Sparkfree Refrigerator RLPR0217/0517/1517 Operating Instructions
Operating instructions for your
Labcold
Sparkfree Refrigerator
RLPR0217/0517/1517
IMPORTANT: These operating instructions contain information essential to the
safe and reliable operation of your refrigerator. Failure to use your refrigerator in
accordance with these instructions may invalidate your warranty.
PLEASE RETAIN AND KEEP IN A SAFE PLACE FOR FUTURE REFERENCE
Contents
Before use ...............................................................................................................1
A closer look ......................................................................................................2
Fitting the handle.................................................................2
Plug in & switch on..............................................................................................3
Front panel display..............................................................................................3
Alarms........................................................................................................................4
Door Lock ................................................................................................................4
Caring for your fridge............................................................................................5
Defrosting.....................................................................................................................6
Trouble Shooting .................................................................................................7
Useful Information..............................................................................................8
Loading.....................................................................................5
Cleaning .......................................................................................5
Original Instructions - Version 3 05.2020
WEEE: Disposal at end of life.
This equipment, when being disposed of in an EU Member State,is subject to the Waste Electrical and
Electronic Equipment Regulations (WEEE)and must be recycled and disposed of in accordance with EU
directive 2002/96/EC asapplied in local laws of that State at the time of disposal. This refrigerator contains
ammable insulation gases and must be disposed of in the appropriate way by competent persons. Ensure
that none of the refrigerant circuit pipes are damaged prior to disposal.
The symbol below on the appliance or accompanying documents indicates that this refrigerator should
not be treated as ordinary waste but must be taken to a special collection centre for the recycling of
electrical equipment. For more information regarding the treatment, recovery or recycling of this product,
contact your competent local oce, electrical waste disposal or vendor from whom you purchased the
refrigerator.
As this item is designed for medical or scientic use, before presenting for collection and disposal it will
be necessary for the user to provide documentary evidence of decontamination and/or that it is entirely
safe to handle and dismantle outside of a controlled environment. Goods that cannot be so certied fall
outside the scope of the Directive and remain the user’s responsibility to dispose of.
WARNING!
This refrigerator contain a ammable gas
MUST NOT be located in a room or area with a volume less than 10m3
This refrigerator contains gas under pressure which may explode if heated
WARNING!
Servicing should ONLY be carried out by a suitably qualied engineer and only engineers who
have been trained in the safe handling and use of hydrocarbon refrigerants should work on the
refrigeration system
If the power supply cord is damaged, it MUST be replaced by the manufacturer, its service
agent or similarly qualied persons in order to avoid a hazard
Do not use mechanical or other means to accelerate the defrosting process. Keep clear of
obstruction all ventilation openings in the appliance enclosure.
This refrigerator is climate
class 4 and is designed to operate at +16°C to +32°C ambient room temperature
Do not damage the refrigerant circuit
If you suspect a leak contact the manufacturer or its service agents immediately.
Do not touch the refrigerant, it can cause severe eye irritation, redness, tearing, blurred
vision, and possible freeze burns. Contact with evaporating liquid may also cause frostbite or
freezing of the skin.
Do not use electrical appliances inside the freezer
Maximum load on shelves and draws is 10Kg/m2
The noise level in normal operation is lower than 70dB
Labcold Sparkfree refrigerators RLPR0217/0517/1517 are designed for storing volatile
substances in a professional environment and to be used by adults only
Please note this refrigerator is not explosion proof.
Do not store explosive substances such as aerosol cans with ammable propellant in this
appliance. Do not store open containers of volatile substances this is misuse and could
lead to explosions.
1
Before Use
2
A Closer Look
Fitting the handle (if required)
Door lock
Adjustable
Feet
Handle
Adjustable
shelves
Maximum load
10kg
Front Panel Display
Drain
Serial Plate
inside fridge
by door hinge
Access Port
To attach the
handle, simply
screw to the unit
using the screws
provided.
WARNING! Failure to t the handle may result in damage to the door gasket
Thank you for purchasing a Labcold RLPR0217/0517/1517 Sparkfree Refrigerator. Your fridge has
been purpose designed and precision built for the safe storage of ammable materials with all
possible sources of ignition removed from the inside of the fridge.
Although great care has been taken in the manufacture of your fridge, damage can occur
in transit. Before using for the rst time please remove all packaging and give your fridge a
thorough visual inspection. If any damage is suspected, please contact your retailer immediately
upon receipt of the product. Failure to do this may invalidate your warranty.
Setting Up
Place your refrigerator in the location in which it is to be used allowing adequate ventilation for
the dissipation of any vapours from the cabinet.
We recommend to avoid injury and damage to
the refrigerator that at least two people are involved with the siting of the fridge. Do not tip
more than 45 when moving in to position.
