Laminvale FR02-C Product information sheet

1
Model# FR02-C
Item# F160072
ASSEMBLY INSTRUCTIONS AND SAFETY GUIDE
100 /16
Type of gas: Butane
Nominal heat input: 16.5 kW
Gas consumption: (G30)-1201 g/h
E, G, CY, CZ, DK, EE, FI, FR, G , GR, HR, HU, IT, LT, LU, LV, MT, NL, NO, RO, SE, SI, SK, TR:
Cat. I3 /P(30) = utane, Propane and their mixtures at 30mbar, Injector: 2.09mm
“Only nationally approved hose and regulator corresponding to the appliance category and pressure must
be used ”
This manual is for: GB
PIN.: 100 CR2974

2
1
ASSEMBLY AND USER INSTRUCTIONS
Your new Fire Table #FR01 is made from the highest quality and eco-friendly materials, and produced under
strict manufacturing controls.
Please read the Instructions for assembly before commencing, and follow the instructions for use carefully. We
congratulate you on your decision to buy this outdoor gas fire pit and wish you great fun when warming with it.
IMPORTANT SAFETY INSTRUCTIONS
1. Please change the gas bulb in a amply ventilated area, away from any ignition source (candle, cigarettes,
other flame producing appliances, ...
2. Please check that the regulator seal is correctly fitted and able to fulfill its function.
3. Do not obstruct the ventilation holes of the bulb housing.
4. Please close the gas supply at the valve of the gas bulb or the regulator after use.
5. In the event of gas leakage, the appliance shall not be used or if alight, the gas supply shall be shut off and
the appliance shall be investigated and rectified before it is used again.
6. Please checking the tubing or the flexible hose at least once per month and each time the bulb is changed.
If it shows signs of cracking, splitting or other deterioration it shall be exchanged for new hose of the same
length and of the equivalent quality.
7. Please check the gas leakage with soap water, do not use a fire.
8. The appliance area must be kept clear and free from combustible materials, gasoline, and other flammable
vapors and liquids.
9. Do not use this appliance if any part has been under water. Immediately call a qualified service technician
to inspect the appliance and to replace any part of the control system and any gas control that has been
under water.
10. Children and adults should be alerted to the hazards of high surface temperatures and should stay away to
avoid burns or clothing ignition.
11. Young children should be carefully supervised when they are in the area of the appliance.
12. Clothing or other flammable materials should not be hung from the appliance or placed on or near the
appliance.
13. Any guard or other protective device removed for servicing the appliance shall be replaced prior to
operating the appliance.
26 FOR OUTDOOR USE ONLY
1. Read the instructions before using the appliance.
2. Warning: Accessible parts may be very hot, keep young children away.
3. Close the valve of the gas bulb or the regulator after use.
4. For use outdoors and in well ventilated areas.
5. The use of this appliance in enclosed areas can be dangerous and is PROHIBITED.
6. The appliance must be installed in accordance with the instructions and local regulation.
7. A well ventilated area must have a minimum of 25% of the surface area open. The surface
area is the sum of the walls surface.

3
14. Installation and repair should be done by a qualified service person. The appliance should be
inspected before use and at least annually by a qualified service person. More frequent cleaning may be
required as necessary. It is imperative that the control compartment, burners, and circulating air
passageways of the appliance are kept clean.
15. DO NOT burn solid fuels in this appliance.
16. This outdoor gas appliance is intended for warming purpose.
17. This outdoor gas appliance is for Outdoor Use ONLY.
18. This outdoor gas appliance is not intended to be installed in or on recreational vehicles and/or boats.
19. This outdoor appliance is not for use on wood decks or other flammable surface.
20. efore each use of this gas appliance, open the door and/or the Gas Tank Drawer and inspect the hose. If
there is evidence of excessive abrasion or wear or if the hose is damaged, the hose assembly must be
replaced prior to the appliance being put into operation. Use only the replacement hose assembly specified
in this manual. Make sure to leak test.
21. efore each use of this gas appliance, inspect the burner. The burner must be replaced prior to the
appliance being put into operation if it is evident that the burner is damaged. Use only the replacement
burner specified in this instruction.
22. Make sure to properly locate the gas hose including locating the hose out of pathways where people may
trip over it or in areas where the hose may be subject to accidental damage.
23. Keep the fuel supply hose away from any heated surface.
24. Never use this appliance closer than 3 meters from anything flammable, including houses or overhead
tree branches.
18. Never use gasoline, kerosene, or any other liquid fuel to start a fire.
19. Always maintain a safe distance from the fire.
20. Always supervise children around the fire.
21. Never leave a fire unattended.
22. The appliance is hot during and after use, always allow ample cooling time before touching or moving.
23. When first use, preheat the lava rocks for 15 minutes to burn out the impurities and air in the natural lava
rocks.
WARNING
1. Read the instructions before installation and use
2. This appliance must be installed and the gas bulb stored in accordance with the regulations in force
3. Do not obstruct the ventilation holes of the bulb housing
4. Do not move the appliance when in operation
5. Shut off the valve at the gas bulb or the regulator before moving the appliance
6. The tubing or the flexible hose must be changed within the prescribed intervals
7. Use only the type of gas and the type of bulb specified by the manufacturer
8. In case of violent wind particular attention must be taken against tilting of the appliance
9. Keep the instructions for future reference
10. For use outdoors or in amply ventilated areas
11. An amply ventilated area must have a minimum of 25 % of the surface area open.
12. The surface area is the sum of the walls surface
13. e careful, accessible parts may be very hot. Keep away from young children

