Lab.gruppen Lake LM 26 User manual

Lake® LM 26
Digital Audio Loudspeaker Processor
Rev 1.1.8
Item: OM-LM26
Operation Manual

Important Safety Instructions
i
LM 26 Operation Manual rev 1.1.8
1. Important Safety Instructions
Before using the device, be sure to carefully read the Safety Instructions. Keep this document with the device at all times.
1.1 Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in accordance
with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including ampliers)
that produce heat.
9. Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades with
one wider than the other. A grounding-type plug has two
blades and a third grounding prong. The wide blade or
the third prong is provided for your safety. If the provided
plug does not t into your outlet, consult an electrician for
replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched,
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
11. Only use attachments/accessories specied by the
manufacturer.
12. Use only with a cart, stand, tripod, bracket, or table specied
by the manufacturer, or sold with the apparatus. When a
cart is used, use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when
unused for long periods of time.
14. Refer all servicing to qualied service personnel. Servicing
is required when the apparatus has been damaged in any
way, such as power-supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
15. Use the mains plug to disconnect the apparatus from the
mains.
16. WARNING: To reduce the risk of re of electric shock, do not
expose this apparatus to rain or moisture.
17. Do not expose this equipment to dripping or splashing and
ensure that no objects lled with liquids, such as vases, are
placed on the equipment.
18. The mains plug of the power supply cord shall remain readily
operable.
19. Do not connect the unit’s output to any other voltage source,
such as battery, mains source, or power supply, regardless
of whether the unit is turned on or off.
20. Do not remove the top (or bottom) cover. Removal of the
cover will expose hazardous voltages. There are no user
serviceable parts inside and removal may void the warranty.
21. An experienced user shall always supervise this professional
audio equipment, especially if inexperienced adults or
minors are using the equipment.
22. The US National Differences clause 16.3 requires that
network cables must be ame rated VW-1.
To prevent electric shock do not remove top or bottom covers.
No user serviceable parts inside, refer servicing to qualied
service personnel.
À prévenir le choc électrique n’enlevez pas les couvercles. Il n’y a
pas des parties serviceable à l’intérieur, tous reparations doit etre
faire par personnel qualié seulment.
To completely disconnect this equipment from the AC mains,
disconnect the power supply cord plug from the AC receptacle.
The mains plug of the power supply cord shall remain readily
operable.
Pour démonter complètement l’équipement de l’alimentation
générale, démonter le câble d’alimentation de son réceptacle. La
prise d’alimentation restera aisément fonctionnelle.
1.2 Standards
This equipment conforms to the require-
ments of the EMC Directive 2004/108/EC
and the requirements of the Low Voltage
Directive 2006/95/EC.
Standards applied: EMC Emission
EN55103-1, E3
EMC Immunity EN55103-2, E3, with S/N
below 1% at normal operation level.
Electrical Safety EN60065, Class I
This equipment is tested and listed accord-
ing to the U.S. safety standard ANSI/ UL
60065 and Canadian safety standard CSA
C22.2 NO. 60065. Intertek made the tests
and they are a Nationally Recognized Test-
ing Laboratory (NRTL).
1.3 Explanation of Graphical Symbols
The lightning bolt triangle is used to alert the user to
the presence of un-insulated “dangerous voltages”
within the unit’s chassis that may be of sufcient
magnitude to constitute a risk of electric shock to
humans.
The exclamation point triangle is used to alert the
user to presence of important operating and service
instructions in the literature accompanying the
product.

ii
Important Safety Instructions
LM 26 Operation Manual rev 1.1.8
1.4 WARNING
To reduce risk of re or electric shock, do not expose this apparatus to rain or moisture.
Pour réduire les risques de blessure ou le choc électrique, n’exposez pas l’appareil à la pluie ou à l’humidité.
Do not expose this system/apparatus to dripping or splashing and ensure that no objects lled with liquids, such
as vases, are placed on the apparatus.
L’appareil ne doit pas être exposé à des egouttements d’eau ou des éclaboussures et de plus qu’aucun objet
rempli de liquide tel que des vases ne doit pas être placé sur l’appareil.
This apparatus must be connected to a mains socket outlet with a protective earthing connection.
Cet appareil doi t être raccordé á une prise de courant qui est branchée à la terre.
The mains plug is used as a disconnect device and shall remain readily operable.
Lorsque la prise du réseau d’alimentation est utilisés comme dispositif de déconnexion, ce dispositif doit
demeuré aisément accessible.
1.5 CAUTION
To reduce the risk of re or electric shock, do not remove screws. No user-serviceable parts inside.
Refer servicing to qualied service personnel.
Pour réduire le risque d’incendie ou de choc électrique, ne pas retirer les vis. Aucune pièce réparable par
l’utilisateur. Coner l’entretien àpersonnel qualié.
1.6 FCC Compliance Notice (Radio Interference)
A sample of this product has been tested and complies with the limits for the European Electro Magnetic
Compatibility (EMC) directive. This equipment has also been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference from electrical equipment. This product uses radio frequency energy
and if not used or installed in accordance with these operating instructions, may cause interference to other
equipment, such as radio receivers.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by turning the
equipment on and off, the user is encouraged to try to correct the interference by one or more of the
following measures:
▸Reorient or relocate the antenna.
▸Increase the separation between the equipment and receiver.
▸Connect the equipment to an outlet on a circuit different from that to which the receiver is connected.

Important Safety Instructions
iii
LM 26 Operation Manual rev 1.1.8
▸Check if the affected unit complies with the EMC limits for immunity, (CE-labeled). If not, address the
problem with the manufacturer or supplier. All electrical products sold in the EC must be approved for
immunity against electromagnetic elds, high voltage ashes, and radio interference.
▸Consult the dealer or an experienced radio/TV technician for help.
1.7 User Responsibility
1.7.1 Mains Connection Grounding
Your apparatus must be connected to a grounded socket outlet.
1.7.2 Maintenance
For safe and reliable operation, the dust lter on the right-hand side air intake should be removed and
cleaned regularly to ensure maximum airow through the device.
If the dust lter is not maintained there will be safety risks; for example, high internal temperatures
could ignite the dust start a re. There is also a risk that the unit will malfunction since it is dependent on
constant airow from left to right. If the dust lter is not clean and the unit malfunctions, any resulting
problems will not be covered by the warranty.

iv
LM 26 Operation Manual rev 1.1.8
Table of Contents
1. Important Safety Instructions ................................................................................................................i
1.1 Important Safety Instructions ............................................................................................................... i
1.2 Standards .............................................................................................................................................. i
1.3 Explanation of Graphical Symbols ......................................................................................................... i
1.4 WARNING ............................................................................................................................................ ii
1.5 CAUTION ............................................................................................................................................. ii
1.6 FCC Compliance Notice (Radio Interference) ....................................................................................... ii
1.7 User Responsibility ..............................................................................................................................iii
2. Welcome ...................................................................................................................................................1
2.1 Introduction .........................................................................................................................................1
2.2 Main Features ......................................................................................................................................1
2.3 Additional Documentation ....................................................................................................................2
3. Installation ................................................................................................................................................3
3.1 Unpacking ............................................................................................................................................3
3.2 Mounting ..............................................................................................................................................3
3.3 Cooling ................................................................................................................................................. 3
3.4 Operating Voltage ................................................................................................................................4
3.5 Grounding .............................................................................................................................................4
4. Product Overview ....................................................................................................................................5
4.1 Front Panel Overview ........................................................................................................................... 5
4.2 Back Panel Overview ...........................................................................................................................7
5. Signal Flow and Lake Processing ........................................................................................................10
5.1 Signal Flow ........................................................................................................................................ 10
5.2 Lake Processing and Control .............................................................................................................. 11
5.3 Modules and Frames ........................................................................................................................ 11
5.4 Loudspeaker Crossover Conguration Overview ............................................................................... 12
5.5 Files and Presets ................................................................................................................................ 12
6. Front Panel Interface ............................................................................................................................. 14
6.1 Overview ............................................................................................................................................ 14
6.2 Front Panel Key Lock .......................................................................................................................... 15
6.3 Power Button .................................................................................................................................. 15
6.4 Meter Button ..................................................................................................................................... 15
6.5 Menu Button ...................................................................................................................................... 16
6.6 Exit Button ........................................................................................................................................ 16
6.7 Dynamic Buttons, Controls and LEDs ................................................................................................ 16
6.8 Module I/O Mute Buttons and LED Meters ....................................................................................... 19
6.9 Meter Mode .......................................................................................................................................20
6.10 Menu Mode .......................................................................................................................................21