WARNING
Keep clear of obstruction all ventilation openings in the appliance enclosure
Do not place your fridge near a direct heat source or direct sunlight and leave at least 6cm all
round the unit for adequate ventilation. Failure to do so may eect the performance of your
refrigerator.
Clean your fridge with mild soapy water to remove any dust that may have accumulated during
manufacture and dry thoroughly.
YOUR REFRIGERATOR SHOULD NOW BE LEFT FOR AT LEAST TWO HOURS BEFORE
CONNECTING TO POWER FOR THE FIRST TIME
WARNING!
Do not store open containers of volatile substances
this is misuse and could lead to dangerous situations.
Ensure your refrigerator is level by adjusting the feet at the bottom of
the unit. Failure to do so may mean that it rocks during operation and
the self close door does not operate correctly.
Please note this fridge is not explosion proof.
Do not store explosive substances such as aerosol cans with ammable propellant in this
appliance.
WARNING
Do not use electrical appliances inside the storage
compartments of the fridge
3
Plug in & Switch on
Before plugging in your Labcold fridge for the rst time make sure the power cable is free from
damage and check that your voltage corresponds to that on the serial plate.
It is recommended that you do not use extension cords or multiple socket adapters. Make sure
the power cable is not bent, pinched or compressed and that it can be easily accessed.
If necessary push the button for 3 seconds to start the fridge.
ALTHOUGH THE FRIDGE WILL REACH 5oC AFTER A FEW HOURS (APPROX) YOU SHOULD
LEAVE THE FRIDGE RUNNING FOR 24 HOURS BEFORE FILLING WITH TEMPERATURE
SENSITIVE PRODUCTS.
Front Panel Display
Manual Defrost
button with defrost
LED
Press to view the
set point
Air temperature
inside the freezer
Your fridge is preset to 5°C so you do not have to program the set point. To check the set point,
simply press the button.
If the compressor LED is on it simply means the compressor is running. This is a normal part
of operation especially after door openings. If the manual defrost LED is on the fridge is
performing a short defrost and if the LED is red, the fridge is either in standby mode or is
o. In either of these states it will not be cooling. Press and hold the o/on button to restart
the refrigerator.
THE REFRIGERATOR HAS A PRE PROGRAMED SET POINT OF 5°C
ONLY A LABCOLD ENGINEER CAN CHANGE THE SET POINT.
If necessary push the button for 3 seconds to start the fridge.
O/On button
Compressor LED
simply press the button.
performing a short defrost and if the LED is red, the fridge is either in standby mode or is
4
Alarms
Door Open Alarm
Your fridge will emit a loud beep and ash Id if the door is left open for approximately 4
minutes. To mute the alarm, press any button on the controller. The display will still ash Id
until the door is closed.
Door Lock
Your Labcold sparkfree laboratory fridge is tted with a door lock and you are provided with
2 keys.
KEYS SHOULD NOT BE LEFT IN THE LOCK AS THEY PROTRUDE FROM THE FRIDGE. THEY
COULD CAUSE A HEALTH AND SAFETY HAZARD OR COULD BE KNOCKED, WHICH MAY
DAMAGE THE LOCK.
To open this lock push the key in
gently and turn the key 90oto the
right. To lock, turn the keys 90o
to the left. The key can safely be
removed from both the locked and
unlocked positions.
High and Low Temperature Alarms
Your refrigerator has been set up to alarm if the temperature goes below -1°C or above 12°C.
As with the door alarm it will make a beeping sound and if the temperature is below -1°C the
display will flash AL and if the temperature exceeds 12°C it will beep and flash AH.
To mute the alarm, press any button on the controller.
WE RECOMMEND ANY TEMPERATURE ALARM IS INVESTIGATED AND THAT YOU
CONTACT THE SERVICE TEAM ON 01256 570 580 IF THE ALARM CONTINUES FOR
ANY LENGTH OF TIME.
5 6
Defrosting
Your refrigerator features an automatic o cycle defrost and should remain frost free as part
of normal operation. However, ice may occur in times of high humidity, if the door has been
opened frequently or left open for a long time, if it is overstocked or the ambient temperature
is high or low.
IT IS ESSENTIAL THAT THE CONTENTS OF THE FRIDGE SHOULD BE REMOVED AND
STORED AND MONITORED AT THE CORRECT TEMPERATURE BEFORE ATTEMPTING
DEFROSTING
For a short defrost you should:
• Press the button for 3 seconds which will activate the defrost program. This will
terminate automatically when the pre-programmed defrost temperature has been
reached.
