WIRELESS 433 MHz WEATHER STATION
Instruction Manual
INTRODUCTION:
Congratulations on purchasing this fancy Cubic Weather station
wireless 433MHz transmission. It not only displays the indoor
temperature and humidity but also receives the outdoor temperature.
It is further acting as a DCF-77 radio controlled clock and gives
colour-changing backlight.
With the totally 15 different weather forecast icons featured by
"weather man", users can easily observe the forecast weather
condition and will no longer worry the sudden weather change. This
innovative product is ideal for use in the home or office.
THE WEATHER STATION
LCD
Display
36
Function
Keys Battery
compartment
cover

FEATURES
•DCF-77 Radio-controlled time and date
•12/24 hour display
•Hour, minute and second time display
•Calendar (weekday, date and month)
•Time zone option ±12 hours
•Weather forecasting with 15 easy-to-read weather forecast
signs featured by weather man
•Displays indoor temperature & humidity
•Display outdoor temperature
•Temperature display in degrees Celsius (°C) or Fahrenheit
(°F) selectable
•Colour-changing EL backlight (with permanent backlight
ON/OFF function, and the case of the weather station will also
be illuminated when the backlight is ON).
Alarm with snooze function•
•LCD contrast setting
•Table standing
37

TEMPERATURE TRANSMITTER: emote transmission of outdoor
•ounting at
ETTING UP rt 4 x AAA, IEC LR3, 1.5V batteries into the weather
2.
•R
Holder temperature to Weather station by
433 MHz
Shower pro-of casing
•Wall mounting case (M
a sheltered place. Avoid direct
rain and sunshine)
S
1. First, inse
station. Once the batteries are in place, all segments of the
LCD will light up briefly. Then the indoor temperature, the
weather man icon and the time as 0:00, will be displayed. If
the indoor temperature is not displayed after a few seconds,
remove the batteries and wait for at least 30 seconds before
reinserting them. Once the indoor data is displayed proceed to
step 2.
Within 45 seconds of activating the Weather station, place 2 x
AA, IEC LR6, 1.5V batteries into the transmitter.
3. After inserting the batteries into the transmitter, the weather
station will start receiving data from the transmitter. The
remote temperature will then be displayed on the station. If
this does not happen after 2 minutes, the batteries will need to
be removed from both units and reset from step 1.
38

4. d just after
5. (and date)
Note:
When the transmitter is set up, there is a testing period. Then
DCF-77 time code reception is automatically starte
the clock is activated. This takes typically between 3 - 5
minutes in good conditions. This time period is an excellent
opportunity to locate the transmitter in suitable location
outdoors. In order to ensure sufficient 433 MHz transmission
however, this should under good conditions be no more than
25 meters from where the Weather station will be finally
positioned (see notes on “POSITIONING THE OUTDOOR
TRANSMITTER” and “433 MHZ RECEPTION”).
If after 10 minutes the DCF time has not been received, use
the MODE/ MIN key to manually enter a time
initially. The unit will still try and receive the time signal
regularly despite it being manually set. When it does receive
the signal, it will change the manually set time into the
received time.
d the total timeShoul of inserting the batteries into the transmitter
nger than 1-1/2 minutes from the time of inserting the
he weather
ation needs to be reset. (See Resetting the weather station)
take lo
batteries into the weather station then temperature reception
problems may occur. If the temperature is not being received, then
see "433 MHZ RECEPTION", before resetting the units.
In the event of changing batteries to the transmitter, t
st
39

RESETTING THE WEATHER STATION
To reset the Weather station to the factory default setting or in case
a malfunction or changing batteries to transmitter, please remove
C adapter from any
he Weather station uses 4 x AAA, IEC LR3, 1.5V batteries (Two no.
eplace the batteries, please follow the steps below:
ttery
2.
rting ad
used:
1. Connect the power adapter t a wall socket
of
all batteries from the unit and unplug the AC/D
power source. Wait at least for 3 minutes before powering up the
Weather station again.
TO INSTALL AND REPLACE BATTERIES INTO THE WEATHER
STATION
T
of batteries for the station functioning and two for the backlight). To
install and r 1. Insert finger or other solid
object in the space at the
bottom centre of the ba
compartment and lift up to
remove the cover.
Insert batteries observing
the correct polarity (see
marking).
3. Replace compartment
cover.
Socket for
adaptor
In addition or instead of inse batteries, the AC apter can be
o
40

