La Crosse Technology WS-9410TWC User manual

Humidity level
bar graph
Indoor temperature
in ºF
Indoor comfort
indicator icon
Indoor relative
humidity in %
Low battery icon
TEMPERATURE STATION
1. Insert finger or other solid object in the space at the right
center of the battery compartment and lift up to remove
the cover.
INTRODUCTION:
Congratulations on purchasing this temperature station with indoor temperature, humidity and comfort
indicator. To enjoy the full benefits of this innovative product, please read this operating manual
completely before operating. 2. Insert batteries observing the correct polarity (see
marking).
3. Replace battery compartment cover.
TEMPERATURE STATION:
TO RESET THE TEMPERATURE STATION:
1. Remove the batteries from the Temperature Station
2. Wait at least 30 seconds and repeat the procedures in Setting up above
BATTERY CHANGE:
It is recommended to replace the batteries in all units on an annual basis to ensure optimum accuracy of
this unit.
Please participate in the preservation of the environment. Return used batteries to an
authorized depot.
FUNCTION KEYS:
FEATURES: The weather station has 1 key function that is easy to use:
• Indoor temperature display in degree Fahrenheit (°F)
• Indoor humidity display in RH% MIN/MAX key:
• Indoor temperature and humidity display with MIN/MAX recordings • Toggle between MIN/MAX indoor temperature
• Relative humidity level bar • Toggle between MIN/MAX indoor humidity data
• Indoor comfort indicator icon • Reset MIN/MAX records by pressing and holding the key for 2 seconds
• Low battery indicator
LCD SCREEN
• Wall mounting or table standing
The Temperature Station’s LCD is divided into 3 sections, displaying humidity level in a bar graph format,
indoor humidity and indoor temperature.
SETTING UP:
Please follow these steps to ensure that your new temperature station works correctly:
1. Insert the batteries into the temperature station. See “How to install and replace batteries in the
Temperature Station” below.
2. Once the batteries are in place, all segments of the LCD will light up briefly. Then the indoor
temperature, humidity and level bar will be displayed. If the indoor temperature is not displayed
after a few seconds, remove the batteries and wait for at least 30 seconds before reinserting them.
HOW TO INSTALL AND REPLACE BATTERIES IN THE WEATHER STATION:
The temperature station uses 2 x AAA, 1.5V batteries. To install and replace the batteries, please follow
the steps below:
Hanging hole
Battery
compartment
Foldable stand
MIN/MAX key
LCD
display

USING THE TEMPERATURE STATION TO TOGGLE BETWEEN THE MIN/MAX INDOOR TEMPERATURE:
THE HUMIDITY LEVEL BAR: 1. Press the “MIN/MAX” key. The MAX indoor temperature will be displayed
2. Press the “MIN/MAX” key a second time. The MIN indoor temperature will be displayed.Located above the temperature/humidity display, it shows the indoor relative humidity level. The range is
from 16% to 98%, and each bar corresponds to 2% of relative humidity. It automatically changes
accordingly to the indoor humidity display.
4. Press the “MIN/MAX” key a third time. The MAX indoor humidity with humidity level bar will be
displayed.
5. Press the “MIN/MAX” key a fourth time. The MIN indoor humidity with humidity level bar will be
displayed.
INDOOR RELATIVE HUMIDITY:
6. Press again the “MIN/MAX” key to return to normal display mode.
The indoor relative humidity is displayed on the second line of the LCD under the humidity level bar. The
Temperature Station’ built in sensor automatically measures the surrounding indoor humidity level once
the batteries are inserted.
Note: If no key is pressed for about 16 seconds, the display will automatically return to normal mode
display
THE COMFORT LEVEL INDICATORS: RESETTING THE MIN/MAX TEMPERATURE AND HUMIDITY RECORDINGS:
Comfortable: A happy face icon “☺” indicating a temperature level between 68.0°F and 78.6°F and
humidity between 45% and 65%. During the MIN/MAX temperature and humidity record display, pressing the “MIN/MAX” key for 2 seconds
will reset the displayed records to the current data.
Uncomfortable: A sad face icon “” indicating any value outside the comfortable range.
POSITIONING THE TEMPERATURE STATION:
INDOOR TEMPERATURE: The Temperature Station comes complete with a foldable stand that gives the option of table standing or
wall mounting.
The indoor temperature is displayed on the last line of the LCD under indoor comfort icon and MIN/MAX
icons. The indoor temperature is automatically displayed once the batteries are inserted.
To wall mount:
MINIMUM AND MAXIMUM INDOOR TEMPERATURE AND HUMIDITY RECORDINGS: 1. Fix a screw into the desired wall, leaving the head extended out by about
5mm.
By pressing the “MIN/MAX” key the current indoor temperature will alternate between the maximum and
minimum records. Once a new indoor temperature and humidity high or low is reached, it will
automatically set into the Temperature Station’s memory.
2. Using the Temperature Station’s hanging hole, carefully hang it onto the
screw.
Note: Always ensures that the unit locks onto the screw head before releasing.
To table stand:
Unfold the Temperature Station’s stand located at the back of the unit
MIN icon
MIN icon
Indoor humidity
display in RH% MAX icon
Relative humidity
level bar
Indoor temperature
display in ºC
MAX icon

