set Time, Date, etc.

Page | 4
Wireless Color Weather Station
To begin: Hold the TIME SET button 2 seconds, then release, to enter the settings menu.
Use the ARROW buttons to adjust values. Press the TIME SET button to confirm and move to next item.
Settings Menu
Settings order:
1. WWVB ON/OFF
2. Time Zone
3. DST ON/OFF
4. 12H/24H
5. Hour
6. Minutes
7. Year
8. Month
9. Date
10.Fahrenheit/Celsius
AST
EST
CST
MST
PST
AKT
HAT
Atlantic
Eastern
Central
Mountain
Pacific
Alaskan
Hawaiian
Time Zones
Note: When WWVB OFF is selected, the menu will move directly to 12/24
hour time setting.
Note: The weekday will set automatically as the year, month, and date
are set.
1. WWVB ON | OFF
2. Time Zone
3. DST ON | OFF
4. 12Hour | 24 Hour
5. Hour
7. Year
6. Minutes
8. Month
9. Date
10. Fahrenheit | Celsius

Page | 5
Wireless Color Weather Station
Your Weather Station Features
2
3
4
1
5
6
7
2
3
4
1
5
6
78
Alerts (HI-LO-OFF)
MIN/MAX | Low Battery
Trend Arrow
Indoor Temp
Mold Risk
MIN/MAX
Indoor Humidity
2
3
4
1
5
6
7
Forecast Symbols
Forecast Trend
AM/PM
Atomic Tower | DST
Alarm/Snooze
Weekday
Month/Date
8
2
3
4
1
5
6
7
Alerts (HI-LO-OFF)
MIN/MAX | Low Battery
Sensor Strength
Remote Temperature
Trend Arrow
Mold Risk
MIN/MAX
8Remote Humidity
8Trend Arrow
Atomic Time
3
4
1
5
67
2
89
9Trend Arrow
2
3
4
1
56
7
8

Page | 6
Wireless Color Weather Station
• From normal time display, press and release the TIME SET button to search for the WWVB time signal.
• Please be sure you have selected your time zone from the list in the Settings menu. When the Atomic time
signal is received, the station will set to the time zone selected. Default is Eastern Time.
• For information about WWVB visit: http://bit.ly/AtomicTime
WWVB Atomic Time
Backlight (HI-LOW-OFF)
• When operating with the power cable, the backlight is adjustable: HI-LOW-OFF.
• Press and release SNOOZE/LIGHT to adjust backlight.
• When operating on batteries only, the backlight will come on briefly when the SNOOZE/LIGHT button
is pressed.
Alarm Time
The alarm will be active when alarm time is set.
1. Hold the ALARM button for 3 seconds to enter alarm settings.
2. The HOUR will show.
3. Press the ARROW buttons to adjust.
4. Press ALARM to confirm and move to the minutes
5. The MINUTES will show.
6. Press the ARROW buttons to adjust.
7. Press ALARM to confirm and exit settings.
Deactivate/Activate Alarm
• The alarm is active when set.
• Press and release the ALARM button to view alarm time. Then press and release the ALARM button to
deactivate or activate the alarm.
• The alarm icon (bell) will show when active.
• When the alarm sounds, press the SNOOZE/LIGHT button to silence the alarm for 10 minutes.
• The snooze icon Zz will flash.
• Press any button except SNOOZE/LIGHT to silence the alarm for 24 hours.
Snooze

Page | 7
Wireless Color Weather Station
Set Temperature Alerts
• Hold the ALERTS button for 3 seconds until the remote HI alert value flashes.
• Press and release the ARROW buttons to adjust the value. Hold to adjust quickly.
• Press and release the ALERTS button to confirm and move to the next alert.
Alert order:
1. Remote HI
2. Remote LO
3. Indoor HI
4. Indoor LO
Arm/Disarm Temperature Alerts
1. Press and release the ALERTS button so the remote HI alert temperature shows and the word HI flashes.
• Press UP ARROW to arm
• Press DOWN ARROW to disarm
2. Press and release the ALERTS button to confirm and move to the remote LO, indoor HI and indoor LO
alerts.
3. A bell appears above and alert when armed.
4. If no alerts are active, OFF will show.
Tip: Setting the alerts is one step. Arming the alerts is a separate step (see below)
Remote HI Alert Remote LO Alert
Indoor HI Alert Indoor LO Alert
HI alert armed LO alert armed Alerts OFF

Page | 8
Wireless Color Weather Station
All MIN/MAX temperature/humidity records will reset automatically at 12:00 (midnight).
• Press and release the DOWN ARROW to view indoor/remote minimum readings.
• Press and release the UP ARROW to view indoor/remote maximum readings.
MIN/MAX Temperature Records
MINIMUM MAXIMUM
Temperature/Humidity Trend Arrows
• The temperature (2°F / 1°C) trend indicators update every 30 minutes.
• The humidity (3% RH) trend indicators update every 30 minutes or less.
• 3 hrs. increments which changes on every ½ hour e.g.: At 3:00 — compares to 12:00 data;
at 3:30 — compares to 12:30, etc.
Rising: Trend is rising over past 3 hours
Steady: No change
Falling: Trend is falling over past 3 hours.
Sensor Search
• Hold the HEAT/DEW button for 3 seconds to search for the remote temperature/humidity sensor.
• The strength signal icon will animate until the sensor signal is received, or for 3 minutes if no signal available.

Page | 9
Wireless Color Weather Station
Heat Index | Dew Point | Mold Risk
• Press the HEAT/DEW button once to view remote Heat Index.
• Press the HEAT/DEW button twice to view remote Dew Point.
• Press the HEAT/DEW button a third time to view indoor and remote Mold Risk (0, LOW, MED, HI)
Forecast
1. The weather station oers these 6 forecast icons based on barometric pressure.
2. When the forecast would normally be Rain or T-Storm and the outdoor temperature is below 32°F, the
forecast will show Snow.
3. Wind indicators will show on T-Storm and Snow forecast.
SUNNY PARTLY SUNNY CLOUDY RAIN T-STORM SNOW

Page | 10
Wireless Color Weather Station
Low Battery
• Battery by Outdoor Temperature, replace batteries in the sensor.
• Battery by Indoor Temperature, replace batteries in the weather station.
Forecast Trend Arrows
Rising: Weather will improve
Steady: No change
Falling: Weather will worsen
Intelligent Weather Forecast:
• This station learns. Please allow 7-10 days for barometric calibration.
• This will ensure an accurate personal forecast for your location.
Restart
When the outdoor readings show dashes:
• Bring the sensor in the house at least five feet from the forecast station.
• Remove batteries from the sensor, as well as, the batteries and AC adapter from the forecast station.
• Press any button 20 times.
• After 15 minutes insert batteries into the sensor and station and re-connect the adapter.
• Wait 15 minutes to establish a strong connection. Place sensor outside in shaded location.
Follow us on our social media outlets for the latest promotions, product support, and awesome giveaways.
Let’s Be Social!
If you have ideas for features or support solutions you’d like to see us make, please let us know!
We truly want to make owning a La Crosse Technology product not only a practical experience, but also a fun
one. So email us at: [e-mail]
Help Us, Help You!