2. Insert the adapter into the jack at the bottom of the station
3. The Weather station will now start receiving the DCF time
he DCF time will signal. After approximately 3 to 5 minutes, t
be displayed (Also see "SETTING UP" below) .
Important!
Use only the adapter provided with the Weather station and make
re that your household voltage is appropriate to the working
nsformer. Otherwise your Weather station may be
her station is first powered by batteries and the power
dapter is subsequently used for extended period of time, the main
wer.
su
voltage of the tra
damaged.
POWER SUPPLIED BY BATTERIES AND AC/DC ADAPTER
If the Weat
a
power source of the Weather station will switch to AC/DC po
The batteries will then act as a backup power source in case of
power failure.
41

TO INSTALL AND REPLACE BATTERIES IN THE
TEMPERATURE TRANSMITTER
The Temperature Transmitter uses 2 x AA, IEC, LR6, 1.5V batteries.
ve the cover.
cover on the unit.
BATTERY CHANGE:
It is recommended to replace the batteries in all units regularly to
ensure optimum accuracy of these units (Battery life See
. Return used batteries to an authorised
depot.
To install and replace the batteries, please follow the steps below:
1. Remo
2. Insert the batteries, observing the
correct polarity (see marking).
3. Replace the battery
Specifications below).
Please participate in the preservation of the
environment
42

Dhe time base for th CF-77 RADIO CONTROLLED TIME
e radio controlled time is a Cesium Atomic Clock
chnische Bundesanstalt
ing. This indicates that the unit
T
operated by the Physikalisch Te
Braunschweig which has a time deviation of less than one second in
one million years. The time is coded and transmitted from
Mainflingen near Frankfurt via frequency signal DCF-77 (77.5 kHz)
and has a transmitting range of approximately 1,500 km. Your radio-
controlled Weather station receives this signal and converts it to
show the precise time in summer or wintertime.
The quality of the reception depends greatly on the geographic
location. In normal cases, there should be no reception problems
within a 1500km radius of Frankfurt.
Once the outdoor reception test period is completed, the DCF tower
con in the time display will start flashi
has detected that there is a radio signal present and is trying to
receive it. When the time code is received, the DCF tower becomes
permanently lit and the time will be displayed.
If the tower icon flashes, but does not set the time or the DCF tower
does not appear at all, then please take note of the following:
•Recommended distance to any interfering sources like
computer monitors or TV sets is a minimum of 1.5 - 2 metres.
•Within ferro-concrete rooms (basements, superstructures), the
received signal is naturally weakened. In extreme cases,
please place the unit close to a window and/or point its front or
back towards the Frankfurt transmitter.
43

Durin
sever cases. A single daily
N KEYS
here are three function keys at the top of the weather station and
Press to initiate the snooze function when the alarm is
ing.
SNO ey MODE/MIN
key Light ON/OFF
key
Top
g nighttime, the atmospheric disturbances are usually less
e and reception is possible in most
reception is adequate to keep the accuracy deviation below 1
second.
FUNCTIO
T
one at the back.
S
•
NOOZE key
sound
•Press to confirm the manual setting in the different setting
modes
OZE k
A OUR
key
Ba
L/H
ck
44

•Press to activate the EL back-light
AL R key
P
/HOU
•ress and hold to advance to the alarm time setting
o set the hour in alarm setting mode
DE/MPress and hold to advance to the manual setting
set the minute in alarm setting mode
tting mode
day & month",
•
•the alarm and snooze
HT OTo Switch On / Off the permanent mode of colour-changing
ht
•Press t
•Press to set the hour in time setting mode
•Press to set the date in calendar setting
•Press to activate the EL back-light
•Press to stop the alarm and snooze
MO IN key
•
•Press to
•Press to set the minute in time setting mode
•Press to set the month and year in calendar se
•Press to toggle between various display for "
"day & weekday", "indoor temperature & humidity" and
"alarm time"
Press to activate the EL back-light
Press to stop
LIG N/OFF key
•LED backlig
45

LCD SCREEN AND SETTINGS:
he LCD screen is split into 4 sections:
ection 1 - TIME
Weather
Tendency icon
Weather
Forecast icon
eat
Time
Outdoor
Temperature
(W
For better distinctness t
S
•In normal mode, display the current time.
her man)
Radio controlled time
ception On icon
Alarm icon
"indoor temperature
and humidity",
"preset alarm time" or
"calendar display"
re
46

Section 2 - WEATHER ICON (FEATURED BY WEATHER MAN)
•Display of the weather to be expected in form of 15 fancy
•ather tendency indicator
ection 3 - INDOOR DATA/ PRESET ALARM TIME/ CALENDAR
ection 4 - OUTDOOR TEMPERATURE
ANUAL SETTING
lding the MODE/MIN key for about 3 seconds,
weather symbols (featured by Weather man) which change
their appearance depending on the air pressure development
(past air pressure change) and the current outdoor
temperature.
Display the we
S
•Display the "day & month", "day & weekday", "indoor
temperature & humidity" or "alarm time"
S
•Display the outdoor temperature.
M
LCD contrast level
After pressing and ho
the manual setting mode is activated. Then The LCD contrast can be
set:
flashing
47

1. The contrast level will be flashing. Press the MODE/MIN key
to adjust the contrast level 0 to 7 (default: 5).
2. Press the SNOOZE key to confirm and enter the Time zone
setting mode.
Time zone setting
The time zone default of the Weather station is “0”. To set a different
time zone:
1. The current time zone value at the bottom of the LCD display
starts flashing.
flashing
2. Press and release MODE/MIN key to adjust the time zone.
The range runs from 0, -1, -2 to -12, then 12, 11, 10 to 0, in
consecutive 1-hour intervals.
3. Confirm with the SNOOZE key and enter the Manual time
setting.
Manual time setting
In case the Weather station cannot detect the DCF-signal (for
example due to disturbances, transmitting distance, etc.), the time
can be manually set. The station will then work as a normal Quartz
48

clock.
Hours
(flashing)
Minutes
(flashing)
1. The hour and the minute digits will start flashing.
2. Use the AL/HOUR key to set the hour; MODE/MIN key to set
the minute.
3. Confirm with the SNOOZE key and enter the Calendar
setting.
Note:
The unit will still try and receive the time signal regularly despite it
being manually set. When it does receive the signal, it will change
the manually set time into the received time.
Calendar setting
The date default of the Weather station is 1. 1. in the year 2005.
Once the radio-controlled time signals are received, the date is
automatically updated. However, if the signals are not received, the
date can also be set manually.
1. The year starts flashing.
49

Year
2. Use the MODE/MIN key to set the year (between year 2003-
2029).
3. Press the SNOOZE key to confirm and to enter the month and
day setting. The month and day digits will start flashing.
4. Use the AL/HOUR key to set the day and MODE/MIN key to
set the month.
"Day. Month." (for 24h time display)
"Month. Day." (for 12h time display)
5. Press the SNOOZE key again to confirm and to enter the
12/24 hour time format setting.
50

12/24 hour time format setting
1. The time format digit starts flashing. Press the MODE/MIN key
to select the 12-hour or 24-hour time format.
flashing
2. Press the SNOOZE key again to confirm and to enter the
Temperature unit (°C/ °F) setting.
Temperature unit (°C/ °F) setting
1. The temperature unit digit starts flashing. Press the
MODE/MIN key to select the unit °C or °F.
flashing
2. Press the SNOOZE key again to confirm and to enter the
Daylight saving time setting.
51

Daylight saving time setting
Note:
The function of daylight saving time on/off is only applicable to
specific area in United states using WWVB time sources. It is not
applicable for DCF-77 signal in European countries.
•User may skip doing this part of setting for this European
version weather station (-press the SNOOZE key to exit the
setting mode and go back to the normal display). Setting of
“dST On” or “dST Off” will have no effects on the reception
time.
TIME ALARM
Setting the alarm
1. Press and hold “AL/HOUR” button for about three seconds
until the alarm time is flashing.
52

Alarm time
(flashing)
Alarm icon
flashing
2. Press and release “AL/HOUR” to advance the hour, and
“MODE/MIN” to advance the minute. The time will display
in 24-hour format.
3. Press the SNOOZE key to confirm. The alarm is now set
and activated.
Activating / Deactivating the alarm
1. After entering the alarm-setting mode, the alarm is
activated.
2. To toggle between activating and deactivating the alarm,
press the “AL/HOUR” button briefly. Alarm-on icon, “(((•)))”
will be displayed next to the time display when the alarm is
activated.
53

Turning alarm off (while sounding)
1. While the alarm is sounding, press and release the
SNOOZE bar to disable the alarm for 10 minutes. (After the
SNOOZE bar is pressed, the alarm icon will keep flashing.
After 10 min, the alarm will sound again.)
2. To disable the alarm, press and release the AL/HOUR or
MODE/MIN button.
WEATHER FORECAST AND TENDENCY:
The weather forecast icons (Weather man):
One of the 15 different weather icons (featured by Weather man with
different clothing) is displayed in the centre of LCD, which indicates
the different forecast weather condition due to air pressure level
(Sunny, Sunny + Cloudy or Rainy) and the current outdoor
temperature:
≥26°C 19
–
25.9°C 10
–
18.9°C 0
–
9.9°C < 0°C
Sunny
54

55
≥26°C 19
–
25.9°C 10
–
18.9°C 0
–
9.9°C < 0°C
≥26°C 19
–
25.9°C 10
–
18.9°C 0
–
9.9°C < 0°C
Sunny +
Cloudy
Rainy
For every sudden or significant change in the air pressure, the
weather icons will update accordingly to represent the change in
weather. If the icons do not change, then it means either the air
pressure has not changed or the change has been too slow for the
