Lang EHS-AP Owner's manual

Lang Manufacturing Company 10 Sunnen Drive St. Louis, MO 63143
Rev. D Phone: [phone] Fax: [phone]
Part # 2M-60800-44 WWW.LANGWORLD.COM
Installation, Operation, & Maintenance
Model: EHS-AP, Electric Full Size Convection Oven

THIS MANUAL MUST BE RETAINED FOR FUTURE REFERENCE. READ, UNDERSTAND
AND FOLLOW THE INSTRUCTIONS AND WARNINGS CONTAINED IN THIS MANUAL.
DANGER POTENTIALLY HAZARDOUS SITUATION WHICH, IF NOT
AVOIDED, COULD RESULT IN DEATH.
WARNING POTENTIALLY HAZARDOUS SITUATION WHICH, IF NOT
AVOIDED, COULD RESULT IN DEATH OR SERIOUS INJURY.
CAUTION POTENTIALLY HAZARDOUS SITUATION WHICH, IF NOT
AVOIDED, MAY RESULT IN MINOR OR MODERATE INJURY.
NOTICE Helpful operation and installation instructions and tips are
present.
FOR YOUR SAFETY
DO NOT STORE OR USE GASOLINE OR OTHER FLAMMABLE VAPORS AND LIQUIDS IN
THE VICINITY OF THIS OR ANY OTHER APPLIANCE.
POST IN A PROMINENT LOCATION
INSTRUCTIONS TO BE FOLLOWED IN THE EVENT USER SMELLS GAS. THIS
INFORMATION SHALL BE OBTAINED BY CONSULTING YOUR LOCAL GAS SUPPLIER.
AS A MINIMUM, TURN OFF THE GAS AND CALL YOUR GAS COMPANY AND YOUR
AUTHORIZED SERVICE AGENT. EVACUATE ALL PERSONNEL FROM THE AREA.
WARNING: IMPROPER INSTALLATION, ADJUSTMENT, ALTERATION, SERVICE OR
MAINTENANCE CAN CAUSE PROPERTY DAMAGE, INJURY OR DEATH. READ THE
INSTALLATION, OPERATING AND MAINTENANCE INSTRUCTIONS THOROUGHLY
BEFORE INSTALLING OR SERVICING THIS EQUIPMENT.
Model #: Purchased From:
Serial #: Location:
Date Purchased: Date Installed:
Purchase Order #: For Service, Call:

UL File # 8138 Rev. D2010
3
TABLE OF CONTENTS
CHAPTER PAGE
TABLE OF CONTENTS ...................................................................................... 3
READ FIRST ........................................................................................................ 4
EQUIPMENT DESCRIPTION ............................................................................. 6
UNPACKING........................................................................................................ 7
INSTALLATION .................................................................................................. 8
INITIAL START-UP ............................................................................................ 12
OPERATION ........................................................................................................ 13
MAINTENANCE & CLEANING PROCEDURES.............................................. 15
TROUBLE SHOOTING ....................................................................................... 16
PARTS LIST ......................................................................................................... 18
WIRING DIAGRAM ............................................................................................ 19

