INSTRUCTION BOOKLET
Model: 19686
SWITCH FILTER
COFFEE MAKER

2
LAKELAND SWITCH FILTER COFFEE MAKER
Thank you for choosing the Lakeland Switch Filter Coffee Maker.
Please take a little time to read this booklet before you use your machine and keep it in a
safe place for future reference.
The Switch Filter Coffee Maker allows you to make one carafe of freshly brewed filter
coffee, or flip the switch to brew a single size travel cup to drink on the move. Permanent
filters are included for easy cleaning and less waste, and the programmable timer means
you can wake up to freshly brewed coffee.
An award winning family-owned business, here at Lakeland we still have the same values
of excellent quality, value for money and exceptional customer care as we did when we
first set up the company in the 1960s.
Our products are carefully selected and rigorously tested to meet our high standards, so
you can be assured that any product you purchase will be easy-to-use and highly durable.

3
CONTENTS
Product features...........................................................................................................4-5
Safety cautions.............................................................................................................6-7
Using the Switch Filter Coffee Maker for the first time .................................................8-9
Instructions for use .................................................................................................8,9,10
Using the carafe..............................................................................................................8
Using the single cup........................................................................................................9
Setting the timer...........................................................................................................10
Hints and tips................................................................................................................11
Troubleshooting ............................................................................................................11
Care and cleaning .........................................................................................................12
Recycling your electricals ...............................................................................................13
Electrical connections....................................................................................................13

4
PRODUCT FEATURES
Cup permanent filter
Cup filter basket
Cord and plug
with cord storage
Coffee bag basket
Cup water tank
Travel cup and lid
Drip tray and base
SINGLE CUP

5
Hot plate
Carafe
Carafe
water tank
Carafe
filter lid
Carafe
water lid
Tank viewing window
Switch
Carafe
filter basket
Carafe
permanent filter
Illuminating
display with clock
On/Off button
CARAFE

6
SAFETY CAUTIONS
Carefully read all the instructions before using the appliance and keep in a safe place
for future reference. Always follow these safety cautions when using the appliance to
avoid personal injury or damage to the appliance. This appliance should be used only as
described in this instruction book.
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the
hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be done by
children unless they are older than 8 and supervised.
• Make sure your electricity supply matches the voltage shown on the appliance.
• Ensure all packaging materials and any promotional labels or stickers are removed from
the appliance before the first use.
• Always inspect the appliance before use for noticeable signs of damage. Do not use if
damaged or has been dropped. In the event of damage, or if the appliance develops a
fault contact the Lakeland customer care team on 015394 88100.
• Do not use this appliance if the lead is damaged. If the lead is damaged it must be
replaced with a special lead contact the Lakeland customer care team on
015394 88100.
• Always use the appliance on a dry, level, heat resistant surface.
• Unplug from the mains when not in use and before cleaning. Allow to cool before
cleaning the appliance. To disconnect, turn the socket to “off “and remove the plug
from the mains socket.
• Do not use any accessories or attachments with this appliance other than those
recommended by Lakeland.
• To protect against fire, electric shock or personal injury, do not immerse cord, plug or
unit in water or other liquids. Do not use near the sink.
• Do not leave the lead hanging over the edge of a kitchen table or worktop. Avoid
contact between the lead and hot surfaces.
• For indoor use only.
• For domestic use only.
• This appliance should be used for preparation of drinks as described within the
instructions for use that accompany it.

7
• Always ensure that your hands are dry before removing the plug from the mains socket.
Never pull the plug out of the mains socket by its lead.
• To avoid injury or possible fire, do not cover the appliance when in use.
• Do not connect this appliance to an external timer or remote control system.
• An extension cable may be used with care. The electrical rating of the cable should be
at least as great as the appliance. Do not allow the cable to hang over the edge of the
worktop or touch any hot surfaces.
• This appliance complies with the basic requirements of Directives 04/108/EC
(Electromagnetic Compatibility) and 06/95/EC (Safety of Domestic Electrical Appliances).
• WARNING: A cut off plug inserted into a 13amp socket is a serious safety (shock)
hazard. Ensure the cut off plug is disposed of safely.
• CAUTION: The plastic bags used to wrap this appliance or the packaging may be
dangerous. To avoid risk of suffocation, keep these bags out of reach of babies
and children. These bags are not toys.
• Do not place on or near a gas or electric oven, or any hot surfaces.
• Only use the carafe with this appliance. It must never be used on a hob or in
a microwave.
• Do not put a hot carafe down onto a wet or cold surface.
• Do not use the carafe if it is damaged.
• This filter coffee maker does not include any user-serviceable parts. To reduce the risk
of fire or electric shock do not remove any covers. Repairs must be done by a qualified
electrician. In the event of damage, or if the appliance develops a fault contact the
Lakeland customer care team on 015394 88100.
• Ensure the carafe lid is securely in place when using the appliance and when pouring
coffee. Do not use force when putting the lid on the carafe.

