La Crosse Technology WW85777v2 Operating and maintenance manual

Wireless Weather Forecast Station with Colored LCD Display
Welcome!
--------------
Congratulations on your new Color Forecast Station and welcome to the
La Crosse Technology family! This product was designed with you in mind by our
hometown team of weather enthusiasts based in La Crosse, Wisconsin.
Instructional Manual
Model: WW85777v2
DC: 040219
Wireless Forecast Station
with Colored LCD Display

Page | 2
Wireless Weather Forecast Station with Colored LCD Display
Table of Contents
Step 1: Power Up
Step 2: Mounting Basics
Step 3: Set Time, Date, etc.
Setting Menu
Your Weather Station Features
Atomic Time
Backlight HI-LOW-OFF
Set Temperature Alerts
Arm/Disarm Alerts
Time Alarm
Deactivate/Activate Alarm
Snooze
Forecast
Forecast Trend Arrows
Temperature Trend Arrows
Humidity Trend Arrows
LO/HI Temperatures
Heat Index/Dew Point Temperature
Channel Selection
Using Multiple Sensors
Sensor Search
Low Battery
Restart
Help Us, Help You!
Let’s Be Social!
Care and Maintenance
Warranty and Support
Specifications
FCC Statement
Canada Statement
3
3
3
4
5
6
6
7
7
8
8
8
9
9
9
9
10
10
11
11
11
11
11
12
12
12
12
13
14
14

Page | 3
Wireless Weather Forecast Station with Colored LCD Display
Insert batteries (in any order):
• 2-AA batteries into thermo-hygro sensor
• 5 volt power cord (required) into WW85777v2 station
*3-AAA batteries for optional backup of your time and date
STEP 1: Power Up
STEP 2: Mounting Basics
At this time, all of your sensor information should be displayed on your station.
Here are a few quick tips for mounting your sensor:
• Keep out of direct sunlight & ensure the sensor is well-ventilated.
• We recommend mounting under a deck or eave facing north.
• Insert the mounting screw through the front of the sensor and into the wall.
• Tighten the screw to snug (do not over tighten).
• Be sure the outdoor sensor is mounted vertically to drain moisture.
• The maximum wireless transmission range is over 330 feet (100 meters) in open air, not including walls or
floors.
AAA
AAA
AAA
AA
AA
AA
AA
AC 5.0V
You can manually adjust your station’s settings:
1. Hold the SET button for 3 seconds to enter settings menu.
2. Press and release the + or - buttons to adjust the flashing values. Hold to adjust quickly.
3. Press and release the SET button to confirm and move to the next item.
Note: Press and release the LIGHT button any time to exit settings
STEP 3: Set Time, Date, etc.

Page | 4
Wireless Weather Forecast Station with Colored LCD Display
To begin: Hold the SET button 2 seconds, then release, to enter the settings menu:
1. BEEP ON | OFF
2. Atomic ON | OFF
3. Time Zone
Set Time Zone
to your area
for the hours
to be correct.
4. DST ON | OFF
6. Hour | 7. Minutes
5. 12Hour | 24 Hour
8. Year 9. Month 10. Date
11. Fahrenheit | Celsius
12. English | Español
Settings Menu
Settings order:
1. Beep ON/OFF
2. Atomic ON/OFF
3. Time Zone
4. DST Indicator
5. 12/24 Hour Time Format
6. Hour
7. Minutes,
8. Year
9. Month
10. Date
11. Fahrenheit/Celsius
12. Language English |
Español
AST
EST
CST
MST
PST
AKT
HAT
Atlantic
Eastern
Central
Mountain
Pacific
Alaskan
Hawaiian
Time Zones
Note: When Atomic OFF is selected, you will move next to 12/24 hour time.
Note: The weekday will set automatically as the year, month, and date are set.

Page | 5
Wireless Weather Forecast Station with Colored LCD Display
Your Weather Station Features
Channel Indicator
Outdoor Temperature
Sensor Reception Icon
Outdoor Temperature HI Alert
Temperature Trend Indicator
Outdoor Temperature LO Alert
Outdoor Humidity
Humidity Trend Arrow
Humidity Comfort Level
9
8
7
6
5
4
3
2
1
9
8
7
6
5
4
3
2
1
9
8
7
6
5
4
3
2
1
9
8
7
6
5
4
3
2
1
Forecast Icons
Forecast Trend Arrow
AM | PM
Atomic Reception Tower
Alarm | Snooze
Atomic Time
Weekday
Month
Date

Page | 6
Wireless Weather Forecast Station with Colored LCD Display
Indoor Temperature
Humidity LO Alert
Indoor Temperature HI Alert
Temperature Trend Indicator
Indoor Temperature LO Alert
Indoor Humidity
Humidity Trend Arrow
Humidity Comfort Level
8
7
6
5
4
3
2
1
8
7
6
5
4
2
1
3
• From normal time display, press and release the SET button to search for the WWVB time signal.
• Please be sure you have selected your time zone from the list in the Settings menu. When the Atomic time
signal is received, the station will set to the time zone selected. Default is Eastern Time.
• For information about WWVB visit: http://bit.ly/AtomicTime
Atomic Time
Backlight (HI-LOW-OFF)
• When operating with the power cable, the backlight is adjustable: HI-LOW-OFF.
• Press and release SNOOZE/BACKLIGHT to adjust backlight.
• When operating on batteries only, the backlight will come on briefly when the SNOOZE/BACKLIGHT button
is pressed.

Page | 7
Wireless Weather Forecast Station with Colored LCD Display
Set Temperature Alerts
1. Hold 2 seconds, then release the ALERTS button to enter alert set mode.
2. Outdoor HI TEMP will flash OFF or ON.
3. Press and release the +/- buttons to select ON. (If disarmed (OFF) skip the alert value and move to next
alert)
4. Press and release ALERTS button and alarm value will flash.
2. Press and release the +/- buttons to adjust values.
3. Press and release the ALERTS button to confirm adjustments and move to the next item.
Alert setting order:
• Outdoor Temp HI
• Outdoor Temp LO
• Outdoor Hum HI
• Outdoor Hum LO
• Indoor Temp HI
• Indoor Temp LO
• Indoor Hum HI
• Indoor Hum LO
Use the +/- buttons to adjust value.
Press ALERTS button to continue.
Default is OFF
+/- button-ON
Alert button-Value ashes
Default (OFF) Default (OFF) Turn ON with +/- buttons
Note: When no HI or LO Temperature Alert is set, OFF will show.
Arm/Disarm Temperature Alerts
• Hold 2 seconds, then release the ALERTS button to view High and Low alerts flashing.
• Press the PLUS button to arm an alert.
• Press the MINUS button to disarm an alert.

Page | 8
Wireless Weather Forecast Station with Colored LCD Display
Alarm Time
The alarm will be active when alarm time is set.
1. Hold the ALARM button for 3 seconds to enter alarm settings.
2. The HOUR will show.
3. Press the +/-buttons to adjust.
4. Press ALARM to confirm and move to the minutes
5. The MINUTES will show.
6. Press the +/- buttons to adjust.
7. Press ALARM to confirm and exit settings.
Alarm Hour
Deactivate/Activate Alarm
• The alarm is active when set.
• Press and release the ALARM button to view alarm time. Then press and release the ALARM button to
deactivate or activate the alarm.
• The alarm icon (bell) will show when active.
Alarm Minutes
• When the alarm sounds, press the SNOOZE/BACKLIGHT button to silence the alarm for 10 minutes.
• The snooze icon Zz will flash.
• Press any button except SNOOZE/BACKLIGHT to silence the alarm for 24 hours.
Snooze

Page | 9
Wireless Weather Forecast Station with Colored LCD Display
Temperature Trend Arrows
Humidity Trend Arrows
• The temperature (2°F / 1°C) trend indicators update every 30 minutes.
• 3 hrs. increments which changes on every ½ hour e.g.: At 3:00 — compares to 12:00 data;
at 3:30 — compares to 12:30, etc.
• The humidity (3% RH) trend indicators update
every 30 minutes or less.
Forecast Trend Arrows
Falling: Weather will worsen
Rising: Weather will improve
Steady: No change
Rising
Scrolls Right
Falling
Scrolls Left
Steady
No Scroll
Forecast
1. The weather station oers these 6 forecast icons based on barometric pressure.
2. When the forecast would normally be Rain or T-Storm and the outdoor temperature is below 32°F, the
forecast will show Snow.
3. Wind indicators will show on T-Storm and Snow forecast.
SUNNY PARTLY SUNNY CLOUDY RAIN T-STORM SNOW
FORECAST FORECAST FORECAST FORECAST FORECAST FORECAST

Page | 10
Wireless Weather Forecast Station with Colored LCD Display
Heat Index / Dew Point
• Press the TEMP button to toggle between Heat Index and Dew Point. Each feature will display for 10
seconds then return to default display if the button is not pressed again.
Tip: If you are using multiple sensors, press the PLUS button to select the channel before pressing the TEMP
button to view Heat Index for that sensor.
• The forecast station automatically resets the HI/LO temperatures at midnight (12:00 AM).
• Press and release the MINUS button to toggle through the LO and HI temperature and humidity readings.
LO/HI Temperatures
2. Press MINUS again to view the Outdoor HI
temperature/humidity records.
3. Press MINUS again to view the Indoor LO
temperature/humidity records.
4. Press MINUS again to view the Indoor HI
temperature/humidity records.
1. Press the MINUS button once to view Outdoor
LO temperature/humidity records.