v
LM 26 Operation Manual rev 1.1.8
7. Back Panel Interface ..............................................................................................................................38
7.1 Analog Inputs and Outputs ................................................................................................................38
7.2 AES3 Digital I/O ................................................................................................................................40
7.3 RJ45 etherCON® Network Connections ............................................................................................42
7.4 GPIO Connection ...............................................................................................................................43
7.5 Universal Power Supply Connection .................................................................................................44
8. Appendix .................................................................................................................................................45
8.1 Faults and Warnings Overview ..........................................................................................................45
8.2 Maintenance ......................................................................................................................................46
8.3 Factory Default Settings.....................................................................................................................46
8.4 Glossary of Terms, Acronyms and Abbreviations .............................................................................. 47
9. Application Guide ..................................................................................................................................50
9.1 Gain Structure ....................................................................................................................................50
9.2 Gain / Level Optimization ................................................................................................................... 51
9.3 Digital Audio Connections .................................................................................................................. 51
9.4 Digital Clock Conguration .................................................................................................................53
10. Technical Specications .......................................................................................................................56
11. Warranty and Support ..........................................................................................................................57
11.1 General ..............................................................................................................................................57
11.2 International Warranties .....................................................................................................................57
11.3 Technical Assistance and Service ......................................................................................................57
11.4 Trademarks .........................................................................................................................................58

Welcome
1
LM 26 Operation Manual rev 1.1.8
2. Welcome
2.1 Introduction
Thank you for choosing the Lake LM 26. We are condent that you will be pleased with the performance,
unique features, conguration exibility, reliability, and long-term durability offered by this product.
For fast installation and use of this product, your welcome package includes a printed copy of the LM 26
Quick Start and Field Reference Guide which contains the information required to safely install the product
and place it in service. Control and editing features are accessible via the front panel interface or via the
included Lake Controller software.
It is recommend that the Quick Start Guide and all product documentation on the included CD-ROM is
reviewed to ensure familiarity with the various conguration and control options.
Thank you again for placing your condence in Lake products.
2.2 Main Features
The Lake LM 26 incorporates a number of sophisticated technologies to ensure the best possible perfor-
mance and many years of reliable operation. The following section summarizes the benets of each feature;
additional information is available in the reference manuals.
2.2.1 Lake Processing and Controller
The Lake LM 26 integrates seamlessly into the Lake Processing environment. Two processing modules
offer precise settings for gain, delay, crossover settings, equalization and limiting. Lake processing features
incorporated in each module include Raised Cosine Equalization™, linear phase crossovers, and LimiterMax™
loudspeaker protection. The Super Module feature allows hardware processing modules in two or more
separate devices to function as a single module in the Lake Controller software. Please refer to the
Lake Controller Operation Manual for further information.
2.2.2 Lake Analyzer Bridge
Lake Controller software provides integration with third-party real-time analyzers, providing simultaneous
measurement display and EQ adjustment via the Lake Controller.
The third-party measurement tools that can be integrated via the Analyzer Bridge include:
▸Smaart Live Version 5.4
▸Live-Capture Light / Live-Capture Pro