8
INSTRUCTIONS FOR USE
• Plug in the coffee maker and switch it on at the socket, the
display will illuminate and the clock will read 0.00.
• Press the ‘HOUR’ and ‘MINUTE’ buttons to set the time.
USING THE CARAFE
1. Ensure the switch is flipped to the right, to ‘Carafe’.
2. Fill the carafe with cold tap water, to the amount you require
using the cup measurements on the side.
3. Lift the carafe water tank lid and pour in the water. Do not fill
past the 12 cup mark on the tank viewing window, or the MAX
FILL guide inside the tank.
4. Place the empty carafe onto the hot plate.
5. Lift the carafe filter lid and remove the carafe filter basket and
permanent filter.
6. For each cup of coffee, put 1 level tablespoon (15ml) of ground
coffee into the filter.
7. Place the permanent filter into the filter basket and place them
inside the coffee maker. Ensure the notch on the side of the filter
basket is slotted into the groove inside the coffee maker.
BREW BUTTON
1. For fuller, stronger flavoured coffee press the ‘Brew’ button, ‘Strong’ will be displayed
on the screen. This setting brews your coffee slower, and will take longer. Press the
‘Brew’ button again to deselect and brew on the normal setting.
USING THE SWITCH FILTER COFFEE MAKER FOR
THE FIRST TIME
• The Switch Filter Coffee Maker allows you to make one carafe of coffee, or a single cup
of coffee using the travel cup included or your own cup. It will only brew either a carafe
or a cup at one time.
• Unpack the coffee maker. Remove all the packaging materials.
• Wash the carafe, travel cup and lid, coffee bag basket, filter baskets and permanent
filters in warm soapy water, dry thoroughly.
• Before first use, fill the carafe water tank with water to the ‘12 cup’ level, and run this
through the coffee maker following the directions below to thoroughly clean.
• Flip the switch to ‘SINGLE CUP’ and repeat, filling the cup water tank with a travel
cup full of water. Run this through the coffee maker following the directions below to
thoroughly clean.

9
2. Press the On/Off button to start brewing. The button will illuminate.
3. The water will filter through and fill the carafe. When your coffee has brewed, press
the On/Off button to turn the coffee maker off. If the coffee maker is not turned off
manually the hot plate will keep your coffee warm for 40 minutes, then the coffee
maker will switch off automatically. If you need to stop the coffee brewing mid cycle
press the On/Off button.
USING THE SINGLE CUP
1. Ensure the switch is flipped to the left, to ‘Single Cup’.
2. Fill the travel cup or your own cup with cold tap water.
3. Lift the cup water tank lid and fill it with the water from your
cup. Do not fill past the ‘MAX FILL’ mark inside the tank.
WARNING: To avoid the risk of burning or scalding from
hot coffee or water do not use more then 410ml of water,
or exceed the ‘MAX FILL’ mark.
4. Place your empty cup onto the drip tray.
If using the travel cup, add the lid first, the coffee will drip
through the lid and stay hotter.
If you are using a shorter cup, you can lift out the drip tray
and base using the tab, flip the base over, and rest the drip
tray on top to raise it higher.
5. Pull out the cup filter basket and the permanent filter.
6. Note: The coffee bag basket is not used for brewing ground
coffee, and should not be attached to the permanent filter.
7. Inside the permanent filter there are two notches, the smaller
one is a MIN fill line and the larger one a MAX fill line. Fill
filter to the MIN line if you are making 250ml of coffee and
to the MAX line if you are making 410ml of coffee. Do not
fill beyond the MAX line as this will cause the coffee maker
to overflow.
8. Place the permanent filter into the filter basket and insert
them back into the side of the coffee maker.
9. Press the On/Off button to start brewing, the button will
illuminate. The coffee maker will automatically switch off
when your cup of coffee has brewed. If you need to stop
the coffee brewing mid cycle press the On/Off button.
Flip the drip tray and base
to raise it higher
Pull out the cup filter basket
and the permanent filter
The MAX fill line and the
MIN fill line
MIN fill lineMAX fill line

