Lamtec F300K Series User manual

www.lamtec.de
Sensors and Systems for Combustion Engineering
Manual
F300K Compact Flame Scanner

2
Table of Contents
Table of Contents
1 Important Information about the Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.1 Purpose/Applicability of the Document . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.2 Purpose . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.3 Target Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.4 Safekeeping of the Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2 General Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.1 Classification of the Safety Instructions and Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.2 Product Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.3 Product-specific Dangers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3 Product Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.1 Structure of the F300K. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.2 Basic variants. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.3 Life Cycle. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.4 Proper Use - Conditions of Use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.4.1 UL Listed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.5 Rating Plate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3.6 Selection Criteria . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.7 Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.7.1 FB30 External User Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.7.2 F300K Remote Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.7.3 Power Supply. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
3.7.3.1 Power Supplies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
3.7.3.2 FN20, FN30-20 Power Supply. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
3.7.3.3 FN30 power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3.7.4 Coupling relays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3.7.5 Adjustable Holder, Cooling-air Housings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3.7.6 FG30 connection housing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
3.7.7 Flame Scanner Testing Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
3.7.8 Connection Cable AK05. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
3.7.9 Fiber Optic. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
4 Design and Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
4.1 Design . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
4.2 Functional Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
5 User Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
5.1 Operating and display elements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
5.2 Menu tree. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
6 Commissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
6.1 Safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
6.1.1 Safety When Putting the Device Into Operation . . . . . . . . . . . . . . . . . . . . . . . . 26
6.1.2 Electrical Safety – Requirements to Be Met by Third-party Manufacturers. . . . 27
6.1.3 Special Points to Note When Using the Device in Explosion-proof Areas. . . . . 28
6.2 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
6.2.1 Prerequisite for Mounting the Device Properly . . . . . . . . . . . . . . . . . . . . . . . . . 30
6.2.2 Positioning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
6.2.3 Alignment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

3
Table of Contents
6.3 Electrical Connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
6.4 Putting the Device into Operation for the First Time . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
6.4.1 Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
6.4.2 Parameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
6.4.3 Adjusting F300K . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
6.4.4 Setting Monitoring Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
6.4.4.1 Automatic setting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
6.4.4.2 Hand optimization of the automatically determined trigger thresholds (levels) . 43
6.4.4.3 Manual setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
6.4.5 Switch-off Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
6.5 Acceptance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
7 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
7.1 Main Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
7.2 Enter Password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
7.3 Reading information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
7.3.1 Read mode 1-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
7.3.2 Reading the device setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
7.3.3 Reading the signal of the flame. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
7.3.3.1 Reading the signal values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
7.3.3.2 Signal simulator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
7.3.4 Displaying faults. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
7.3.4.1 Reading the cause of a problem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
7.3.4.2 Reading the fault history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
7.4 Automatic setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
7.5 Manual setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
7.5.1 Changing the switch-on/startup parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
7.5.2 Changing switch-off parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
7.5.3 Resetting the factory settings (up load). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
7.5.4 Save parameters (down load) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
7.5.5 Load parameters (up load) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
7.5.5.1 Load operating mode parameters (up load) . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
7.5.5.2 Device parameters load (up load) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
7.5.5.3 Transfer parameters to an other F300K. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
7.6 Changing the device settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
7.6.1 Parameterising the flame scanner. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
7.6.2 Parameterising the User Interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
7.6.3 Resetting the device parameter factory settings . . . . . . . . . . . . . . . . . . . . . . . . 73
7.6.3.1 Resetting the flame scanner factory settings. . . . . . . . . . . . . . . . . . . . . . . . . . . 73
7.6.3.2 Resetting the factory settings of the User Interface. . . . . . . . . . . . . . . . . . . . . . 74
7.6.4 Changing Password. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
7.6.4.1 Changing the level 1 password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
7.6.4.2 Changing the level 2 password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
7.7 Firmware Update . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
8 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
8.1 Maintenance Tasks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
8.1.1 Flame Scanner Testing Device replace Battery. . . . . . . . . . . . . . . . . . . . . . . . . 79
8.2 Customer Service Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
8.3 Warranty and Delivery Terms. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

