La Crosse Technology V15 User manual

SET UP GUIDE
MODEL NUMBER V15
Wi-Fi COLOR FORECAST
STATION

Table of Contents
BASICS
Initial Setup
Station Settings
Buttons
LCD Display Brightness
Auto-Dim Settings
Low Battery Indicators
02
06
07
08
08
16
TEMP. AND HUMIDITY
Viewing Current
Conditions
Accessing Indoor/Outdoor
Readings
Viewing TH Records
Temp. & Humidity Alerts
09-13
09
12
13
APPENDIX
Cautions/Statements
Warranty
Recycling & Disposal
Specifications
FCC Statement
Canada Statement
18-20
19
19
19
20
20
LA CROSSE VIEW
Connecting to the App
Connecting Your Station
Adding Your Sensor to
the App
Manually Add Sensor to
the App
03
04
05
05
FORECAST
Viewing Your Forecast Data
Viewing Extended Forecasts
Standalone Forecast Icons
Enhanced Forecast Data
Relative Pressure
13
14
15
15
16
SENSORS
Placement & Mounting
Add-On Sensors
Adding Extra Sensors
17
17
17
SUPPORT
We’re Here to Help
Factory Reset
Stay in Touch
21
21
21

02
Initial Setup
Power Up
Note: It may take up to 10 minutes for your sensor data to appear on your
station’s screen.
BASICS
Weather Station
Insert the 5V Power Adapter into an outlet, and then plug it into the Power Jack on the back of
the station. Next, remove the Insulation Tab from the Station’s Battery Compartment.
Thermo-Hygro Sensor
Install 2 fresh “AA” batteries according to polarity and replace battery cover. The blue LED light
will flash when transmitting.
Back of Station
(V15)
Thermo-Hygro Sensor
(LTV-TH5i)
Power Jack

03
Connecting to the App
LA CROSSE VIEW
Download the La Crosse View App
Visit the App Store or Google Play Store to download the free
La Crosse View app onto your mobile device.
Stay connected to your home anytime, anywhere with the
La Crosse View app.
Monitor your home environment and set custom alerts to
notify you when conditions change.
Connecting your station is optional and the display will
function as a standalone unit without the Wi-Fi connection.
However, we recommend connecting during the initial
setup, as it will save you time and allows access to some
advanced features right away.
Launch the App
Connecting Your Station to the App
Open the La Crosse View app. Follow the on-screen setup instructions
to create an account, add new devices, and connect your station to
your Wi-Fi network.
Stay Connected to Your Home
Anytime, Anywhere.
Now that you’ve created your La Crosse View account, it’s time to add your station into your account
and connect your station to your home router using the La Crosse View app.
NOTE: For the steps listed on the next page, you’ll need your Wi-Fi network name (SSID) and password.
Make sure your mobile device is connected to the same Wi-Fi network.

04
Adding & Connecting Your Station to Wi-Fi
LA CROSSE VIEW
Checking Your Station’s Wi-Fi Status
Press the SET button on the top of the station to view your Wi-Fi Status.
Having Trouble Connecting to Wi-Fi?
The app should guide you through the best method for your Wi-Fi network and router. However, if you
have trouble connecting, please go to: bit.ly/v15_wifi or scan the QR code. This will explain additional
connectivity options, including connecting by WPS or contacting our technical support team for
further assistance.
ALL OK CONNECTED: Your station is connected to your
Wi-Fi and its data should be available on the station and
in the app.
SEE APP TO CONNECT: Check the app for notifications.
NO WEATHER SERVICE: Your Internet weather and time
services are not connecting. These should resolve on their
own, please be patient.
LOST WIFI: Check your router and network connections.
The La Crosse View app is required to connect the station to your Wi-Fi network. Download, install,
and log into your La Crosse View account first.
New User Initial Setup: When first setting up your
station, the app will lead you through a series of
instructions to help get your station added into your
account and connected to your home Wi-Fi network.
Manually Add & Connect Display: After the initial walkthrough,
stations can be added and connected via the Devices tab in the
app’s main menu. Simply tap the Add Device or +button at the
bottom of the Devices page in the app.
1.
Follow the initial app instructions or manually add the display into your account.2.
Next, the app will prompt you to use your phone to scan the device ID barcode located on the back of
the station. Please note, adding a device to your account and connecting it to Wi-Fi are two dierent
steps. You can complete either step separately after if you have any trouble.
When connected, the station will beep, and time and forecast information should populate on the
display. The indicator will become solid.
3.
4.

