Lang 124T User manual

IL1552
1
THERMOSTATIC
ELECTRIC GRIDDLE
Commercial & Marine
124T, 124TC, 124THE, 124TSS
136T, 136TC, 136TNTS
148T, 148TC, 148TSS
160T, 160TC, 160TSS
172T, 172TC, 172TSS
Installation and
Operation
Instructions
2M-W352 Rev. F 10/01/08
136T

2
These symbols are intended to alert the user to the presence of
important operating and maintenance instructions in the manual
accompanying the appliance.
FOR YOUR SAFTEY
DO NOT STORE OR USE GASOLINE OR OTHER FLAMMABLE VAPORS AND LIQUIDS IN
THE VICINTIY OF THIS OR ANY OTHER APPLIANCE.
POST IN PROMINENT LOCATION
INSTRUCTIONS TO BE FOLLOWED IN THE EVENT USER SMELLS GAS. THIS
INFORMATION SHALL BE OBTAINED BY CONSULTING YOUR LOCAL GAS SUPPLIER.
AS A MINIMUM, TURN OFF THE GAS AND CALL YOUR GAS COMPANY AND YOUR
AUTHORIZED SERVICE AGENT. EVACUATE ALL PERSONNEL FROM THE AREA.
WARNING
IMPROPER INSTALLATION, ADJUSTMENT, ALTERATION, SERVICE OR MAINTENANCE
CAN CAUSE PROPERTY DAMAGE, INJURY OR DEATH. REAT THE INSTALLATION,
OPERATION & MAINTENANCE INSTRUCTIONS THOROUGHLY BEFORE INSTALLING OR
SERVICING THIS EQUIPMENT.
WARNING
RISK OF FIRE OR ELECTRIC SHOCK
DO NOT OPEN
WARNING, TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT REMOVE
CONTROL PANEL. NO USER-SERVICABLE PARTS INSIDE.
REPAIRS SHOULD BE DONE BY AUTHORIZED SERVICE PERSONNEL ONLY.
NOTICE
Using any part other than genuine Star factory supplied parts relieves the manufacturer of all
liability.
Star reserves the right to change speci¿cations and product design without notice. Such
revisions do not entitle the buyer to corresponding changes, improvements, additions or
replacements for previously purchased equipment.
Due to periodic changes in designs, methods, procedures, policies and regulations, the
speci¿cations contained in this sheet are subject to change without notice. While Star
Manufacturing exercises good faith efforts to provide information that is accurate, we are
not responsible for errors or omissions in information provided or conclusions reached as a
result of using the speci¿cations. By using the information provided, the user assumes all risks
in connection with such use.
MAINTENANCE AND REPAIRS
Contact your local dealer for service or required maintenance. Please record the model number, serial
number, voltage and purchase & Installation Information in the area below and have it ready when you
call to ensure a faster service.
SAFETY SYMBOL
Model No.:
Serial No.:
Voltage:
1-Phase or 3 Phase:
Purchased From:
Location:
Purchase Date:
Installed Date:

3
TABLE OF CONTENTS
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 5
Equipment Description . . . . . . . . . . . . . . . . . . . . . . . . 6
Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Installation
Leg Installation . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Ventilation & Clearence . . . . . . . . . . . . . . . . . . . . . . 9
Electrical Connection . . . . . . . . . . . . . . . . . . . . . . . 9
Technical Data. . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Phasing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Initial Start-Up
Pre-Power On . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Power On . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Seasoning Cooking Surface. . . . . . . . . . . . . . . . . . . . 10
Operation
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Loading the Griddle . . . . . . . . . . . . . . . . . . . . . . . . 11
Suggested Times and Temperatures . . . . . . . . . . . . . . . 11
Maintenance
Cleaning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Crome Surface Griddle Care . . . . . . . . . . . . . . . . . . . 13
Troubleshooting
Symptoms / Possible Causes . . . . . . . . . . . . . . . . . . . 14
Possible Causes / Test . . . . . . . . . . . . . . . . . . . . . . 14
Wiring Diagram
208/240VAC. . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
480VAC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Exploded View & Parts List . . . . . . . . . . . . . . . . . . . . . 18-23
PROBLEMS, QUESTIONS or CONCERNS
Before you proceed consult you authorized Lang service agent directory
or
Call the Lang Technical Service & Parts Department at 1-800-807-9054.
NOTICE Service on this or any other Lang appliance must be performed by qualified
personnel only. Consult your Lang Authorized Service Agent Directory.
You can call our toll free number 1-800-807-9054 or visit our website
WWW.STAR-MFG.COM for the service agent nearest you.