UL File # 8138 Rev. D2010
4
IMPORTANT READ FIRST IMPORTANT
CAUTION EACH UNIT WEIGHS 225 LBS (102.23 KILOGRAMS). FOR SAFE HANDLING,
INSTALLER SHOULD OBTAIN HELP AS NEEDED, OR EMPLOY
APPROPRIATE MATERIALS HANDLING EQUIPMENT (SUCH AS A
FORKLIFT, DOLLY, OR PALLET JACK) TO REMOVE THE UNIT FROM THE
SKID AND MOVE IT TO THE PLACE OF INSTALLATION.
CAUTION ANY STAND, COUNTER OR OTHER DEVICE ON WHICH OVEN WILL BE
LOCATED MUST BE DESIGNED TO SUPPORT THE WEIGHT OF THE OVEN.
CAUTION SHIPPING STRAPS ARE UNDER TENSION AND CAN SNAP BACK WHEN
CUT.
DANGER THIS APPLIANCE MUST BE GROUNDED AT THE TERMINAL PROVIDED.
FAILURE TO GROUND THE APPLIANCE COULD RESULT IN
ELECTROCUTION AND DEATH.
WARNING INSTALLATION OF THE UNIT MUST BE DONE BY PERSONNEL QUALIFIED
TO WORK WITH ELECTRICITY AND PLUMBING. IMPROPER INSTALLATION
CAN CAUSE INJURY TO PERSONNEL AND/OR DAMAGE TO EQUIPMENT.
UNIT MUST BE INSTALLED IN ACCORDANCE WITH ALL APPLICABLE
CODES.
NOTICE The data plate is located on the back of the oven above the power outlet. The
oven voltage, wattage, serial number, wire size, and clearance specifications
are on the data plate. This information should be carefully read and
understood before proceeding with the installation.
NOTICE The installation of any components such as a vent hood, grease extractors,
fire extinguisher systems, must conform to their applicable National, State
and locally recognized installation standards.
NOTICE During the first few hours of operation you may notice a small amount of
smoke coming off the oven, and a faint odor from the smoke. This is normal
for a new oven and will disappear after the first few hours of use.
CAUTION ALWAYS KEEP THE AREA NEAR THE APPLIANCE FREE FROM
COMBUSTIBLE MATERIALS.
CAUTION KEEP FLOOR IN FRONT OF EQUIPMENT CLEAN AND DRY. IF SPILLS
OCCUR, CLEAN IMMEDIATELY, TO AVOID THE DANGER OF SLIPS OR
FALLS.
WARNING KEEP WATER AND SOLUTIONS OUT OF CONTROLS. NEVER SPRAY OR
HOSE CONTROL CONSOLE, ELECTRICAL CONNECTIONS, ETC.
CAUTION MOST CLEANERS ARE HARMFUL TO THE SKIN, EYES, MUCOUS
MEMBRANES AND CLOTHING. PRECAUTIONS SHOULD BE TAKEN TO
WEAR RUBBER GLOVES, GOGGLES OR FACE SHIELD AND PROTECTIVE
CLOTHING. CAREFULLY READ THE WARNING AND FOLLOW THE
DIRECTIONS ON THE LABEL OF THE CLEANER TO BE USED.
NOTICE Never leave a chlorine sanitizer in contact with stainless steel surfaces
longer than 10 minutes. Longer contact can cause corrosion.
NOTICE Service on this, or any other, LANG appliance must be performed by
qualified personnel only. Consult your authorized service station directory
or call the factory at 1-800-224-LANG (5264), or WWW.LANGWORLD.COM for
the service station nearest you.

UL File # 8138 Rev. D2010
5
IMPORTANT READ FIRST IMPORTANT
WARNING BOTH HIGH AND LOW VOLTAGES ARE PRESENT INSIDE THIS APPLIANCE
WHEN THE UNIT IS PLUGGED/WIRED INTO A LIVE RECEPTACLE. BEFORE
REPLACING ANY PARTS, DISCONNECT THE UNIT FROM THE ELECTRIC
POWER SUPPLY.
CAUTION USE OF ANY REPLACEMENT PARTS OTHER THAN THOSE SUPPLIED BY
LANG OR THEIR AUTHORIZED DISTRIBUTORS CAN CAUSE BODILY
INJURY TO THE OPERATOR AND DAMAGE TO THE EQUIPMENT AND WILL
VOID ALL WARRANTIES.

UL File # 8138 Rev. D2010
6
EQUIPMENT DESCRIPTION
Lang Model: EHS-AP
Exterior Construction
The oven exterior dimensions are 30” (76.2 cm) Wide, 25.25” (74.3 cm) High, 26.5” (67.31
cm) Deep. The Top, Front, Back, and Sides are constructed of stainless steel with an
aluminized bottom.
The oven door comes standard with a window.
The door handle is constructed of Polycarbinate.
The oven cavity is insulated with high temperature insulation for efficiency and reduced heat
loss.
Interior Construction
The oven cavity dimensions are 15” (38.1 cm) Wide, 20” (50.84 cm) High, 21” (53.38 cm)
Deep.
The oven is designed for five shelves and comes with five Chrome Plated Racks.
The interior of the oven is constructed of stainless steel.
Operation
The EHS-AP oven is a forced air convection oven with a vented oven cavity.
A 1/3 HP fan motor drives the air.
Controls
Easy to use manual control knobs.
Solid-state temperature sensing and controls.
Pulse and two-speed fan.
Technical
Oven operates as shipped on either 208, 240, or 480-Volt Single, or Three Phase.
The oven can be shipped with a Power Cord and Plug attached, but must be specified upon
ordering (part number is listed in the Parts portion of this manual).
Floor space required is 42” (106.68cm) Wide, 32.5” (82.55cm) Deep.
The oven weighs 225 lb. (102.5 Kilograms).
The ovens are stackable and can include stacking kit if requested.

UL File # 8138 Rev. D2010
7
UNPACKING
Receiving the Oven
Upon receipt, check for freight damage, both visible and concealed. Visible
damage should be noted on the freight bill at the time of delivery and signed by the
carrier's agent. Concealed loss or damage means loss or damage, which does not
become apparent until the merchandise has been unpacked. If concealed loss or
damage is discovered upon unpacking, make a written request for inspection by the
carrier's agent within 15 days of delivery. All packing material should be kept for
inspection. Do not return damaged merchandise to Lang Manufacturing
Company. File your claim with the carrier.
Location
Prior to un-crating, move the oven as near to its intended location as practical. The
crating will help protect the unit from the physical damage normally associated
with moving it through hallways and doorways.
Un-crating
The oven will arrive completely assembled inside a wood frame and strapped to a
skid. Cut the straps and remove the wood frame.
CAUTION EACH UNIT WEIGHS 225 LBS (102.23 KILOGRAMS). FOR SAFE HANDLING,
INSTALLER SHOULD OBTAIN HELP AS NEEDED, OR EMPLOY
APPROPRIATE MATERIALS HANDLING EQUIPMENT (SUCH AS A
FORKLIFT, DOLLY, OR PALLET JACK) TO REMOVE THE UNIT FROM THE
SKID AND MOVE IT TO THE PLACE OF INSTALLATION.
CAUTION ANY STAND, COUNTER OR OTHER DEVICE ON WHICH OVEN WILL BE
LOCATED MUST BE DESIGNED TO SUPPORT THE WEIGHT OF THE OVEN.
CAUTION SHIPPING STRAPS ARE UNDER TENSION AND CAN SNAP BACK WHEN
CUT.
The unit may now be removed from its skid.

UL File # 8138 Rev. D2010
8
INSTALLATION
DANGER THIS APPLIANCE MUST BE GROUNDED AT THE TERMINAL PROVIDED.
FAILURE TO GROUND THE APPLIANCE COULD RESULT IN
ELECTROCUTION AND DEATH.
WARNING INSTALLATION OF THE UNIT MUST BE DONE BY PERSONNEL QUALIFIED
TO WORK WITH ELECTRICITY AND PLUMBING. IMPROPER INSTALLATION
CAN CAUSE INJURY TO PERSONNEL AND/OR DAMAGE TO EQUIPMENT.
UNIT MUST BE INSTALLED IN ACCORDANCE WITH ALL APPLICABLE
CODES.
NOTICE The data plate is located on the back of the oven above the power outlet. The
oven voltage, wattage, serial number, wire size, and clearance specifications
are on the data plate. This information should be carefully read and
understood before proceeding with the installation.
NOTICE The installation of any components such as a vent hood, grease extractors,
fire extinguisher systems, must conform to their applicable National, State
and locally recognized installation standards.
Leg Installation
Legs are available for single, double, and counter top installations. Single deck
installations require a 28-inch leg, double deck installations require a 16-inch leg,
and counter top installations require a 4-inch leg.
To install the 28-inch legs, place some cardboard on the floor and gently tip the
oven onto its back. Fasten two legs to the oven's front. Lift the oven onto its front
legs and block the back up using one of the 28-inch legs set upside down in the
center rear of the oven body. Install the last 28-inch leg onto the oven body on the
control side rear. Gently lift the oven rear, remove the leg set to support the oven
center and install it on the last rear corner.
To install the 16-inch legs follow the same instructions as the 28-inch legs.
To install the 4-inch legs, place some cardboard on the floor and gently tip the oven
onto its back. Fasten the four 4-inch legs into the threaded holes provided on the
bottom of the convection oven. Gently lift the oven onto the legs.
Stacking the Ovens
Stacking kits must be requested upon purchase.
Remove all the plug buttons from the top of the lower oven.
Remove the stacking kit from the oven compartment of one oven and install the 1
1/4-inch plastic bushing into the top of the lower oven.
Tip the top oven backwards and install two pins into the front leg holes of the top
oven.
Lift the top oven and gently set on top of the lower oven so that the studs nest into
the holes of the lower oven.

UL File # 8138 Rev. D2010
9
INSTALLATION CONT’D
Reversing the door
1. Disconnect oven from power.
2. Remove the top and bottom door hinge covers (4) by removing the two 10-32 Phillip
head screws (8).
3. Remove the top door hinge bracket (1) from the oven by removing the two ¼-20
Phillip head screws (7). The hinge should now slide off of the door pin (this will now
be your right hand lower hinge)
4. Lift the door off of the bottom pin and set aside.
5. Remove the bottom door hinge bracket (2) by removing the two ¼-20 Phillip head
screws (7) (this will now be your upper right hand hinge).
6. Remove the lower hinge mounting plate (9) by pulling it from behind the leg pad
adapter on the bottom of the oven.
7. Remove the two Phillips head screws in the bottom right corner of the oven, where the
new hinge will be placed.
8. Slide the hinge mounting plate (9) into place and mount the hinge bracket (this should
be your old upper hinge) using two ¼-20 (7) Phillips head screws.
9. Remove the two Phillips head screws in the upper right corner of the oven where the
new hinge will be placed.
10. Rotate the door 180°and slide the door pin into the bottom hinge bracket.
11. Slide the upper door hinge (1) onto the upper door pin and then screw into place using
two ¼-20 Phillip head screws.
12. Place the top and bottom door hinge covers (4) back on the oven using two 10-32
Phillip head screws (8).

UL File # 8138 Rev. D2010
10
INSTALLATION CONT’D
Vent Cap Installation
NOT REQUIRED IF OVEN HAS SOLID TOP!
Step one: Attach vent flange to oven top with screws
Vent Flange Oven TopScrew (2x)
Step two: Attach vent cover to vent flange with screws
Vent Cover Oven Top
Screw (2x)
Step three: Assembly is complete

UL File # 8138 Rev. D2010
11
INSTALLATION CONT’D
Ventilation and Clearances
Standard minimum clearance from combustible construction is as follows.
4” from side
4” from back
6” from floor
These ovens may be set directly, without legs, on a curbed base or non-combustible
floor.
If the oven is set without legs on a non-combustible floor or a curbed base, maintain a
4-inch back clearance.
If the oven is set directly against a non-combustible back wall, maintain a 6-inch
clearance to the floor.
Do not install the oven closer than 4 inches from another oven on the right hand side
(control panel side).
Do not install the oven closer than 12 inches from an uncontrolled heat source (char
broiler etc.) on the right side.
Keep the appliance area free and clear of combustible material and do not obstruct the
flow of combustion or ventilation air.
The installation of any components such as a vent hood, grease extractors, and/or fire
extinguisher systems, must conform to the there applicable nationally recognized
installation standards.
Electrical Connection
The electrical connection must be made in accordance with local codes or in the
absence of local codes with NFPA No. 70 latest edition (in Canada use: CSA STD.
C22.1).
The electrical service entrance is provided by a 1 1/4-inch knockout at the oven back
directly behind the control compartment. A grounding lug is provided at the rear
service entrance.
The EHS-AP can be purchased with a Cord & Plug kit (Part number is listed in the
parts portion of this manual.). This kit includes a 48” cord with a NEMA L15-30P
plug
Oven Voltage
The Lang Model EHS oven can be operated on 208, 240 (single or three phase), or
480-volt (three phase only) source. The Amp draw, KW rating, and phasing can be
found in the wiring diagram section of this manual.

UL File # 8138 Rev. D2010
12
INITIAL START UP
Pre-Power On
After the oven is installed and connected to power, prior to turning on, verify the
following:
•The door opens and closes freely.
•All racks are in the oven correctly.
•All packing materials have been removed from the inside of the oven.
Power On
Once oven has been turned on verify that the blower wheel is spinning freely in a
clockwise position and that the elements are heating properly.
Confirm that both thermostat knob and timer knob move freely and that the timer
beeps.
NOTICE During the first few hours of operation you may notice a small amount of
smoke coming off the oven, and a faint odor from the smoke. This is normal
for a new oven and will disappear after the first few hours of use.

UL File # 8138 Rev. D2010
13
OPERATION
Control Panel
Typical Operation Sequence
ACTION RESULT
Turn power switch to ON. Control panel heat call light comes on.
Adjust proper temperature, between 140°F& 450°F
and allow to preheat up to 20 minutes.
Oven begins heating.
Open oven doors and insert product, set timer up to
60 minutes.
Timer begins counting down.
Timer beeps continuously when done. Product should now be done.
Power switch.
Pulse fan switch. Pulse fan
setting will only turn the fan
on when the oven is calling
for heat.
Dual speed switch.
Toggles the fan between
high and low speed.
Timer Control. Electronic one
hour timer with continuous
beeper.
Temperature Control. Allows
temperature to be set in 25°F
increments from 140°F.
TIME
TEMP
PULSE FAN HI-SPEED
FAN LOW-SPEED
ON
OFF

UL File # 8138 Rev. D2010
14
OPERATION CONT’D
Hints & Suggestions
Convection ovens constantly circulate air over and around the product. This strips
away the thin layer of moisture and cool air from around the product allowing heat to
penetrate more quickly.
Cooking times can be shortened and cooking temperatures can be reduced.
To convert standard deck oven recipes, reduce the temperature 50 degrees and the time
by 25%. Make minor adjustments as necessary.
The lower the oven temperature the more even the bake.
Always weigh your product. This will give you a more consistent size, color and
quality.
Check the product near the end of the initial cooking.
Do not open the oven doors during baking as this will change the baking characteristics
of the oven and make it difficult to determine a final program.
If the product is overdone on the outside and underdone on the inside, reduce the
baking temperature.
If the product is pulling away from the edge of the pan, the temperature is too high or
the cooking time too long.
The convection is a mechanical piece of equipment. The same control settings will
always give the same results. If the results vary, problems may be because of product
preparation.
Loading
When loading and unloading the oven, stage products and racks so the oven doors are
opened for the least amount of time.
Be sure that racks are level within the oven.
Bent or warped pans can greatly affect the evenness of the cook or bake.
If using baker’s parchment, be sure the parchment does not blow over the product.
The will create an uneven bake.
Load each shelf evenly. Spaces should be maintained equally between the pan and
oven walls, front and back.
Do not overload pan’s this will create a uneven bake.
For best baking results, load the oven from the center out during random loading.
CAUTION ALWAYS KEEP THE AREA NEAR THE APPLIANCE FREE FROM
COMBUSTIBLE MATERIALS.
CAUTION KEEP FLOOR IN FRONT OF EQUIPMENT CLEAN AND DRY. IF SPILLS
OCCUR, CLEAN IMMEDIATELY, TO AVOID THE DANGER OF SLIPS OR
FALLS.

UL File # 8138 Rev. D2010
15
MAINTENANCE & CLEANING
WARNING KEEP WATER AND SOLUTIONS OUT OF CONTROLS. NEVER SPRAY OR
HOSE CONTROL CONSOLE, ELECTRICAL CONNECTIONS, ETC.
CAUTION MOST CLEANERS ARE HARMFUL TO THE SKIN, EYES, MUCOUS
MEMBRANES AND CLOTHING. PRECAUTIONS SHOULD BE TAKEN TO
WEAR RUBBER GLOVES, GOGGLES OR FACE SHIELD AND PROTECTIVE
CLOTHING. CAREFULLY READ THE WARNING AND FOLLOW THE
DIRECTIONS ON THE LABEL OF THE CLEANER TO BE USED.
NOTICE Never leave a chlorine sanitizer in contact with stainless steel surfaces
longer than 10 minutes. Longer contact can cause corrosion.
Cleaning
•Always start with a cold oven.
•Always follow the cleaner manufacturer's instructions when using any cleaner.
•Care should be taken to prevent caustic cleaning compounds from coming in
contact with the blower wheel.
•Always apply these cleaners when the oven is cold and rub in the direction of the
metal's grain.

UL File # 8138 Rev. D2010
16
TROUBLESHOOTING
Symptoms
What follows is a chart of Symptoms and Possible Causes to aid in diagnosing
faults with the oven.
Refer to the Symptoms column to locate the type of failure then to the Possible
Cause for the items to be checked.
To test for a possible causes refer to the TEST section and locate the Possible
Cause then refer to test to identify test procedures.
SYMPTOM POSSIBLE CAUSE
Power indicator is not lit. •No power to cord outlet
•Oven unplugged from outlet
•Failed power cord or plug
•Failed power switch
•Failed indicator light
Oven will not heat •Power Switch is not “ON”
•Failed Transformer
•Failed Probe
•Failed Circuit board
•Failed Contactor
•Failed Over-temperature Thermostat
•Failed Element
Oven motor will not run •Power Switch is not “ON”
•Failed Transformer
•Failed Contactor
•Failed Motor
Product burning •Product is cooked too long
•Failed Probe
•Failed Circuit board
Product under done •Product is not cooking long enough
•Failed Probe
•Failed Circuit board

UL File # 8138 Rev. D2010
17
TROUBLESHOOTING CONT’D
NOTICE Service on this, or any other, LANG appliance must be performed by
qualified personnel only. Consult your authorized service station directory
or call the factory at 1-800-224-LANG (5264), or WWW.LANGWORLD.COM for
the service station nearest you.
WARNING BOTH HIGH AND LOW VOLTAGES ARE PRESENT INSIDE THIS APPLIANCE
WHEN THE UNIT IS PLUGGED/WIRED INTO A LIVE RECEPTACLE. BEFORE
REPLACING ANY PARTS, DISCONNECT THE UNIT FROM THE ELECTRIC
POWER SUPPLY.
TESTS
If an item on the list is followed by an asterisk (*), the work should be done by a
factory authorized service representative.
Possible Cause TEST
Product is cooked too long •No test available, operational condition
Failed Probe •Check probe for proper resistance*
Failed Circuit board •Confirm that Circuit board is getting correct
voltage and putting out correct voltage*
Failed Transformer •Check both Primary and Secondary coils for
correct voltage*
Failed Contactor •Remove the wires from the contactor coil and
check for continuity across the contactor coil
connection*
•Ensure the contactor moveable points move
freely up and down*
Failed Motor •Confirm that motor is getting correct voltage*
Failed or disconnected safety
thermostat
•Check across the thermostat connectors for
continuity*
Failed Element •Confirm that Elements are getting correct
voltage and have continuity*
CAUTION USE OF ANY REPLACEMENT PARTS OTHER THAN THOSE SUPPLIED BY
LANG OR THEIR AUTHORIZED DISTRIBUTORS CAN CAUSE BODILY
INJURY TO THE OPERATOR AND DAMAGE TO THE EQUIPMENT AND WILL
VOID ALL WARRANTIES.

UL File # 8138 Rev. D2010
18
PARTS LIST EHS-AP Half Size Convection Oven
DESCRIPTION PART NO.
Element EHS Oven 208 Volt 7500 Watts 2N-11090-20
Element EHS Oven 240 Volt 7500 Watts 2N-11090-21
Element EHS Oven 480 Volt 7500 Watts 2N-11090-22
Stacking Pins 2C-20108-01
Motor 1/3 HP 480 Volt 2 Speed 2U-30200-16
Motor 1/3 HP 208/240 Volt 2 Speed 2U-30200-17
Switch Toggle On-Off 2E-30303-06
Switch 12 Position 2E-30304-16
Thermostat Safety 490°F Open Q9-60102-102
Terminal Block 3 Pole 2E-30501-02
Contactor 3 Pole 24 VAC 2E-30700-06
Contactor 2 Pole 24 VAC 2E-30701-05
Timer, Electric PS-60101-W4
Buzzer, Electric Timer 2J-30802-02
Transformer 480/240 VAC 2E-31400-04
Transformer 120-208-240/24 VAC 2E-31400-07
Pilot Light 2J-31601-07
Circuit Board Temperature Control 2E-40101-W19
Probe Temperature Sensor 2E-41100-12
Oven Rack 2B-50200-34
Oven Rack Slide 2B-50200-83
Door Handle 11 1/2” Long Black “T” Style 2R-50800-12
Complete Door Assembly Q9-51100-53
Baffle Q9-60101-621
Door Magnet Q9-60102-147
Top Panel Q9-60102-136
Rear Panel Q9-60102-1361
Right Hand Panel Q9-60102-1364
Motor Cover Q9-60102-1368
Switch, Plunger Q9-60102-40
Switch, Plunger Oven Door (Between V-27971 & W-48418, except
for reversible doors) 2E-30301-17
Switch Micro Convection Oven Door (Before V-27971 & After W-
48418 and all reversible doors) Q9-51100-18
Door Seal Q9-60102-97
Panel Label OB-60301-25
Hinge Bracket Assembly, Upper and Lower Q9-50313-030
Knob Time/Temperature Control 2R-70701-28
Window Assembly, Oven Door 2Q-71301-04
Blower Wheel 2U-71500-06

UL File # 8138 Rev. D2006
19
WIRING DIAGRAM 208/240

UL File # 8138 Rev. D2006
20
WIRING DIAGRAM 480