10
USING COFFEE BAGS
1. Take the coffee bag basket and insert the notches on the
side into the slots in the side of the permanent filter. It will
click into place.
2. Place the coffee bag into the coffee bag basket and follow
the instructions in ‘Using the Single Cup’. If you are making
250ml of coffee use 1 pod, if you are making 410ml of
coffee or would like stronger coffee use 2 pods.
SETTING THE TIMER
1. Press and hold the ‘TIMER’ button until the clock flashes.
2. Continue to hold the ‘TIMER’ button and press the
‘HOUR’ and ‘MINUTE’ buttons until you have selected
the time you would like to start brewing. Then release the
‘TIMER’ button.
3. Press ‘TIMER’ once again, the LED light on the side of the
button will illuminate to show the timer is set.
If you need to check when you have set the timer for, just
press and hold the ‘TIMER’ button.
Press the ‘TIMER’ button again to deselect.

11
Problem Possible cause Solution
The coffee tastes too weak. Not enough ground coffee is
being used.
Add more coffee to the permanent
filter. Ensure coffee bags are in the
centre of the coffee bag basket.
Coffee is overflowing from the
permanent filter, filter basket,
or cup.
There is too much water in the
water tank.
Use your cup or the carafe to
measure the amount of water you
are putting into the cup or carafe
water tank.
The filter basket is overflowing or
the coffee is brewing too slowly.
There is too much coffee in
the filter.
Use less ground coffee in the filter.
The coffee may be ground too
finely. The appliance may need
cleaning.
The coffee is not brewing or the
appliance will not turn on.
The carafe is not on the hot plate.
The water tank is empty. The maker
is not plugged in.
Check the water tank is filled and
the appliance is plugged in.
The appliance is taking a long time
to brew.
The appliance may need cleaning. See ‘Care and cleaning’.
HINTS AND TIPS
• To avoid the coffee maker overflowing, use less ground coffee when brewing decaf or
flavoured coffee.
• For hotter coffee when using a cup, rinse your cup with warm water before brewing.
• Ground coffee does not stay fresh for as long as coffee beans. If you are using ground
coffee, watch expiry dates and buy in small amounts.
• If you are grinding coffee beans, set your grinder to a fine/medium grind, and try to
use the ground coffee within a week of grinding.
• Use approximately 1 level tablespoon (15ml) of ground coffee for each cup.
• Very finely ground coffee may cause the filter basket to overflow.
• Ensure you regularly clean the coffee maker, see ‘Care and Cleaning’.
TROUBLESHOOTING
The following are some common problems that can occur when using the Switch Filter
Coffee Maker. Please review the problems, their possible cause and any corrective action
that should be taken to ensure successful coffee making.

12
CARE AND CLEANING
• Before the first use and after every use, clean each part thoroughly.
• Check all parts before reassembly.
• Switch off and unplug the appliance from the socket before cleaning and when not in
use. Always allow the appliance to cool down completely before cleaning.
• To clean the outer parts of the appliance, wipe with a clean damp cloth and dry before
storing.
• The filter baskets, permanent filters, carafe and coffee bag basket can be washed in
warm soapy water. The carafe is dishwasher safe.
• Do not use steel wool, or abrasive cleaners or materials on any parts.
• Never immerse the appliance in water or any other liquid.
• Store the appliance with the power cable loosely coiled. Never wrap it tightly around
the base unit.
CLEANING THE CARAFE WATER TANK
• We recommend cleaning the water tank once a month, or more frequently in hard
water areas.
• Mix 250ml of cold water and 250ml of white wine vinegar, and pour into the carafe
water tank.
• Ensure the switch is flipped to the right, to ‘Carafe’. Place the carafe onto the hot plate.
• Press the On/Off button to switch on. After 30 seconds press the On/Off button again
and leave the coffee maker off for 30 minutes.
• After 30 minutes switch on the machine and then switch it off when the water and
vinegar has filtered through.
• Then fill the water tank with clean cold tap water to the ‘MAX FILL’ mark inside the
carafe water tank. Press the On/Off button to start brewing, and allow the water to
filter through and fill the carafe. Do this three times.
CLEANING THE SINGLE CUP WATER TANK
• Follow the instructions in ‘Cleaning the Carafe Water Tank’, mixing 125ml of water and
125ml of white wine vinegar.
• Ensure the Single cup/carafe switch is flipped to the left, to ‘Single Cup’. Place the travel
cup onto the drip tray, and pour into the single cup water tank.