4
WD
H
4” (101.6mm) 2.5”
Elec. Connect.
6.8”
Elec. Connect.
36”
Elec. Connect.
(160 & 172 only)
IL1547
Model
Height x Width x Depth Clearance from Weight
Freight Class(Not including legs) combustible surface Actual Shipping
124 15.0" x 24.0" x 28.2" 243 lbs. 280 lbs.
85
381mm x 610mm x 717mm 110 kg 127 kg
136 15.0" x 36.0" x 28.2" 368 lbs. 410 lbs.
381mm x 914mm x 717mm 167 kg 186 kg
148 15.0" x 48.0" x 28.2" Sides: 2" 483 lbs. 515 lbs.
381mm x 1219mm x 717mm Back: 2" 220 kg 234 kg
160 15.0" x 60.0" x 28.2" 621 lbs. 665 lbs.
381mm x 1524mm x 717mm 282 kg 302 kg
172 15.0" x 72.0" x 28.2" 724 lbs. 800 lbs.
381mm x 1830mm x 717mm 329 kg 364 kg
EQUIPMENT SPECIFICATIONS
Current Model Volts AC Hz. PH. Kw
TOT. Amp 1PH. Supply Wire
1 PH
Amp 3 Ph Kw
TOT. Amp 1PH. Supply Wire
1 PH
Amp 3 Ph Supply
Wire
3 PH
L1 L2 L3 L1 L2 L3
124T-380VM 380V 50/60 3 12 27.3 15.7 15.7 10
124T-440VM 440V 50/60 3 12 23.6 13.6 13.6 10
124T-480VM 480V 60 3 12 22 13 13 12
124T-M 208/240V 60 1/3 12 58 4 50 29 29 6
136T-440VM 440V 60 3 18 23.6 23.6 23.6 12
136T-480VM 480V 60 3 18 22 22 22 12
136T-M 208/240V 60 1/3 18 87 2 50 50 50 6
148T-440VM 208/240 60 1/3 18 87 2 50 50 50 6
148T-480VM 480V 60 3 24 33 33 22 8
148T-M 208/240V 60 1/3 24 116 1 75 75 50 3
160T-M 208/240V 60 1/3 12 58 2 50 29 29 6 18 87 2 50 50 50 6
172T-440VM 440V 60 3 18 23.6 23.6 23.6 12 18 23.6 23.6 23.6 12
172T-480VM 480V 60 3 18 22 22 22 12 18 22 22 22 12
172T-M 208/240V 60 1/3 18 87 2 50 50 50 6 18 87 2 50 50 50 6
SPECIFICATIONS MARINE

