ENFORCER SK-2611-SFSQ User manual

®
SK-2611-SFSQ
Fingerprint Reader and Keypad
Manual
Features:
500DPI Optical fingerprint reader
Up to 1,000 users (up to 500 fingerprint
users, up to 500 PIN users)
User code length 4~6 digits
Fingerprint identification time – <1 second
Fingerprint false acceptance rate – 0.0001%
Fingerprint false rejection rate – 0.01%
12VDC Operation
Form C relay output
Tamper alarm output
Adjustable relay output time –
1~99 seconds, or toggle
For indoor use only
Illuminated fingerprint reader window

ENFORCER Fingerprint Reader and Keypad
2SECO-LARM U.S.A., Inc.
This page is for installers looking to do a basic installation and programming of the fingerprint reader
and keypad. For more in-depth installation and programming instructions, see "Table of Contents"
on pg. 4.
Quick Wiring Diagram:
Mounting Diagram:
Quick Installation Guide:
NOTE: Connect the included diode as close as possible and in parallel with an electric strike. This
absorbs possible electromagnetic interference to prevent operation of the strike from damaging the
fingerprint reader/keypad. Do not connect a diode when using electromagnetic locks.
Green
–
Not used
White
–
Not used
Purple
–
Output
(
N.C.
)
Blue
–
Output
(
N.O.
)
Yellow
–
E
g
ress Input
(
N.O.
)
Black
–
Ground
(
–
)
Gra
y
–
Tamper Alarm Output
(
GND
)
Oran
g
e
–
Output
(
COM
)
Red
–
12VDC
(
+
)
12VDC
Power
Suppl
y
(
+
)
Egress
Button
(
–
)
(
+
)
(
–
)
Or
Cathode
Electric
Lock
IN4007
Output Relay
N.O. Output for Fail-secure Lock
N.C. Output for Fail-safe Lock
(
+
)
A
larm
(
–
)
Diode IN4007
(
For DC use onl
y
, see note
)
Mounting screws
Mounting bracket
Securit
y
screws

ENFORCER Fingerprint Reader and Keypad
SECO-LARM U.S.A., Inc. 3
Quick Programming Guide:
Programming Tips:
Master fingerprints (up to 5) should be programmed before any other programming is completed.
A flashing red LED indicates that fingerprint reader/keypad is in standby mode. A solid blue or
purple LED indicates the unit is in programming mode.
Programming Instructions:
Follow the instructions below if the following covers your needs:
A new master fingerprint.
Setting one user fingerprint and one user code.
A 3-second programming delay time in opening the door after the output is activated.
1. Enter programming mode:

NOTE: is only the master code until a master fingerprint is learned.
2. Set the master fingerprint:

NOTE: is the new master fingerprint.
3. Set a user fingerprint to operate the output (unlock the door):

NOTE:
 chooses fingerprint user ID #1 of 500 possible fingerprint users (1~500).
is the new user fingerprint.
4. Set a user code to operate the output (unlock the door):

NOTE:
 chooses user code ID #501 of 500 possible user codes (501~1000).
 is the new user code for user ID #501.
5. Set the output delay time (skip this step if the default value of 5 seconds is acceptable):

NOTE: sets the output delay time for 3 seconds.
6. Exit programming mode:


ENFORCER Fingerprint Reader and Keypad
4SECO-LARM U.S.A., Inc.
Operating voltage 12VDC
Current draw Standby 40mA
Active 100mA
Outputs Form C 2A@12VDC
Tamper alarm 2.5A@12VDC
Egress input N.O. Ground
Enclosure material Zinc alloy
Operating temperature -4°~122° F (-20°~50° C)
Operating humidity 20~90%
Dimensions 25/8"x57/8"x15/16" (66x150x24 mm)
Weight 14.8-oz (420g)
Specifications:
Features:
Table of Contents:
Quick Installation Guide: .........................................2
Mounting Diagram: ..................................................2
Quick Wiring Diagram:.............................................2
Quick Programming Guide: .....................................3
Table of Contents: ...................................................4
Features: .................................................................4
Specifications: .........................................................4
Overview:.................................................................5
Parts List:.................................................................5
LED Indicators and Fingerprint
Reader Sounds:.......................................................5
Important Notes: ......................................................5
Installation: ..............................................................6
Wiring Diagram:.......................................................6
Sample Application: ................................................7
Getting Ready to Program: ..................................7-8
Programming the Master Fingerprints: ...................8
Programming User Fingerprints:..........................8-9
Programming User Codes:......................................9
Deleting User Fingerprints or User Codes: ........9-10
Programming the Output Mode
and Output Timing:................................................10
Resetting the Fingerprint Reader/Keypad:............ 11
Manually Resetting the Master Fingerprint: ..........11
Operating the Fingerprint Reader/Keypad: ...........11
Troubleshooting: ...................................................12
Also Available from SECO-LARM®: ...............12
Warranty:...............................................................12
12VDC Operation
Up to 500 fingerprint users (1~500)
Up to 500 user codes (501~1000)
Output: Form C relay, 2A@12VDC max.
Output can be programmed to activate for
up to 99 seconds or toggle
Tamper alarm output: Transistor ground,
2.5A@12VDC max.
Fingerprint reader window illuminates
when finger is present
EEPROM Memory protects programmed
information in case of power loss
All features programmed directly from the
fingerprint reader/keypad: No need for an
external programmer
Egress input lets users exit the premises
without presenting a fingerprint or keying
in a code
500DPI Optical fingerprint reader
Fingerprint identification time – <1 second
Fingerprint false acceptance rate – <0.0001%
Fingerprint false rejection rate – <0.01%
For indoor use only

ENFORCER Fingerprint Reader and Keypad
SECO-LARM U.S.A., Inc. 5
Overview:
Status Sounds LED
In standby mode -- 1 Red flash/ 10 seconds
Enter programming mode 2 Beeps Blue steady
In programming mode -- Blue/Purple steady*
Exit programming mode 2 Beeps 1 Red flash and 1 blue flash
Successful operation 1-Sec long beep 1 Blue flash
Unsuccessful operation 3 Fast beeps 1 Red flash
Tamper alarm output Rapid beeping --
LED Indicators and Fingerprint Reader/Keypad Sounds:
*Blue or purple LED depending on what stage of programming.
Important Notes:
1. Always disconnect power before servicing the fin
g
erprint reader/ke
y
pad. Do not appl
y
power until
all connection wiring is completed.
2. The fingerprint reader/keypad must be properly grounded. Use a minimum 22AWG wire
connected to the common ground wire. Failure to do so may damage the unit.
3. All wiring and programming should be done by a professional installer to reduce the risk of
improper installation.
4. The user's operating guide for this fingerprint reader/keypad is located on pg. 11 of this manual.
Be sure to store this manual in a safe place for future reference.
Parts List:
1x Fingerprint reader and keypad 1x Manual 1x Diode
4x Mounting screws 4x Mounting screw anchors 1x Mounting bracket
2x Security screws 1x Security wrench
5
7
/
8
"
(
150mm
)
2
5
/
8
"
(
66mm
)
15
/
16
"
(
24mm
)
IF USING THE FINGERPRINT READER/KEYPAD WITH A
MECHANICALLY OPERATED DOOR OR GATE, MOUNT THE UNIT AT
LEAST 15' (5m) FROM THE DOOR OR GATE TO PREVENT USERS
FROM BEING CRUSHED OR PINNED. FAILURE TO DO SO MAY
RESULT IN SERIOUS INJURY OR DEATH.
!!

