User & Installation Guide
HJA6853
50/50
Integrated Fridge/Freezer

12
Congratulations on your choice of a LAMONA quality Appliance which has been designed to give you
service for many years.
WARNING !
IMPORTANT !
DO NOT connect your appliance to the electricity supply until all packing and transit protectors have been
removed.
•Leave to stand for at least 4 hours before switching on to allow compressor oil to settle if transported
horizontally.
•If you are discarding an old refrigerator with a lock or latch fitted to the door, disable the lock/latch,
ensure that it is left in a safe condition to prevent the entrapment of young children.
• This fridge/freezer must only be used for its intended purpose i.e the storing and freezing of edible
foodstuff.
•Do not dispose of the appliance on a fire. At L A M O N A , the care and protection of our environment
is an ongoing commitment. This appliance which is among the latest range introduced is particularly
environment friendly. Your appliance contains non CFC / HFC natural substances in the cooling
system (Called R600a) and in the insulation (Called cyclopentane) which are potentially flammable
if exposed to fire. Therefore, take care not to damage, the cooling circuit / pipes of the appliance in
transportation and in use. In case of damage do not expose the appliance to fire, potential
ignition source and immediately ventilate the room where the appliance is situated.
• We suggest you contact your local authority for disposal information and facilities available.
• We do not recommend use of this appliance in an unheated, cold room.
(E.g.: garage, conservatory, annex, shed, out-house etc.) See Installation Instructions on page 5
for further information.
•To obtain the best possible performance and trouble free operation from your appliance it is very
important to carefully read these instructions.
• Ensure that the plug remains readily accessible. Do not use multiple adapter bar.
•Failure to observe these instructions may invalidate your right to free service during the guarantee
period.
• Route electrical supply cord to allow easy connection and disconnection after installation.
• We recommend a separate switch be employed to ensure easy switch on / off.
WARNING - Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of
obstruction.
WARNING - Do not use mechanical devices or other means to accelerate the defrosting process, other than
those recommended by the manufacturer.
WARNING - Do not damage the refrigerant circuit.
WARNING - Do not use electrical appliances inside the food storage compartments of the appliance, unless
they are of the type recommended by the manufacturer.
• We suggest you keep these instructions in a safe place for easy reference.
• This appliance is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.
• Children should be supervised to ensure that they
do not play with the appliance.
C O N T E N T S P A G E
SAFETY FIRST / ELECTRICAL REQUIREMENTS
TRANSPORTATION INSTRUCTIONS
INSTALLATION INSTRUCTIONS - GUIDELINES
GETTING TO KNOW YOUR FRIDGE / FREEZER
SUGGESTED ARRANGEMENT OF FOOD IN THE FRIDGE / FREEZER
TEMPERATURE CONTROL AND ADJUSTMENT
STARTING
STORING FROZEN FOOD
FREEZING FRESH FOOD
MAKING ICE CUBES
DEFROSTING
CLEANING AND CARE
REPLACING THE INTERIOR LIGHT BULB
DO'S AND DON'TS
ENERGY SAVING TIPS
PROBLEM SOLVING
INSTALLATION INSTRUCTIONS - DETAILED STEP BY STEP
INSTRUCTIONS
REVERSING THE DOORS
GUARANTEE DETAILS
HOW TO OBTAIN SERVICE
3
4
5
6
7
8
9
9
10
10
11
13
14
15
16
16
17-23
24-25
26
27

FITTED WITH
BS 1362 13A FUSE ALWAYS
FIT BS 1362 REPLACEMENT
CARTRIDGE FUSE
GREEN &
YELLOW
OR
GREEN
N
BLUE
OR
BLACK
L
BROWN
OR
RED
22mm.
6mm.
6mm.
6mm. 32mm.
12mm.
FUSE
CORD GRIP
T R A N S P O R T A T I O N I N S T R U C T I O N S
1 . The appliance should be transported only in a vertical upright position. The
packing as supplied must be intact during transportation.
2 . If during the course of transport the appliance has to be transported
horizontally, it must only be laid on its left hand side when standing in the front
of the appliance. After bringing it to upright position,it must not be operated
for at least 4 hours to allow the system to settle.
3 . Failure to comply with the above instructions could result in damage occuring
to the appliance. The manufacturer will not be held responsible if these
instructions are disregarded.
4 . The appliance must be protected against rain, moisture and other
atmospheric influences.
5 . When positioning your appliance take care not to damage your flooring,
kitchen furniture, related parts and doors, pipes, wall coverings etc. Do not
move the appliance by pulling the door.
6 . Empty any water in the drain tray before moving. See section ‘Defrosting’ and
‘Care & cleaning’ for further information.
7 . Make sure that the defrosted water pipe at the back of the product is fixed to
the plastic evaporating pan on the top of the compressor, to avoid defrosted
water spillage on the floor.
I M P O R T A N T : Care must be taken while cleaning / carrying the appliance to
avoid touching the bottom of the condenser metal wires at the back of the
appliance as you might injure your fingers and hands.
Do not attempt to sit or stand on top of your appliance as it is not designed for
such use. You could injure yourself or damage the appliance.
" I M P O R T A N T : Make sure that mains cable is not caught under the appliance
during and after carrying / moving the appliance, to avoid the mains cable
becoming cut or damaged."
Do not allow children to play with the appliance or tamper with the controls.
L A M O N A declines to accept any liability should the instructions not be followed.
• This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning use
of the appliance by a person responsible for their safety.
• Children should be supervised to ensure that they do not play with the appliance.
43
ELECTRICAL REQUIREMENTS
Before you insert the plug into the wall socket make sure that the voltage and the
frequency shown in the rating plate inside the appliance corresponds to your
electricity supply.
Rating label is on the left hand side of fridge inner liner.
We recommend that this appliance is connected to the mains supply via a
suitable switched and fused socket in a readily accessible position.
Should the mains lead of the appliance become damaged or should it need
replacing at any time, it must be replaced by a special purpose made mains lead
which can only be obtained from a L A M O N A Authorised Service Agent.
W A R N I N G ! T H I S A PP L I A N C E M U S T B E E A R T H E D
If the fitted moulded plug is not suitable for your socket, then the plug should be
cut off and an appropriate plug fitted. Destroy the old plug which is cut off as a
plug with bared cord could cause a shock hazard if inserted into a socket
elsewhere in the house.
The moulded plug on this appliance incorporates a 13 A fuse. Should the fuse
need to be replaced an ASTABEAB approved BS 1362 fuse of the same rating
must be used. Do not forget to refit the fuse cover. In the event of losing the fuse
cover the plug must not be used until a replacement fuse cover has been fitted.
Colour of the replacement fuse cover must be the same colour as that visible on
the pin face of the plug. Fuse covers can be obtained from a L A M O N A authorised
service agent.
I M P O R T A N T ! F I TT I N G A D I FF E R E N T P L U G
As the colours of the wires in the
mains lead of this appliance may
not correspond with the coloured
markings identifying the terminals
in your plug proceed as follows:
(See diagram).
1 . Connect the green-yellow or
green (Earth) wire to the terminal
in the plug marked 'E' or with
the symbol or coloured
green and yellow or green.
2 . Connect the blue (Neutral) wire
to the terminal in the plug
marked 'N' or coloured black.
3 . Connect the brown (Live) wire to
the terminal in the plug marked 'L'
or coloured red.
With alternative plugs a 13 A fuse must be fitted either in the plug or adaptor or
in the main fuse box.
If in doubt contact a qualified electrician.

