LAMAX ACTION X6 User manual

- 1 -
LAMAX ACTION X6 Action Camera
Waterproof up to 30 m
Full HD video 1920 x 1080
12 MP camera
WiFi

- 2 -
Safety precautions
1. Do not drop the camera or subject it to any powerful physical shock that may cause
mechanical damage.
2. Do not place the camera near objects that generate magnetic elds, such as magnets
or electric motors or near objects that emit strong radio waves, such as antenna.
Powerful magnetic elds or radio waves may cause damage to the camera or corrupt
the captured video and audio recordings.
3. Do not expose the unit to high temperatures or direct sunlight.
4. Use only a high-quality Micro SD card. Cards produced by unveried manufacturers are
not guaranteed to function properly.
5. Do not place the Micro SD card near a magnetic eld or in a place with static electricity
as this may cause the loss of data.
6. If the device overheats, emits smoke or a suspicious odour, immediately disconnect the
device from the power supply.
7. Whilst charging the camera, keep it out of reach of children as the power cable may
cause electric shock or asphyxiation.
8. Store camera in a cool, dry and dust-free environment.
Introduction
Congratulations on purchasing the LAMAX ACTION X6 camera. It is a high-quality,
multifunctional product, highly resistant to extreme weather conditions. With the LAMAX
ACTION X6 action camera you can capture video with audio in Full HD, take photos and
immediately display the recordings on the LCD display. This rugged, weather-resistant
camera is ideal for scuba diving, cycling and other means of transport, winter sports, all
outdoor activities and wherever a high-quality recording is required in harsh weather
conditions.

- 3 -
The LAMAX ACTION X6 Action Camera has the following features:
- Compact design.
- Comes supplied with a protective waterproof housing able to withstand depths of up
to 30 m enabling you to capture stunning underwater shots or your favourite water
sports.
- Includes an integrated LCD display for immediate playback of your recordings.
- Can shoot video or take photographs whilst charging (except when charging via a PC).
- Shoots Full HD video 1920 x 1080.
- Up to 12 MP photos.
- Wide-angle lens with a range up to 170°.
- Wide choice of video and photo resolutions.
- Multiple photography modes.
- Option to manually set photo and video exposure.
- Wide range of supplied accessories allows you to shoot video anytime and anywhere.
- Can be used as a dashcam.
- Can be used as a webcam.
- Supports Micro SDHC cards up to 32 GB.
- USB and HDMI connectivity.
- Integrated WiFi allows connection to wireless devices.
- Intuitive to use and easy to connect to a PC or smartphone.
- User-friendly software.

- 4 -
Camera from the front right
Camera Parts:
1 Shutter / Conrm
2 Power / Mode
3Action indicator (red)
4HDMI port
5 Lens
6USB port
7 Micro SD card slot
8 Microphone
1
Camera from the back right
Camera Parts:
1 Operation indicator (red)
2 Charging indicator (blue)
3LCD display
4Down / WiFi
5 Up / Gallery
6Speaker
7
4
5
2
6
3
8
3
5
4
6
1
2

- 5 -
Camera from below
Camera parts:
1 Battery cover
2 Battery cover lock
Camera in waterproof housing
from front left
Case parts:
1 Down / WiFi
2 Up / Gallery
3 Shutter / Conrm
4Power / Mode
5 Waterproof case door lock
6Lens
12
6
4
3
2
1
5

- 6 -
Waterproof case
Pole mount
Frame for use without waterproof case
J mount
Charger
Fast plug-in
Quick clip mount
Self-adhesive mount, straight (2pcs)
3-axis connector (3 parts)
Tripod adapter
Accessories
Tripod screw adapter
Universal straps with hook and loop fastener
3M replacement pads
USB cable
Li-ion battery (2 pcs)
Replacement door
Cable ties
Wire rope sling
Microbre cloth
User manual

- 7 -
Camera assembly

- 8 -
Using the LAMAX ACTION X6 camera
1. Inserting the Micro SD card
The Micro SD card can be inserted into or removed from the SD card slot when the
camera is o and not connected to a computer.
Note: Use only a high-quality Micro SDHC cards. Cards produced by unveried
manufacturers are not guaranteed to function properly.
2. Installing the battery
a. Press down on the battery cover lock and remove the battery cover.
b. Insert the battery (connector end rst) into the compartment so that the connectors
are on the correct side.
c. Reattach the battery cover and secure it with the lock.
3. Charging
a. The camera can be charged by connecting it to a computer or using the AC adapter.
b. In the car you can charge the camera using the car charger plugged into the
cigarette lighter.
c. Whilst charging it is still possible to take pictures or shoot video (except when being
charged via PC).
d. The camera can also be charged whilst switched o.
4. Turning the camera ON and OFF
a. To turn the camera ON press the“Power”button.
b. To turn the camera OFF press and hold the“Power”button for 3-5 seconds.
5. Switching modes
Pressing the “Mode”button allows you to switch between modes: Video / Single shot /
Burst / Self-timer (time-lapse) / Menu. The mode icon appears at the top of the screen.

- 9 -
6. Shooting video and taking photos
a. Shooting video
Set the camera mode to Video and press the “Shutter” button. A recording animation
appears and starts to count down the recording time. To stop recording press“Shutter”
button. The status bar displays the video camera icon and status information.
b. Taking photos in various modes
- Single shot: Set the camera to “Single shot” mode and press the “Shutter” button.
This will take a photo. You can immediately take another photo by pressing“Shutter”
button again.
- Burst: Set the camera to “Burst” mode and press the “Shutter” button. This will take 3
photos in 1 second. Once completed, it is possible to perform further actions.
- Self-timer: Set the camera to “Self-timer (time-lapse)” mode and press “Shutter”
button. Once pressed it will begin counting down the time that you have set for the
self-timer (setting“photo interval”). Once completed, it is possible to perform further
actions.
- Time-lapse: Set the camera to “Self-timer (time-lapse)” mode and press the “Shutter”
button. Once pressed it will begin to take photos at the set interval (setting “photo
interval”). The setting “time-lapse” must be turned ON for the camera to take photos
repeatedly. To stop taking photos press the“Shutter” button again.
7. Viewing camera media
a. Access the gallery by pressing the “Gallery” button. Using “Down” select whether
you want to view videos or photos and conrm your selection by pressing“Conrm”.
You can browse the gallery by using the“Up”and“Down”buttons. To exit the gallery
press“Mode”and then“Gallery”.
b. Connect the camera to a computer via USB.
c. Remove the Micro SD card and insert it into a card reader.
d. Connect via WiFi to a device equipped with a WiFi receiver.

- 10 -
8. Setting up the device
Go to settings by pressing the “Mode” button. Conrm entry into the settings menu
by pressing“Conrm”.
a. Video resolution: Choose 1920 x 1080 at 30 fps or 1280 x 720 at 60 fps.
b. Loop recording: Turn loop recording ON or OFF. When switched ON, this function
enables continuous recording, meaning that once the SD card is full it will
automatically begin overwriting the oldest unlocked recordings.
c. Date stamp: Enable or disable the date and time of the recording.
d. Exposure: Set exposure in the range of -2 - +2 at intervals of 1/3.
e. Photo resolution: Can be set at 12 MP - 4000 x 3000, 8 MP - 3264 x 2448,
5 MP – 2560 x 1920 or 2 MP - 1920 x 1080.
f. Burst: When pressing the“Shutter”in this mode the camera takes 3 shots in 1 second.
g. Photo interval: Set the interval between photos (2, 3, 5, 10, 20, 30, 60 s).
h. Time-lapse camera: Enable and disable time-lapse camera mode. If it is disabled the
“Self-timer (time-lapse)” mode will function as a self-timer (i.e. it will take a photo
after the time set in the “photo interval” settings). If it is enabled it will begin to
repeatedly take photos at the selected interval. To stop taking photos press
“Shutter”.
i. Network frequency: Select a frequency in accordance with the grid frequency (on
the European continent the network stream is kept at a frequency of 50 Hz, in the
Americas and parts of Asia it is 60 Hz).
j. Language: Set the language on the device.
k. Date and time: Set the date and time on the device. You can also change the format
of the data displayed.
l. Sounds: Disable shutter and button sounds, select the welcome tune and select the
sound volume.
m. Display rotate: Rotate the image display by 180°.

- 11 -
n. LCD OFF: Auto power OFF the display when idle for 1, 3 or 5 min.
o. Auto power OFF: Auto power OFF the device when idle for 1, 3 or 5 min.
p. Format: Format the Micro SD card.
q. Factory settings: Restore the device to factory settings. Once conrmed this cannot
be undone.
r. Version: Display the rmware version of the device.
9. WiFi connection
The camera can be connected via WiFi to your computer or mobile device running
Android or iOS by following these instructions:
a. Install iSmart DV onto your computer or mobile device (the app can be found on
Google Play for Android devices or in the App Store for iOS devices).
b. Turn on the camera and activate WiFi by pressing “WiFi”button.
c. Activate WiFi on your mobile device. The camera WiFi connection is listed under
“LAMAX ACTION X6”. The password for the connection is 1234567890.
d. Once connected, you can use the application to control the camera or browse the
recorded data.
10. Additional camera functions
a. Take a photo whilst recording video: While shooting video, you can simply take
a photo at any time by pressing the“Up” button.
b. Speed Dial mode: Holding the “Shutter” for 2 seconds displays the dierent modes.
Navigate to the desired mode using the “Up” and “Down” keys and press “Conrm”
to select.