5
SPECIFICATIONS
EQUIPMENT SPECIFICATIONS
Current Model Volts AC Hz. PH Kw
Tot. Amp 1ph. Sply Wire
1ph
Amp 3 Ph Sply
Wire
3ph
Kw
Tot. Amp 1ph. Sply Wire
1ph
Amp 3 Ph Sply
Wire
3ph
L1 L2 L3 L1 L2 L3
124T 208/240V 60 1/3 12 58 4 50 29 29 6
124T-220V 220V 50/60 1/3 10 45.5 6 39.4 22.7 22.7 8
124T-220VCW 220V 50/60 1/3 10 45.5 6 39.4 22.7 22.7 8
124T-380V 380V 60 3 12 27.3 15.7 15.7 10
124T-480V 480V 60 3 12 22 13 13 12
124T-480VSJ 480V 60 3 12 22 13 13 12
124T-BK 208/240V 60 1/3 12 58 4 50 29 29 6
124TC 208/240V 60 1/3 12 58 4 50 29 29 6
124TC-TE 208/240V 60 1/3 12 58 4 50 29 29 6
124THE 208/240V 60 1/3 12 58 4 50 29 29 6
124THE2L 208/240V 60 1/3 12 58 4 50 29 29 6
124T-PE 208/240V 60 1/3 12 58 4 50 29 29 6
124T-PE-480V 480V 60 3 12 22 13 13 12
124TSS 208/240V 60 1/3 12 58 4 50 29 29 6
124TSS-480V 480V 60 3 12 22 13 13 12
136T 208/240V 60 1/3 18 87 2 50 50 50 6
136T-480V 480V 60 3 18 22 22 22 12
136TC-TE 208/240 60 1/3 18 87 2 50 50 50 6
136TC-TE-380 380V 50 3 18 27 27 27 10
136TNTS 208/240V 60 1/3 18 87 2 50 50 50 6
148T 208/240V 60 1/3 24 116 1 75 75 50 3
148T-480V 480V 60 3 24 33 33 22 8
148TC 208/240V 60 1/3 24 116 1 75 75 50 3
148TC-TE 208/240V 60 1/3 24 116 1 75 75 50 3
148TC-TE-380 380V 50 3 24 41 41 27 6
148T-SJ 208/240V 60 1/3 24 116 1 75 75 50 3
148TSS 208/240V 60 1/3 24 116 1 75 75 50 3
148TSS-480V 480V 60 3 24 33 33 22 8
160T 208/240V 60 1/3 12 58 2 50 29 29 6 18 87 2 50 50 50 6
160T-480V 480V 60 3 12 22 13 13 12 18 22 22 22 12
160T-480VCP 480V 60 3 12 22 13 13 12 18 22 22 22 12
160TC-TE 208/240V 60 1/3 12 58 4 50 29 29 6 18 87 2 50 50 50 6
160TSS 208/240V 60 1/3 12 58 2 50 29 29 6 18 87 6 50 50 50 6
160TSS-480V 480V 60 3 12 22 13 13 12 22 22 22 12
172T 208/240V 60 1/3 18 87 2 50 50 50 6 18 87 2 50 50 50 6
172T-480V 480V 60 3 18 22 22 22 12 18 22 22 22 12
172T-480VSJ 480V 60 3 18 22 22 22 12 18 22 22 22 12
172TC 208/240V 60 1/3 18 87 2 50 50 50 6 18 87 2 50 50 50 6
172TC-TE 208/240V 60 1/3 18 87 2 50 50 50 6 18 87 2 50 50 50 6
172T-PE 208/240V 60 1/3 18 87 2 50 50 50 6 18 87 2 50 50 50 6
172T-PE-480V 480V 60 3 18 22 22 22 12 18 22 22 22 12
172T-SJ 208/240V 60 1/3 18 87 2 50 50 50 6 18 87 2 50 50 50 6
172TSS 208/240V 60 1/3 18 87 2 50 50 50 6 18 87 2 50 50 50 6
172TSS-480V 480V 60 3 18 22 22 22 12 18 22 22 22 12

6
EQUIPMENT DESCRIPTION
Exterior Construction
The griddle dimensions are 17” (43.18cm) High, 30” (76.20cm) Deep, and width is dependent on the
actual model number.
The Sides, Bottom, and Rear wall are constructed of double wall stainless steel, which allows closer
installation to combustible surfaces.
The griddle surface is made of 1” thick, highly polished steel to reduce hot and cold spots, recovery
problems, warping, and ensure even heat to the edges of the griddle.
Controls
Each twelve-inch section has its own temperature selector switch that snaps into place to lock in any
temperature from 175°F to 450°F (79°C to 232°C) in 25° increments.
Each twelve-inch section of the griddle is controlled by an area sensitive RTD probe, which can sense
and react to a temperature change of +/- 4°F.
Each twelve-inch section has a set of 6 K.W. elements for high efficiency, quick recovery and outstanding
performance
Technical
The 100 series thermostat griddle operates on either 208, 220, 240, 380 or 480V, are shipped three
phase, (unless in specific specifications). 208, 220, 240V can be field converted to single phase.
Minimum clearances: 2” from side and back
NOTICE The data plate is on the right side of the griddle. The oven voltage,
wattage, serial number, wire size, and clearance specifications are
on the data plate. This information should be carefully read and
understood before proceeding with the installation.
Griddle Surface
Gutter
Grease Pan
Legs
Section
Temp. Dial Section
Pilot Light
IL1553