56
G E TT I N G T O K N O W Y O U R C O M B I F R I D G E / F R EE Z E R
4 . Do not place the appliance near cookers, radiators or in direct sunlight as this
will cause your appliance to work harder. If installed next to a source of heat
or freezer, maintain the following minimum side clearances:
From Cookers 50 mm (2")
From Radiators 300 mm (12")
From Freezers 25 mm (1")
A special receptacle is supplied to store the mains plug during transit.
The receptacle is fixed at the back of the
cabinet, on the side of the compressor.
(See diagram) Gently remove the plug
from the receptacle. Never pull the
mains cord, you may damage the
appliance. In the case of transportation,
ensure you locate the plug in the receptacle
provided to avoid transit damage.
5 . Refer to cleaning and care section to prepare your appliance for use.
6 .
I M P O R T A N T
I N S T A LL A T I O N I N S T R U C T I O N S
1 . The space in the room where the appliance is installed must not be smaller
than 10 cubic metres.
2 . See pages 17 to 24 for detailed Installation Instructions including reversing
door opening direction.
3 . Do not put your fridge freezer in a cold room where the temperature is likely
to go below +5 degrees C (41 degrees F) during night time and/or especially
in winter.
This fridge freezer has been designed to operate in ambient temperatures
between +5 and +32 degrees C (41 and 90 degrees F) Therefore if the
appliance is installed in an unheated/cold room (eg: conservatory/annex/
shed/garage etc) then the appliance will not operate causing the freezer
compartment to run warmer and as a result the storage time of frozen food
may be reduced.
DEFROST WATER
COLLECTION CHANNEL
EGG TRAY
SALAD
CRISPER
CABINET SHELVES
THERMOSTAT KNOB
INTERIOR LIGHT
DOOR
SHELF
BOTTLE
SHELF
FROZEN FOOD
COMPARTMENTS
FAST FREEZE
COMPARTMENT

SUGGESTED ARRANGEMENT OF FOOD IN THE FRIDGE/FREEZER
Arrangement Examples (See diagram)
1. Baked, chilled cooked food,
dairy products, cans.
2. Meat, sausages, cold cuts.
3. Fruit, vegetables, salads.
4. Frozen food and
freezing of fresh food.
5. Frozen food.
6. Butter, cheese.
7. Small bottles, cans, tubes.
8. Eggs.
9. Tall, large bottles, beverages.
TEMPERATURE CONTROL AND ADJUSTMENT
Operating temperatures are controlled by the thermostat knob (see diagram) located
on the ceiling of fridge compartment. Settings may be made from 1 to 5, 5 being
the coldest position.
When the appliance is switched on for the rst time, the thermostat should be
adjusted so that after 24 hours, the average fridge temperature is no higher than
+5°C (+41°F). We recommend you set the thermostat half way between the 1 and
5 setting and monitor to obtain the desired temperature i. e. towards 5 you will
obtain a colder fridge temperature and vice versa. Some sections of the fridge may
be cooler or warmer ( such as the salad crisper and the top part of the cabinet )
which is quite normal.
The normal storage temperature of the freezer should be -18°C (0°F). Lower
temperatures may be obtained by adjusting thermostat knob towards 5 position.
We recommend that you check the temperature with an accurate thermometer to
ensure that the storage compartments are kept to the desired temperature.
Remember you must take your reading very quickly since the thermometer
temperature will rise very rapidly after you remove it from the freezer.
Please remember each time the door is opened cold air escapes and the internal
temperature rises. Therefore never leave the door open and ensure it is closed
immediately after food is put in or removed.
In case of a temporary ice build up in the fridge compartment, reduce the
thermostat setting to 1, monitoring at the same time that the fridge temperature
is maximum +5 degrees C [41 degrees F]. Once the ice build up disappears
and the appliance starts auto defrosting again as normal, then you may
increase the thermostat setting, if required.
87
The following guidelines and recommendations are suggested to obtain the best
results and storage hygiene.
1. The fridge compartment is for the short term storage of fresh food and drinks.
2. The freezer compartment is rated and suitable for the freezing and
storage of pre frozen food. The recommendation for storage as
stated on the food packaging should be observed at all times.
3. Cooked dishes must be stored in airtight covered containers.
4. Fresh wrapped produce can be placed on the shelf. Fresh fruit and
vegetables should be cleaned and stored in the crisper bins.
5. Bottles can be placed in the door section.
6. To store raw meat, wrap in polythene bags and place on the lowest shelf. Do
not allow to come into contact with cooked food to avoid contamination. For
safety, only store raw meat for two to three days.
7. Keep the food packed, wrapped or covered. Allow hot food and beverages
to cool before placing them in the fridge. Do not store explosive substances.
High proof alcohol must be stored upright in sealed containers. Left over canned
food should not be stored in the can.
8. Fizzy drinks should not be frozen and products such as avoured water ices
should not be consumed too cold.
9. Some fruit and vegetables suer damage if kept at temperatures near 0°C.
Therefore wrap pineapples, melons, cucumbers, tomatoes and similar produce
in polythene bags.
10. Place chilled cooked food and similar food near the rear of the fridge inner
liner where the cold wall is located.
11. Shelves, racks, crisper bins, drawers, aps, bottle grippers are all removable.
12. Do not leave frozen food at room temperature to thaw; the best way to defrost
food is to put it in the fridge to thaw slowly. Make sure you avoid defrosting
food or food juices drip onto other food.
13. For hygiene reasons, always wrap food using a suitable packaging material
before storing in your appliance to avoid contact with the appliance surface.
6
9
3
5
2
7
1
5
5
8
4
SUGGESTED ARRANGEMENT OF FOOD IN THE FRIDGE/FREEZER
Arrangement Examples (See diagram)
1. Baked, chilled cooked food,
dairy products, cans.
2. Meat, sausages, cold cuts.
3. Fruit, vegetables, salads.
4. Frozen food and
freezing of fresh food.
5. Frozen food.
6. Butter, cheese.
7. Small bottles, cans, tubes.
8. Eggs.
9. Tall, large bottles, beverages.
1
1