13
ELECTRICAL CONNECTIONS
THIS APPLIANCE MUST BE EARTHED.
This appliance is fitted with a fused three-pin plug to BS1363 which is suitable for use
in all homes fitted with sockets to current specifications. If the fitted plug is not suitable
for your socket outlets, it should be cut off and carefully disposed of. To avoid an electric
shock, do not insert the discarded plug into a socket.
Fitting a new plug
If for any reason you need to fit a new plug, the flexible mains lead must be connected
as shown here. The wires in the mains lead fitted to this appliance are coloured in
accordance with the following code:
Connect BLUE to Neutral (N)
Connect GREEN & YELLOW to Earth (E)
Connect BROWN to Live (L)
13amp fuse to be used
If the colours of the wires in the mains lead of this appliance do not correspond with the
coloured markings identifying the terminals in your plug, proceed as follows. The wire
which is coloured green and yellow MUST be connected to the terminal which is marked
with the letter E (Earth). The wire which is coloured blue MUST be connected to the
terminal which is marked with the letter N (Neutral). The wire which is coloured brown
MUST be connected to the terminal which is marked with the letter L (Live).
Before refitting the plug cover, check that there are no cut or stray strands of wire inside
the plug. Use a 13amp BS1362 fuse. Only BSI or ASTA approved fuses should be used. If
you are at all unsure which plug or fuse to use, always refer to a qualified electrician.
Note: After replacing or changing a fuse on a moulded plug which has a fuse cover, the
cover must be refitted to the plug; the appliance must not be used without a fuse cover.
If lost, replacement fuse covers can be obtained from an electrical shop. This appliance
complies with the following EU Directives: 2006/95/EC (Low Voltage Directive) and
2004/108/EC (EMC Directive).
RECYCLING YOUR ELECTRICALS
Along with many other high street retailers, Lakeland has joined a scheme
whereby customers can take their unwanted electricals to recycling points
set up around the country.
Visit www.recycle-more.co.uk to find your nearest recycling point.

14
FILTERKAFFEEMASCHINE
MIT UMSCHALTFUNKTION

15
GEBRAUCHSANWEISUNG
Modell: 70148
FILTERKAFFEEMASCHINE
MIT UMSCHALTFUNKTION

16
LAKELAND FILTERKAFFEEMASCHINE
MIT UMSCHALTFUNKTION
Vielen Dank, dass Sie sich für den Kauf der Filterkaffeemaschine mit Umschaltfunktion von
Lakeland entschieden haben.
Bitte lesen Sie sich diese Anleitung vor der Inbetriebnahme Ihres neuen Geräts aufmerksam
durch und bewahren Sie sie gut auf, falls Sie später auf die hier enthaltenen Informationen
zurückgreifen möchten.
Freuen Sie sich auf eine Kanne frisch aufgebrühten Filterkaffee oder – per Knopfdruck –
einen Thermosbecher für den Genuss unterwegs. Die Filterkaffeemaschine mit Umschalt-
funktion von Lakeland ermöglicht beides. Die Dauerfilter dieser Kaffeemaschine sind leicht
zu reinigen und umweltfreundlich. Dank des programmierbaren Timers können Sie sich
vom köstlichen Duft Ihres frisch aufgebrühten Kaffees wecken lassen.
Unser mehrfach ausgezeichneter Familienbetrieb legt heute genauso viel Wert auf ein
Höchstmaß an Qualität, ein gutes Preis-Leistungsverhältnis und einen hervorragenden
Kundenservice wie damals in den 60er Jahren, als Lakeland gegründet wurde.
Unsere Artikel werden mit größter Sorgfalt ausgewählt und im Einklang mit unseren stren-
gen Standards gründlich geprüft. So können Sie sicher sein, dass jeder Artikel, den Sie bei
uns kaufen, ebenso benutzerfreundlich wie haltbar ist.