Add Your Sensors to the App
LA CROSSE VIEW
05
123456-ABC
* This step is only required if you do not receive the Add Device notification within the app.
Prior to mounting/positioning your sensor, make sure your station is receiving sensor data.
Upon getting the station connected to your Wi-Fi network, the app will
explain how your connected sensor should be brought in. Within the
next 15 minutes, you should receive an Add Device notification in your
app. This is indicated by the Red Cloud and the numbers inside of it.
Tap this icon to begin adding your sensor into the app.
1.
Manually Add Your Sensor to the App*
3.
4.
2.
Open your La Crosse View app. On the Main Menu, scroll to
ADD/EDIT and select DEVICES.
Scan the Barcode on your Sensor or type in the Device ID
manually.
Confirm the sensor image and Device ID and add a Device
Name and Location Name. Select DONE.
On the Devices page, select the ADD DEVICE or PLUS (+) button.
123456-ABC
Back of Sensor

Station Settings
BASICS
When the station is first powered on, it will begin searching for the sensor, which should
connect within 10 minutes.
06
Settings Menu Order
• Greeting/HELLO
• Language (English/Spanish/French/German)
• Beep ON/OFF
• 12/24 Hour Time Format
• Hour | Minute | Year | Month | Date
• Calendar Order Month/Date or Date/Month
• Temperature Units (Fahrenheit/Celsius)
• Pressure Units (InHg/hPa)
• Pressure Number Setting
The default pressure reading is 29.91 INHg (1013 hPa).
The station will acclimate on it’s own if the pressure
number is not set. Learn more on page 16
• THANK YOU
Important: Settings such as language and units of measure must
be set manually within the station’s Settings Menu. These are not
controlled by the La Crosse View app.
The language selected will aect menu instructions as well as
weekday and month readouts.
Weekday will set automatically after year, month, and date
settings are adjusted.
When in 24 hour time format, seconds will show in place of
AM/PM markings.
If you’re connected to Wi-Fi, the time/date will automatically
update from the Internet. See pages 3-4 for more info.
Navigating the Settings Menu
To manually set language, time/date, and other
settings, hold the SET button to enter the
Settings Menu.
1.
Use the +/- buttons on the top of the station to
adjust the values.
2.
Press the SET button to confirm your selection
and move to the next setting.
3.
You may exit the Settings Menu at any time by
pressing the button on the front of the station.
4.

Buttons
BASICS
07
1. ALERTS: Hold to enter alerts setting. Use +/-
buttons to turn alerts on/o.
3. EXTRA SENSOR: Press to view sensor ID
numbers. Hold to add sensors. While viewing,
hold the MINUS button delete the sensor.
2. TEMP: Press to view Temp. & Humidity History.
While viewing, hold MINUS button to reset the
history reading.
4. SET: Press to view Wi-Fi status. Hold to enter
Settings Menu.
5. PLUS/MINUS (+/-): Use to adjust values.
7. FORECAST REFRESH*: Press to refresh
Forecast Readings.
9. BACKLIGHT ( ): Press to adjust backlight.
Hold to enter Auto-Dim settings.
6. IN/OUT: Press to view switch between Indoor
Outdoor Temperature/Humidity display or
autoscroll
8. FORECAST/PRECIP. ( )*: Press to change
Forecast Times. Hold to select Percent of
Precipitation or Amount of Precipitation reading.
10. WIFI: Press during initial setup for Wi-Fi
Connection. Hold to re-enter Configuration
Mode and clear previous Wi-Fi settings.
* Your display must be connected to Wi-Fi to receive Daily/Hourly forecast information.
Front of Station Back of Station

08
LCD Display Brightness
The Auto-Dim Icon ( ) will appear on the LCD when the Auto-Dim feature is activated.
BASICS
Please Note: Only the hour can be set.
Auto-Dim Settings
Program your display to automatically
dim during preselected times.
Adjusting the LCD Display Brightness
Press the button to adjust the backlight
intensity. There are 4 brightness levels,
plus an o option.
1. Hold the button to enter the
Auto-Dim Settings Menu.
2. Press the +/- buttons to turn the
Auto-Dim feature on or o.
Press to confirm.
3. Press the +/- buttons to adjust the
starting hour. Press to confirm.
4. Press the +/- buttons to adjust the
stopping hour. Press to confirm
and exit.

Viewing Current Conditions
TEMPERATURE & HUMIDITY
09
Your indoor/outdoor temperature & humidity readings
share the same section on the LCD.
Press the IN/OUT button on the top of the station to
switch between Indoor & Outdoor readings, or select
the Auto-Scroll option to alternate between readings.
Accessing Indoor/Outdoor Readings
Indoor Data Example
Indicated by house icon in top left
Outdoor Data Example
Indicated by tree icon in top right
Programming the Auto-Scroll Option
Press the IN/OUT button until AUTOSCROLL
TEMP DATA appears on the LCD.
To deactivate the Auto-Scroll option, press the
IN/OUT button until the Auto-Scroll Icon ( )
disappears. The station will stay on your
current selection.
The Auto-Scroll icon ( ) located in the bottom
left corner will appear when active.

Viewing Current Conditions
TEMPERATURE & HUMIDITY
10
1. INDOOR ICON ( )
5. OUTDOOR ICON ( )
2. TEMPERATURE ALERT ICONS
6. AUTO-SCROLL ICON ( )
3. INDOOR OR OUTDOOR TEMPERATURE
7. LOW BATTERY INDICATOR ( )
9. SENSOR RECEPTION INDICATOR ( )
4. INDOOR OR OUTDOOR HUMIDITY
8. HUMIDITY ALERT ICONS
Indicates you are viewing indoor temperature
and humidity
Indicates you are viewing outdoor temperature
and humidity
Indicates an active high ( ) or low ( )
temperature alert
Icon will appear when auto-scroll is active
Current indoor or outdoor temperature
(based on setting)
Indicates the batteries in the thermo-hygro
sensor should be replaced soon
Indicates if the station is receiving data from the thermo-hygro sensor
Current indoor or outdoor humidity
(based on setting)
Indicates an active high ( ) or low ( )
humidity alert
Current Conditions Section Close-Up

11
Viewing Current Conditions
TEMPERATURE & HUMIDITY
Resetting Individual Records
Records Viewing Order
Press the TEMP. button to view the
individual values you’d like to reset.
Next, hold the MINUS (-) button until
dashes appear on the LCD. This reading
is now reset to your current temperature
or humidity value.
•Outdoor High Temperature
•Outdoor Low Temperature
•Outdoor High Humidity
•Outdoor Low Humidity
•Indoor High Temperature
•Indoor Low Temperature
•Indoor High Humidity
•Indoor Low Humidity
•Heat Index
•Dew Point
Press the TEMP. button to toggle through indoor/
outdoor temperature and humidity records with time
and date stamps.
Viewing Records
Outdoor Low Temperature Record Example Heat Index Example

12
Customizable Alerts
TEMPERATURE & HUMIDITY
1.
2.
3.
Hold the ALERTS button to enter the
Alert Settings Menu.
Use the +/- buttons to activate/deactivate
individual alerts, or press the ALERTS
button to skip to the next alert option.
Once activated, use the +/- buttons to
adjust the alert value. Press the ALERTS
button to confirm and move forward.
Setting Custom Alerts
Outdoor High Humidity Alert LCD Example
Alerts Setting Order
Outdoor High Temperature •Outdoor Low Temperature •Outdoor High Humidity •Outdoor Low Humidity
Indoor High Temperature •Indoor Low Temperature •Indoor High Humidity •Indoor Low Humidity
Activating/Deactivating Alerts
1.
2.
Hold the ALERTS button to enter alert settings.
Use the +/- buttons to activate/deactivate alerts.
Active alerts are indicated by the and / icons in
the Current Conditions section on the screen.
Note: The default setting for
alerts is OFF.
Alerts Sounds
•If the alert sounds and you do not see a flashing
alert icon, press the IN/OUT button to view the
other reading.
•When an alert value is reached, the station will
beep 5 times each minute until the value moves
out of the alert range.
•Press any button to stop the alert sound.
•Alerts set on the station are separate from
those created within the app.

13
Viewing Your Forecast Data
* Your display must be connected to Wi-Fi to receive AccuWeather forecast data.
** When connected, your station will display 6 additional forecast icons.
*** Refreshing the forecast may result in the same readings if they are current.
FORECAST
You can view up to 6 days of forecasts and 12 hours of forecast data. The default display will
show your current and following 2 days of forecasts, detailing weather conditions, chance of
precipitation, and high/low temperature predictions.
1. INTERNET ICON ( )
5. FORECAST ICONS
2. CHANCE OF PRECIPITATION
6. FORECAST REFRESH ICON ( )
3. DAILY FORECASTED HIGH TEMPERATURE
7. EXTENDED FORECAST SECTION
4. DAILY FORECASTED LOW TEMPERATURE
Indicates the station is connected and receiving
AccuWeather forecasts*
Predicts weather conditions in the next 12 hours**
Percent chance of precipitation*
Hold button to view amount of precipitation*
Press the FORECAST REFRESH button to
refresh the 3-day forecast. The icon will cycle
for 30 seconds***
Forecasted daily high temperature*
Forecast icons and daily forecasted highs and lows for the next 2 days
Press the button to view additional 3-day and 12-hour forecast information
Forecasted daily low temperature*
Forecast Section Close-Up

FORECAST
14
Viewing Your Forecast Data
Extended Forecast Examples
Forecast When not Connected Day/Night Forecast
When station is not connected, you’ll see current
temperature and humidity, as well as daily high/low
temperature and humidity records from your sensor.
Forecast icons will only appear in the circular area.
When connected, the sun icon will show in daylight
hours and the moon icon will show during nighttime
hours if the forecast is for sunny or partly sunny.
•The times the sun and moon icons appear are
pre-programmed and cannot be adjusted.
•The station must be connected Wi-Fi to
activate the day/night forecast feature.
Forecast data for upcoming 4-6 days Forecast data for next, 2nd, and 3rd hours Forecast data for upcoming 4th, 5th, and 6th hours
Sun Icon (7:00am to 6:59pm) Moon Icon (7:00pm to 6:59am)
Press the button to view the next 3 days and next
12 hours forecast.
Viewing Extended Forecast

15
Viewing Your Forecast Data
Please Note: The Forecast Icons may not represent your current weather. They are a future prediction of
the weather to come over the next 12 hours.
When connected to Wi-Fi, the station will receive additional weather icons, chance of precipitation values,
and future forecast information. These enhanced Internet features are powered by AccuWeather.
Additional forecast scenes include:
Tip: The icon will appear in the top right corner of the forecast section when your display is
connected and receiving AccuWeather forecasts.
When using as a standalone station, the display will use changes in barometric pressure to predict your
weather to come in the next 12 hours. These will be represented by the following 6 forecast scenes:
Forecast Icons
Secondary Forecast Icons | The following icons appear in the extended forecast section:
Sunny Rain SnowClouds Light
Snow
IcePartly
Sunny
T-Storms WindLight
Rain
Wintry
Mix
Fog
Sunny
Light Rain
Rain
Wind
Partly Sunny
Light Snow
T-Storms
Ice
Clouds
Wintry Mix
Snow
Fog
FORECAST