S T O R I N G F R O Z E N F OO D
Prepacked commercially frozen food should be stored in accordance with the
frozen food manufacturer's instructions for a frozen food storage
compartment.
To ensure that the high quality achieved by the frozen food manufacturer and the
food retailer is maintained, the following should be remembered:
1 . Put packets in the freezer as quickly as possible after purchase.
2 . Ensure that contents are labelled and dated.
3 . Do not exceed "Use By", "Best Before" dates on the packaging.
If there is a power failure do not open the door. Frozen food should not be
affected if the failure lasts for less than 14 hrs. If the failure is longer, then the
food should be checked and either eaten immediately or cooked and then re-
frozen.
M A K I N G I C E C U B E S
Fill the ice - cube tray 3/4 full with water. Loosen frozen trays with the handle of
a spoon, never use sharp edged objects such as knives, forks.
N o t e : If freshly made ice cubes are not consumed for several weeks, they will
slowly reduce in size and eventually disappear completely.
9
S T A R T I N G
Final Check
Before you start using the fridge/freezer check that:
1 . The interior is dry and air can circulate freely at the rear of the cabinet.
2 . Clean the interior as recommended under "CLEANING AND CARE."
3 . Insert the plug into the wall socket and switch on the electricity supply.
• When the door is open the fridge interior light will come on.
4 . You will hear a noise as the compressor starts up. The liquid and gases sealed
within the refrigeration system may also give rise to noise, whether the
compressor is running or not which is quite normal.
5 . Set the thermostat knob half way between 1 and 5.
6 . Front edges of the cabinet may feel warm. This is normal. These areas are designed to be
warm to avoid condensation.
7 . " D o n o t l o a d t h e a pp li a n c e i mm e d i a t e l y i t i s s w i t c h e d o n . W a i t u n t il t h e
c o rr e c t s t o r a g e t e m p e r a t u r e h a s b ee n r e a c h e d . W e r e c o mm e n d t h a t y o u c h e c k
t h e t e m p e r a t u r e w i t h a n a cc u r a t e t h e r m o m e t e r ( s ee ; T e m p e r a t u r e C o n t r o l a n d
A d j u s t m e n t ) "
F R EE Z I N G F R E S H F OO D
Please observe the following instructions to obtain the best results.
Do not freeze too large a quantity at any one time. The quality of the food is best
preserved when it is frozen right through to the core as quickly as possible.
Do not exceed the freezing capacity of your appliance in 24 h which is 4 kg (9 lb)
Placing warm food into the freezer compartment causes the refrigeration compressor to
operate continuously until the food is frozen solid. This can temporarily lead to excessive
cooling of the refrigeration compartment.
You may place fresh food to be frozen in any part of the freezer.
T a k e s p e c i a l c a r e n o t t o m i x a l r e a d y f r o z e n f oo d a n d f r e s h f oo d .
10

