Landmann 42209 Guide

MODEL 42132 / 42209
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at: 1-800-321-3473 8:00 AM - 5:00 PM (EST) English Only,
or Email [email protected]
3 Burner LP Barbecue Grill
Español p. 26
Français p. 51
ASSEMBLY, CARE AND USE INSTRUCTIONS
READ CAREFULLY
IMPORTANT:
RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
This appliance is for
Household use only.
This is not a
commercial appliance.

2
Important Safety Information ................................... 2
Liquid Propane (LP) Safety Information.................... 4
Package Contents.................................................... 6
Preparation............................................................... 7
Hardware Contents .................................................. 7
Tools Required.......................................................... 7
Assembly Instructions .............................................. 7
Lighting Instructions................................................. 17
Care and Maintenance ............................................. 18
Cooking Methods and Grilling Tips.......................... 19
Troubleshooting........................................................ 20
Replacement Parts List ............................................ 21
Grilling Guidelines .................................................... 22
Warranty .................................................................. 24
Assembler/Installer
This instruction manual contains important information necessary for the proper assembly and safe use of this
appliance. Read and follow all warnings and instructions before assembling and using this appliance.
Leave these instructions with the consumer.
Consumer/User
Follow all warnings and instructions when using this appliance.
Keep these instructions for future reference.
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish open flame.
3. Open lid.
4. If odor continues, keep away from the
appliance and immediately call your gas
supplier or your fire department.
5. Failure to follow these instructions could
result in explosion, or burn hazard which
could cause property damage, personal
injury or death.
1. DO NOT store or use gasoline or other
flammable liquids or vapors in the vicinity of this
or any other appliance.
2. An LP (liquid propane) cylinder not
connected for use should not be stored in the
vicinity of this or any other appliance.
3. This grill is FOR OUTDOOR USE only and
shall not be used in a building, garage, under
overhangs or any other enclosed area.
4. DO NOT leave a lit grill unattended. Keep
children and pets away from the grill at all times.
5. This appliance is for Household use only.
This is not a commercial appliance.
Table of Contents
Important Safety Information
Warnings and Cautions contained
in this instruction manual may result
in serious bodily injury or death,
or may result in a fire or explosion
causing damage to property.
UÊÊ Ê>iÊÃÕÀiÊÌÊvÜÊ>Ê>ÃÃiLÞÊÃÌÀÕVÌÃÊ
carefully. Improper assembly of this grill may be
dangerous.
UÊÊ ÊNEVER use charcoal, lighter fluid, gasoline,
kerosene or alcohol to ignite this grill.
UÊÊ Ê7iÊ}Ì}ÊÌiÊ}ÀÊÀÊV}]ÊDO NOT lean
over the open grill.
UÊÊ ÊÜ>ÞÃÊ«iÊÌiÊ}ÀÊ`ÊÃÜÞÊ>`ÊV>ÀivÕÞÊ>ÃÊi>ÌÊ
trapped inside the grill can cause severe burns.
UÊÊ ÊDO NOT place hands or fingers at edge of the
firebox when the lid is open or the grill is hot.
UÊÊ Êii«ÊV`ÀiÊ>`Ê«iÌÃÊ>Ü>ÞÊvÀÊÌiÊ}ÀÊÜiÊÊ
use. Accessible parts may be very hot.
UÊÊ ÊDO NOT attempt to disconnect the gas regulator
and hose assembly or any gas fitting while your
grill is operating.

3
UÊÊ Ê/ÃÊ}ÀÊSHOULD NOT be located under any
overhead unprotected combustible construction.
Always allow at least 24" from the top, bottom,
back and 24" from the sides of the grill (see below).
UÊÊ Ê/ÃÊ}ÀÊÃÊ>ÊÕÌÃ`iÊ>««>ViÊ>`ÊSHOULD
NOT be operated in a building, garage, or any
other enclosed area.
UÊÊ ÊDO NOT obstruct the flow of combustion and
ventilation air. Keep the ventilation openings of the
cylinder enclosure free and clear of debris.
UÊÊ Ê-Õ`ÊÌiÊLÕÀiÀÃÊ}ÊÕÌÊÜiÊÌiÊ}ÀÊÃÊÊ
operation, turn all gas valves off. Open the lid and
wait five minutes before attempting to relight the
grill, using the igniting instructions.
UÊ Êii«ÊÌÃÊ}ÀÊVi>ÀÊ>`ÊvÀiiÊvÀÊVLÕÃÌLiÊ
material, gasoline and other flammable vapors and
liquids.
UÊÊ NEVER store an extra or disconnected liquid
propane cylinder under or near this grill.
UÊÊ ÊÜ>ÞÃÊÕÃiÊi>ÌÀiÃÃÌ>ÌÊL>ÀLiVÕiÊÌÌÃÊÀÊ}ÛiÃÊ
when operating the grill.
UÊÊ ÊDO NOT leave a hot grill unattended or move it
during operation.
UÊÊ Ê/ÃÊ}ÀÊÃÊÌÊÌi`i`ÊÌÊLiÊÕÃi`ÊÊÀÊÃÌ>i`Ê
on recreational vehicles, boats, portable trailers, or
in any moving location.
UÊÊ ÊDO NOT put a grill cover or anything flammable on
the grill while the grill is in operation or is hot.
UÊ ÊÊ-ÌÀ>}iÊvÊ>ÊÕÌ`ÀÊV}Ê}>ÃÊ>««>ViÊ
indoors is permissible only if the cylinder is
disconnected and removed from the outdoor
cooking gas appliance.
UÊÊ Ê7iÊÌiÊ}ÀÊÃÊÌÊÊÕÃi]Ê>iÊÃÕÀiÊÌiÊ}>ÃÊÃÊ
turned OFF at the supply cylinder.
UÊÊ ÊÞ`iÀÃÊÕÃÌÊLiÊÃÌÀi`ÊÕÌ`ÀÃÊ>`ÊÕÌÊvÊÌiÊ
reach of children. Cylinder must not be stored in a
building, garage or other enclosed areas.
UÊÊ ÊÜ>ÞÃÊëiVÌÊÌiÊ}>ÃÊÃÕ««ÞÊÃiÊLivÀiÊiÛiÀÞÊ
use. If the hose shows any signs of abrasions or
cuts, DO NOT use the grill. The hose must be
replaced before using again.
UÊÊ ÊÜ>ÞÃÊViVÊÌiÊLÕÀiÀÃÊ>`ÊÛiÌÕÀÊÌÕLiÃÊvÀÊ
insects and insect nests.
UÊÊ ÊÜ>ÞÃÊViVÊÌiÊViVÌÃÊvÀÊi>ÃÊi>VÊÌiÊ
you connect and disconnect the LP gas supply
cylinder.
The pressure regulator and hose
assembly supplied with this grill
must be used. Any requirements for
a replacement regulator and hose
assembly must be made through the
manufacturer, LANDMANN-USA.
UÊÊ Ê>ÃÊVÞ`iÀÃÊÕÃÌÊVÕ`iÊ>ÊV>ÀÊÌÊ«ÀÌiVÌÊÌiÊ
cylinder valve.
UÊÊ ÊiÌi`ÊÀÊÀÕÃÌÞÊ*Ê}>ÃÊVÞ`iÀÃÊ>ÞÊLiÊ
hazardous and need to be checked by your LP gas
supplier.
UÊÊ ÊDO NOT use LP gas cylinders with a damaged
valve.
UÊÊ ÊDO NOT enlarge the valve orifices or burner ports
when cleaning the valves or burners.
UÊÊ ÊvÊÞÕÊÃii]ÊÃiÊÀÊi>ÀÊÃÃ}ÊvÊ}>ÃÊiÃV>«}Ê
from the LP gas cylinder, move away from the
LP gas cylinder. DO NOT attempt to correct the
problem yourself and call the fire department.
UÊÊ ÊvÊ>Ê}Ài>ÃiÊwÀiÊVVÕÀÃ]ÊÌÕÀ OFF all burners and
leave the lid closed until the fire is out.
UÊÊ ÊÊDO NOT alter this grill in any manner. Any
alteration automatically voids the warranty.
UÊÊ ÊÊDO NOT use the grill in high wind situations.
Important Safety Information
24"
(609 mm)
24”
(609 mm)
24”
(609 mm)

4
This product contains one or more
chemicals known to the state of
California to cause cancer.
This product contains one or more
chemicals known to the state of
California to cause birth defects or
other reproductive harm.
Important Safety Information
4
A fire causing death or serious
injury may occur if the following
is not followed exactly:
NEVER store or use gasoline or
other volatile substances in the
vicinity of this grill. NEVER store
a spare propane cylinder in the
vicinity of this grill, or in the vicinity
of another potential heat source.
NEVER fill the propane cylinder
beyond 80% full.
DO NOT store spare gas
cylinder in or near grill.
Place dust cap on cylinder valve
outlet whenever the cylinder is not
in use. Install only the type of dust
cap on cylinder valve outlet that is
provided with the cylinder valve.
Other types of caps or plugs may
result in leakage of propane.
State of California Proposition 65 WarningsThe LP gas supply cylinder to be used must be
constructed and marked in accordance with the
Specification for LP Gas Cylinders of the U.S.
Department of Transportation (DOT) or the National
Standard of Canada, CAN/CSA-b339 (Cylinders,
Spheres, and Tubes for transportation of Dangerous
Goods).
The LP gas cylinder must be:
– provided with a listed overfilling prevention device
– provided with a cylinder connection device
compatible with the connection for outdoor
cooking gas appliances.

5
General Information
UÊ Ê/ÃÊ}ÀÊÃÊ`iÃ}i`ÊÌÊLiÊÕÃi`ÊÜÌÊ>ÊÃÌ>`>À`ÊÓäÊ
lb. LP gas cylinder.
UÊ ÊÞÊLÀ>`ÊvÊÓäÊL°Ê*Ê}>ÃÊVÞ`iÀÊÃÊ>VVi«Ì>LiÊ
for use on this grill, provided that it is compatible
with the grill’s retention means (tank tray bolt).
UÊ Ê/ÃÊ}ÀÊÃÊ`iÃ}i`ÊViÀÌwi`ÊLÞÊ-ÊÌiÀ>Ì>Ê
for local LP gas supply.
UÊ Ê/ÃÊ}ÀÊCANNOT be converted to natural gas.
DO NOT attempt to convert this grill with a
different gas type.
Safety Information
UÊ Ê*Ê}>ÃÊ>ÃÊ>Ê`ÀÊÃ>ÀÊÌÊ>ÌÕÀ>Ê}>ð
UÊ Ê*Ê}>ÃÊÃÊi>ÛiÀÊÌ>Ê>ÀÊ>`Êi>}Ê}>ÃÊ>ÞÊ
collect in low areas and resist dispersion.
UÊ Ê*ÊVÞ`iÀÃÊÕÃÌÊLiÊÃÌ>i`]ÊÌÀ>ëÀÌi`Ê>`Ê
stored in an upright position.
UÊ Ê*ÊVÞ`iÀÃÊÃÕ`ÊÌÊLiÊ`À««i`ÊÀÊ>`i`Ê
roughly.
UÊ ÊDO NOT use a damaged LP cylinder. A dented or
rusty LP cylinder or an LP cylinder with a damaged
valve may be hazardous and should be replaced
with a new cylinder immediately.
UALWAYS close the cylinder valve after use.
UÊ ÊALWAYS close the cylinder valve when
disconnecting the regulator.
UÊ ÊALWAYS treat possible empty LP cylinders with
the same care as a full LP cylinder. There may
still be gas pressure inside a possible empty LP
cylinder.
UÊ ÊNEVER store or transport an LP cylinder where the
temperature can reach 125ºF.
UÊ Êii«Ê*ÊVÞ`iÀÃÊ>Ü>ÞÊvÀÊV`ÀiÊ>`Ê«iÌð
UÊ ÊDO NOT store disconnected LP cylinders in a
building, garage or other enclosed areas.
UÊ ÊvÊÌiÊ*ÊVÞ`iÀÊÃÊi«ÌÊÊÌiÊ}ÀÊLiÌÜiiÊÕÃiÃ]Ê
make sure to keep both the grill and the cylinder in
an outdoor area with good ventilation.
UÊ ÊALWAYS leak test the LP cylinder connection to
the regulator whenever changing LP cylinders.
Installation of LP Cylinder
1. Maker sure all burner controls are in the OFF
position.
2. Open the cabinet door.
3. Carefully position in the large hole on the bottom
panel.
4. To secure the LP cylinder in place, screw the tank
holding tray bolt through the bottom section of the
LP cylinder.
5. Attach the regulator to the cylinder by carefully
HAND TIGHTENING only.
6. NEVER use a wrench or other tool to tighten this
connection.
7. Observe all governing codes and ordinances.
Important
The United States LP gas appliance installation must
conform with local codes and ordinances. In the
absence of local codes, appliance installation must
conform with either the National Fuel Gas Code, ANSI
Z223.1/NFPA54, Natural Gas and Propane Appliance
code, CSA B149.1, or Propane Storage and Handling
Code, B149.2, as applicable.
For Canada, installation of this grill must comply with
local codes and/or Standard CSA-B149.2 (Propane
Storage and Handling Code).
Liquid Propane (LP) Safety Information
Please review the below guidelines and safety information when using Liquid Propane (LP) gas.

6
Package Contents
A
W
BC
L
D
K
E
F
G
H
N
O
V
Q
R
S
T
U
M
J
N-S O-S
Z
P
I
P-S
Part Description Quantity
A Bottom panel 1
B Non-locking caster 2
C Locking caster 2
D Tank tray bolt 1
E Left side panel of cart 1
F Right side panel of cart 1
G Back panel of cart 1
H Cart frame 1
I Ignition line 1
J Grill body 1
K Door 1
L Door bottom pin 1
M Control Knob 1
N Left shelf 1
N-S Left shelf support 1
Part Description Quantity
O Side burner 1
O-S Side burner grate 1
P Right shelf 1
P-S Right shelf support 1
Q Flame tent 3
R Cooking grate 2
S Warming rack 1
T Grease tray 1
U Grease box 1
V AA Battery 1
W Lower door magnet 1
X Match lighting tool
(not shown)
1
Z Control Knob base 1

7
Hardware Contents
BB
Spring
Washer
Qty: 16
CC DD
AA
M6 x 12mm
Bolt
Qty: 53
M5 x 10mm Bolt
Qty: 3
M4 x 10mm Bolt
Qty: 5
L
V
Door
Bottom Pin
Qty : 1
AA Battery
Qty : 1
+ –
Preparation
Before beginning assembly of this grill, make sure all parts are present (see Package Contents on page 6 and
Hardware Contents below). If any part is missing or damaged, DO NOT attempt to assemble the product.
Estimated assembly time: 50 minutes with two people
Assembly Instructions
1
BB
AA
A
BAC
2
AA x8
BB
AA
Attach non-locking casters (B) to the front of the
bottom panel (A) and secure using spring washers
(BB) and bolts (AA).
Attach locking casters (C) to bottom panel (N) and
secure with spring washers (BB) and bolts (AA).
Tools Required
2 pt Phillips
Screwdriver
Adjustable Wrench

8
Assembly Instructions
4A
W
DD
Thread tank tray bolt (D) through hole in back of bottom
panel (A) and holder. Secure firmly with washer and
small bolt.
Note: Washer and small bolt are attached to the tank
tray bolt (D) and must be removed for assembly.
Attach magnet (W) to bottom panel (A) and secure
with bolts (DD) as shown.
6
A
F
AA x3 AA
Attach right side panel (F) to bottom panel (A) with
bolts (AA).
3A
D
5
AA
A
E
Attach left side panel (E) to bottom panel (A) with
bolts (AA).

9
Assembly Instructions
8
F
E
G
AA
9
E
H
F
From front of cart, install cart frame (H) to top of left
and right side panels (E,F).
Secure back panel (G) to left and right side panels
(E, F) using bolts (AA) as shown.
10
E
H
F
AA
Secure cart frame (H) with bolts (AA) to top of left and
right panels (E,F) as shown.
7G
A
AA
Attach back panel (G) to bottom panel (A) using
bolts (AA).

10
Assembly Instructions
Lower grill body (J) onto left and right side panels
(E, F) and align bolts from step 12 with keyholes on
top of side panels. Slide grill body forward. Insert
bolts (AA) into back bolt location. Securely tighten all
four bolts underneath grill body.
IMPORTANT NOTE:
This step requires two people to properly
and safely position and attach the grill
body.
J
E
F
AA
1313
11
E
H
F
AA
AA
12
J
AA
Finish securing cart frame (H) to side panels (E,F) with
additional bolts (AA) as shown.
Carefully place the grill body (J) on its back. Insert
bolts (AA) into the two bolt locations closest to the
front of grill body. Insert these bolts ONLY half way.
IMPORTANT NOTE:
This step requires two people to properly
and safely position the grill body.

11
Assembly Instructions
F
DD
1414
Secure the regulator and hose assembly to the inside
right side panel (F) with one bolt (DD) as shown.
1515
K
H
K
A
L
Thread door bottom pin (L) into hole on bottom panel
(A). Align bottom hole on lower right corner of door (K)
to fit over door bottom pin (L). Carefully push down
spring pin on top right corner of door (K) and move
door so spring pin slides into the hole on cart frame (H).

12
Attach bolts (AA) half way (as shown) to left and right
side of the grill body (J).
Attach right shelf support (P-S) to the bottom of right
shelf (P) with bolts (AA) .
Attach left shelf support (N-S) to the bottom of left
shelf (N) with bolts (AA) .
Line up keyholes on right shelf (P) with bolts (AA)
installed on grill body (J) in Step 16. Slide right shelf
down until bolts are in the narrow part of the keyhole.
Insert Ignition line (I) into hole in bottom of right
shelf (P). Secure with bolt (CC).
1717
P
N
N-S
P-S
AA
AA
P
I
1818
CC
1616
AA
J
1919
AA
P
Assembly Instructions

13
2020
AA
N
Line up keyholes on left shelf (N) with bolts (AA)
installed on grill body (J) in Step 16. Slide left shelf
down until bolts are in the narrow part of the keyhole.
2121
AA
N
P
Line up lower holes on both left shelf (N) and right
shelf (P) with holes on grill body (J). Insert bolts (AA) to
secure. Fully tighten all bolts (AA).
Assembly Instructions
Secure the gas valve to the side shelf (P) by placing
knob base (Z) over the valve and secure knob base (Z)
to the gas valve using bolts (CC).
2222
Carefully pull the gas valve out and fit it into the hole
on the front side of the side burner rack (P).
2323
CC Z

14
2525
CC
Attach side burner (O) to right shelf (P) with bolts
(CC). Install electrode wire to the side burner valve by
plugging the end of the wire into the socket.
Assembly Instructions
2626
M
P
O-S
Place side burner grate (O-S) into the matching holes
on right shelf (P). Press fit knob (M) onto the gas valve
stem.
First insert flame tents (Q), then cooking grates (R)
and warming rack (S) in that order.
2727
R
S
Q
Slide side burner (O) through the upper hole in right
shelf (P). Guide the front tube of side burner so it
mates to the gas valve.
2424
O
P

15
Assembly Instructions
J
U
T
2828
From back of grill, first slide grease tray (T) into slots
on the grill body (J) until it lines up with the bottom of
the grill. Then place the grease box (U) into the slot on
the bottom of the grease tray.
+–
29
J
V
Unscrew the igniter button cap on the control panel of
grill body (J). Insert the AA battery (V) so the positive
end of battery is facing outward.

16
Tank Assembly
33 44
D
Place the 20 lb LP gas fuel tank bottom collar into the
mounting hole in the tank tray.
IMPORTANT NOTE:
The 20 lb LP gas fuel tank dimensions should be
D 315mm x H 480mm.
Tighten the tank bolt (D) clockwise against the bottom
collar of the 20 lb LP gas fuel tank to secure.
Twist the tank bolt (D) counterclockwise until it is
loosened.
11
K
Open cabinet door (K).
22
D

17
Connecting Gas Cylinder
1. ALWAYS place the propane cylinder on the tank
holder under the cart.
2. ALWAYS confirm that all burner control knobs
are in the OFF position before activating the gas
supply.
3. Before connection, be sure that there is no debris
caught in the head of the gas cylinder, head of the
regulator valve, or in the head of the burner and
burner ports.
4. ALWAYS connect the gas supply regulators as
follows: Insert the nipple of the valve coupling into
the tank valve and tighten the connection collar by
turning it clockwise with one hand while holding
the regulator with the other hand.
5. Disconnect the propane cylinder from the regulator
valve when the grill is not in use.
6. DO NOT obstruct the flow of combustion air and
ventilation air to the grill.
7. Keep ventilation openings of the cylinder
enclosure free and clear from debris.
Please make sure the cylinder valve connection
device shall properly and safely mate with the
connection device attached to the inlet of the pressure
regulator.
Checking for Leaks
1. Make 2-3 oz. of leak solution by mixing one part
liquid dishwashing soap with three parts water.
2. Make sure control knobs are in the OFF position.
3. Spray some solution on the tank valve up to the
valve connection. (See diagram to below.)
4. Inspect the solution at the connections for bubbles.
If no bubbles appear, the connection is secure.
5. If bubbles appear, you have a leak. Go to step 6.
6. Disconnect the regulator from the tank and
reconnect. Make sure the connection is tight and
secured.
7. Retest with solution.
8. If “growing” bubbles appear do not use or move the
LP cylinder. Contact an LP gas supplier or your fire
department!
To prevent fire or explosion
hazard when testing for a leak:
1. ALWAYS perform the “leak test“
before lighting the grill and each
time the cylinder is connected
for use.
2. DO NOT smoke or allow other
sources of ignition in the area
while conducting a leak test.
3. Conduct the leak test outdoors
in a well-ventilated area.
4. DO NOT use matches, lighters
or a flame to check for leaks.
5. DO NOT use grill until all
leaks have been stopped. If
you are unable to stop a leak,
disconnect the propane supply,
call for gas appliance service or
your local propane gas supplier.

18
Lighting Instructions
Prior to the first use, it is important to clean your grill
with heat. This will clean the internal parts by burning
off any residue and odor from the manufacturing
process. To perform this cleaning, operate the grill for
approximately 30 minutes at the highest heat setting
with the lid closed.
IMPORTANT
Please read these instructions before attempting to
light the grill.
Failure to open the lid before igniting
may result in an explosive flare-up,
which can cause serious bodily
injury or death.
DO NOT lean over the open grill
when lighting.
1. Turn all gas control knobs to the OFF position.
2. Turn on gas valve from gas source.
3. Lid MUST be open when lighting.
4. To ignite a burner, push and turn any control knob
to the HIGH position.
5. Press and hold the electronic igniter button to
light the selected burner.
6. If the burner does NOT ignite in five seconds, turn
the burner control knob to the OFF position,
wait at least five minutes for the gas to clear and
repeat this lighting procedure.
Failure to follow the five-minute
waiting period may result in an
explosive flare-up, which can cause
serious bodily injury or death.
7. To extinguish the burner, push in the control
knob(s) and turn clockwise to the OFF position.
Side Burner Lighting
1. Turn OFF gas burner control valves.
2. Turn on gas source or tank.
3. Open lid during lighting.
4. Push and hold down the control knob and turn
SLOWLY (2 to 3 seconds) to IGNITE. You should
hear the igniter click.
5. If ignition does not occur in 5 seconds, turn the
burner control OFF, wait 5 minutes and repeat
the lighting procedure.
Match Lighting
Note: Match lighting tool (W) is located on the inside
of the door (K).
1. Turn all gas control knobs to the OFF position.
2. Turn on gas valve from gas source.
3. Lid MUST be open when lighting.
4. Remove the match lighting tool and stick a match
into the end of the tool.
5. Light the match.
6. Once lit, guide the lit match under the grate.
7. Push in and turn the control knob to HIGH for the
burner closest to the light match. The burner should
light immediately.
8. Adjust burner control knob to the desired cooking
temperature.

19
Care and Maintenance
Please use the following guidelines to keep your grill
clean and looking new. Before any cleaning, make
sure all the burners are in the OFF position and grill
is cool to the touch.
Cleaning the Outside of the Grill
For the stainless steel surfaces, wash the outside of
the surface with a soft cloth and a soap and water
solution, and rinse with water.
UÊ Ê7iÊVi>}]Ê>Ü>ÞÃÊÀÕLÊÀÊÜ«iÊÊÌiÊ`ÀiVÌÊ
of the stainless steel grain.
UÊ ÊÀÊÃÌÕLLÀÊëÌÃ]Ê>Ü>ÞÃÊVi>ÊÊÌiÊ`ÀiVÌÊvÊ
the stainless steel grain.
UÊ ÊDO NOT clean stainless steel with anything
containing acid, mineral spirits or xylene.
UÊ ÊDO NOT use a wire brush or any abrasive cleaner
on the stainless steel surface as this will cause
scratches in the stainless steel finish.
Cleaning the Inside of the Grill
For safety and efficiency, it is important to remove any
debris or excess grease that may accumulate inside
the grill.
UÊ Ê7«iÊvvÊÌiÊiÀÊ`ÊiÀÊÜÌÊ>Ê«>«iÀÊÌÜiÊÌÊ
prevent grease build up.
UÊ Ê7>ÃÊÌiÊÃ`iÊvÊÌiÊ`ÊÜÌÊÜ>À]ÊÃ>«ÞÊÜ>ÌiÀÊ
and rinse with water.
UÊ ÊÃ`iÊÌiÊV}ÊV>LiÀÊÜ>ÃÊÜÌÊÜ>À]Ê
soapy water and rinse with water.
UÊÊÊ/iÊLÕÀvvÊiÌ`ÊÃÊiÊÜ>ÞÊÌÊVi>ÊÌiÊ
stainless steel rod grates. After cooking, turn
the burners to HIGH and run for approximately
15 minutes with the lid closed. Then turn off the
burners, carefully open the lid and use a wire brush
to clean the excess food residue off the grates.
UÊ ÊÀÊÌiÊÃÌ>iÃÃÊÃÌiiÊy>iÊÌiÌÃ]ÊVi>ÊÀiÃ`ÕiÊvvÊ
with wire brush and wash with a mild soapy water.
Rinse with water.
UÊ Ê,iÛiÊÌiÊ}Ài>ÃiÊLÝÊvÀÊÌiÊÌÀ>ÞÊ>`ÊÜ«iÊ
off the inner box with a paper towel to remove
excess grease. Then wash the inside of box with
warm, soapy water and rinse with water. For easier
cleanups, you can line the interior of the box with
aluminum foil.
UÊ Ê,iÛiÊÌiÊ}Ài>ÃiÊÌÀ>ÞÊvÀÊÌiÊ}ÀÊ>`ÊÜ«iÊ
off the top surface with a paper towel to remove
excess grease. Then wash the top surface with
warm, soapy water and rinse with water.
DO NOT line the grease tray with
aluminum foil.
Hose Inspection
The hose should be inspected periodically for any
signs of cracking, nicks, cuts or abrasions.
UÊ ÊvÊÌiÊÃiÊÃÊvÕ`ÊÌÊLiÊ`>>}i`ÊÊ>ÞÊÜ>Þ]Ê
DO NOT use the grill.
UÊ Ê/iÊÃiÊÕÃÌÊLiÊÀi«>Vi`ÊLÞÊ>ÊViÀÌwi`ÊÃiÊ>ÃÊ
shown in the replacement parts section.
Checking the Flame
The flame coming out of the burners should be a
blue/yellow combination and between one to two
inches tall (see below).
To Remove Burner
Make sure all control knobs are in the OFF position,
the LP gas supply valve has been closed, and the gas
hose is disconnected from the gas supply.
1. Open Lid and remove warming rack, cooking racks
and flame tents.
2. Using a 2 pt Phillips screwdriver, loosen the bolt
holding the burner in the back of the grill.
Note: This is a bolt/nut combination so make sure
to hold the nut while removing the bolt.
3. Slide the burner forward and out of the firebox.
4. Detach the ignition wire from the ignitor.
To Clean Burner
UÊ Ê>iÊÃÕÀiÊ>ÊLÕÀiÀÊ«ÀÌÃÊ>ÀiÊVi>ÀÊvÊ>ÞÊV}ð
Tip: Use a pin or paper clip to unclog.
UÊ Ê>iÊÃÕÀiÊÌiÊLÕÀiÀÊÃÊvÀiiÊvÊ>ÞÊ`>>}i°ÊvÊ
damage is found, replace the burner.
UÊ Ê>iÊÃÕÀiÊÌiÊi`ÊvÊÌiÊLÕÀiÀÊ>`Ê«À>ÀÞÊ>ÀÊ
screen are clear from insect nests, dirt, or debris.
Good Flame
Yellow
Light Blue
2 in.(5 cm)
Blue
Yellow
Light Blue
Blue
Bad Flame

20
Direct Heat
Direct heat cooking means that the food is placed on
grill grates directly over the lighted burners.
UÊ ÊÊ/iÊ`Ê«ÃÌÊV>ÊLiÊiÌiÀÊÕ«ÊÀÊ`Ü°
UÊ ÊvÊÌiÊ`ÊÃÊÊÌiÊÕ«Ê«ÃÌ]Ê}iiÀ>ÞÊV}Ê
time may be longer.
UÊÊÊÊÊÀiVÌÊi>ÌÊÃÊÕÃi`ÊÌÊÃi>ÀÊÌiÊv`ÊÌÊÃi>ÊÊÌiÊ
natural juices by cooking with intense heat for a
short period of time. The outside of the food is
browned with a flavorful grilled coating.
Indirect Heat
Indirect heat cooking means the food is placed on the
grill grate above an unheated burner, allowing the heat
from the lighted burner(s) on either side to cook the food.
UÊÊÊÊÀÊLiÃÌÊÀiÃÕÌÃ]ÊÌÕÀÊÊÌÜÊLÕÀiÀÃÊ>`ÊVÊÜÌÊ
the lid down. This will shorten the cooking time.
UÊ ÊDO NOT select indirect heat cooking when
it is windy outside.
Before Grilling
UÊ Ê>iÊÃÕÀiÊÌ>ÌÊÌiÊv`ÊÌiÃÊ>ÀiÊV«iÌiÞÊ
thawed before grilling.
UÊ Ê7ÌÊÌiÊ`ÊVÃi`]Êi>ÌÊÌiÊ}ÀÊÊ}ÊÕÃ}Ê>Ê
burners) for 10-15 minutes until the temperature
reaches over 500º F. This timing is influenced by
ambient conditions such as wind and air temperature.
UÊ ÊDO NOT lift the lid during the heating process.
UÊ Ê/iÊ«Àii>Ì}Ê«ÀViÃÃÊÜÌÊ}Êi>ÌÊÃÊiViÃÃ>ÀÞÊ
to brown and seal juices of the food.
UÊ ÊÀÊ}v>ÌÊi>ÌÊ>`Ê«ÕÌÀÞ]ÊÌÀÊiÝViÃÃÊv>ÌÊvÀÊ
meats and shorten the preheat time. Both will help
reduce flare-ups from dripping grease.
UÊ Ê}ÌÞÊÊÌiÊV}Ê}À>ÌiÃÊÜiÊV}ÊÜv>ÌÊ
meat, fish or poultry. Beware that using too much
oil can cause a gray ash to deposit on the food.
During Grilling
UÊ Ê/iÊÌi«iÀ>ÌÕÀiÊ}>Õ}iÊÊÌiÊ`Ê`V>ÌiÃÊÌiÊ
cooking temperature inside the grill.
UÊ Ê/ÕÀÊv`ÃÊÞÊViÊvÊ«ÃÃLi°ÊÕViÃÊ>ÀiÊÃÌÊ
when meat is turned several times.
UÊ Ê/ÕÀÊi>ÌÊÕÃÌÊÜiÊÌiÊÕViÃÊLi}ÊÌÊ>««i>ÀÊÊ
the surface.
UÊ ÊÛ`Ê«ÕVÌÕÀ}ÊÀÊVÕÌÌ}ÊÌiÊi>ÌÊÌÊÌiÃÌÊ
doneness. This allows the juices to escape.
UÊ Ê``ÊL>ÀLiVÕiÊÃ>ÕViÊÞÊ`ÕÀ}ÊÌiÊ>ÃÌÊ£äÊ
minutes of cooking to avoid burning the sauce.
UÊ Ê/iÊ`iiÃÃÊvÊÌiÊi>ÌÊÜÊLiÊVÌÀi`ÊLÞÊÌiÊ
type of meat, the size, shape and thickness of the
meat, the heat setting or method, and the length of
time on the grill.
UÊ Ê}ÊÌiÊÜÊLiÊ}iÀÊÜÌÊ>Ê«iÊ}ÀÊ`°
UÊ ÊÜÊvÀÊÀiÊV}ÊÌiÊÊV`Ê>`ÊÜ`ÞÊ
days, or at higher altitudes. In reverse, allow for
less cooking time in extremely hot weather.
UÊ ÊÀ}ÊV`ÌÃÊ>ÞÊÀiµÕÀiÊ>`ÕÃÌiÌÃÊvÊÌiÊ
burners to obtain and maintain the correct cooking
temperatures.
UÊ ÊÀÜ`}Êv`ÊÊÌiÊV}Ê}À>ÌiÊÜÊÀiµÕÀiÊ
more time to cook the food.
UÊ Ê1ÃiÊÌ}ÃÊvÀÊÌÕÀ}Ê>`Ê>`}Êi>ÌÊÃÌi>`ÊvÊ
a fork, to avoid losing the meat juices.
UÊ ÊvÊ>Êy>ÀiÊÕ«ÊVVÕÀÃ]ÊÌÕÀÊ>ÊÌiÊLÕÀiÀÃÊÌÊÌi OFF
position and move the food to another area of the
cooking grate. After flames subside, relight the
burners using the lighting instruction in this manual.
UÊ ÊNEVER use water to extinguish flame on a gas grill.
Cooking Methods And Grilling Tips
Care and Maintenance
To Reinstall Burner
1. Be sure the gas valve orifices are correctly
positioned inside the burner inlet.
2. Reattach the bolt/nut combination.
3. Reposition flame tents, cooking racks, and
warming rack.
Changing AA Battery
When changing the AA battery, make sure to only use
standard AA batteries, ensuring the proper polarity
when positioning the battery. Remove the Igniter
button cape and insert the AA battery so the positive
(+) terminal of the battery is facing out of the
battery box.