ENFORCER Fingerprint Reader and Keypad
6SECO-LARM U.S.A., Inc.
1. Find a suitable location to mount the fingerprint
reader/keypad. Install it at a height at which most
users will be able to easily operate the unit.
2. Run wiring through the wall to the fingerprint
reader/keypad's location and through a hole cut in
the wall which is large enough to allow the wiring
to fit without crimping.
3. Using the included security wrench, unscrew
the security screws located on the bottom of the
fingerprint reader/keypad's mounting bracket
(Fig. 1).
4. Carefully remove the fingerprint reader/keypad
from the mounting bracket.
5. Thread the wiring through the center of the
fingerprint reader/keypad's mounting bracket.
6. Install the mounting bracket using the included
mounting screws and mounting screw anchors
(if necessary). Ensure the correct orientation as
shown in Fig. 2.
7. Connect the wires to the fingerprint reader/keypad
according to "Wiring Diagram" below.
8. Finish assembly by attaching the fingerprint
reader/keypad to the mounting bracket.
Wiring Diagram:
Connection Wires
Color Function Description
Red Power (+) Connect to +12VDC power supply
Black (2 wires) Ground (-) Connect to Ground
Yellow Egress Input
N.O. Pushbutton contact to ground. Press button to
activate the output
Blue Output N.O.
NO/NC/COM, relay output, max. 2A@12VDC
Orange Output COM
Purple Output N.C.
Gray Tamper Alarm
Output
Transistor ground output, max. 2.5A@12VDC. Switches to
ground (-) when tamper switch activated.
Green Not used Not used
White Not used Not used
Installation:
Fig. 2
Fig. 1

ENFORCER Fingerprint Reader and Keypad
SECO-LARM U.S.A., Inc. 7
NOTE: Connect the included diode as close as possible and in parallel with an electric strike. This
absorbs possible electromagnetic interference to prevent operation of the strike from damaging the
fingerprint reader/keypad. Do not connect a diode when using electromagnetic locks.
The fingerprint reader/keypad is controlled by either a fingerprint or a user code.

A
ll fin
g
erprints and user codes must have a unique User ID
(
between 1 and 1000
)
. User IDs ma
y
be
specifically selected or automatically assigned. It is important to record all User IDs.
 The initial master code is disabled after programming the first master fingerprint.
Fingerprints:
There are two types of fingerprint entries:
 Master fingerprints – Up to 5 fingerprints can be assigned as master fin
g
erprints. Master fin
g
erprints
are used to enter programming mode.
 User fingerprints – Up to 500 fingerprints can be assigned as user fingerprints. User fingerprints are
used to activate the relay.
User Codes:
User codes ma
y
be 4~6 di
g
its in len
g
th. Up to 500 user codes can be assi
g
ned. User codes are used to
activate the relay.
Enter and Exit Programming Mode:
All programming of the fingerprint reader/keypad is done in programming mode.
1. Enter programming mode for the first time:

2. Enter programming mode after a master fingerprint has been programmed: Place the master
fingerprint on the reader window for 1 second. The unit will beep twice and the LED will light blue
to indicate the unit is in programming mode.
Sample Application:
Getting Ready to Program:
Green
–
Not used
White
–
Not used
Purple
–
Output
(
N.C.
)
Blue
–
Output
(
N.O.
)
Yellow
–
E
g
ress Input
(
N.O.
)
Black
–
Ground
(
–
)
Gra
y
–
Tamper Alarm Output
(
GND
)
Oran
g
e
–
Output
(
COM
)
Red
–
12VDC
(
+
)
12VDC
Power
Supply
(
+
)
Egress
Button
(
–
)
(
+
)
(
–
)
Or
Cathode
Electric
Lock
IN4007
Output Relay
N.O. Output for Fail-secure Lock
N.C. Output for Fail-safe Lock
(
+
)
A
larm
(
–
)
Diode IN4007
(For DC use only, see note)

ENFORCER Fingerprint Reader and Keypad
8SECO-LARM U.S.A., Inc.
Getting Ready to Program (continued):
3. Exit programming mode:
Press the key or wait 15 seconds to exit automatically.
NOTE:
DO NOT DISCONNECT THE FINGERPRINT READER/KEYPAD FROM POWER WHILE IN
PROGRAMMING MODE. Disconnecting the unit while in programming mode may cause a
memory error.
If you are unsure what mode the fingerprint reader/keypad is in, press the key until the LED
flashes red and the unit beeps 3 times. The fingerprint reader/keypad is now in standby mode.
Programming the Master Fingerprints:
The master fingerprints are used to enter programming mode. The master fingerprints do not serve as
user fingerprints activating the output. To program the master fingerprints:
1. Enter programming mode using the initial master code:

2. Add the first master fingerprint:

3. Add additional master fingerprints (if necessary):

4. Exit programming mode:

NOTE:
 represents the master fingerprint, which must be presented twice.
The initial master code () is only valid until a master fingerprint is learned.
There can be up to five master fingerprints for the unit.
If the master fingerprint is unavailable, see "Manually Resetting the Master Fingerprint" on pg. 11.
If no activity within 15 seconds, the fingerprint reader/keypad will automatically exit programming
mode.
Programming User Fingerprints:
When programming user fingerprints, use the following general formula:

– to  – 500 unique User IDs for user fingerprints for the output.
– User’s fingerprint.
NOTE:
For all programming functions, the fingerprint reader/keypad must first be in programming mode.
To enter programming mode, present the master fingerprint once.
Entering a User ID followed by the key allows the programmer to assign a particular User ID to
the subsequent user fingerprint. If this step is omitted then the fingerprint reader/keypad will
automatically assign the user fingerprint to the next available User ID.
Each User ID must be unique and cannot be repeated for multiple user fingerprints or codes.
 represents the user fingerprint, which must be presented twice.
Exit programming mode by pressing the key after all programming is completed.

ENFORCER Fingerprint Reader and Keypad
SECO-LARM U.S.A., Inc. 9
Examples:
1. Program a user fingerprint for User ID #10:

2. Program a user fingerprint to an automatically assigned User ID
(g
enerall
y
not recommended, since
the User ID will be needed to delete a user when their fingerprint is not available):

NOTE: In this example, the fingerprint reader/keypad will assign the next available User ID.
When programming user codes, use the following general formula:

–  to  – 500 unique User IDs for user codes for the output.
– User code – 4~6 digits long
NOTE:
For all pro
g
rammin
g
functions, the fin
g
erprint reader/ke
y
pad must first be in pro
g
rammin
g
mode. To
enter programming mode, present the master fingerprint once.
Each User ID must be unique and cannot be repeated for multiple user fingerprints or codes.
Exit programming mode by pressing the key after all programming is completed.
Examples:
1. Program user code  for User ID #501:

2. Program user code  for User ID #750:

Programming User Fingerprints (continued):
Programming User Codes:
Deleting User Fingerprints or User Codes:
To delete user fingerprints when the user is available, use the following general formula:

 – Delete Users
– User fingerprint
To delete user fingerprints when the user is unavailable, or to delete user codes, use the following
general formula:

 – Delete Users
– to  – User ID
To delete all users, use the following formula:


ENFORCER Fingerprint Reader and Keypad
10 SECO-LARM U.S.A., Inc.
Programming the Output Mode and Output Timing:
NOTE:
For all pro
g
rammin
g
functions, the fin
g
erprint reader/ke
y
pad must first be in pro
g
rammin
g
mode. To
enter programming mode, present the master fingerprint once.
Exit programming mode by pressing the key after all programming is completed.
When deleting user fingerprints or user codes, the master fingerprint can be presented twice within
5 seconds instead of presenting the master fingerprint once and then pressing . The LED will
be lit red during this mode.
Examples:
1. Delete a user fingerprint for an available fingerprint:
 (present the user fingerprint to be deleted)
2. Delete a user fingerprint for an unavailable fingerprint assigned to User ID #1:

3. Delete a user code for User ID #501:

4. Delete all users:
  
Deleting User Fingerprints or User Codes (continued):
The rela
y
can be pro
g
rammed to to
gg
le ON and OFF with a user fin
g
erprint or user code
(
to
gg
le mode
)
,
or to trigger for a programmed length of time up to 99 seconds before automatically turning OFF. The
toggle or timed output can be used for locking or unlocking a door or for a variety of functions that can
be controlled with the fingerprint reader/keypad.
When programming the output mode and time, use the following general formula:

 – Program Output Mode and Time
– Output Mode and Time
Output Mode and Time:
– Start/stop (toggle) mode. In this case, the output starts when a user fingerprint/code is
entered, and stops when a user fingerprint/code is entered again.
to  – The output triggered by a user fingerprint/code lasts up to 99 seconds before
automatically turning off (default: 5 seconds).
NOTE:
For all programming functions, the fingerprint reader/keypad must first be in programming mode.
To enter programming mode, present the master fingerprint once.
Exit programming mode by pressing the key after all programming is completed.
Examples:
1. Set the output to toggle mode:

2. Set the output to 60 seconds:

