Ladybird JC1206 User manual

LBCS_0134_0912_V3
Group 1, 2, 3, Car Seat
Suitable for 9kg to 36 kg
(approximately 9 months to 11 years)
Model: JC1206

Helpline Number 0845 268 2000
Red (headrest
height adjustment)
Belt guide
Harness connector
Seat belt routing slot
Belt
guide
Headrest
Belt guide
Harness Slot
Harness
Chest pad
Backrest
Buckle &
crotch pad
Booster seat
Harness adjuster
strap
Harness adjuster
lever
Instruction
Pocket
Red Clip
PARTS AND FITTINGS

1
2
3
45
ATTACHING THE BACKREST TO THE BOOSTER SEAT

Helpline Number 0845 268 2000
1
2
3
4
CHANGING THE SHOULDER STRAP HEIGHT
CORRECT SHOULDER STRAP HEIGHT
No — Too Low No — Too High Yes — Correct
Locate the harness connector on the rear of the car seat. Slide one
of the harness straps off the harness connector (1).
From the front of the seat, pull it through the slot in the seat backrest
and fabric cover (2).
Thread the harness strap back through the next slot up or down on
the cover and backrest (3).
Re-thread the harness strap back onto the harness connector at the
back of the seat (4).
Repeat for the other harness strap. Ensure both straps are at the
same height.

1 2 3
11
2
FASTENING THE SAFETY SEAT BUCKLE
TIGHTENING THE HARNESS
Slot the two metal sections of the buckle connectors together (1).
Slot the two buckle connectors into the slot in the top of the
buckle until they “click” into place (2).
Always check the harness is correctly locked by pulling the
shoulder straps upwards (3).
To release the harness, press the red button on the buckle
downwards.
Pull the shoulder straps upwards to
remove the slack from the lap
sections of the harness (1). Now pull
the adjuster strap until the harness is
fully tightened (2).
The harness should be adjusted as
tightly as possible without causing
discomfort to your child.
Ensure that the lap strap portion of
the harness is located as low as
possible towards the thighs-not
around the tummy.
A loose harness can be dangerous.
Check the harness adjustment and
tighten each time the child is
placed in the seat

Helpline Number 0845 268 2000
2
1
2
SLACKENING THE HARNESS
FITTING THE CAR SEAT WITH THE 3-POINT LAP
AND DIAGONAL SEAT BELT 9 – 18KG
(APPROXIMATELY 9 MONTHS TO 4 YEARS).
The harness is slackened by pressing
the lever (under the seat cover) on
the front of the seat.
Whilst gripping the two shoulder
straps with your other hand, press
down the lever (1) and pull the
shoulder straps towards you to
loosen the harness (2).
Take care when adjusting the
shoulder straps that you do not trap
the harness adjuster straps as you
press the lever down.
Place the child safety seat on the
vehicles seat ensuring it is firmly
pressed against the car seat
backrest (1).
Thread the car seat belt through the
seat belt route slot in the seats
plastic backrest furthest from the
cars seat belt buckle, and then out
through the other seat belt route slot
and fasten it into the seat belt
buckle (2).

35
4
Check the webbing of the seat belt has not become twisted
or tangled and that the lap belt goes under the armrest and
the diagonal belt under the headrest belt guide then goes
over the red belt guide on the side of the backrest (3).
Place your knee on the base of the safety seat and grip the
top piece of the seat belt webbing. Pull the webbing
upwards to tighten the seat belt (4).
Finish tightening the webbing by pulling the diagonal strap
upwards until there is no slack and the seat is held firmly in
place, attach the red clip to the diagonal belt near to the
buckle (5).
Now you can strap your child into the seat. Make sure the
seat belt has not become twisted. Also check that the cover
is not impeding the movement or fit of the seat belt webbing
in any way. To remove your child seat follow the above
instructions in reverse order.
Red
Clip

Helpline Number 0845 268 2000
123
ADJUSTING THE HEADREST HEIGHT
REMOVING THE SAFETY HARNESS CROTCH STRAP
(According to the child’s height) The
headrest can be adjusted up or
down.
Put your left (or right) hand on the
backrest for support.
Pull the red headrest adjuster with
your other hand.
Move the headrest up or down as
required ensuring the position fits for
your child.
Pull the front of the seat cover upwards and slot the crotch strap
buckle through the slot in the seat base (1).
Slot the buckle through the second slot in the base and through the
slot in the cover (2).
Pull the crotch strap through the loop on the crotch pad (3).
Important: Before fitting the seat remove the crotch straps and
shoulder strap.

REMOVING THE SAFETY HARNESS
SHOULDER STRAPS
1
23
45 6
Locate the harness connector on the rear of the car seat (1).
Slide both the harness straps off the harness connector (2 & 3).
Pull the webbing through the slots in the seat backrest and
fabric cover (4).
Locate the two webbing retainers on the underside of the
seat (5).
Turn the webbing retainers on their narrowest end and feed
them through the slots in the base of the seat, then through the
slots in the fabric cover (6).
Place the crotch and shoulder straps in a safe place away
from children.

Helpline Number 0845 268 2000
FITTING THE CAR SEAT USING THE VEHICLES
SEAT BELT 15 – 25KG
(APPROXIMATELY 3 YEARS TO 11 YEARS).
2
1 3
4
Place the child safety seat on the vehicle’s seat ensuring it is firmly
pressed against the car seat backrest (1).
Place the child in the child safety seat (2).
Fasten the seat belt, making sure that both the sections of the seat
belt webbing go under the armrest closest to the buckle. The
diagonal belt goes through the red belt guide on the side of the
headrest.
Check that the webbing has not become twisted and tighten the
seat belt by pulling the diagonal strap upwards (3).
Slot the end of the diagonal strap over the seat belt guide in the side
of the head rest and retighten (4). Make sure the seat belt has not
become twisted.
Also check that the cover is not impeding the movement or fit of the
seat belt webbing in any way.

REMOVING THE BACKREST
1
2
Remove the car seat from the car and lay on a clean flat
surface. Push the top of the backrest downwards until it is on
the floor (1). Lift the bottom of the backrest upwards until the
lugs are clear of the seat (2).
Place the backrest in a safe place away from children.

Helpline Number 0845 268 2000
FITTING THE BOOSTER SEAT 22 – 36KG
(APPROXIMATELY 4 YEARS TO 11 YEARS).
1
2
3
4
Place the booster seat on the vehicle’s seat ensuring it is pushed
firmly against the vehicle’s seat and backrest (1).
Place the child on the booster seat (2).
Fasten the seat belt, making sure that the lap belt webbing goes
under both armrests and the diagonal belt webbing goes over the
armrest near the buckle. Tighten the seat belt by pulling upwards on
the diagonal strap (3).
Check the seat belt to ensure there is no slack and the belt has not
become twisted or trapped (4).
Check that the cover is not impeding the movement or fit of the seat
belt in anyway.
To release the child, simply unfasten the seat belt in the
normal manner.
These instructions are important. Please read
carefully and retain for future reference.
Backrest cover removal: First release the
elastic strap at the bottom of the backrest
cover. Slide the cover off. The cover can now
be cleaned.
Headrest, booster seat cover removal:
Slide the cover off. The cover can now be
cleaned.
Washing the covers: The covers should be
hand washed using a mild soap and warm
water. Do not use chemicals and never
attempt to bleach or dye the webbing.
Allow to dry naturally.
IMPORTANT Note:
The seat restraint must not be used without
the cover.
The seat cover should only be replaced with
one recommended by the manufacturer,
because the cover constitutes an integral
part of the restraint's performance.
Do not use the car seat after an impact or
accident.
6. Do not allow the seat to come into contact
with corrosive chemicals etc.
Only suitable if the vehicle is fitted with
3-point static, 3-point retractor safety belts,
approved to UN/ECE Regulation no. 16 or
other equivalent standards.
EXTREME HAZARD
Do not use in passenger seats equipped with
air bags (SRS)
Please remove the car seat from the vehicle
when it is not used and keep out of reach of
your child.
Please always fasten the car seat when it is
inside the vehicle.
Please always read the manual before using it.
The manual is in the pocket located on the
back of the cover.
1. This is a “Universal” child restraint, it is approved
to ECE Regulation 44.04 for general use in
vehicles and will fit most, but not all vehicle
seats.
2. A correct fit is likely if the vehicle manufacturer
has declared in the vehicle handbook that the
vehicle is capable of accepting a “Universal”
child restraint of this group.
3. This child restraint has been declared
“Universal: under more stringent conditions
than those applied to earlier designs which do
not carry this notice.
4. If in any doubt, consult either the child restraint
manufacturer or the retailer.
5. Keep the seat covered when the weather is
hot as the buckle and other metal objects may
become hot.

CARE AND MAINTENANCE
These instructions are important. Please read
carefully and retain for future reference.
Backrest cover removal: First release the
elastic strap at the bottom of the backrest
cover. Slide the cover off. The cover can now
be cleaned.
Headrest, booster seat cover removal:
Slide the cover off. The cover can now be
cleaned.
Washing the covers: The covers should be
hand washed using a mild soap and warm
water. Do not use chemicals and never
attempt to bleach or dye the webbing.
Allow to dry naturally.
IMPORTANT Note:
The seat restraint must not be used without
the cover.
The seat cover should only be replaced with
one recommended by the manufacturer,
because the cover constitutes an integral
part of the restraint's performance.
Do not use the car seat after an impact or
accident.
6. Do not allow the seat to come into contact
with corrosive chemicals etc.
Only suitable if the vehicle is fitted with
3-point static, 3-point retractor safety belts,
approved to UN/ECE Regulation no. 16 or
other equivalent standards.
EXTREME HAZARD
Do not use in passenger seats equipped with
air bags (SRS)
Please remove the car seat from the vehicle
when it is not used and keep out of reach of
your child.
Please always fasten the car seat when it is
inside the vehicle.
Please always read the manual before using it.
The manual is in the pocket located on the
back of the cover.
1. This is a “Universal” child restraint, it is approved
to ECE Regulation 44.04 for general use in
vehicles and will fit most, but not all vehicle
seats.
2. A correct fit is likely if the vehicle manufacturer
has declared in the vehicle handbook that the
vehicle is capable of accepting a “Universal”
child restraint of this group.
3. This child restraint has been declared
“Universal: under more stringent conditions
than those applied to earlier designs which do
not carry this notice.
4. If in any doubt, consult either the child restraint
manufacturer or the retailer.
5. Keep the seat covered when the weather is
hot as the buckle and other metal objects may
become hot.

