Rotary Tillers, Reverse Tine Rotation
Features and Benefits
Designs, specifications, features and information are subject to change without notice.
83
RTR10 Series
Features Benefits
American made Many tillers are imported. American made means better parts availability.
Reverse tilling action Reverse action ‘sucks’ tiller into ground, does not walk on top of hard ground like
forward rotation tillers can.
Tractor HP range 17-25 HP
Gearbox Warranty 5 Years on housing, seals, & bearings. shows our confidence in the product.
Working widths 42”, 50”, 58” to meet specific customer needs.
6 1/2” Digging depth For deep soil penetration.
Plate steel upper hitch Plate steel is stronger than flat bar type hitch.
Clevis lower hitch Provides additional strength and easy one person hook-up.
Hitch offset capability Offset by moving lower hitch points and gearbox mount to cover right tire track.
Offset Dimensions 42” Width
50” Width
58” Width
16” - 26” Std. 13” - 29” Max. Right 23” - 19” Max. Left
25” - 25” Std. 18” - 32” Max. Right 32” - 18” Max. Left
29” - 29” Std. 22” - 36” Max. Right 36” - 22” Max. Left
Fits Land Pride Quick-Hitch Allows for quick and easy one person hook-up.
(Offset cannot be used with Quick-Hitch.)
Adjustable parking stand Allows for easy hook-up and storage.
Adjustable skid shoes Control depth with seven adjustments.
Formed and reinforced rear
deflector Keeps dirt in and leaves a level finish. Forming gives deflector additional strength. Adjustable deflector allows for various finish results.
Front deflector Front deflector is flexible to take the beating from rocks or debris.
4 ‘C’ shaped heat-treated
tines per flange ‘C’ Shaped tines require less HP to move through the ground.
Solid rotor shaft 1 3/4” Solid steel rotor shaft for strength.
15” Rotor swing diameter For deep tilling and turning the soil over faster.
Double lip seal on rotor bearing Double lip seal helps keep the dirt out and the grease in.
Fully shielded shear pin or
slip-clutch driveline Protects the gearbox and rotor shaft upon hitting obstructions. Slip-clutch saves having to replace shear-pins.
#80 Drive chain enclosed in oil
bath Heavy drive chain stretches less, and oil bath keeps wear to a minimum.
Stamped chain cover Stamped forming gives the chain cover strength.
311-431F continued on next page
16/23/10

Rotary Tillers, Reverse Tine Rotation
Features and Benefits
Designs, specifications, features and information are subject to change without notice.
84
RTR15 Series
Features Benefits
American made Many tillers are imported. American made means better parts availability.
Reverse tilling action Reverse action ‘sucks’ tiller into ground, does not walk on top of hard ground like
forward rotation tillers can.
Tractor HP Range 17 - 50 HP; Dependent upon width and Series of tiller.
Gearbox Warranty 5 Years on housings, seals, bearings. Shows our confidence in the product.
Working widths 50”, 58”, 66” & 74” To meet specific customers needs.
6 1/2” Digging depth For deep soil penetration.
Plate steel upper hitch Plate steel is stronger than flat bar type hitch.
Clevis lower hitch Provides additional strength and easy one person hook-up.
Hitch sideshift capabilities Sideshift tiller to cover right tire track. Gearbox slides with tiller.
Sideshift dimensions 50” Width
58” Width
66” Width
74” Width
25” - 25” Std. 12” - 38” Max. Right 31” - 19” Max. Left
29” - 29” Std. 12” - 46” Max. Right 35” - 23” Max. Left
33” - 33” Std. 12” - 54” Max. Right 39” - 27” Max. Left
37” - 37” Std 16” - 58” Max. Right 43” - 31” Max. Left
Fits Land Pride Quick-Hitch Allows for quick & easy one person hook-up. Offset cannot be used with Quick-Hitch.
Adjustable Parking stand Allows for easy hook-up and storage.
Adjustable skid shoes Control depth with various settings.
Formed and reinforced
rear deflector Forming gives deflector additional strength. Adjustable deflector allows for various finish results.
Front deflector Front deflector is flexible to take the beating from rocks or debris.
4 ‘C’ Shaped heat-treated
tines per flange ‘C’ Shaped tines require less HP to move through the ground.
RTR1550 & RTR1558
1 3/4” Solid steel rotor shaft
RTR1566 & RTR1574
2” Solid steel rotor shaft
Solid steel shaft for strength.
15” Rotor swing diameter For deep tilling and turning the soil over faster.
Double lip seal on rotor bearing Double lip seal helps keep the dirt out and the grease in.
Cat. 3 heavy-duty fully shielded
shear pin or slip-clutch driveline Protects gearbox and rotor shaft upon hitting obstructions. Slip-clutch saves having to replace shear-pins.
#80 Drive chain
enclosed in oil bath Heavy drive chain stretches less, and oil bath keeps wear to a minimum.
Stamped chain cover Stamped forming gives the chain cover strength.
311-431F end
6/23/10