2
Welcome
LM 26 Operation Manual rev 1.1.8
Smaart, distributed and supported by Rational Acoustics, provides real-time sound system measurement,
optimization and control. Smaart combines several powerful audio frequency measurement and analysis
tools.
Live-Capture, created by WaveCapture, offers easy-to-use software and measurement tools for sound
engineers, installers, consultants and designers. The Lake Analyzer Bridge in conjunction with Live-Capture
Light provides a completely free spectrum analyzer via your Lake Controller software interface.
2.2.3 Dante™ Audio Network
The Lake LM 26 includes Dante digital audio networking as standard. Utilizing the latest advances in Eth-
ernet technology, Dante offers simplied system conguration and extremely low latency while delivering
very high quality uncompressed digital audio across the Lake network. The Zen™ automatic conguration
feature enables plug-and-play setup without third-party DHCP or DNS servers. Dante is compatible with
high-bandwidth networks, allowing large numbers of audio channels to be distributed alongside control and
analyzer data.
2.3 Additional Documentation
This document, the Lake LM 26 Operation Manual, serves as the primary reference source for detailed
information on the installation and operation of the Lake LM 26. It also provides detailed information on
set-up and conguration using the front-panel interface.
If you intend to use the device as part of a networked system, or access features via the Lake Controller,
please refer to the various supporting documents which can be located via these methods:
▸Start > Programs > Lake Controller > Documentation (after installing Lake Controller software)
▸On the Installer CD-ROM or the downloaded software installer
▸Online at: http://labgruppen.com/index.php/products/documentation/

Installation
3
LM 26 Operation Manual rev 1.1.8
3. Installation
3.1 Unpacking
Carefully open the shipping carton and check for any damage to the device or the supplied accessories.
Every Lake product is tested and inspected before leaving the factory and should arrive in perfect condition.
If any damage is discovered, please notify the shipping company immediately. Only the consignee may
initiate a claim with the carrier or their insurers for damage incurred during shipping. Save the carton and
packing materials for the carrier’s inspection.
In addition to the Lake LM 26, the shipping carton include the following items:
▸Lake LM 26 Quick Start and Field Reference Guide
▸AC mains lead (IEC power cable) with locking connector
▸AES break-out cable (4-in, 8-out)
▸Software Installer and Documentation CD-ROM
Please keep the original carton and associated packaging to facilitate shipping of the device should the need
arise.
3.2 Mounting
Airow for cooling the LM 26 is from side to side (right-side intake to left-side fan). Please ensure there is
sufcient space each side of the unit to allow airow; the space provided by standard rack-rails should be
sufcient. This device has no top or bottom vents and therefore may be stacked directly on top of each
other.
Sufcient space should be available at the front of the rack to accommodate the handles, and at the rear to
accommodate connectors and cables; allowance must be made for cable or loom bends within a rack.
3.3 Cooling
The Lake LM 26 uses a forced-air cooling system, with airow from right to left. The dust lter on the air
intake (right-side) should be regularly cleaned, especially after exposure to dusty environments, to ensure
the maximum possible airow through the unit.
The LM 26 is designed to operate in situations where the ambient temperature is below 55 oC (131 oF ).
Automatic actions and warnings occur at following temperature thresholds:
▸At 40 oC (104 oF )or less, the fan is OFF
▸At more than 40 oC (104 oF ) the fan is ON

4
Installation
LM 26 Operation Manual rev 1.1.8
▸At 55 oC (131 oF ) a temperature warning is indicated on the front panel as ‘TEMP WARNING’ and in the
Controller Event Log as ‘Temp warning: DSP area’.
▸At 70 oC (158 oF ) the LM 26 has exceeded the maximum normal operating temperature. This fault is
indicated on the front panel as ‘OVERTEMP’ and in the Controller Event Log as ‘Temp fault: DSP area’.
The Processor will NOT mute or shut down when the
temperature reaches or exceeds 70 oC (158 oF), however,
sustained performance at this temperature cannot be
guaranteed.
3.4 Operating Voltage
The label above the GPIO connector, and to the left of the mains (AC) connector indicates the AC mains
voltage range for which the LM 26 is approved.
The LM 26 utilizes a universal power supply, and will operate within the range 70-265V~50-60Hz : 30W. If
the plug on the IEC cable provided is not appropriate for your country, a locally-sourced IEC cable with the
appropriate molded plug should be used.
Once a suitable AC power supply is connected, the device can be turned on using the front panel power
button. When turned on, a diagnostic routine is performed and the power button LED changes from red
(Standby) to green (Active).
3.5 Grounding
Analog inputs and outputs feature Iso-Float™ ground isolation, a technology which combines the benets of
transformer-coupled isolation with the advantages of clean, direct-coupled inputs and outputs.
The audio converters are galvanically isolated, and not connected to the main ground. High-speed transform-
ers and opto-isolators create a barrier between the device and the outside electrical environment.
The Iso-Float feature is activated by default, but
may be disabled via the Lake Controller software,
or via the front panel menu.
Use correctly-shielded balanced audio input connections to minimise hum and interference. Please refer to
section 7.1.5 for further information.
NEVER disconnect the earth (ground) pin on the mains cable (AC power cord).

Product Overview
5
LM 26 Operation Manual rev 1.1.8
4. Product Overview
This chapter provides and overview of key features and functionality. For further information please see
chapters to 9 of this Operation Manual.
4.1 Front Panel Overview
Figure 4-1: LM 26 Front Panel Overview
The front panel controls are clustered around a daylight readable LCD , allowing adjustment and monitor-
ing of the majority parameters and meters. The two clusters of controls on either side of the LCD include
three dedicated function buttons , six dynamic function buttons with embedded LEDs and
a rotary data encoder . To the right of these controls are dedicated module input and output mute
buttons and level meters.
Handles
Two sturdy metal handles are tted to the front panel. The handles should be used when carrying the
device, and when tting it in or removing it from a rack. Ensure that any door or removable rack front cover
has sufcient depth to clear the handles.
Standby
The LM 26 is powered on and to standby using the left-most button, or via the Lake Controller.
All audio in and out of the processor is muted
when in Standby mode. Network communication
remains active to allow the LM 26 to be turned on
via the Lake Controller.

6
Product Overview
LM 26 Operation Manual rev 1.1.8
Display
The display illuminates when the device is on. The LCD, function buttons, and the rotary encoder provide
real-time control and monitoring of most parameters. The LEDs embedded in the function buttons indicate
available menu options, provide conrmation of Controller communication, and indicate various faults and
warnings.
The brightness and contrast of the display and front panel LEDs can be adjusted via the front panel menu.
Please refer to chapter 6 for further details.
Meter
The METER button toggles between two alternative meter views: Home View and I/O Status. Pressing
METER from Menu Mode returns the screen to Meter Mode with Home View displayed. Please refer to
section 6.4 for further details.
Menu
After pressing the MENU button, the LCD will display the top level menu. In Menu Mode the function
buttons enable access to various information and functions. Please refer to section 6.5 for further details.
Exit
The EXIT button is used primarily while navigating the menu system in Menu Mode; pressing EXIT will
return the menu up one level. In Meter Mode, pressing EXIT returns the metering display to the default
Home View.
Dynamic Function Buttons with LEDs (Left of LCD)
The function of these buttons change according to the currently selected view or menu.
The left LED in the top button illuminates white to indicate the Frame is selected in the Lake Controller, or
ashes white to indicate communication from the Lake Controller. If this button is pressed while in Home
View, and with the Lake Controller on the Home page or the Modules Menu, then Module A of the selected
frame will be highlighted in the Controller.
The three LEDs on the right side of each button illuminate white when an associated option is available on
the LCD screen.
Please refer to chapter 6 for further details.