- 12 -
LAMAX ACTION X6 Action Camera parameters
LCD 1.5 inch LTPS
Lens A+++ HD wide-angle lens with a range up to 170°
Languages
Czech, English, German, French, Italian, Russian, Spanish,
Chinese Traditional, Chinese Simplied, Japanese,
Portuguese, Polish, Indonesian, Korean
Video resolution 1920 x 1080 at 30 fps, 1280x720 at 60 fps
Video format MOV
Photo format JPG
Video codec H.264
Photo resolution options 12 MP – 4000x 3000, 8 MP – 3264 x 2448,
5 MP – 2560 x 1920, 2 MP – 1920 x 1080
Photo modes Single shot / Burst (3/s) / Self-timer (2, 3, 5, 10, 20, 30, 60 s) /
Time-lapse (2, 3, 5, 10, 20, 30, 60 s)
Network frequency 50 Hz / 60 Hz
USB devices Micro USB 2.0
Storage compatibility Micro SDHC up to 32 GB
Connectivity WiFi, Micro USB 2.0, HDMI
Battery Capacity 900 mAh
Battery life Full HD video 1080p / cca. 90 minutes
Charging time cca. 3 hours
Compatible operating
systems
Windows XP / Vista / 7 / 8
MacOS
Camera dimensions 59 x 41 x 24,5 mm
Weight 63 g
Note: These specications are subject to change in the event that parts of the camera have been
replaced or the device software has been updated.

- 13 -
Other information
1) For households: This marking indicates that this product should not be disposed with other
household wastes throughout the EU. To prevent possible harm to the environment or human
health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable
reuse of material resources. To return your used device, please use the return and collection
systems or contact the retailer where the product was purchased. They can take this product for
environmental safe recycling. In case of incorrect disposal of this kind of wastes user can be ned
according to national laws. User information for disposal of electric and electronic devices in
countries outside the EU: The symbol stated above (crossed recycle bin) is valid only in countries
in European Union. For correct disposal of electric and electronic devices ask your city hall or
distributor of these devices. Everything is expressed by the symbol of crossed recycle bin on
product, cover or printed materials.
2)You can determine a warranty service at the place of purchase. In case of technical problems or
queries contact your dealer who will inform you about the following procedure. Follow the rules
for work with electric devices. User is not allowed to disassembly the device neither replace any
of its components. To reduce the risk of electric shock, do not remove or open the cover. In case
of incorrect setup and plug in of device you will expose yourself risk of electric shock.
Declaration of Conformity:
Hereby, MagiCam HD SOLUTIONS s.r.o., declares that all LAMAX products are in compliance with
the essential requirements and other relevant provisions of Directive 2004/108/EC. Products
are intended for sale without any restriction in Germany, Czech Republic, Slovak Republic,
Poland, Hungary and other EU countries. Products are covered for two years warranty, unless
otherwise stated. You can download the Declaration of Conformity from the website: www.
lamax-electronics.com.
Exclusive importer of LAMAX product in EU:
MagiCam HD SOLUTIONS s.r.o., Braškovská 308/15, 161 00 Praha 6
http://www.lamax-electronics.com.

- 1 -
Akční kamera LAMAX ACTION X6
Vodotěsná do 30 m
Full HD videozáznam 1920 x 1080
Fotograe vrozlišení 12 Mpx
WiFi

- 2 -
Bezpečnostní opatření
1. Kameru nevystavujte nárazům, zabraňte pádu na zem a dalším možnostem vzniku
mechanického poškození.
2. Kameru nedávejte do blízkosti objektů vytvářejících silné magnetické pole, jako
například magnety nebo elektromotory. Kameru také nedávejte do blízkosti objektů
vysílajících silné rádiové vlny, jako například antény. Silné magnetické pole, nebo
rádiové vlny mohou způsobit poškození kamery, nebo poškození pořízených
obrazových a zvukových záznamů.
3. Nevystavujte kameru působení vysokých teplot a přímého slunečního záření.
4. Používejte pouze značkové Micro SD karty. Karty neznačkových výrobců nezaručují
správné chování datového úložiště.
5. Neumísťujte Micro SD karty do blízkosti magnetického pole, nebo do míst vzniku silné
statické elektřiny. Zabráníte tím ztrátě uložených dat.
6. V případě, že dojde při nabíjení k přehřátí zařízení, tvoření kouře, nebo podezřelého
zápachu, zařízení ihned odpojte a přerušte nabíjení.
7. Během nabíjení kameru uchovávejte mimo dosah dětí. Napájecí kabel by mohl
způsobit úraz elektrickým proudem nebo dušení dítěte.
8. Kameru uchovávejte na chladném, suchém a bezprašném místě.
Úvod
Gratulujeme Vám k zakoupení videokamery LAMAX ACTION X6. Jedná se o značkový,
multifunkční produkt, který je velmi odolný proti povětrnostním vlivům. Sakční kamerou
LAMAX ACTION X6 můžete pořizovat ozvučené záznamy ve Full HD rozlišení, fotografovat
a pořízené záznamy ihned zobrazovat na LCD displeji. Odolnost kamery ji činí ideální pro
použití při potápění, jízdě na kole a dalších dopravních prostředcích, zimních sportech,
veškerých outdoorových aktivitách, a všude tam, kde je vyžadován kvalitní záznam
vnáročných povětrnostních podmínkách.

- 3 -
Akční kamera LAMAX ACTION X6 má tyto vlastnosti:
- Kompaktní rozměry.
- Je dodávána s ochranným voděvzdorným pouzdrem, se kterým se můžete potápět
do hloubky až 30 m, a máte tak možnost zachytit úžasné podmořské záběry, nebo
například záznam některého zVašich oblíbených vodních sportů.
- Obsahuje integrovaný LCD displej, na kterém si ihned můžete přehrát právě pořízený
záznam.
- Lze nahrávat video nebo pořizovat fotograe v průběhu nabíjení (nelze v případě
nabíjení prostřednictvím PC).
- Natáčí Full HD video 1920 x 1080.
- Pořizuje fotograe rozlišení až 12 Mpx.
- Čočka sširokým úhlem záběru až 170°.
- Možnost volby rozlišení videa i fotograe.
- Výběr režimů pořizování fotograí.
- Možnost nastavit expozici fotograí i videa.
- Velké množství dodávaného příslušenství, díky kterému budete moci nahrávat videa
kdykoliv a kdekoliv.
- Možnost využití jako černé skříňky vautomobilu.
- Možnost využití jako webkamery.
- Podpora Micro SDHC karet do velikosti až 32 GB.
- USB a HDMI konektivita.
- Integrované WiFi pro propojení sbezdrátovými zařízeními.
- Intuitivní používání, snadné propojení sPC, nebo chytrým mobilním zařízením.
- Uživatelsky příjemná softwarová aplikace.

- 4 -
7
4
6
8
5
2
3
3
5
4
1
2
Obrázek kamery pohled čelně zprava
Názvy odkazů na části kamery:
1 Spoušť / Potvrdit
2 Zap./Vyp. / Změna režimu
3Kontrolka akce (červená)
4HDMI port
5 Čočka objektivu
6USB port
7 Slot pro Micro SD kartu
8 Mikrofon
1
Obrázek kamery zezadu zprava
Názvy odkazů na části kamery:
1 Kontrolka provozu (červená)
2 Kontrolka nabíjení (modrá)
3LCD displej
4Dolů / WiFi
5 Nahoru / Galerie
6Reproduktor
6

- 5 -
Obrázek kamery ve vodotěsném
pouzdra zepředu zleva
Názvy odkazů na části kamery:
1 Dolů / WiFi
2 Nahoru / Galerie
3 Spoušť / Potvrdit
4Zap. / Vyp. / Změna režimu
5 Zámek dvířek vodotěsného pouzdra
6Čočka objektivu
6
4
3
2
1
5
12
Obrázek kamery zespodu
Názvy odkazů na části kamery:
1 Kryt baterie
2 Zámek krytu baterie

- 6 -
Obrázky příslušenství
Vodotěsné pouzdro
Držák na trubku
Rám pro použití bez vodotěsného pouzdra
J mount
Nabíječka
Fast plug-in
Quick clip mount
Samolepící držák rovný (2 ks)
3-axis connector (3 části)
Adaptér na stativ
Stativová redukce
Univerzální pásky se suchým zipem
Náhradní 3M podložky (2 ks)
USB kabel
Li-ion baterie (2 ks)
Náhradní dvířka
Stahovací pásky
Ocelové lanko
Utěrka z mikrovlákna
Uživatelská příručka