4
Table of Contents
9 Repairs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
10 Correcting Faults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
10.1 Fault Finding and Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
10.1.1 Commissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
10.1.2 F300K Error Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
10.1.3 Error codes at the level of the operating unit. . . . . . . . . . . . . . . . . . . . . . . . . . . 84
10.2 Information About the Repair Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
11 Network. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
12 Decommissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
13 Disposal Notes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
14 Appendix. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
14.1 Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
14.1.1 F300K . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
14.1.2 FB30 External User Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
14.1.3 Power Pack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
14.1.3.1 FN20, FN30-20 Power Supply. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
14.1.3.2 FN30 power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
14.1.4 FG30 connection housing and FG30-21 stainless steel . . . . . . . . . . . . . . . . . 102
14.1.5 M12 - Mounting box for front / screw mounting with M16 thread. . . . . . . . . . . 105
14.1.6 Flame Scanner Testing Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
14.1.7 Connection Cable AK05. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108
14.2 Connection Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
14.2.1 F300K With Power Pack FN20, FN30. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
14.2.2 F300K With ETAMATIC, FMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
14.3 EU Declaration of Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
14.4 Order Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115

5
1 Important Information about the Manual
1 Important Information about the Manual
1.1 Purpose/Applicability of the Document
This manual enables users to handle the F300K compact flame scanner system safely and
efficiently.
The manual is valid for all F300K systems in any configuration.
The information in this document applies to software version F300K V1.3.0.0 and User Inter-
face V1.4.0.0. If you have a different version of the software, you may find that some of the
functions described are not available or that not all of the available functions are described.
The F300K system complies with the following standards and directives:
• DIN EN 298:2012
• DIN EN 60730-2-5:2015
• DIN EN 50156:2016, Section 10.5
• DINEN746-2:2011(Industrialthermoprocessingequipment–Part2:Safety requirements
for combustion and fuel handling systems)
• 2014/68/EU (Pressure Equipment Directive)
• 2009/142/EC (Gas Appliances Directive)
• EU/2016/426 Gas Appliance Regulation (GAR)
• 2014/35/EU (Low Voltage Directive)
• 2014/30/EU (EMC Directive)
• DIN EN 61508:2011, parts 1-7 (SIL 3 requirements)
• ISO/IEC 80079-34:2011 Potentially explosive areas - Quality Management System (QAR)
• 2011/65/EU (RoHS2 Directive)
• UL372
1.2 Purpose
In single-burner and multiple-burner furnaces, the flame scanner performs a high-safety mon-
itoring of the burner flame. When the flame goes out, the safe control state’ Flame ’ is reached.
The flame scanner is mainly used in large-scale power plants, thermal power stations and
chemical plants as well as for monitoring furnaces which are operated from.
– oil
– gas
– bio-mass
– dust coal
– chemicals and other waste products

6
1 Important Information about the Manual
1.3 Target Group
These instructions must have been read carefully and completely before commencing with
any work. The basic prerequisite for working safely is compliance with all the specified safety
instructions.
NOTICE
All assembly, commissioning, troubleshooting and maintenance work may only be carried
out by authorised and trained personnel.
The device may be operated and maintained only by those who are capable of doing so
in terms of their level of knowledge and training.
For F200K, the covers must be removed for commissioning, but then only by authorised
personnel. Any further opening or disassembly is not permitted.
The open flame scanner must be protected from ingress of dust and moisture.
Contact with the electronics is only permitted if ESD measures are observed.
Opening the devices is not permitted under any circumstances except for commissioning
(F200K).
For safety reasons, access to parameterisation must be restricted to authorised
personnel.
1.4 Safekeeping of the Manual
Look after the manual and all the associated documents carefully.
The manual is part of the product and must be kept safe and be accessible to personnel at all
times.
Moreover, it is important that the manual:
• Is available when required.
• Is kept for the entire service life of the device.
• Is available to its next operator.

7
2 General Safety Instructions
2 General Safety Instructions
2.1 Classification of the Safety Instructions and Warnings
Thefollowing symbols are usedin this document todraw the user'sattentionto important safe-
ty information. They are located at points where the information is required. It is essential that
the safety information is observed and followed, and that applies particularly to the warnings.
DANGER!
This draws the user's attention to imminent danger. If it is not avoided, it will result in death or
very serious injury. The plant including its surroundings could be damaged.
WARNING!
This draws the user's attention to the possibility of imminent danger. If it is not avoided, it may
result in death or very serious injury. The plant including its surroundings could be damaged.
CAUTION!
This draws the user's attention to the possibility of imminent danger. If it is not avoided, it may
result in minor injuries. The plant including its surroundings could be damaged.
NOTICE
This draws the user's attention to important additional information about the system or system
components and offers further tips.
The safety information described above is incorporated into the instructions.
Thus, the operator is requested to:
1 Comply with the accident prevention regulations whenever work is being carried out.
2 Do everything possible within his control to prevent personal injury and damage to prop-
erty.

8
2 General Safety Instructions
2.2 Product Safety
WARNING!
This product is state-of-the-art technology and complies with the generally accepted
safety-related rules and regulations.
Every device is tested before delivery to ensure that it is working properly and safely.
Only use this product when it is perfect condition and in accordance with the manual, the
prevailing regulations and guidelines and the applicable safety and accident prevention
regulations.
WARNING!
The risk of danger in the event of external fire, traffic and wind, flood waves and earthquakes
depend on the installation situation and the installation site to be assessed separately where
appropriate.
2.3 Product-specific Dangers
DANGER!
The F300K is not designed to switch off the fuel valves.
The subsequent signal processing must be carried out in the control system, which is
adapted to suit the combustion plant.
WARNING!
The F300K is a safety device. Only specialist staff of the manufacturer or people approved by
the manufacturer may intervene. No interventions by anyone else are permissible. This ap-
plies, in particular, in the event of a defective fuse.
WARNING!
Radio interference suppression of the output contacts
In the interests of safety, ensure when installing the output contacts that:
The user suppresses radio interference in such a way that the contacts of the safety relay
contact output cannot be shorted by defective components of the suppressor circuitry.
WARNING!
The power supply of the flame scanner and the user interface with 24 VDC must be ensured
by an external power supply unit, which supplies SELV or PELV.

9
3 Product Description
3 Product Description
3.1 Structure of the F300K
Fig. 3-1 The components of the F300K
1Lens holder
2F300K housing
3Cover with operating unit
UI (user interface) or
LED display
4Device connector
5Connecting cable

10
3 Product Description
3.2 Basic variants
There are two basic variants of the F300K
NOTICE
The basic functions of the variants are identical. The differences lie merely in how they are
operated and their displays.
F300K with LED display
Fig. 3-2 F300K display unit with LED display
NOTICE
For operation of F300K (with LED display) you need an external User Interface UI or the
F300K Remote Software.
1LEDs in the display strip show the intensity of the flame: a series of two yellow and three
green LEDs; point display for intensity, flashing for a warning
2Green LED: mode 3
3Green LED: mode 2
4Green LED: mode 1
5Red LED: Flame OFF/stand-by – flashes in the event of a fault

11
3 Product Description
F300K with user interface
3.3 Life Cycle
The device is designed to have a service life of 10 years or 250,000 cycles. The functional
safety calculations are based on these values.
Theactualservice lifeofthe F300Kdependson theambienttemperature amongotherfactors.
In particular, operation at high temperatures reduces the actual service life.
3.4 Proper Use - Conditions of Use
The F300K is designed to monitor the safety of burner flames in single- and multi-burner com-
bustion plants and in combustion chambers for dust- and grate-fired systems.
As an explosion-proof device, the flame scanner can be used in potentially explosive atmos-
pheres (up to Zone 2).
Anyotherusage going beyond this isconsidered to be improper use.The plant operatingcom-
pany is liable for any damages that resulting from this.
The table in Section 3.6 Selection Criteriashows the applications to which the various device
types are suited.
Please heed the following information when operating the F300K:
• The safety information in this manual
• Section 14.1 Technical Data in this manual
3.4.1 UL Listed
In preparation
NOTICE
For applications within the scope of the UL Listed certification procedure, it must be ensured
that the components used are "Listed" certified. That is, in addition to the flame detector used
must also be the connection cable and if used the power supply "Listed" certified.
The applicable installation rules according to NFPA70 (NEC) must be observed.
Fig. 3-3 F300K operating and display unit with UI
1Display
2LED shines red: Flame OFF/ready for
operation
LED flashes red: fault
3LED shines green: flame ON
LED flashes green: warning
4ENTER key
5UP key
6DOWN key
7ESC/BACK key

12
3 Product Description
3.5 Rating Plate
Fig. 3-4 Position of the rating plate
T= position of the type plate
On the rating plate you will find information on the configuration of your flame sensor:
Rating plate example:

13
3 Product Description
3.6 Selection Criteria
The spectral sensitivity of the flame scanners determines their suitability for specific fuels.
NOTICE
LAMTEC guarantees that the flame sensor is in perfect working order but cannot offer any
guarantees if it is used improperly.
Note the specific requirements of your plant when selecting the flame sensors. We will be
pleased to answer any questions you may have in relation to LAMTEC products.
The following table provides an overview:
*in preparation, use may only be made with LAMTEC IR fiber optic system
The suitability of the device types may differ from that indicated in the table depending on par-
ticular circumstances.
Fig. 3-5 Spectrum of the flame
Type Fiber
Optic Sensi tivity Spectral range
in nm
Sight
angle
approx
Preferred area of application/fuels
F300K UV-4 X ++ 215 ... 360 8° • Oil
• Gas
• Special gases such as refi nery gases,
blast furnace gases and hydrogen
F300K UV-4.6 X +++ 215 ... 360 10°
F300K IR-2 * ++ 850 … 1200 • Combustion chamber monitoring
F300K IR-3 * ++ 1000 … 1700 60° • Oil-, gas-, wood-, coal- and dust-fired
furnaces with a high level of flue-gas
recirculation
• Yellowish waste gases without UV radi-
ation or with shielding of the UV spec-
trum by water vapour and dust
F300K IR-4 * +++ 1000 ... 2200 60°
F300K UVIR-1
X ++ 215 ... 360 8° • as F300K UV-4
• as F300K IR-3(double sensor) ++ 1000 ... 1700

14
3 Product Description
3.7 Accessories
NOTICE
When installing electrical accessories you must ensure that the necessary protection class is
reached.
3.7.1 FB30 External User Interface
The FB30 external operating unit offers the same range of functionality as the internal UI built
intothe F300K. It canbeused with anF300K(without an integratedoperatingunit) or aF300K
UI (with an integrated operating unit).
You canconnect theFB30 directlyto theFG30 connectionhousing usingits plug-inconnector.
The FB30 is then supplied with 24 VDC from the power supply of the F300K.
You will find the technical specifications for this device in section 14.1.2 FB30 External User
Interface.
3.7.2 F300K Remote Software
NOTICE
LAMTEC provides a CAN/USB adapter with the F300K Remote Software. You can use this
with a specific adapter cable to connect your PC to the CAN bus of the F300K.
The F300K Remote Software allows you to do all the parameterisation of an F300K. In addi-
tion, it also offers analysis, data backup and recording functions.
In addition to the data of the F300K, you can also record external, analogue and/or digital data
by means of CAN modules. All of the data is synchronised.
Fig. 3-6 Remote PC software
You will find further information in a separate description F300K-Remote-Software
(DLT-No. 7652).

15
3 Product Description
3.7.3 Power Supply
3.7.3.1 Power Supplies
You can use a commercially available power supply with an output voltage of 24 V that meets
the protective separation requirements. See section 6.1.2 Electrical Safety – Requirements to
Be Met by Third-party Manufacturers.
3.7.3.2 FN20, FN30-20 Power Supply
NOTICE
The FN20 (115 V) is UL Listed approofed.
WARNING!
Instalation
The wires must be installed/attached in such a way that, if a wire is unintentionally loosened,
a sufficient distance is still maintained between SELV/PELV and the other voltages.
WARNING!
Secure output contact and secure indicator contact
Danger due to electric shock! This may result in personnel injury.
Basic insulation is used for protective separation, i.e. you may not use SELV (safety extra
low voltage) and mains voltage at both of the contacts at the same time.
You can use the FN20 power supply to operate the F300K at mains AC voltage. The power
supply is designed for top-hat rail mounting (for F300K can be supplied as an option with built
in an IP65 housing).
The power supply is equipped with safety output relays (to EN 298) for mainsAC voltage. The
power supply complies with SIL 2 (Safety Integrity Level) to EN 61508.
When you connect the F300K to the FN20 power supply, you do not connect all of the wires
of the connecting cable to the terminals. You have to connect the surplus wires to separate
terminals. These terminals are part of the F300K's IP65 housing.
You will find the technical specifications for this power supply in section 14.1.3.1 FN20, FN30-
20 Power Supply.
Fig. 3-7 FN20 for top-hat rail mounting Fig. 3-8 FN20 as a built-in unit

16
3 Product Description
3.7.3.3 FN30 power supply
The power supply unit FN30 can only be used to operate the F300K on anAC mains voltage
within the scope of EN 60950 or UL 60950.
The power supply is available in two versions:
• For top-hat rail mounting
• As a built-in unit in a housing
When connecting the F300K to the FN30-00 power supply, not all wires of the connection ca-
ble are connected to the power supply connections. Surplus wires must be connected to sep-
arate terminals. These terminals are part of the housing.
Technical data for this power supply unit can be found in section 14.1 Technical Data.
3.7.4 Coupling relays
To connect the contact outputs of the F300K to voltages higher than 42 V or voltages without
protective separation, you have to use coupling relays. These must met the protective sepa-
ration requirements. See section 6.1.2 Electrical Safety – Requirements to Be Met by Third-
party Manufacturers.
In addition, you also require appropriate certification for the coupling relay with a safety con-
tact output (flame signal) for the purpose for which it is to be used (e.g. to EN 298 and/or to
EN 61508 with SIL III or SIL II).
The LAMTEC FN20 and FN30-20 power supply has coupling relays for the flame signal.
These meet EN 298 und EN 61508-2 SIL 2 requirements.
If you want suitable coupling relays or have any questions, please contact our support staff at
[email protected] or on [phone].
3.7.5 Adjustable Holder, Cooling-air Housings
You will find a complete overview of the holders and cooling-air housings for LAMTEC flame
scanners in the document "Flame Monitoring Systems and Accessories" (DLT7673).
Fig. 3-9 FN30-00 top-hat rail mounting Fig. 3-10 FN30-10 as a built-in unit

17
3 Product Description
3.7.6 FG30 connection housing
Regard the applicable rules and regulations for mounting and installation, note also the addi-
tional requirements described in section 6.1.1 Safety When Putting the Device Into Operation
LAMTEC offers two versions of the FG30 connection housing:
• FG30-00 with cable glands and an M12 circular connector for FSB
• FG30-20 Ex-II for use in potentially explosive atmospheres with cable glands and an M12
circular connector for FSB
You will find technical specifications for the housings in section 14.1.4 FG30 connection hous-
ing and FG30-21 stainless steel.
Fig. 3-11 FG30-00 connection housing Fig. 3-12 FG30-20 Ex-II connection housing

18
3 Product Description
3.7.7 Flame Scanner Testing Device
Fig. 3-15 Positions of the internal jumper UV + IR
You can use the FFP30 to test that your flame scanner is working properly.
The testing device simulates a variable flame frequency.
If the internal jumper(1) is plugged on IR, UV or IR can be chosen via the toggle switch.
If the internal jumper is plugged on IR+UV, the switch position IR as well as UV rays can be
detected simultaneously. The latter can be interesting for flame scanner with dual sensor.
Flame scanner testing device is off in the average position of the toggle switch. The flame
scanner testing device switches off automatically after a preset time of approximately 4 min to
reserve the battery resource.
The testing device is screwed onto the flame scanner.
For the recognition of the flame simulation, the F300K must be set to sufficiently sensitive (in-
crease, trigger threshold and frequency).
To change the battery, see chapter 8.1.1 Flame Scanner Testing Device replace Battery
WARNING!
After a possibly necessary modification of the F300K setting for the test, the original
settings must be set back and controlled through the CRC manual of the operating
mode parameter.
DANGER!
Explosion hazard!
Flame sensors must not be tested in a potentially explosive atmosphere.
You will find the technical specifications for this device in section Fig. 14-27 Dimensioned
drawing of the FB30.
Fig. 3-13 Toggle switch UV/IR Fig. 3-14 FFP30 flame-scanner testing device

19
3 Product Description
3.7.8 Connection Cable AK05
DANGER!
The Connection Cable are approved for use with SELV or PELV only.
NOTICE
For special requirements it may be necessary to protect cable additionally.
The specific installation rules are to be observed.
NOTICE
Only the Connection Cable AK05-51 is UL Listed approofed. For the use of the Flame scan-
ner as UL Recognized approofed, the other Connection Cable can be used.
Devices shall be wired in accordance with NEC field wiring requirements for the
location.
Fig. 3-16 Connection Cable AK05-51