Product Overview
7
LM 26 Operation Manual rev 1.1.8
Dynamic Function Buttons with LEDs (Right of LCD)
The function of these buttons change according to the currently selected view or menu.
The right bi-color LED in the top button illuminates red or yellow to indicate faults or warnings. If this button
is pressed while in Home View, and with the Lake Controller on the Home page or the Modules Menu, then
Module B of the selected frame will be highlighted in the Controller.
The three LEDs on the left side of each button illuminate white when an associated option is available on
the LCD screen.
Please refer to chapter 6 for further details.
Rotary Encoder
The rotary encoder is used to modify various parameters (e.g. input level) via the menu. When a menu item
is selected that permits adjustment of parameter values, the ring around the rotary encoder illuminates. In
Home View the encoder can be used to scroll through the Meter Views.
Input Mutes and Meters
Independent mute buttons and ve-segment LED meters are provided for the inputs to Module A & B. The
associated meters provide signal, pre-clip and clip conditions. The embedded LEDs conrm if the Module
input is muted (red), unmuted (white), or unused (not illuminated). The button can be used to mute/unmute
the inputs as required. Please refer to section 6.7 for further information.
Dedicated Output Mute Buttons and LED Meters
Independent mute buttons and ve-segment LED meters are provided for Outputs 1 > 6. The embedded
LEDs conrm if the Module output is muted (red), unmuted (white), or unused (not illuminated). The bottom
three segments (green) indicate signal; the 4th segment (yellow) indicates signal 2 dB below clipping; the
5th segment (red) indicates signal clipping. Please refer to section 6.7 for further information.
4.2 Back Panel Overview
Figure 4-2: LM 26 Back Panel Layout

8
Product Overview
LM 26 Operation Manual rev 1.1.8
Analog Outputs
Six analog outputs are provided via standard XLR3M connections. The outputs are electronically balanced
and feature Lake Iso-Float circuitry. The output impedance is 50 ohms, providing a maximum output level of
+21 dBu. Please refer to section 7.1 for further information.
Analog Inputs
Two analog inputs are provided via standard XLR3F latching connectors. The inputs are electronically
balanced and feature Lake Iso-Float circuitry. The impedance is 20 kOhms (balanced), and the inputs can
accept a maximum input level of +26 dBu. Please refer to section 7.1 for further information.
AES3 I/O
AES inputs and outputs are provided via a 25-pin DB25 connector. Inputs can be received on AES1 (Ch.1,2)
and AES2 (Ch.3,4). Outputs are via AES1 (Ch.1,2), AES2 (Ch.3,4), AES3 (Ch.5,6) and AES4 (Ch.7,8). Please
refer to section 7.2 for further information.
The sample rates available for AES3 inputs and outputs are 44.1, 48, 88.2, 96, 176.4, 192 kHz.
Primary Network Connector
The primary Neutrik RJ45 etherCON® connection provides integration into an Ethernet control network
which may include other Lake Processors and the Lake Controller software. Network connection permits full
control of all functions along with real-time metering from a remote position. This device supports the Dante
audio networking protocol, which allows transmission of multichannel, high-denition digital audio over the
same Ethernet connection.
Use the primary connector when using a star network topology, consisting of individual Cat-5e connections
between the devices and an Ethernet switch. Alternatively this connection can be used to daisy chain
directly to another Lake Processor. The daisy chain topology should not be used with Dante.
For a technical reference of the Ethernet Port, please refer to section 7.3. Additional information is available
in the Lake Network Conguration Guide.
The Ethernet ports automatically switch to operate at Ethernet data
rates of 100 Mbps or 1000 Mbps, and allow straight or crossed
network cables. Two LEDs above each port indicate valid network
connection (LINK) and network activity (ACT).

Product Overview
9
LM 26 Operation Manual rev 1.1.8
Secondary Connector
The secondary network connector can be used to daisy-chain multiple PLM Series, LM 26 and legacy Lake
devices. Alternatively, a dual-network topology can be created by connecting all secondary network connec-
tors to a separate Ethernet switch, ensuring full redundancy in the event of a network component failure.
Additional processor conguration is required for a
dual redundant network setup. See the Lake
Controller Operation Manual for further details.
For a technical reference of the Ethernet Port, please refer to section 7.3. Additional information is available
in the Lake Network Conguration Guide.
When connecting multiple devices to an Ethernet
network, care must be taken NOT to create a
closed loop which causes network malfunction.
GPIO Connector
A 9-pin GPIO (General Purpose Input Output) connection is provided to enable integration with external
systems such as alarm/re systems, providing basic control of power state, mute along with fault notica-
tion to an external monitoring system. Please refer to sections 6.10.4.4 and 7.4 for further details.
Mains Power Connector
A universal power supply capable of accepting 70-265 V ~ 50-60 Hz : 30 W is built into the LM 26. The IEC
power cable provided includes a locking feature via a pin on the bottom of the connector; the connector can
accept standard or locking IEC power cables.
The power supply must be connected to AC mains using a power cable with a correctly wired plug for the
country of operation.

10
Signal Flow and Lake Processing
LM 26 Operation Manual rev 1.1.8
5. Signal Flow and Lake Processing
5.1 Signal Flow
Figure 5-1 depicts the audio signal ow inside an LM 26. It is worth noting that this sophisticated device
provides ve points in the signal chain where the signal level can be adjusted, muted or disconnected.
Important information regarding correct setting of the gain structure can be found in section 9.1.
Figure 5-1: Signal Flow Diagram (LM 26)
5.1.1 Level Adjustments & Mute Points
Input Router Stage - Input selection and MUTE
Input Mixer Stage - Router ON/OFF connection to mixer and gain settings
Module Input Stage - Mute and gain settings
Module Output Stage - Mute and gain settings
Output Router Stage - Output ON/OFF routing connections

Signal Flow and Lake Processing
11
LM 26 Operation Manual rev 1.1.8
Input routers 1-4 provide all ve stages of functionality via the front panel interface or the Lake Controller.
The pass-thru input routers 5&6 allow stage 1 input selection only (MUTE is unavailable), along with stage 5
output ON/OFF routing connections.
If the required audio signal is not passing correctly,
verify the connection, mute and volume settings at
all ve stages.
5.2 Lake Processing and Control
As outlined in section 2.2.1, this device integrates seamlessly into the Lake Processing environment,
providing all features, functionality and connectivity associated with all Lake Processors. The internal Lake
Processing includes programmable crossovers, EQ, dynamics and other functions, and can be fully con-
trolled via the supplied Lake Controller software. Additionally, many functions can be controlled or accessed
directly via the front panel.
The Lake Controller Operation Manual and Lake Network Conguration Guide are supplied on the accompa-
nying CD ROM and additional documentation is available from the Start Menu after software installation.
5.3 Modules and Frames
5.3.1 Overview
A Frame represents one physical Lake Processor (e.g. a PLM or LM 26). A maximum of two Modules are
contained within each Frame; these are referred to as Module A and Module B. The number of Modules
shown in a given Frame is dependent upon the signal processing conguration of that Frame.
Each Module can be congured as a Classic Crossover (Bessel, Butterworth, Linkwitz-Riley), as a Linear
Phase Crossover, or as multiple full bandwidth Auxiliary Outputs. The default conguration for the LM 26 is
2 x Classic 3-Way Modules, providing a total of six module outputs.
Please refer to the Lake Controller Operation Manual for further information.
5.3.2 Super Modules
Super Modules allow control of multiple Modules of the same type, distributed across multiple Frames, as
a single entity within the Lake Controller software. A change made in the Super Module is replicated across
all assigned Modules, resulting in improved efciency in system conguration and a reduction of on-screen
icons within the Lake Controller software.

12
Signal Flow and Lake Processing
LM 26 Operation Manual rev 1.1.8
The key benet of this feature is the ability to connect and control crossovers, levels and EQ across multiple
hardware devices simultaneously from the Lake Controller. For example, one device may be driving sub and
low-frequency speakers, while another device controls mid-range and hi-frequency drivers. Using a single
adjustment the crossover points between the two devices can be changed simultaneously.
Please refer to the Lake Controller Operation Manual for further information regarding Super Modules.
5.4 Loudspeaker Crossover Conguration Overview
The Lake Processing system within LM 26 devices may be congured with up to two inputs and up to
six Module outputs. Each set of processing elements is referred to as a Module and can be congured as
crossovers, full-bandwidth auxiliary outputs, or a combination of the two. The relationship between inputs
and outputs is dened via the Lake Controller or via the front panel I/O CONFIG Menu.
The Lake Processing system provides two distinct categories of crossovers:
▸Innite Impulse Response lters (IIR) such as the classic Bessel, Butterworth or Linkwitz-Riley types;
these are available with slopes ranging from 6 dB/octave to 48 dB/octave.
▸Finite Impulse Response lters (FIR) providing zero phase shift with steep transition slopes at the
crossover frequencies. These are also referred to as Linear Phase Crossovers.
Further details on these types of crossovers and information on conguring various module types can be
found in the Lake Controller Operation Manual.
5.5 Files and Presets
The Lake system provides various methods for storing and recalling Module, Frame, or system-wide data. A
overview is provided below; for further information please refer to the Lake Controller Operation Manual.
5.5.1 Module, System and Sub-System Conguration Files
Module, System and Sub-System Conguration les are stored on the Lake Controller PC, and data is
passed across the network when recalling or storing these type of les.
▸A Module le is the smallest set of data that can be stored and recalled; it contains crossover, gain,
delay, and limiter information for an individual loudspeaker. A Module le may be recalled into other
Lake devices. It is not possible to store a Module File directly on the hardware device.
▸A System or Sub-System Conguration File contains a set of Module le information in addition to
Frame related information such as I/O routing, along with Group control information.

Signal Flow and Lake Processing
13
LM 26 Operation Manual rev 1.1.8
5.5.2 Frame and System Presets
This device allows the complete processor conguration to be stored as a Frame Preset on the
hardware unit itself. Presets can be recalled via the front panel (please refer section 6.10.6) to or via the
Lake Controller software (please refer to the Lake Controller Operation Manual.
A maximum of 100 Frame Presets can be stored on this device. The data within a Frame Preset includes the
congurations of both Modules in the Frame, including all levels, crossover, EQ, input mixer, output routing,
and all other Module, Frame and Group parameters. As Frame Presets are stored in the device, complete
processor congurations may be recalled without the need to connect the device to a PC.
Using the System Presets function in the Lake Controller, entire system congurations can be stored and
recalled across a network of LM 26, PLM, Mesa Quad EQ, Contour Pro 26, and Dolby Lake Processors. This
enables fast retrieval and switching of entire system congurations as minimal data is being sent between
the Controller and Processors.

14
Front Panel Interface
LM 26 Operation Manual rev 1.1.8
6. Front Panel Interface
An overview of the front panel interface is provided in section 4.1. This chapter describes each cluster of
controls as shown in Figure 6-1.
Figure 6-1: Front Panel Interface
6.1 Overview
The majority of LM 26 functions can be controlled and monitored via LCD display screen , function
buttons , rotary encoder and the dedicated Module input and Module output mute
buttons and metering LEDs.
The front panel has two basic modes: Meter Mode and Menu Mode.
▸Meter Mode provides two views: Home View (default). To toggle these views, press the METER
button. Please refer to section 6.9 for further information on Meter Mode.
▸Menu Mode provides various menus for viewing and editing parameters and is selected by pressing the
MENU button. Select the required submenu by pressing the associated button. Please refer to section
6.10 for further information on Menu Mode.
6.1.1 Warning, Fault and Mute Indications
Fault or warning conditions are indicated via the tricolor LEDs embedded in the dynamic function buttons; a
simultaneous description is shown adjacent to the button, on the LCD.
A full list, description and priority of the fault and warning indications is provided in section .
6.1.2 Highlighting a Module in the Lake Controller software via the LM 26
It is sometimes useful to identify which Module icon/s in the Lake Controller software are associated with a
particular hardware Frame. To highlight the module in the Lake Controller software:
