Lang ECOD-PT User manual

1
IL1948
ELECTRIC FULL SIZE
COMPUTERIZED
CONVECTION OVEN
ECOD-PT
ECOF-PT
Installation and
Operation
Instructions
2M-W487 Rev. B 1/8/2010
ECOF-PT

2
These symbols are intended to alert the user to the presence of
important operating and maintenance instructions in the manual
accompanying the appliance.
FOR YOUR SAFTEY
DO NOT STORE OR USE GASOLINE OR OTHER FLAMMABLE VAPORS AND LIQUIDS IN
THE VICINTIY OF THIS OR ANY OTHER APPLIANCE.
POST IN PROMINENT LOCATION
INSTRUCTIONS TO BE FOLLOWED IN THE EVENT USER SMELLS GAS. THIS
INFORMATION SHALL BE OBTAINED BY CONSULTING YOUR LOCAL GAS SUPPLIER.
AS A MINIMUM, TURN OFF THE GAS AND CALL YOUR GAS COMPANY AND YOUR
AUTHORIZED SERVICE AGENT. EVACUATE ALL PERSONNEL FROM THE AREA.
WARNING
IMPROPER INSTALLATION, ADJUSTMENT, ALTERATION, SERVICE OR MAINTENANCE
CAN CAUSE PROPERTY DAMAGE, INJURY OR DEATH. READ THE INSTALLATION,
OPERATION & MAINTENANCE INSTRUCTIONS THOROUGHLY BEFORE INSTALLING OR
SERVICING THIS EQUIPMENT.
WARNING
RISK OF FIRE OR ELECTRIC SHOCK
DO NOT OPEN
WARNING, TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT REMOVE
CONTROL PANEL. NO USER-SERVICABLE PARTS INSIDE.
REPAIRS SHOULD BE DONE BY AUTHORIZED SERVICE PERSONNEL ONLY.
NOTICE
Using any part other than genuine Lang factory supplied parts relieves the manufacturer of all
liability.
Lang reserves the right to change specications and product design without notice. Such
revisions do not entitle the buyer to corresponding changes, improvements, additions or
replacements for previously purchased equipment.
Due to periodic changes in designs, methods, procedures, policies and regulations,
the specications contained in this sheet are subject to change without notice. While
Lang exercises good faith efforts to provide information that is accurate, we are not
responsible for errors or omissions in information provided or conclusions reached as a
result of using the specications. By using the information provided, the user assumes all risks
in connection with such use.
MAINTENANCE AND REPAIRS
Contact your local dealer for service or required maintenance. Please record the model number, serial
number, voltage and purchase & Installation Information in the area below and have it ready when you
call to ensure a faster service.
SAFETY SYMBOL
Model No.:
Serial No.:
Voltage:
1-Phase or 3 Phase:
Purchased From:
Location:
Purchase Date:
Installed Date:

3
TABLE OF CONTENTS
Specications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Equipment Description . . . . . . . . . . . . . . . . . . . . . . . . 5
Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Installation
Leg Installation . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Leg Pad Adapter Installation . . . . . . . . . . . . . . . . . . . 8
Stacking the Oven. . . . . . . . . . . . . . . . . . . . . . . . . 9
Ventilation & Clearence . . . . . . . . . . . . . . . . . . . . . . 10
Electrical Connection . . . . . . . . . . . . . . . . . . . . . . . 11
Oven Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Initial Start-Up
Pre-Power On . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Power On . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
General Operation & Programming
Control Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Typical Operation Sequence . . . . . . . . . . . . . . . . . . . 13
Hints & Suggestions. . . . . . . . . . . . . . . . . . . . . . . . 14
Loading . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Pace Timers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Program Enable Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . .16 - 19
Maintenance
Cleaning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Troubleshooting
Symptoms / Possible Causes / Test. . . . . . . . . . . . . . . . 21
Wiring Diagram
208/240VAC. . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
480, 380VAC . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
220/380VAC & 240/415VAC. . . . . . . . . . . . . . . . . . . . 24
Exploded View & Parts List . . . . . . . . . . . . . . . . . . . . . 25-31
PROBLEMS, QUESTIONS or CONCERNS
Before you proceed consult you authorized Lang service agent directory
or
Call the Lang Technical Service & Parts Department at [phone].
NOTICE ServiceonthisoranyotherLangappliancemustbeperformedbyqualied
personnel only. Consult your Lang Authorized Service Agent Directory.
You can call our tech service number [phone] or visit our website
www.langworld.com for the service agent nearest you.

4
2M-W487, Full Size Electric Convection Oven, Plantinum
SPECIFICATIONS
Model Height x Width x Depth Clearance from Weight
(without optional stand) combustible surface Installed Shipping Freight Class
ECOF 27.9” x 40.1” x 39.1” Side:6”, Back: 6”, Floor: 6” 380 lbs. 420lbs 70
708mm x 1019mm x 994mm (173 kg) (191 kg)
ECOD 27.9” x 40.1” x 46.0” Side:6”, Back: 6”, Floor: 6” 460 lbs. 500lbs 70
708mm x 1019mm x 1168mm (209 kg) (227 kg)
15.1”
384mm
2.5”
54mm
ELECTRICAL
CONNECTION
2.5”
54mm
ELECTRICAL
CONNECTION
27.0”
687mm
0.9”
23mm
IL1520
Front View Right Side View Top View
W
H
D
SPECIFICATIONS
MODEL VOLTSAC Hz. MOTOR
AMPS PHASE AMPS 3PH/ NEUTRAL KW TOT. AMPS 1 PH SUPPLY WIRE 1 PH L1 L2 L3 WIRE 3 PH
ECOF-PT2/4MF 240/415 50 3PH-4 WIRE 17.8
11.5
17.8 15.3 15.3 12
ECOD-PT 208
50/60 3.3 6
6 2.7 2.7 8
240 4.2 3.7 3.7 10
ECOF-PT 208 6 2.7 2.7 8
240 4.2 3.7 3.7 10
ECOF-PT-MF 208 6 2.7 2.7 8
240 4.2 3.7 3.7 10
ECOF-PT-NT 208 6 2.7 2.7 8
240 4.2 3.7 3.7 10
ECOF-PT480MF
480 60 3
15.6 15.6 10.5 14
ECOF-PT480NT 15.6 15.6 10.5 14
ECOF-PT-480V 15.6 15.6 10.5 14

5
2M-W487, Full Size Electric Convection Oven, Plantinum
EQUIPMENT DESCRIPTION
Exterior Construction
The oven exterior dimensions are 40” (100 cm) Wide, 27” (67.5 cm) High, 38” (95 cm) Deep. The Top,
Front, Back, and Sides are constructed of stainless steel with an aluminized bottom.
The oven doors come standard with double pane windows.
The door handle is constructed of Stainless Steel and Phenolic Tubing.
The oven cavity is insulated with high temperature insulation for efciency and reduced heat loss.
Interior Construction
The oven cavity dimensions are 29” (72.5 cm) Wide, 20” (50.84 cm) High, 21” (53.38 cm) Deep.
The interior of the oven is constructed of porcelainized stainless steel.
Operation
The ECOD-PT oven is a forced air convection oven with a vented oven cavity. The air is driven by a 1/3
HP fan motor.
Controls
Icon driven (touch) panel allows for easy operation. Complete computerized controls. Pre-Programmable
product selections. Independent shelf timers for each shelf. Load control through use of Cooking Curves.
Shelf compensation for uniform baking. Solid state temperature sensing and controls. Dual speed fan.
Manual override controls.
Technical
The ECOD-PT oven operates on either 208/240V or 480V. Thismustbespeciedwhenordering.
Floor space required is 48” (122.6 cm) wide, 44” (112.5 cm) deep. The oven weighs 430 lbs.
NOTICE The data plate is on the back side of the oven above the power cord.
The oven voltage, wattage, serial number, wire size, and clearance
specicationsareonthedataplate.Thisinformationshould
be carefully read and understood before proceeding with the
installation.
W
Door Handle Controls Steam Valve
Cover
Motor Vent
Side Access
Panel
Blower
Wheel
H
DIL1521

6
2M-W487, Full Size Electric Convection Oven, Plantinum
UNPACKING
Receiving the Oven
Upon receipt, check for freight damage, both visible and concealed.
Visible damage should be noted on the freight bill at the time of delivery and
signed by the carrier’s agent. Concealed loss or damage means it does not
become apparent until the merchandise has been unpacked. If concealed
loss or damage is discovered upon unpacking, make a written request for
inspection by the carrier’s agent within 15 days of delivery. All packing
material should be kept for inspection. Do not return damaged merchandise
to Star Manufacturing Company. File your claim with the carrier.
Location
Prior to un-crating, move the oven as near to its intended location as practical. The crating will help
protect the unit from the physical damage normally associated with moving it through hallways and
doorways.
Un-crating
The oven will arrive completely assembled inside a wood frame and strapped to a skid.
Cut the straps and remove the wood frame.
The oven can now be removed from the skid.
EACH UNIT WEIGHS 430 LBS. FOR SAFE HANDLING, INSTALLER SHOULD
OBTAIN HELP AS NEEDED, OR EMPLOY APPROPRIATE MATERIALS HAN-
DLING EQUIPMENT (SUCH AS A FORKLIFT, DOLLY, OR PALLET JACK)
TO REMOVE THE UNIT FROM THE SKID AND MOVE IT TO THE PLACE OF
INSTALLATION.
ANY STAND, COUNTER OR OTHER DEVICE ON WHICH OVEN WILL BE
LOCATED MUST BE DESIGNED TO SUPPORT THE WEIGHT OF THE OVEN.
SHIPPING STRAPS ARE UNDER TENSION AND CAN SNAP BACK WHEN CUT.
CAUTION

7
2M-W487, Full Size Electric Convection Oven, Plantinum
INSTALLATION
Leg Installation
Legs are available separately for both the
single and double deck installations. Single
deck installations require a 27-inch leg or
equipment cart. Double deck installations
require 6-inch legs or casters. All these are
available separately.
Place some cardboard on the ground and
with assistance carefully lay the unit on its
back. In stacked
The adjustable feet may be screwed in
or out as necessary to level the oven. A
torpedo level placed on an oven rack will
assist in leveling the oven.
Double-Stack Ovens
To install the 6-inch legs, adj. feet or casters
on the lower unit, follow the Leg Pad
instructions in the following section or in the
instructions included with the leg pads.
Single Oven
To install 27” legs or cart to your unit, place
the unit laying on its back onto a piece of
cardborad. Be sure to read all instructions
& follow the instructions provided with the
kit.
27” Leg Installation
With unit in position, fasten the two legs to the front corner pads then to the oven’s front corners
using the four 5/16 inch bolts provided in the leg kit. See leg pad adapter illustration to dermine
differences between front & rear support assemblies.
Lift the oven onto its front legs and block the back up using one of the 27-inch legs set upside
down in the center rear of the oven body. Install the third 27-inch leg onto the oven body on the
control side rear. Gently lift the oven rear, remove the temporary support leg & install it on the last
rear corner.
Rear
Support Assy
Front
Support Assy
Swivel
Caster
Caster Cardboard IL1524A
Above: typical leg and caster installation.
Below: accessory options, legs, casters & equipment carts sold
separately. Follow installation instructions with the each specic kit.
Stacked Units
Caster Sets 27” Leg Set
(marine also)
27” Equipment Cart
6” Adj. Leg Sets
6” Adj. Bolt Down Leg Sets
(marine only)
Accessory Options
Single Units
IL1525

8
2M-W487, Full Size Electric Convection Oven, Plantinum
INSTALLATION cont.
Leg Pad Adapter
Identify the front and rear leg adapters (the
front adapters have two threaded inserts, the
rear has four). The leg adapters are included
with each specic accessory kit.
Leg to Adapter Installation:
Install the leg’s threaded stud through the hole
in the adapter labeled “C” with the bent ange
of the adapter facing away from the leg.
Screw the 3/4-inch nut supplied in the adapter
kit onto the leg stud and tighten.
Secure to oven using hardware provided.
Caster to Adapter Installation:
Place the swivel caster against the front leg
pad adapter with the ange of the adapter
facing away from the caster.
Install the four 5/16 inch bolts through the
caster base and the adapter holes labeled “A”
then install the 5/16 inch nuts with washer and
lock washers.
Place the rigid casters against the rear leg
adapter with the ange of the adapter facing
away from the caster.
Align the caster to the holes in the adapter
labeled “B”. NOTE: There are two sets of “B” holes set at 90° from the each other. One set will
create a left rear adapter and the other set will create a right rear adapter.
Install four 5/16-inch bolts through the caster base and the adapter holes labeled “B” then install
5/16-inch nuts with lock washers and at washers.
Adapter to Oven Installation:
Gently tip the oven onto its back. Place the front leg adapter into the front corers of the oven.
The holes without the threaded inserts face the front of the oven and the ange on the adapter points
toward the bottom of the oven.
The edge of the leg adapter with the threaded insert slips under the ange on the oven side, while
the edge without the inserts sits on top of the threaded angle on the oven front.
Install two 3/8-inch bolts with lock washers and at washers through the front holes “D” in the leg
adapter and into the threaded inserts on the oven.
Thread one 3/8-inch bolt with lock washer and at washer into the rear threaded hole labeled “E” on
each of the leg adapters.
The forward threaded hole on the front leg adapter does not get a bolt installed.
Place the rear leg adapters into the rear corners of the oven so that the adapter is under the ange of
the oven side and back.
NOTE: If installing a caster place the adapter on the oven so that the casters roll forward.
Install for 3/8-inch bolts with lock washers and at washers through the holes labeled “E” in the ange
of the oven and into the threaded inserts of the leg adapter.
D
E
E
E
E E E E
E
E
E
A A
A
B
B
B
B
A
C
D D D
C
CC
OVEN BOTTOM
OVEN FRONT
IL1523
Above: Bottom on unit showing the placement of the leg adapters
and their hole assignment.

9
2M-W487, Full Size Electric Convection Oven, Plantinum
INSTALLATION cont.
Stacking the Ovens
Remove all the plug buttons from the top of the lower oven.
Remove the stacking kit from the oven compartment of one oven and install the 1 1/4-inch plastic
bushing into the top of the lower oven.
Tip the top oven backwards and install two 3/8-inch socket head bolts, found in the stacking kit,
into the two front leg holes that match the holes in the top of the lower oven. Install the socket
head bolts with the heads of the bolt pointing away from the oven.
Lift the top oven and gently set on top of the lower oven so that the heads of the socket head
bolts nest into the holes in the top of the lower oven.
NOTE: Each unit must have separate electrical connections
Button Plugs Bushing
Stacking Bolts
Upper Oven
Lower Oven
IL1526

10
2M-W487, Full Size Electric Convection Oven, Plantinum
INSTALLATION continued
Ventilation and Clearances
Standard minimum clearance from combustible construction is as follows.
4” from side
4” from back
6” from oor
• These ovens may be set directly, without legs, on a curbed base or non-combustible oor.
• If the oven is set without legs on a non-combustible oor or a curbed base, maintain a 4-inch back
clearance.
• If the oven is set directly against a non-combustible back wall, maintain a 6-inch clearance to the
oor.
• Do not install the oven closer than 4 inches from another oven on the right hand side (control panel
side).
• Do not install the oven closer than 12 inches from an uncontrolled heat source (char broiler etc.) on
the right side.
• Keep the area free & clear of combustible material, and do not obstruct the ow of combustion or
ventilation air.
• The installation of any components such as a vent hood, grease extractors, and/or re extinguisher
systems, must conform to the applicable nationally recognized installation standards.
NOTICE The installation of any components such as a vent hood, grease
extractors,reextinguishersystems,mustconformtotheir
applicable National, State and locally recognized installation
standards.

11
2M-W487, Full Size Electric Convection Oven, Plantinum
WARNING
WARNING
INSTALLATION continued
Electrical Connection
The electrical connection must be made in accordance with local codes or in the absence of local
codes with NFPA No. 70 latest edition (in Canada use: CSA STD. C22.1).
The electrical service entrance is provided by a 1 1/4-inch knockout in the bottom right front corner
of each oven, or at the oven back directly behind the control compartment.
Grounding lugs are provided at both the front and rear service entrances.
The 208/240-volt oven is a dual voltage oven and is shipped from the factory as 208 volt. The oven
must be eld converted to operate on a 240-volt power supply. To convert the oven to 240 volt,
remove the jumper wire located under the control compartment behind the bottom trim piece.
As well as changing the transformer input wire to the 240V, color on the primary side of transformer
(see illustration below).
With 380V, 440V & 480-volt installations check to be sure that the motor rotates in a clockwise
direction as viewed from the front of the oven. To reverse the motor rotation, switch any two
incoming power supply leads and recheck the rotation.
Supply wire size must be large enough to carry the amperage load for the number of ovens being
installed. Wire size information can be found on the oven DATA PLATE or in the specications
section on page 4..
208/240V ovens can be installed on both single and three-phase supplies and is shipped from the
factory for three-phase. To phase the oven to match the power supply, follow the charts on the
wiring diagram located at the back of the manual.
Certain units are provided with or can be purchased with a Cord & Plug kit
(Part number 9Q-ECOF-CK). This kit includes a 48” cord with a NEMA L15-50P plug and is
for 208/240V units ONLY. In stacked situations each units needs to have separate cord & plug
assemblies.
Oven Voltage
The Lang Model ECOF & ECOD ovens can be operated on 208, 240-volt (single or three phase), or
240/415, 480V (three phase only) source. The Amp draw, KW rating, and phasing can be found in
specication section of this manual.
THIS APPLIANCE MUST BE GROUNDED AT THE TERMINAL PROVIDED.
FAILURE TO GROUND THE APPLIANCE COULD RESULT IN ELECTROCUTION
AND DEATH.
INSTALLATION OF THE UNIT MUST BE DONE BY PERSONNEL QUALIFIED TO
WORK WITH ELECTRICITY AND PLUMBING. IMPROPER INSTALLATION CAN
CAUSE INJURY TO PERSONNEL AND/OR DAMAGE TO EQUIPMENT. UNIT
MUST BE INSTALLED IN ACCORDANCE WITH ALL APPLICABLE CODES.
208/240V
Transformer
208/240V
Jumper Location
Trim Piece
IL1593
Left: 208/240V Dual Volatage units are shipped as
208V and must be eld converted to 240V.

12
2M-W487, Full Size Electric Convection Oven, Plantinum
INITIAL START UP
Pre-Power On
After the oven is installed and connected to power, prior to turning on, verify the following:
• The doors open and close freely.
• All racks are in the oven correctly.
• All packing materials have been removed from the inside of the oven.
Power On
Once oven has been turned on verify that the blower wheel is spinning freely in a clockwise position and
that the elements are heating properly.
Conrm that both thermostat knob and timer knob move freely and that the timer beeps..
NOTICE Duringtherstfewhoursofoperationyoumaynoticeasmall
amount of smoke coming off the oven, and a faint odor from the
smoke. This is normal for a new oven and will disappear after the
rstfewhoursofuse.INITIAL START UP

13
2M-W487, Full Size Electric Convection Oven, Plantinum
GENERAL OPERATION & PROGRAMMING
Convection ovens constantly circulate air over and around the product. This strips away the thin layer of moisture
and cool air from around the product allowing heat to penetrate more quickly.
Cooking times can be shortened and cooking temperatures can be reduced.
To convert standard deck oven recipes, reduce the temperatrue 50° degrees and the time by 25%.
Make minor adjustments as necessary.
Always weigh your product. This will give you a more consistent size, color and quality.
Check the product near the end of the initial cooking.
Do not open the oven door during baking, as this will change the baking characteristics of the oven and make it
difcult to determine a nal program.
If the product is overdone on the outside and underdone on the inside, reduce the baking temperature.
If the product is pulling away from the edge of the pan, the temperature is too high or the cooking time too long.
A convection oven is a mechanical piece of equipment. The same control settings will always give the same results.
If the results vary, problems may be because of changes in the product preparation.
ECOH-PT Control Panel
The control panel consists of the following items. Detailed
operational descriptions are given later this section.
Power Switch: Turns the oven on and off
Function Keys: Keys are active when a program option
is displayed on the display adjacent to that key.
Up & Down Buttons: Allows you to scroll through the
programming selections.
Cancel: When scrolling through menus this will allow you
to back up to the previous menu. In program mode this
will allow you to back up to the previous step.
Alpha Numeric Display: Visual interface.
Typical Operation Sequence
Power Switch
AlphaNumeric
Display
Function Keys
Up & Down Button
Cancel Button
IL1476
ACTION RESULT
Press the on switch. Control panel comes on; display says “LANG, Run Oven,
Time Date Program”.
Select “Run Oven”.Display will show a list of product
to choose.
Select Product button next to
Icon desired. Display says “Preheating to XXXF”.
Beeper sounds briey. Display says “Ready”
Select Product to start. Display shows possible product
selection for that temperature.
Select Product to start.. Display says, “Select shelf”
Press Product button next to
desired shelf. Display will show icon chosen and begin to count down.
Beeper sounds continuously. Display shows “DONE”, press button and remove product from
that shelf.
Oven is ready for another
product.

14
2M-W487, Full Size Electric Convection Oven, Plantinum
GENERAL OPERATION & PROGRAMMING CONT.
Hints & Suggestions
Convection ovens constantly circulate air over and around the product. This strips away the thin layer of
moisture and cool air from around the product allowing heat to penetrate more quickly.
Cooking times can be shortened and cooking temperatures can be reduced.
To convert standard deck oven recipes, reduce the temperature 50 degrees and the time by 25%. Make
minor adjustments as necessary.
The lower the oven temperature the more even the bake.
Always weigh your product. This will give you a more consistent size, color and quality.
Check the product near the end of the initial cooking cycle by turning on the oven light and looking
through the oven door windows.
Do not open the oven doors during baking as this will change the baking characteristics of the oven and
make it difcult to determine a nal program.
If the product is overdone on the outside and underdone on the inside, reduce the baking temperature.
If the product is pulling away from the edge of the pan, the temperature is too high or the cooking time
too long.
The convection is a mechanical piece of equipment. The same control settings will always give the
same results. If the results vary, problems may be because of product preparation.
Opening the vent will to allow mositure to escape the cooking chamber during part or all of the cooking
process. This will allow a more crispy product, example: french fries, sh, crispy crusts. Close the vent
for dough products like cinnamon rolls, breads. This is something to experiment with to determine what
is best for your specic menu.
Loading
Here are some things to remember when loading your oven.
• When loading and unloading the oven, stage products and racks so the oven door is opened for the
least amount of time.
• Be sure that racks are level within the oven.
• Bent or warped pans can greatly affect the evenness of the cook or bake.
• If using baker’s parchment, be sure the parchment does not blow over the product. That will create
an uneven bake.
• Load each shelf evenly. Spaces should be maintained equally between the pan and oven walls, front
and back.
• Do not overload pan’s this will create an uneven bake.
• For best baking results, load the oven from the center out during random loading.
ALWAYS KEEP THE AREA NEAR THE APPLIANCE FREE FROM
COMBUSTIBLE MATERIALS.
KEEP FLOOR IN FRONT OF EQUIPMENT CLEAN AND DRY. IF
SPILLS OCCUR, CLEAN IMMEDIATELY, TO AVOID THE DANGER OF
SLIPS OR FALLS.
CAUTION

15
2M-W487, Full Size Electric Convection Oven, Plantinum
Record Your Menus Here Before Entering Your Program.
Record your specic menu items using the table below, prior to entering them
into your units program. Keep for your records.
1 Appetizer A 2 Appetizer B 3 Appetizer C 4 Appetizer C, Option 2 5 Apple 6 Bagel A 7 Bagel B 8 Bagel C 9 Baked Potato 10 Banana 11 Biscuit 12 Bread French 13 Bread French Option 2 14 Bread Loaf 15 Bread Sourdough Round 16 Bread Stick 17 Brownies 18 Cake A Chocolate 19 Cake B White 20 Calzone
21 Casserole 22 Cheese Stick 23 Cheese Cake 24 Cheery 25 Chicken 26 Chicken Strips 27 Cinnamon Roll 28 Cinnamon Roll, Option 2 29 Cookie A 30 Cookie A, Option 2 31 Cookie B 32 Cookie C 33 Cookie Chocolate Chip 34 Cookie D 35 Cornbread 36 Doughnut 37 Doughnut, Option 2 38 Egg Dish 39 Egg Roll 40 Fish
41 Fish, Option 2 42 Flag 43 French Fries 44 Ham 45 Hash browns 46 Hash browns, Option 2 47 Hoagie 48 Hot Dog 49 Lasagna 50 Lemon 51 Mufn A 52 Mufn B 53 Mufn C 54 Onion Rings 55 Onion Rings, Option 2 56 Pastry 57 Peanut 58 Pear 59 Pie A 60 Pie B
61 Pie C 62 Pie D 63 Pie Cherry 64 Pizza A 65 Pizza B 66 Pizza Cheese 67 Pizza Pepperoni 68 Pork Chop 69 Pot Pie 70 Potatoes 71 Pretzel 72 Quiche 73 Quiche, Option 2 74 Ribs 75 Roast Beef 76 Roll 77 Roll, Option 2 78 Sandwich A 79 Sandwich on Hoagie
80 Sandwich on Hoagie, Option 2 81 Sausage 82 Scone 83 Seafood 84 Square 85 Star 86 Triangle 87 Vegetable 88 89 Vegetable 90 Birthday Cake
Icon No. Description
Product Name Icon No.
Tier 1 Tier 2 Tier 3
Cooking
Temp Cooking
Time Cooking
Curve Fan Speed Pulse
Rate Cooking
Temp Cooking
Time Cooking
Curve Fan
Speed Pulse Rate Cooking
Temp Cooking
Time Cooking
Curve Fan Speed Pulse
Rate
ex: Biscuits 11 325°F 12:30 50% HI 100%
Product Icons: This list shows the icons available for your menu programs, they appear in the same order as shown here.
Icon No. Description Icon
No. Description Icon
No. Description Icon
No. Description

16
2M-W487, Full Size Electric Convection Oven, Plantinum
Cancel Up Down On/OffLight
Function
Keys
Function
Buttons
LCD Screen
IL1477
Platinum PROGRAMING
When using the Platinum Control Panel follow
these simple steps.
Function Keys: Are active when selecting an op-
tion that is displayed on the LCD Screen.
Function Buttons:
Cancel: During Program Mode it will take you to
the next step, otherwise it will take you back to
the
previous menu.
Up & Down: Will move you through the
selections/settings displayed on the LCD Screen
which will be used when programming your
specic requirements. (Example: access codes,
temperature settings, cooking time, curve , fan
speed etc.)
On/Off: Main Power Switch
Programming Step Contents:
Step 7 Select Product Icon,
Step 8 Select Product Name,
Step 9 Select Product Temperature,
Step 10 Select Tier Cook Time,
Step 11 Select Cooking Curve,
Step 12 Select Fan Speed,
Step 15 Continue To Next Tier
Cooking Curve: Cooking curve is a programmable function
that adjusts the cooking time to compensate for planned
times when the oven temperature would be lower than the
programmed temperature.
(i.e. temperature loses during loading and unloading).
Cooking Curve 40%, is the most commonly used. Cooking
Curve settings from 0% (no time adjustment) to 100% (max
time adjustment) are available. As a general rule the longer
the cooking time the lower the cooking curve, the shorter the
cooking time the higher the cooking curve.
Pulse Fan Function: A Fan Pulse Rate setting allows the fan to
be programmed to cycle on and off at regular intervals during
the period in the cooking cycle when there is no heat applied.
(The computer will not allow the fan to be OFF whenever the
heat is ON).
Tier Cooking: “Tiered” programming is the ability to change the
cooking temperature or fan function while cooking. (i.e. some
products may require high heat and the fan to be LO for the
rst half of the cooking cycle. Tier 1 would be programmed
with the Heat up and the fan LO and Tier 2 would then be
programmed with the heat lowered and the fan HI for the
remainder of the cycle.)
Multiple shelf baking function is disabled when using Tier
Baking programs.
Platinum PROGRAMMING

17
2M-W487, Full Size Electric Convection Oven, Plantinum
Cancel Up Down On/Off
Light
®
◄ MANUAL MODE
◄ RECIPE MODE
◄ PROGRAMMING
TIME DATE TEMP STATUS
12:00 01/01/01 325 STANDBY
Cancel Up Down On/Off
Light
◄ DISPLAY PRODUCT
◄ TIMER ONLY
◄ SET TIME / DATE
◄ PROGRAM COMPUTER
TIME DATE TEMP STATUS
12:00 01/01/01 325 STANDBY
Cancel Up Down On/Off
Light
ENTER ACCESS CODE
A
USE ▲▼ KEYS TO SELECT
THEN PRESS ENTER
◄ ENTER
PRESS CANCEL TO QUIT
Step 1. Turn power switch on. If the oven
is on, press cancel until the above
screen is displayed.
Step 2. Select TIME/DATE/PROGRAM
Step 3
Select PROGRAM COMPUTER Step 4 Using the ▲▼ arrows, enter access code “A B C D E F”
hitting ENTER after each letter.
Cancel Up Down On/Off
Light
◄ PROGRAM PRODUCT
◄ EDIT ACCESS CODE
◄ CONFIGURE TIME OF DAY
◄ CONFIGURE OVEN OPERATING
Cancel Up Down On/Off
Light
SELECT PRODUCT ICON
USE ▲▼ KEYS TO SELECT
THEN PRESS
ENTER TO ACCEPT
PIE A
◄ ENTER
Cancel Up Down On/Off
Light
SELECT PRODUCT NAME
APPETIZER A
USE ▲▼ KEYS TO SELECT
PIE A
◄ ACCEPT
◄ ENTER
Step 5 Select PROGRAM PRODUCTS
then
Step 6 Select
CREATE NEW PRODUCTS
Step 7 Select Product Icon,
This is the rst screen in creating a
product program. Press ▲▼ until
you nd a icon which resembles
your product.
Select ENTER to accept the icon
and move to the next screen.
Note: Refer to the Chart on page 13 for a
selection of icons available.
Step 8 Select Product Name,
This is where you enter the name
of the product into the computer.
Using the ▲▼ keys type over the
default name, blank space is before
the A and after the 9.
Select ACCEPT to continue.
Note: Curser must be moved past the last
digit to save the entire entry.
Platinum PROGRAMMING

18
2M-W487, Full Size Electric Convection Oven, Plantinum
Cancel Up Down On/Off
Light
SELECT PRODUCT TEMP
100
USE ▲▼ KEYS TO SELECT
PIE A
TIER 1
◄ ACCEPT
◄ ENTER
Cancel Up Down On/Off
Light
SELECT TIER COOK TIME
00:45:00
USE ▲▼ KEYS TO SELECT
PIE A
TIER 1
TEMP: 320°F
◄ ACCEPT
◄ ENTER
Cancel Up Down On/Off
Light
SELECT COOKING CURVE
000%
USE ▲▼ KEYS TO SELECT
PIE A
TIER 1
TEMP: 320°F TIME: 00:45:00
◄ ACCEPT
◄ ENTER
Step 9 Select Product Temperature,
Press the ▲▼ to select the rst
digit, then press ENTER to move
to the next digit. It will
automatically move to the next
screen after the third digit.
Step 10 Select Tier Cook Time,
Time is entered in
hours:minutes:seconds.
The maximum is 12:59:59.
Select ENTER to move the cursor
to the place you want to enter the
number.
Select ACCEPT to continue.
Step 11 Select Cooking Curve,
press ▲▼ to select the numbers,
press the ENTER to move the
cursor to the next space.
Cooking Curve may be any
number between 0% and 100%.
Select ACCEPT to continue.
Cancel Up Down On/Off
Light
SELECT FAN SPEED
HIGH LOW
USE ▲▼ KEYS TO SELECT
PIE A
TIER 1
TEMP: 320°F TIME: 00:45:00
COOKING CURVE: 80%
◄ ACCEPT
◄ ENTER
Step 12 Select Fan Speed,
Press the ▲▼ to move the curser
between the HIGH and LO
settings.
Press ENTER to make your
selection and move to the next
screen.
Cancel Up Down On/Off
Light
CORRECT?
YES NO
USE ▲▼ KEYS TO SELECT
PIE A
TIER 1
TEMP: 320°F TIME: 00:45:00
FAN: HI RATE: 100%
CCURVE: 80%
◄ ACCEPT
◄ ENTER
Step 13 Correct
The computer is asking if the
display is correct. If any part of
the program is incorrect press ▲▼
NO, and you will be taken back to
Step 7.
Selecting YES will advance the
screen.
Platinum PROGRAMMING

19
2M-W487, Full Size Electric Convection Oven, Plantinum
Cancel Up Down On/Off
Light
CONTINUE TO NEXT TIER
YES NO
USE ▲▼ KEYS TO SELECT
PIE A
TIER 1
TEMP: 320°F TIME: 00:45:00
FAN: HI RATE: 100%
CCURVE: 80%
◄ ACCEPT
◄ ENTER
Step 15 Continue To Next Tier
The cursor automatically appears
on NO. Select ENTER or
ACCEPT to end programming
or
move the curser ▲▼ to YES.
This will allow your to enter an-
other tier to this program, repeat-
ing steps 6 - 14 to program second
tier.
Cancel Up Down On/Off
Light
◄ CREATE NEW PROGRAM
◄ EDIT PRODUCT
◄ DELETE PROGRAM
Step 16 After programing the last tier, the
computer will automatically ad-
vance the screen to program more
products. If no other products
need to be programmed, select
CANCEL three times to advance
screen to the boot up screen.
Cancel Up Down On/Off
Light
®
Step 17 Boot-up Screen
You may now preheat the oven
for any product you have pro-
grammed.
Step 18 Select MANUAL OR RECIPE
MODE
◄ MANUAL MODE
◄ RECIPE MODE
◄ PROGRAMMING
TIME DATE TEMP STATUS
12:00 01/01/01 325 STANDBY
Platinum PROGRAMMING

20
2M-W487, Full Size Electric Convection Oven, Plantinum
TROUBLESHOOTING
Symptoms & Possible Causes
The following are charts of Symptoms and Possible Causes to aid in diagnosing faults with your unit.
Refer to the symptoms column to locate the type of failure then to the Possible Cause for the items to be checked.
To test for a possible cause refer to test to identify test procedures. Test indicated with an “*” should be done by a
Lang factory authorized service representative.
NOTICE If an item on the list is followed by an asterisk (*), the work should be done by
a Lang factory authorized service representative.
USE OF ANY REPLACEMENT PARTS OTHER THAN THOSE SUPPLIED BY
LANG OR THEIR AUTHORIZED DISTRIBUTORS CAN CAUSE BODILY INJURY
TO THE OPERATOR AND DAMAGE TO THE EQUIPMENT AND WILL VOID ALL
WARRANTIES.
NOTICE ServiceonthisoranyotherLangappliancemustbeperformedbyqualied
personnel only. Consult your Lang Authorized Service Agent Directory. You
can call our tech service number [phone] or visit our website
Www.langworld.com for the service agent nearest you.
BOTH HIGH AND LOW VOLTAGES ARE PRESENT INSIDE THIS APPLIANCE
WHEN THE UNIT IS PLUGGED/WIRED INTO A LIVE RECEPTACLE. BEFORE
REPLACING ANY PARTS, DISCONNECT THE UNIT FROM THE ELECTRIC
POWER SUPPLY.
CAUTION
WARNING
Symptom Possible Cause
Display will not come on
No power to cord outlet
Oven unplugged from outlet
Failed power cord or plug
Contrast needs to be adjusted
Failed display board
Oven will not heat
Power Switch is not “ON”
Product not selected
Failed Transformer
Failed Probe
Failed Circuit board
Failed Contactor
Failed Over-temperature Thermostat
Failed Element
Oven motor will not run
Power Switch is not “ON”
Product not selected
Failed Transformer
Failed Contactor
Failed Motor
Failed output on circuit board.
Product burning Product is cooked too long Failed Probe
Failed Circuit board
Product under done Product is not cooking long enough
Failed Probe
Failed Circuit board
Possible Cause Test
Product is cooked too long No test available, operational condition
Failed Probe Check probe for proper resistance*
Failed Circuit board Conrm that Circuit board is getting correct voltage and putting out correct
voltage*
Failed Transformer Check both Primary and Secondary
coils for correct voltage*
Failed Contactor
Remove the wires from the contactor
coil and check for continuity across the
contactor coil connection*
Ensure the contactor moveable points
move freely up and down*
Failed Motor Conrm that motor is getting correct
voltage*
Failed or disconnected
safety thermostat Check across the thermostat connectors for continuity*
Failed Element Conrm that Elements are getting
correct voltage and have continuity*