D E F R O S T I N G
A ) F R I D G E C O M P A R T M E N T
The fridge compartment defrosts
automatically. The defrosting water runs
to the drain tube via a collection
container at the back of the appliance (1).
(see diagram)
During defrosting water droplets may form
at the back of the fridge compartment
where concealed evaporator is located.
Some droplets may remain on the liner and
refreeze when defrosting is completed. Do
not use pointed or sharp edged objects such as knives, forks to remove the droplets
which have frozen.
If at any time the defrosted water does not drain from the collection channel, check
to ensure that no food particles have blocked the drain tube. The drain tube can
be cleared by pushing the special plastic plunger provided down the drain tube
(2). If the frost layer reaches about 1/4"(7 mm), reduce the setting (i.e. from 4 to
1) to restart automatic defrosting.
B ) F R EE Z E R C O M P A R T M E N T
D E F R O S T I N G
Defrost twice a year or when a frost layer of around 7 mm (1/4") has formed.
To start defrosting procedure turn the thermostat knob to zero position
(Alternatively you may switch off the freezer at the socket outlet and pull out the
mains plug.)
All food should be wrapped in several layers of newspaper and stored in a cool
place (e.g. fridge or larder).
Remove all freezer drawers ( F i g 1 ) . Fold out the spout, place a tray underneath the
spout ( F i g 2 ) to collect the water.
Containers full of warm water may be placed carefully in the freezer to speed up
the defrosting.
11 12
(1)
(2)
F i g 1
F i g 2
D o n o t u s e p o i n t e d o r s h a r p e d g e d o b j e c t s s u c h a s k n i v e s , f o r k s t o r e m o v e
t h e f r o s t .
N e v e r u s e h a i r d r y e r s , e l e c t r i c a l h e a t e r s a n d o t h e r s i m il a r e l e c t r i c a l
a pp li a n c e s f o r d e f r o s t i n g .
When defrosting has finishe, dry the interior
(Fig1- 2 thoroughly. Close the freezer door. Insert the plug into the wall socket and
switch on the electricity supply. Don't forget to tape over the switch to avoid accidental
disconnection.
D r a i n T u b e
D e f r o s t e d
W a t e r
C o ll e c t i o n

R E P L A C I N G T H E I N T E R I O R L I G H T B U L B ( S ee d i a g r a m )
Should the light fail to work, proceed as follows.
1 . S w i t c h o ff a t t h e s o c k e t o u t l e t a n d p u ll o u t t h e m a i n s p l u g .
• You may find it useful to remove shelves for easy access.
2 . Use a flat tipped screwdriver to remove the light diffuser cover by inserting the
blade in the centre between diffuser and thermostat housing.
3 . First check that the bulb hasn’t worked loose by ensuring it is screwed securely
in the holder. Replace the plug and switch on. If the bulb works, replace the light
cover by pushing upwards to locate the lugs.
4 . If the light still fails to work, switch off at the socket outlet and pull out the mains
plug. Replace the bulb with a new 15 watt (max) screw cap (SES) bulb.
5 . Carefully dispose of the burnt-out light bulb immediately.
Replacement light bulb can easily be obtained from a good local electrical or DIY
store.
C L E A N I N G A N D C A R E
** We recommend that you switch off the appliance at the socket outlet and pull
out the mains plug before cleaning.
** Never use any sharp abrasive instrument, soap, household cleaner, detergent
and wax polish for cleaning.
** Use luke warm water to clean the cabinet of the appliance and wipe it dry.
** Use a damp cloth wrung out in a solution of one teaspoon of bicarbonate of
soda to one pint of water to clean the interior and wipe it dry.
** Make sure that no water enters the lamp housing.
** Excess deposits of ice should be removed on a regular basis with the handle of
a spoon. Large accumulation of ice will impair the performance of the
appliance.
** If the appliance is not going to be used for a long period of time switch it off,
remove all food, clean it and leave the door ajar.
** Check door seals regularly to ensure they are clean and free from food
particles.
** Removal of door tray
• To remove door racks, remove all the contents and then simply push the
door rack upwards from the base.
** To remove a freezer drawer, pull it as far as possible, and then tilt it upwards,
and then pull it out completely.
1413

