Lance-Larkin Brew Express BE-104C Manual

IMPORTANT:
Read and follow instructions carefully before installing your BREW EXPRESS™ in-the-wall
COFFEE SYSTEM. For best results it is advised that you hire a qualified professional.
1. Overall Dimensions (Finished Unit with Rough-in-Box) approximately 12.5” x 12.5” (see below).
2. Dimensions for Rough-in-Box (Mounting Structure) approximately 11.5” x 11.5” x 4”.
3. Electrical Requirements 120VAC, 60HZ. (1400 watts).
4. Water Requirements 1/4” water supply line (copper or poly) minimum 30 psi to a maximum of
90 psi. Potable COLD water is required.
NOTE: If water is not available, an alternate water dispenser jug (5 gallons) can be used with the
optional pump accessory (not supplied). Contact dealer or Lance Larkin™.
Please Note: A filter and shut off valve at water source is required.
The filter such as an ice maker type filter, can easily be installed at the source.
If water lines are not purged or clear of debris or a filter is NOT installed, foreign
particles (debris) in water may clog brewer system causing failure, and may
void all warranties.
SPECIFICATIONS AND REQUIREMENTS
AREA ON WALL
TO BE CUT
(USE TEMPLATE)
11-1/2"
(292.1mm)
