LAMAX Dots1 User manual

EN - User Guide
Dots1
1 2 3
1 Charging Station
2 Charging Station LED indicator
3 Multi-function button with LED indicator
Controls
On / O Press and hold the multi-function button
Play / Pause Press the multi-function button
Next Track Press the multi-function button twice
Accept / End Call Press the multi-function button
Reject Call Press the multi-function button twice
Turn On / O
Siri or Google
Assistant
While playing music or in standby mode press and
hold the multi-function button on the left earphone
for one second
LED Indicators
Charging station
Charging station charge status:
0-25% Blue LED ashes once every 2 seconds
25-50% Blue LED ashes twice every 2 seconds
50-75% Blue LED ashes 3 times every 2 seconds
75-100% Blue LED ashes 4 times every 2 seconds
When fully charged, the blue LED lights up.
Earphones
Pairing White and blue LEDs on the earphones ash
alternately
Successful pairing Blue LED on the earphones ashes once every 7
seconds
Power On Blue LED on the earphones lights up for one second
Power O White LED on the earphones lights up for one second
Charging White LED on the earphones lights up and turns o
when fully charged
Power On / O
The earphones switch on automatically when they are removed from the
charging station. A blue LED lights up for one second on the earphone and
a beep sounds.
When switched on, the earphones automatically connect to each other.The left
earphone functions as the "Master".
To turn o both earphones, press and hold the multi-function button on the
left "Master" earphone for 4 seconds. A white LED lights up on the earphone for
1 second and a beep sounds. The left "Master" earphone switches o and the
right earphone switches o automatically.
If you only use one earphone, press and hold the multi-function button for
4 seconds to switch it on or o.
The earphones are automatically switched o when inserted into the charging
station. The white LED on the earphones lights up until the earphones are
charged and then switches o.
If the earphones are not paired with a Bluetooth device, they switch o
automatically after 10 minutes to conserve battery power.

Pairing
The distance from your device to the earphones should not exceed one metre
when pairing.
Pairing both earphones
1. Take the earphones out of the charging station and remove the protective
labels. The earphones automatically connect to each other and a "Left
channel / Right channel" voice message is heard.
2. Press and hold the multi-function button on both earphones for 2 seconds at
the same time. The earphones switch on and automatically connect to each
other. After connecting, the left "Master" earphone goes into pairing mode.
Pairing mode is indicated by alternate ashing of the white and blue LEDs on
the earphones. The right earphone is in standby mode and the blue LED on
it ashes once every 7 seconds. Activate Bluetooth on your device and set up
a new Bluetooth device. Select "LAMAX Dots1" from the list of found devices.
After successful pairing, a beep sounds. When the second earphone is paired
automatically, you hear the notication "Second device connected".
If the pairing of the earphones has not worked properly, please turn o both
earphones. Then press and hold the multi-function button on both earphones
for 4 seconds until the white and blue LEDs ash alternately. The earphones
automatically connect to each other and the blue LED ashes twice every
2 seconds. The "Left channel / Right channel" voice message is heard. Continue
from step 2.
Pairing one earphone
To turn on the earphone, press and hold the multi-function button for
4 seconds until the beep sounds and the white and blue LEDs ash alternately.
Activate Bluetooth on your device and set up a new Bluetooth device. Select
"LAMAX Dots1" from the list of found devices.
After successful connection, the blue LED ashes once every 7 seconds.
Charging
To charge using the charging station, connect the cable to the Micro USB port
on the back of the charger and plug the other end of the cable into a USB power
supply with a maximum voltage of 5V. The ashing blue LED on the charging
station indicates its charging status. At full charge, the blue LED lights up.
The charging time for the earphones is approximately 2 hours. The white LED
on the earphones remains on until the earphones are charged and switches o
when they are fully charged. When removing the earphones from the charging
station while charging, the earphones automatically switch on.
Main Features
- Cable-free, wireless transfer via Bluetooth 4.2
- Automatic pairing between earphones
- Lightweight earbuds with minimalistic "invisible" design
- Pure, rich sound across the entire frequency range
- Ability to charge the battery while in motion using the charging station
- Handsfree calling
- Control music and calls directly on the earphones
- 3 earplug sizes and ear hooks come as part of the package
Parameters
Wireless technology Bluetooth 4.2
Maximum pairing distance up to 10 metres
Battery in earphones 100 mAh LiPo
Battery in charging station 520 mAh LiPo
Earphone charging time about 2 hours
Playback time up to 6 hours
Standby mode up to 150 hours
Earphone dimensions 16 x 21 x 25 mm
Earphone weight 4.2 g
Weight with charging station 49.3 g
The current version of user guide can be downloaded from here:
http://beat.lamax-electronics.com/Dots1/manuals