Helpline Number 0845 268 2000
These instructions are important. Please read
carefully and retain for future reference.
Backrest cover removal: First release the
elastic strap at the bottom of the backrest
cover. Slide the cover off. The cover can now
be cleaned.
Headrest, booster seat cover removal:
Slide the cover off. The cover can now be
cleaned.
Washing the covers: The covers should be
hand washed using a mild soap and warm
water. Do not use chemicals and never
attempt to bleach or dye the webbing.
Allow to dry naturally.
IMPORTANT Note:
The seat restraint must not be used without
the cover.
The seat cover should only be replaced with
one recommended by the manufacturer,
because the cover constitutes an integral
part of the restraint's performance.
Do not use the car seat after an impact or
accident.
6. Do not allow the seat to come into contact
with corrosive chemicals etc.
Only suitable if the vehicle is fitted with
3-point static, 3-point retractor safety belts,
approved to UN/ECE Regulation no. 16 or
other equivalent standards.
EXTREME HAZARD
Do not use in passenger seats equipped with
air bags (SRS)
Please remove the car seat from the vehicle
when it is not used and keep out of reach of
your child.
Please always fasten the car seat when it is
inside the vehicle.
Please always read the manual before using it.
The manual is in the pocket located on the
back of the cover.
1. This is a “Universal” child restraint, it is approved
to ECE Regulation 44.04 for general use in
vehicles and will fit most, but not all vehicle
seats.
2. A correct fit is likely if the vehicle manufacturer
has declared in the vehicle handbook that the
vehicle is capable of accepting a “Universal”
child restraint of this group.
3. This child restraint has been declared
“Universal: under more stringent conditions
than those applied to earlier designs which do
not carry this notice.
4. If in any doubt, consult either the child restraint
manufacturer or the retailer.
5. Keep the seat covered when the weather is
hot as the buckle and other metal objects may
become hot.

These instructions are important. Please read
carefully and retain for future reference.
Backrest cover removal: First release the
elastic strap at the bottom of the backrest
cover. Slide the cover off. The cover can now
be cleaned.
Headrest, booster seat cover removal:
Slide the cover off. The cover can now be
cleaned.
Washing the covers: The covers should be
hand washed using a mild soap and warm
water. Do not use chemicals and never
attempt to bleach or dye the webbing.
Allow to dry naturally.
IMPORTANT Note:
The seat restraint must not be used without
the cover.
The seat cover should only be replaced with
one recommended by the manufacturer,
because the cover constitutes an integral
part of the restraint's performance.
Do not use the car seat after an impact or
accident.
6. Do not allow the seat to come into contact
with corrosive chemicals etc.
Only suitable if the vehicle is fitted with
3-point static, 3-point retractor safety belts,
approved to UN/ECE Regulation no. 16 or
other equivalent standards.
EXTREME HAZARD
Do not use in passenger seats equipped with
air bags (SRS)
Please remove the car seat from the vehicle
when it is not used and keep out of reach of
your child.
Please always fasten the car seat when it is
inside the vehicle.
Please always read the manual before using it.
The manual is in the pocket located on the
back of the cover.
1. This is a “Universal” child restraint, it is approved
to ECE Regulation 44.04 for general use in
vehicles and will fit most, but not all vehicle
seats.
2. A correct fit is likely if the vehicle manufacturer
has declared in the vehicle handbook that the
vehicle is capable of accepting a “Universal”
child restraint of this group.
3. This child restraint has been declared
“Universal: under more stringent conditions
than those applied to earlier designs which do
not carry this notice.
4. If in any doubt, consult either the child restraint
manufacturer or the retailer.
5. Keep the seat covered when the weather is
hot as the buckle and other metal objects may
become hot.
What’s the law on car seats?
The law states that you must use a car
seat from birth until your child reaches
either 135cm in height or 12 years of
age — whichever comes first.
It is the driver’s responsibility to make
sure that children under the age of
14 are restrained correctly.

Manufactured for:
Shop Direct Home Shopping Limited
Skyways House
Speke Road
L70 1AB
UK