CARE AND MAINTENANCE:
• Avoid placing the unit in areas prone to vibration and shock as these may cause damage.
• Avoid areas where the unit can be exposed to sudden changes in temperature, i.e. direct sunlight,
extreme cold and wet/moist conditions as these will lead to rapid changes in temperature which
reduces the accuracy of readings.
• When cleaning the LCD and casing, use a soft damp cloth only. Do not use solvents or scouring
agents.
• Do not submerge the unit into water.
• Immediately remove all low powered batteries to avoid leakage and damage.
Replace only with new batteries of the recommended size.
• Do not make any repairs to the unit. Please return it to the original point of purchase for repair by a
qualified engineer. Opening and tampering with the unit may invalidate its guarantee.
SPECIFICATIONS:
Indoor temperature measuring range: 14.2°to 122°F with 0.2ºF resolution
(“OF.LºF” displayed if outside this range)
Indoor humidity measuring range : 1% to 99% with 3 digits display resolution
(“- - . -%” displayed if outside this range)
Indoor temperature and humidity checking intervals: every 8 seconds
Power source : 2 x AAA, 1.5V batteries
Battery life : Approximately 12 months (Alkaline batteries recommended)
Dimensions (L x W x H) : 6” x 5.5” x 0.65” (152.2 x 141.2 x 17 mm)
LIABILITY DISCLAIMER:
• The manufacturer and supplier cannot accept any responsibility for any incorrect readings and any
consequences that occur should an inaccurate reading take place.
• This product is designed for use in the home only as indication of the temperature.
• This product is not to be used for medical purposes or for public information.
• The specifications of this product may change without prior notice.
• This product is not a toy. Keep out of the reach of children.
• No part of this manual may be reproduced without written authorization of the manufacturer.
WARRANTY INFORMATION:
La Crosse Technology provides a 1-year warranty on this temperature station. Contact La Crosse
Technology immediately upon discovery of any defects covered by this warranty.
Before sending the temperature station in for repairs, contact La Crosse Technology. The temperature
station will be repaired or replaced with the same or similar model.
This warranty does not cover any defects resulting from improper use, unauthorized repairs, faulty
batteries, or the temperature stations inability to receive a signal due to any source of interference.
LA CROSSE TECHNOLOGY WILL NOT ASSUME LIABILITY FOR INCIDENTAL, CONSEQUENTIAL,
PUNITIVE, OR OTHER SIMILAR DAMAGES ASSOCIATED WITH THE OPERATION OR
MALFUNCTION OF THIS TEMPERATURE STATION. THIS PRODUCT IS NOT TO BE USED FOR
MEDICAL PURPOSES OR FOR PUBLIC INFORMATION. THIS PRODUCT IS NOT A TOY. KEEP OUT
OF CHILDRE’S REACH.
This warranty gives you specific legal rights. You may also have other rights specific to your State.
Some States do no allow the exclusion of consequential or incidental damages therefore the above
exclusion of limitation may not apply to you.
For warranty work, technical support, or information contact
La Crosse Technology
190 Main Street
La Crescent, MN 55947
Phone: [phone]
Fax: [phone]
e-mail:
[e-mail]
(warranty work)
[e-mail]
(information on other products)
web:
www.lacrossetechnology.com
All rights reserved. This handbook must not be reproduced in any form, even in excerpts, or duplicated or
processed using electronic, mechanical or chemical procedures without written permission of the
publisher.
This handbook may contain mistakes and printing errors. The information in this handbook is regularly
checked and corrections made in the next issue. We accept no liability for technical mistakes or printing
errors, or their consequences.
All trademarks and patents are acknowledged.