4
SPECIFICATIONS
The gas fire pit, with gas type I3 /P(30), is designed to operate on utane or Propane or their mixtures at 30mbar.
Gas consumption, prefssures and injectors orifice sizes are listed in the below table.
Appliance category Injector Orifice Nominal Heat Input (Hs) Gas Consumption (G30)
I3B/P(30) 2.09 mm 16.5 kW 1201 g/h
DO NOT use this appliance with an adjustable regulator. We suggest you use this appliance with a 7 kgs
utane gas bulb.

5
Part List
No. Description Q’TY No. Description Q’TY
01 Lava rock (6 kgs) 1 pkg 14 Electrode 1
02 urner 1 15 Washer 6
03 Thermocouple 1 16 olt (M6 x 25) 4
04 Regulator 1 17 Nut (M6) 13
05 Gas valve 1 18 olt (M6 x 10) 5
06 Control knob 1 19 olt (M5 x 8) 1
07 Pulse ignition system 1 20 Nut (M5) 1
08 attery 1 21 Fire bowl 1
09 Control panel 1 22 Fire pit body 1
10 Corrugated pipe 1 23 Foot glider 4
11 Injection orifice 1 24 Weather cover 1
12 Grounding wire 1
13 Pilot box 1
ASSEMBLY INSTRUCTIONS
1. Carefully unpack all parts from the box, compare parts with package content listed above, make sure all
parts are present before beginning assembly of product. If any part is missing or damaged, do not attempt
to assemble the product. Contact customer service for replacement parts.
2. Put the Lava rock (Part# 01) around the burner until lava rocks are just over the top of the burner, see
Figure 1. A gas fire pit requires 6 kg lava rock. NOTE: DO NOT completely cover the burner element or
block the pilot box with the lava rocks. When the first use, preheat the lava rocks for 15 minutes to
burn out the impurities and air in the natural lava rocks.
WARNING: keep children away during assembly, as this item contains lava rock, which are small
pieces and can be swallowed by children.

6
Figure 1
3. Clip directly the gas regulator onto the manifold inlet fitting, NOTE the fire and gas cylinder must have
minimum distance of 40cm, see Figure 2.
40cm
Figure 2
4. Please use a flexible hose with a length less than 150cm.
5. Please use a regulator complied with standard EN12864.
6. Cover the fire pit with the outdoor weather cover when not in use to protect it from the elements or when
fire pit is cool COMPLETELY after the use, see Figure 3.
Figure 3
lava rock
pilot box
w
eather cover

7
BATTERY
Make sure the control knob is in the “OFF” position. Unscrew the push button cap on the igniter module located
on the control panel to access the battery compartment. The igniter module requires one AAA size battery.
WARNING:
1. Please observe proper polarity and use the correct battery type when placing or replacing the battery.
Improper installation could result in ignition failure.
2. Please remove the battery if consumed or if product is to be left unused for a long period of time.
LEAK TEST
To prevent fire or explosion hazard when testing for a leak:
1. Always perform the leak test as described below before lighting this appliance or each time the gas bulb is
connected for use.
2. Do not smoke or allow other sources of ignition in the area while conducting a leak test.
3. Conduct the leak test outdoors in a well-ventilated area.
4. Do not use matches, lighters or a flame to check for leaks.
5. Do not use this appliance until any and all leaks are corrected. If you are unable to stop a leak, disconnect
the propane supply. Call a gas appliance service shop or your local propane gas supplier.
To perform a leak test:
1. Make 2~3 oz. of leak solution by mixing one part liquid dishwashing detergent and three parts water.
Noted: make sure control knob is “OFF”.
2. Apply several drops of solution on each connection and check for bubbles.
3. If NO bubbles appear, the connection is secure.
4. If bubbles appear, the connection has the leak, disconnect the part, reconnect, perform another leak check.
5. If you continue to see bubbles after several attempts, the part is defective and should replace the part.
LIGHTING INSTRUCTIONS
1. Push in gas control knob slightly and turn to “OFF”.
2. Turn gas control knob the “ON/MIN”.
3. Push in gas control knob all the way and hold. Continue to press the ignition button for 15 seconds.
4. If the burner does not light in 15 seconds, release the knob and it will pop back out. Wait 5 minutes before
attempting to light the burner again, repeat step 1 to 3.
TO TURN OFF GAS
1. Push in gas control knob slightly and turn to “OFF”.
WARNING: For your safety, read and follow the Lighting Instructions in this manual and in the Rating Plate
on the appliance. IMPROPER LIGHTING PROCEDURES COULD RESULT IN A FIRE HAZARD OR
EXPLOSION HAZARD OR PROPERTY DAMAGE, INJURY OR LOSS OF LIFE.

