Lafalink LF-R500U User manual

2.4Ghz 150Mbps Outdoor
Wireless Access Point
Quick Installation Guide
2.4Ghz 150Mbps Outdoor
Wireless Access Point
Quick Installation Guide

Hardware and Operation Mode
Interface
PoE Power Supply
PoE Port: Transfer the power and data at same time
LAN Port: Transfer data only through Ethernet cable
Thank you for purchasing the Access Point
This manual suit for quick
installation of 11N
wireless AP & High Power Router.This manual
will instruct you how to configure and manage
this 11N wireless AP & High Power Router
Introduction
LED
RST: Reset Button,and hold the RESET button for at least 18 seconds when
PWR: Power on/OFF.
WAN/LAN: When a device linked to the corresponding port, the LED light is On.
WLAN: Wi- on/OFF.
wifi led is off, and then the AP reboots to its factory default settings.
WAN/LAN: The Ethernet port is used to connect to the POE port of the provided
Power Injector. 1
in right ways.
PWR WLAN WAN LAN
AP is used for remote point-to-point and point-to-multipoint
applications. It makes remote Internet share possible.
The typical connection for access point is shown as above. Please make
sure that the two CPEs are placed face to face, otherwise, the wireless signal
correct.
.
Typical Network
Point-to-Multipoint Application
AP Client 2
Client 1
Point-to-Point Application
Client
AP

2
Installation Steps
Hardware Connection
Setting the Computer
Log in the Web Management
Setting the AP
Test the Wireless Network
Install the AP to the Ceiling
Note:
1. Before Install the AP on the Ceiling, you would
better complete the software setting.
2. Before the setting of the AP, you would better
complete the design of Topology of network
and IP address the devices.
Hardware Connection
1Locate a suitable mounting site for your CPE. To achieve the best performance
of the devices, please select an elevated location where trees, buildings and
maximum line-of-sight propagation for the devices.
2Adjust the direction of your CPE for a best signal. Place the straps through the
slots on the back of the CPE and then around the pole. Tighten the straps.
3Connect one end of an Ethernet cable to the PoE port of the provided PoE and
the other end of the Ethernet cable to the LAN port of the CPE. Then, connect
the LAN port of the PoE to a PC using another Ethernet cable. Finally, plug the
provided power adapter into a standard electrical wall socket.
Access PointPOE Power Supply
Turn on all your network devices and then check to see if the LEDs on the AP
display normally as the diagram below describes.
5If you use two CPEs to build the network, please make sure that the two CPEs
are placed face to face
4
Setting the Computer
before logging in
the management page. Here we take the procedures in Windows 7 for example.
1Go to Start > Settings >
Panel, and then you will see the
following page. Click
network status and tasks
2Click Change adapter settings
3Right-click Local Area Connec-
tion, then click Properties

3
1
2
4Double-click Internet Protocol
Version 4 (TCP/IPv4).
5Select Use the following IP
address, enter 192.168.0.100 into
the IP address
255.255.255.0 into the Subnet
mask
6Click OK
tions for your computer.
Log in the Web Management
Open your web browser, type 192.168.0.1 in the address bar
1
2
After successful login, you can see web management page of the CPE, please go to Wizard
on the top menu．
Enter the User name/Passwords: preset as admin/admin, then you can found on
the label attached to the router, click OK
Setting the AP
Select the Operation Mode Type according to your needs. Click Next.
If you want to set up a point-to-point connection with Access Point, please
skip to . In this part, you will
Access Point
and Repeater mode with two
dierent APs.
.
(To be continued...)

4
Setting the AP
Two devices are needed for this application.
The AP A Setting to Access Point Mode
The AP B Setting to Repeater Mode
Select Access Point for the operation mode, then click Next.
1
Select Repeater for the operation mode, then click Next.
1
The IP Address will be change to a same sunbet with former Router/Switch’s LAN.
Here the Router which AP connect to is 192.168.1.1. So we set the AP’s IP address
to 192.168.1.2. The DHCP is distable, then chlick Next.
When a windows pops “Change the LAN IP address of the system will reboot, are you
sure to continue?” Please chilck the Sure.
2
The IP Address will be change to a same sunbet with former Router/Switch’s LAN.
Here the Router which AP A connect to is 192.168.1.2. So we set the AP B’s IP address
to 192.168.1.3. The DHCP is distable, then chlick Next.
2
3
When a windows pops “Change operation mode, the device will be reboot, are you
sure to continue?” Please chilck the Sure. Then device will be reboot,
5
4Create an easy-to-remember name for your wireless network. Here we take
CPE8150_ce60
mode and enter a wireless password below to prevent unauthorized access
to your AP. Click Finished.
for example. Select Most Secure (WPAPSK/WPA2PSK)

5
When a windows pops “Change the LAN IP address of the system will reboot, are you
sure to continue?” Please chilck the Sure.
3
4
As for AP B, you can disable the wi status of AP. then click Finished.
5
After AP is reboot successful, choose the “wireless connect” you can see the
AP Signal Strength and Link Quality, that means AP B and AP A are connect
with each other.
6
You also can click the “Throughput Statistic” to see the realtime Wireless
Throughput Statistic.
7

6
Test the Wireless Network
Management
Click Management to enter into the management page as follow
System:
system, or reboot to default setting.
Manager: set the the manager and passwords
Log: Log Enable or disable, or view the system log from here
computer wireless connection as local connection settings mentioned above.
wireless network’s performance.
Trouble Shooting
Symptoms Treatment
Forget the login user
name and passwords
Can’t login AP
through WEB
management
Forget the AP’s SSID
and passwords
Forget the AP’s SSID
and passwords
No Power indicator
1. Check the AP’s DHCP and make it enable in
Gateway mode and WISP mode
2. Check the connection between AP and
the top networking in AP and Repeater mode
1. If DC Power, check the local power supplier
2. If PoE Power, check the PoE adapter and Internet
cable
Restore to factory default
Restore to factory default
Appendix I
1 Pls make sure the PC and AP’s IP Address
are in same network segment, can be checked
through Ping: PC start--input CMD in Run, then
ping 192.168.0.1
2Login after Restore AP to factory default
3Make sure there isn’t any equipment take IP
address of 192.168.0.1 in AP networking
4Check your computer and network cable to
avoid any problem, recommend to use unshielded
twisted pair 10/100M Ethernet cable.

7
PoE Power Supply Data
Power
PoE Power SupplyAppendix 3
The PoE power supply of Access Point, line 1.2.3.6 is using transfer the data,
and 4.5.7.8 is using transfer the power, 4.5 is “+”, 7.8 is “-”.
Hotel Wireless SolutionAppendix 2
Topology
Router
AP Mode Repeater Mode
Switch