16
D O ' S A N D D O N ' T S
Do- Clean and defrost your appliance regularly (See "Defrosting")
Do- Keep raw meat and poultry below cooked food and dairy products.
Do- Take off any unusable leaves on vegetables and wipe off any soil.
Do- Leave lettuce, cabbage, parsley and cauliflower on the stem.
Do- Wrap cheese firstly in greaseproof paper and then in a polythene bag
excluding as much air as possible. For best results take out of the fridge
compartment an hour before eating.
Do- Wrap raw meat and poultry loosely in polythene or aluminium foil. This
prevents drying.
Do- Wrap fish and offal in polythene bags.
Do- Wrap food which have a strong odour or can dry out in polythene bags,
aluminium foil or place in an airtight container.
Do- Wrap bread well to keep it fresh.
Do- Chill white wines, beer, lager and mineral water before serving.
Do- Check contents of the freezer every so often.
Do- Keep food for as short a time as possible and adhere to "Best Before",
"Use by" etc. dates.
Do- Store commercially frozen food in accordance with the instructions given
on the packets that you buy.
Do- Always choose high quality fresh food and be sure it is thoroughly clean
before you freeze it.
Do- Prepare fresh food for freezing in small portions to ensure rapid freezing.
Do- Wrap all food in aluminium foil or freezer quality polythene bags and
make sure any air is excluded.
Do- Wrap frozen food when you buy it and put it in to the freezer as soon as
possible.
Do- Defrost food in the fridge compartment.
Do- Remove ice cream from the freezer 10-20 minutes before serving.
Don't- Store bananas in your fridge compartment.
Don't- Store melon in your fridge. It can be chilled for short periods as long as it
is wrapped to avoid it flavouring other food.
Don't- Store poisonous or any dangerous substances in your appliance.
It has been designed for the storage of edible foodstuffs only.
Don't- Consume food which has been stored for an excessive time in the fridge.
Don't- Store cooked and fresh food together in the same container. They should
be packaged and stored seperately.
Don't- Let defrosting food or food juices drip onto food.
Don't- Leave the door open for long periods as this will make the appliance more
costly to run and cause excessive ice formation.
Don't- Use pointed sharp edged objects such as knives, forks to remove the ice.
Don't- Put hot food into the appliance. Let it cool down first.
Don't- Put liquid-filled bottles or sealed cans containing carbonated liquids into
the freezer as they may burst.
Don't- Exceed the maximum freezing loads (4 kg in any 24 hours) when
freezing fresh food.
Don't- Give children ice-cream and water ices direct from the freezer. The low
temperature may cause 'freezer burns' on lips.
Don't- Freeze fizzy drinks.
Don't- Try to keep frozen food which has thawed, it should be eaten within
24 hours or cooked and refrozen.
Don't- Remove items from the freezer with wet hands.
Don't- Close the freezer door before placing the compartment cover in its place.
Don’t- Leave frozen food at room temperature to thaw; the best way to defrost
food is to put it in the fridge to thaw slowly. Make sure you avoid defrosting
food or food juices drip onto other food.
E N E R G Y S A V I N G T I P S
1 - Ensure your appliance is installed in a well ventilated area. If the ambient
temperature is low (but in no case lower than 5 degrees C), then the energy
saving will be more. In this case, check temperatures of fridge and freezer
compartments with an accurate thermometer and lower the thermostat setting
(towards 1) if necessary.
2 - Ensure the time between buying chilled/frozen food and placing them in your
appliance is kept at minimum, particularly in summer. We recommend you use
a cool bag or a special carrier bag to carry frozen food.
3 - Do not leave the door (s) of your appliance open longer than necessary and
ensure they are closed properly after each opening.
4 - Defrost your appliance regularly (see "Defrosting")
5 - Defrost frozen food in the fridge compartment, so that frozen food acts as an
ice pack to assist cooling in the fridge.
P R O B L E M S O L V I N G
If the appliance does not operate when switched on, check whether:
• The plug is inserted properly in the socket and that the power supply is on. (To
check the power supply to the socket, plug in another appliance)
• The fuse has blown/circuit breaker has tripped/main distribution switch has
been turned off.
• The temperature control has been set correctly.
• New plug is wired correctly if you have changed the fitted moulded plug.
If the appliance is still not operating after the above checks, please refer to the
section on “How To Obtain Service”.
Please ensure that above checks have been made as a charge will be made if no
fault is found.
15

17 18
I N S T A LL A T I O N I N S T R U C T I O N S ( A ll d i m e n s i o n s a r e i n mm )
1
3
3
2
2
45 °
F R O N T F EE T
45 °
4
5
R E A R F EE T
45 °

19 20

21 22

23 24
R E V E R S I N G T H E D OO R S
1
23
4
5
1
0
6
7
8
9
13
11
12
16
17
15
18
2
2
14
21
2
0
2
3
19

25
G U A R A N T EE D E T A I L S
W h a t i s c o v e r e d ?
• Repairs necessary as a result of faulty materials, defective components
or manufacturing defect.
• The cost of functional replacement parts, but excluding consumable items.
• The labour costs of a L A M O N A approved repairer to carry out the repair.
W h a t i s n o t c o v e r e d ?
• Transit, delivery or accidental damage or misuse and abuse.
• Cabinet or appearance parts, including knobs, flaps, handles or container
lids.
• Accessories or consumable items including but not limited to, ice trays,
scrapers, cutlery baskets, filters and light bulbs.
• Repairs required as a result of unauthorised repair or inexpert installation
that fails to meet the requirements contained in the user instruction book.
• Repairs to products used on commercial or non-residential household
premises.
• Loss of frozen food in freezers or fridge/freezers. (Food loss insurance is
often included within your household contents insurance policy, or may
be available separately from your retailer).
I m p o r t a n t n o t e s .
• Your L A M O N A product is designed and built for domestic household use
only.
• The guarantee will be void if the product is installed or used in commercial
or non-residential domestic household premises.
• The product must be correctly installed, located and operated in accordance
with the instructions contained in the User Instructions Booklet provided.
• The guarantee is given only within the boundaries of the United Kingdom.
• The guarantee is applicable only to new products and is not transferable
if the product is resold.
• L A M O N A disclaims any liability for incidental or consequential damages.
The guarantee does not in anyway diminish your statutory or legal rights.
26
R E V E R S I N G T H E D OO R S
To change door from R/H to L/H please follow procedure below:
1. Carefully remove the lower then the upper Torx screws that hold the door to the hinges.
2. Open hinges fully then carefully remove the self tap countersunk screws holding the
hinges to the cabinet.
3. Remove the plastic covers from the L/H hinge fixing points and carefully re insert in
the R/H holes.
4. Carefully place the self tap screws into the new fixing points applying gentle pressure
until they start to bite (at this point it may help to have someone at the back of
appliance to support).
5. For ease of fixing we recommend screwing all the way in, and then ease back out.
6. Re fit hinge
7. Tighten the screws firmly.
8. Re fit door, loosely fixing the top screws first, and then fit the lower screws.
9. When all screws fitted; tighten firmly and check door for alignment.
Top Door
1.Unscrew top hinge (4).
2.Carefully remove the top door.
3.Unscrew lower hinge (6)
4.Remove plastic plugs (10 &11).
5.Refit top hinge (4) as lower hinge (14) on the left hand side.
6.Replace top door
7.Refit lower hinge (6) as top hinge (16) on the left hand side.
Lower door
1.Unscrew top hinge (7)
2.Carefully remove the lower door.
3.Unscrew lower hinge (9).
4.Remove plastic plugs (12 &13).
5.Refit hinge (7) as lower hinge (19) on the left hand side.
6.Replace lower door
7.Refit lower hinge (9) as top hinge (21) on the left hand side.
Refit plastic plugs (10, 11, 12 & 13) into the screw holes on the right hand side (17, 18, 22 &
23).
Screw the plastic fixing piece (1) to the top of the appliance.
Stick the decorative sealing strip (3) to the right hand side of the appliance.

27
Recycling This product bears the selective sorting symbol for waste electrical and electronic equipment
(WEEE).
This means that this product must be handled pursuant to European Directive 2002/96/EC
in order to be recycled or dismantled to minimize its impact on the environment.
For further information, please contact your local or regional authorities.
Electronic products not included in the selective sorting process are potentially
dangerous for the environment and human health due to the presence of hazardous
substances.