For a thorough defrost you should:
• Remove all the contents and unplug or disconnect the fridge from the electricity supply
• Leave the unit unplugged with the door open at room temperature until all the ice is
melted
• Collect water in tray or with towel
• Do not use a sharp implement to remove any ice, as this will damage the inside of the
fridge
• Do not use mechanical, electric or chemical means to speed up the defrosting process
• Dry thoroughly and remove any surplus water before returning to use
• Plug in and leave cooling and wait for the temperature to return to the set point and the
unit to maintain the correct temperature before re-stocking the fridge
WARNING
Do not use mechanical or other means to accelerate the defrosting process
Press the button for 3 seconds which will activate the defrost program. This will
5
As with all refrigerators, your Labcold sparkfree fridge, although designed to provide you with
many years of fault free service, will perform better if attention is paid to the loading and that
it is regularly cleaned and defrosted.
Loading
In order to ensure even temperature distribution throughout your fridge it is important that:
• The shelves are not over lled
• The contents are not packed too closely together
• The maximum loading of the shelves is 10kg, do not overload
• The contents do not touch the wall or the bottom of the fridge
• After restocking the fridge, check the temperature 10 minutes later to ensure that the
refrigerator is cooling down, running satisfactorily and is not over lled.
Cleaning
It is recommended that your refrigerator is cleaned on a regular basis.
Before cleaning it is essential that you unplug the fridge from the electricity
supply, transfer the contents where they can be stored and monitored at the correct
temperatures, and defrost it fully.
When cleaning you should:
• Not use strong detergents or bleach.
• Wipe the inside of the fridge in the same solution and dry with a soft cloth.
• Wipe the door seal with a damp cloth.
• Gently remove the dust on the outside and back of the fridge. Take care not to damage
the pipes.
WARNING! If the power supply cord is damaged, it MUST be replaced by the
manufacturer, its service agent or similarly qualied persons in order to avoid a hazard
Caring for your Fridge
7
Trouble Shooting Useful Information
Your Labcold sparkfree refrigerator comes complete with a two years parts and labour
warranty (UK customers only).
To register your warranty, please complete the enclosed warranty form or visit our web site
at www.labcold.com, click on the ‘Warranty Registration’ tab and follow the instructions. Full
warranty terms and conditions can also be viewed and downloaded from the Labcold website.
In the unlikely event that there is a problem with your refrigerator, you should contact your
retailer in the rst instance. If you bought your fridge directly from Labcold you should contact
When you register your warranty or want to report a performance issue you will need to have
the following information to hand. Please ll this in as soon as you get your fridge so we can
help you as quickly as possible in the event of a problem.
Model Number
Serial Number
Retailer
Date Purchased
the professional choice for medical
and scientic refrigeration...
Labcold Ltd, Cherrywood, Chineham Park, Basingstoke, RG24 8WF, UK 01256 705 555
8
My refrigerator is not working
• Check that the fridge is plugged in and the plug socket is turned on.
• Try another appliance in the power socket. If this appliance works but your fridge doesn’t,
please contact your retailer. If the second appliance also doesn’t work the problem is
likely to be with your power socket.
My fridge is making a gurgling noise
All Labcold refrigerators work by condensing an environmentally friendly gas. This is what
causes the back of the refrigerator to get cold, and as part of this process the gas has to be
compressed into liquid. This is why sometimes you will hear liquid sounds coming from the
fridge.
There is a build up of water in my fridge
If you have defrosted the fridge any ice in the chamber is melted and runs into the drain hole
at the back of the fridge. If the drain is blocked, water will remain inside the fridge. Please
check and clear the drain hole so water can run away freely.
There is ice in my fridge
• A small amount of ice is perfectly normal but ice can build up for a variety of reasons:
• The room is too warm or even damp.
• The temperature is set too low – please check the set point by pushing the set button.
Please contact the Labcold service team if the set point is too low.
• The door is left open too long or too frequently.
What does the code mean on the display?
Code Displayed Description Action Required
Id Door open alarm Close the door
DEF Defrost in operation None - no fault
Fridge in standby mode Press for 3 seconds
AH High temperature alarm Push any button to mute
AL Low temperature alarm Push any button to mute
My independent thermometer shows a dierent temperature to the front of the fridge
Your Labcold sparkfree fridge has a probe placed at the rear of the refrigerator and the
temperature displayed is calculated by analysing and averaging the temperature data
collected by the probe. A thermometer placed in a dierent part of the fridge may read a
slightly dierent temperature especially if it is placed close to the door or at the top or bottom
of the unit as these are the areas where the greatest temperature uctuations occur.
My fridge won’t start after a power cut
This is because the compressor may have stopped mid cycle. Either keep it plugged in and
wait for it to start, or unplug the fridge and plug it back in to restart the compressor.
Press for 3 seconds
www.labcold.com
This manual suits for next models
2
Table of contents
Other Labcold Refrigerator manuals