16
Relative Pressure
Low Battery Indicators
Note: The default pressure reading is 29.91 InHg (1013 hPa). The station will acclimate on its own if the pressure number is not set.
•Your Relative Pressure reading will come
from your station’s internal barometer.
•Please allow up to 10 days for automatic
calibration, or program your local pressure
value in the Settings Menu.
•The green arrows located above the values
represent Pressure Tendency.
•If a blue low battery indicator appears in the forecast/
circular section, replace batteries in the TH sensor. You’ll
only see this icon if you’re not connected to the app.
•If a light green low battery indicator appears in the
extra sensor section, replace batteries in the extra sensor.
•If an green low battery indicator appears in the outdoor
temperature section, replace batteries in the TH sensor.
•If a white low battery indicator appears next to the time
display, replace the coin cell battery in the station.
•Select your desired unit of measurement (InHg or hPa) in the Settings Menu.
You can also set a specific pressure number setting if desired.
Pressure Tendency Arrows
BASICS
FORECAST

17
SENSORS
• Use the hole at the top to hang your sensor from the back using a
nail. Or, insert one mounting screw through the front of your sensor.
• Mount your sensor on a north-facing wall or in any shaded area.
Under an eave or deck rail is preferred to avoid inaccurate
readings from the sun.
• The maximum wireless transmission range to the station is up to
400 feet (121 meters) in open air, not including walls or floors.
• Be sure your sensor is mounted vertically, to allow moisture to
drain out properly.
Sensor Placement & Mounting
Adding Sensors to Your Station
3. Your sensor should connect within the next 3
minutes, briefly displaying its ID and type on the
LCD. The Sensor Reception Indicator will show
solid on the screen when a sensor is connected.
1. Hold the EXTRA SENSOR button until the
Sensor Reception Indicator starts to animate.
2. Install batteries into your sensor. If the sensor
has a TX button, press it to force a transmission
signal. This button is usually located in or near
the sensor’s battery compartment. The LED light
on the sensor will flash once.
bit.ly/v15_parts
Find all of your add-on
sensor options by scanning
the QR code or visiting:
SENSORION SENSOR: This thermo-
hygro sensor features a sensorion chip,
providing improved temperature &
humidity readings, unrivaled accuracy
tolerances, and faster data transfer.
Add-On Sensors
Whether you choose to connect to the La Crosse View app or not, this
station can display data for up to 4 extra sensors. This data will appear
in the light green section on the LCD and in your La Crosse View app
if connected.
Note: When first powering up, or after a factory reset, extra sensors should automatically connect to your station.
Viewing Add-On Sensor Data
If you have multiple add-on sensors connected,
press the EXTRA SENSOR button to cycle through
the data you’d like displayed on the LCD. The Auto
Scroll Icon ( ) will appear if activated. This setting
will also include relative pressure data in the cycle.
^Water Leak Sensor Example

18
APPENDIX
Care & Maintenance
Battery Replacement Instructions
When batteries of dierent brand or type are used together,
or new and old batteries are used together, some batteries
may be over-discharged due to a dierence of voltage or
capacity. This can result in venting, leakage, and rupture and
may cause personal injury.
•Always purchase the correct size and grade of battery
most suitable for the intended use.
•Always replace the whole set of batteries at one time,
taking care not to mix old and new ones, or batteries of
dierent types.
•Clean the battery contacts and also those of the device
prior to battery installation.
•Ensure the batteries are installed correctly with regard to
polarity (+ and -).
•Remove batteries from product during periods of non-use.
Battery leakage can cause corrosion and damage to this
product.
•Remove used batteries promptly.
•For recycling and disposal of batteries, and to protect the
environment, please check the internet or your local phone
directory for local recycling centers and/or follow local
government regulations.
Replace the Coin Cell Battery
1. Use a coin to turn the battery cover to the left to remove it.
2. Pull back the metal pin and gently remove thebattery.
3. Insert a fresh CR2032 battery with the +side up and snap
into place.
4. Replace the battery cover and use the coin to turn it to the
right to lock.
The manufacturer is not responsible for any radio or TV
interference caused by unauthorized changes or modifications
to this equipment. Such changes or modifications could void
the user authority to operate the equipment.
All rights reserved. This manual may not be reproduced
in any form, even in part, or duplicated or processed using
electronic, mechanical or chemical process without the written
permission of the publisher.
This booklet may contain errors or misprints. The information
it contains is regularly checked and corrections are included
in subsequent editions. We disclaim any responsibility for any
technical error or printing error, or their consequences.
All trademarks and patents are recognized.
Caution!
WARNING: KEEP BATTERIES OUT OF REACH OF CHILDREN
Swallowing may lead to serious injury in as little as 2 hours or death,
due to chemical burns and potential perforation of the esophagus.
If you suspect your child has swallowed or inserted a button battery,
immediately seek urgent medical assistance.
Examine devices and make sure the battery compartment is correctly
secured, e.g. that the screw or other mechanical fastener is tightened.
Do not use if compartment is not secure.
Dispose of used button batteries immediately and safely. Flat batteries
can still be dangerous.
Tell others about the risk associated with button batteries and
how to keep their children safe.
WARNING
This product contains a button battery.
If swallowed, it could cause severe injury or death in just 2 hours.
Seek medical attention immediately.
1.
2.
3.
4.
5.
6.
1.
2.
3.
California Residents
WARNING: This product can expose you to chemicals
including styrene, which is known in the State of
California to cause cancer. For more information, go to:
www.P65Warnings.ca.gov

19
Warranty
La Crosse Technology, Ltd. provides a 1-year
limited time warranty (from date of purchase) on
this product, relating to manufacturing defects in
materials and workmanship.
For full warranty details, visit:
www.lacrossetechnology.com/support
La Crosse Technology, Ltd.
2830 S. 26th Street, La Crosse, Wisconsin 54601
APPENDIX
Recycling & Disposal
Please consider the environment when deciding
to dispose of this product. Although household
electronics are generally safe to use on a daily
basis, incorrect disposal can cause negative and
potentially irreversible impacts on our environment.
Check with local donation centers to see if your
product can be donated for future use. If disposal is
the only option, federal agencies, local governments,
and certified retailers may have electronic recycling
programs in place. Programs may vary based on
location.
Please Recycle
Specifications
Wi-Fi NETWORK REQUIREMENTS
• Broadcast Frequency: 2.4GHz (802.11 b/g/n)
• Network Name/Password: Must Not Exceed 45
Characters
• Network Speed: Must Be Greater than 1 Mbps
Note: If you have multiple band router, this device will
connect to the 2.4GHz band when connecting to Wi-Fi.
STATION SPECIFICATIONS (V15)
• Indoor Temperature Range: 32°F to 122°F
(0°C to 50°C)
• Indoor Humidity Range: 10 to 99%RH
• Relative Pressure Range: 23.62 to 32.48 InHg
(800 to 1100 hPa)
• Power Requirements:
• Primary Power: 5.0V Adapter (included)
•Battery Backup: 1 “CR2032” Coin Cell Battery
(included)
• Station Dimensions: 6.50 in. L x 1.09 in. W x 6.81 in. H
(16.5 cm L x 2.78 cm W x 17.3 cm H)
• LCD Brightness: 4 Intensity Levels + OFF
(Programmable Auto-Dim Backlight Option)
• Language Options: English, Spanish, French, and
German (Translation Available for Menus & Calendar)
SENSOR SPECIFICATIONS (LTV-TH5i)
• Outdoor Temperature Range: -40°F to 140°F
(-40°C to 60°C)
• Outdoor Humidity Range: 10 to 99%RH
• Transmission Range: 400 feet (121 Meters) open air
• Update Interval: Every 51 Seconds
• Power Requirements: 2 “AA” Batteries (not included)
• Sensor Dimensions: 1.97 in. L x 0.75 in. W x 5.73 in. H
(5.0 cm L x 1.91 cm W x 14.55 cm H)
MOBILE REQUIREMENTS
• Apple phones require iOS with cellular or Wi-Fi service.
• Android phones require Android OS with cellular or
Wi-Fi service.