8
CARE AND MAINTENANCE
To enjoy the outstanding performance from your fire pit, make sure you perform the following activities on a
regular basis:
1. Use warm soapy water for cleaning. Never use flammable or corrosive cleaning agents.
2. While cleaning the fire pit, make sure to keep the area around the burner dry at all times. DO NOT
submerge the control valve assembly. If the gas control is submerging in water, DO NOT use it. It must be
replaced.
3. Air flow must be unobstructed. Keep controls, burner, and circulating air passageways clean. Signs of
possible blockage include:
(1). Gas odor with extreme yellow tipping of flame.
(2). Fire pit does NOT reach the desired temperature.
(3). Fire pit flame is excessively uneven.
(4). Fire pit makes popping noises.
(5). Spiders and insects can nest in burner or orifice. This dangerous condition can damage fire pit and
render it unsafe for use. Clean burner holes by using a heavy-duty pipe clearer. Compressed air may
help clear away small particles.
4. Carbon deposits may create a fire hazard. Clean burner with warm soapy water if any carbon deposits
develop.
5. Cover your fire pit with an outdoor weather cover when not in use to protect it from the elements.
NOTE: Always allow fire pit to cool COMPLETELY before you cover the fire pit with an outdoor weather cover
or you attempt the service or maintenance.

9
WARRANTY
Firepits
urner, cast aluminum & steel fire pit bowls, all mechanical parts and fittings to control panel and burner
assembly, and all aluminum fire pit tops that are not cast aluminum are warranted for a period of one (1) year
from original date of purchase, against defects in material and or workmanship. Rust is not covered.
Frames
Frames are warranted to be free from defects in materials and workmanship for a period of one (1) year.
Damage to frames or welds due to improper assembly or exposure to water and sub-freezing temperatures, is
not covered. reakage that is a result of product being dropped, acts of God, acts of war, etc. are not covered.
Finish
The finish is warranted against peeling, cracking, or blistering for a period of one (1) years provided the product
has not been scratched or abraded. Scratches and chips resulting from normal wear and tear are not covered.
Fading resulting from exposure to elements is not covered. Stains as a result of chemical spills and certain
food items are not covered.
Table Tops
All table tops are warranted for a period of one (1) year from original date of purchase, against defects in
material and or workmanship. reakage, discoloration, staining, and or any other weather related issues are
not covered.
Warranty Exclusions
Failure caused by unreasonable or abusive use. Fire pits that were clearance items, display models or items
purchased in an "as is" condition, freight damage, fire pit damaged by acts of nature, vandalism, fire, abuse,
lack of proper care and maintenance, or improper assembly; straps and normal fading or discoloration from
exposure to elements, oils, spills, fluids or chemicals; Table top against breakage; hardware against corrosion
or rusting; buckling or splitting of tubing resulting from exposure to water and freezing temperatures; glass
table tops, purchased or replacement parts; plastics. Also excluded: loss of use of time and or inconvenience,
money, travel, packaging or any other consequential or incidental damages. In no event shall Foremost Groups
Inc. responsibility exceed the value of the replacement product. Warranty is to the original purchaser when
items are purchased from one of our authorized retailers and is not transferable. All warranty claims must be
submitted with a dated register receipt within the warranty period. Should replacement of the warranted item be
unavailable, Foremost Groups Inc. reserves the right to substitute items of our choice similar in style, color and
quality. For quality control purposes and verification, we reserve the right to request photographs of the
damage item(s). The terms of this warranty are subject to change without notice.
Produced on behalf of:
Laminvale Ltd.
arkestone Lane, ottesford, Nottingham,
NG13 ODH, UK
Phone: [phone]
Fax: [phone]
E-mail: [e-mail]