17
INHALT
Ausstattungsmerkmale.............................................................................................18-19
Sicherheitshinweise ..................................................................................................20-21
Vor dem ersten Gebrauch Ihrer Filterkaffeemaschine mit Umschaltfunktion ...................22
Gebrauchsanweisung....................................................................................................23
Verwendung der Kanne.................................................................................................23
Verwendung des Thermosbechers .................................................................................24
Timer-Einstellung...........................................................................................................25
Tipps und Tricks.............................................................................................................26
Fehlersuche...................................................................................................................26
Pflege und Reinigung ....................................................................................................27

18
AUSSTATTUNGSMERKMALE
Dauerfilter Becher
Filtereinsatz Becher
Kabel und Netzstecker
mit Kabelaufwicklung
Kaffeebeuteleinsatz
Wassertank Becher
THERMOSBECHER
Thermosbecher
mit Deckel
Abtropfschale mit Untersatz

19
Heizplatte
Kanne
Sichtfenster Wassertank
Schalter
Beleuchtete
Digitalanzeige
mit Uhr
Ein/Aus-Taste
Wassertank
Kanne
Filterdeckel
Kanne
Wasserdeckel
Kanne
Filtereinsatz
Kanne
Dauerfilter
Kanne
KANNE

20
SICHERHEITSHINWEISE
Lesen Sie sich die Gebrauchsanweisung vor Inbetriebnahme des Geräts sorgfältig durch
und bewahren Sie diese für den weiteren Gebrauch sicher auf. Befolgen Sie beim
Gebrauch des Geräts stets diese Sicherheitshinweise, um Körperverletzungen oder
Schäden am Gerät zu vermeiden. Dieses Gerät ist nur für den vorgesehenen Zweck gemäß
der Beschreibung in dieser Gebrauchsanweisung vorgesehen.
• Dieses Gerät darf von Kindern ab 8 Jahren und Personen
mit verminderter körperlicher, sensorischer oder geistiger
Fähigkeit oder mit fehlenden Erfahrungen und Kenntnissen
nur dann verwendet werden, wenn sie von einer Person, die
für ihre Sicherheit verantwortlich ist, beaufsichtigt werden
und sie im Gebrauch und hinsichtlich der potentiellen
Gefahren des Geräts unterwiesen wurden. Dieses Gerät
ist kein Spielzeug. Das Gerät darf nicht in die Hände von
Kindern gelangen. Kinder ab 8 Jahren dürfen das Gerät nur
unter Aufsicht reinigen und benutzen.
• Stellen Sie sicher, dass Ihre Stromversorgung mit der auf dem Gerät angegebenen
Spannung übereinstimmt.
• Entfernen Sie vor der ersten Ingebrauchnahme alle Verpackungsmaterialien sowie
Werbeetiketten vom Gerät.
• Vergewissern Sie sich stets vor Gebrauch des Produkts, dass es keine erkennbaren
Schäden aufweist. Verwenden Sie es nicht, falls es Schäden aufweist oder versehentlich
fallen gelassen wurde. Wenden Sie sich im Falle von Schäden oder Defekten am Gerät
an den Kundenservice von Lakeland unter der Rufnummer 0800 444 1500.
• Verwenden Sie das Produkt nicht, falls das Netzkabel beschädigt ist. Falls das Netzkabel
beschädigt ist, muss es durch ein Spezialkabel ersetzt werden. Wenden Sie sich in
diesem Fall bitte unter der Rufnummer 0800 444 1500 an den Kundenservice von
Lakeland.
• Stellen Sie das Gerät zum Gebrauch stets auf einer trockenen, ebenen und
hitzebeständigen Fläche auf.
• Ziehen Sie den Netzstecker bei Nichtgebrauch und vor der Reinigung des Geräts aus der
Netzsteckdose. Lassen Sie das Gerät vor der Reinigung vollständig abkühlen. Um das
Gerät abzuschalten, bedienen Sie die Ein/Aus-Taste und ziehen den Netzstecker aus der
Netzsteckdose.
• Verwenden Sie nur die von Lakeland empfohlenen Zubehörteile und Aufsätze.
• Tauchen Sie Netzkabel, Netzstecker oder Gerät nicht in Wasser oder andere Flüssigkeiten
ein. Es besteht Brand-, Stromschlag- und Verletzungsgefahr! Nicht in der Nähe von
Wasserquellen, zum Beispiel der Spüle, verwenden.