7
UNPACKING
Receiving the Griddle
Upon receipt, check for freight damage, both visible and concealed.
Visible damage should be noted on the freight bill at the time of delivery and
signed by the carrier’s agent. Concealed loss or damage means it does not
become apparent until the merchandise has been unpacked. If concealed
loss or damage is discovered upon unpacking, make a written request for
inspection by the carrier’s agent within 15 days of delivery. All packing
material should be kept for inspection. Do not return damaged
merchandise to Star Manufacturing Company. File your claim with the
carrier.
Location
Prior to un-crating, move the oven as near to its intended location as practical. The crating will help
protect the unit from the physical damage normally associated with moving it through hallways and
doorways.
Un-crating
The griddle will arrive completely assembled inside a wood frame and strapped to a skid. Cut the
straps and remove the wood frame.
The oven can now be removed from the skid.
THE UNIT IS EXTREMELY HEAVY. FOR SAFE HANDLING, INSTALLER
SHOULD OBTAIN HELP AS NEEDED, OR EMPLOY APPROPRIATE MATERIALS
HANDLING EQUIPMENT (SUCH AS A FORKLIFT, DOLLY, OR PALLET JACK)
TO REMOVE THE UNIT FROM THE SKID AND MOVE IT TO THE PLACE OF
INSTALLATION.
ANY STAND, COUNTER OR OTHER DEVICE ON WHICH OVEN WILL BE
LOCATED MUST BE DESIGNED TO SUPPORT THE WEIGHT OF THE GRIDDLE.
SHIPPING STRAPS ARE UNDER TENSION AND CAN SNAP BACK WHEN CUT.
CAUTION

8
INSTALLATION
Leg Installation
There are four, 4” legs provided for 2, 3 and
4 foot griddles.
There are eight 4” legs provided for 5 and 6
foot griddles.
The legs are shipped in the grease drawers
of the griddle. Install them into the threaded
holes on the underside of the griddle body.
Leveling adjustment may be done by screwing the bottom portion of the leg in and out.
IL1554
Std Leg
Marine Bolt Down Leg
DANGER: THIS APPLIANCE MUST BE GROUNDED AT THE TERMINAL PROVIDED.
FAILURE TO GROUND THE APPLIANCE COULD RESULT IN ELECTROCUTION
AND DEATH.
INSTALLATION OF THE UNIT MUST BE DONE BY PERSONNEL QUALIFIED TO
WORK WITH ELECTRICITY AND PLUMBING. IMPROPER INSTALLATION CAN
CAUSE INJURY TO PERSONNEL AND/OR DAMAGE TO EQUIPMENT. UNIT
MUST BE INSTALLED IN ACCORDANCE WITH ALL APPLICABLE CODES.
NOTICE: The data plate is located behind access panel between controls and grease
drawer. The grill voltage, wattage, serial number, wire size, and clearance
specifications are on the data plate. This information should be carefully
read and understood before proceeding with the installation.
NOTICE: The installation of any components such as a vent hood, grease extractors,
fire extinguisher systems, must conform to their applicable National, State
and locally recognized installation standards.
ALWAYS KEEP THE AREA NEAR THE APPLIANCE FREE FROM
COMBUSTIBLE MATERIALS.
KEEP FLOOR IN FRONT OF EQUIPMENT CLEAN AND DRY. IF SPILLS
OCCUR, CLEAN IMMEDIATELY, TO AVOID THE DANGER OF SLIPS OR FALLS.
CAUTION
WARNING
Above: typical leg installation.
2.5”
IL1550
For bolt down legs see above illustration for dimensions.

9
INSTALLATION cont.
Ventilation and Clearances
Standard minimum clearance from combustible construction is as follows.
2” from side
2” from back
These griddles may be set directly, without legs, on a curbed base or non-combustible surface.
If the griddle is set without legs on a non-combustible floor or a curbed base, maintain a 4-inch
back clearance.
Do not install the griddle directly against a non-combustible back wall or surface.
Do not install the griddle closer than 12 inches from an uncontrolled heat source (char broiler etc.).
Keep the appliance area free and clear of combustible material and do not obstruct the flow of
combustion or ventilation air.
Electrical Connection
Detach cover on junction box at rear of unit. There is one power supply connection on the 2, 3,
and 4-foot griddles. There are two power supply connections on 5 and 6-foot griddles. Refer to the
power supply chart in the Technical Specification Data portion of this manual (pg 4 & 5), for proper
power supply size.
There is (1) one 1 1/4-inch conduit knockout on 2, 3 and 4-foot griddles located at the rear of the
griddle, through the back and the bottom of the griddle body. There are (2) two 1 1/4-inch conduit
knockouts provided on the 5 and 6-foot griddles. Use a supply wire suitable for at least 90°C/194°F.
This griddle is shipped from the factory set up for a three phase service. On 208V, 220V & 240V the
wiring can be changed in the supply terminal junction box to convert the griddle to single phase.
Technical Data
Phasing
All griddles are shipped from the
factory set up for a three-phase
service. Rearrange the wires in
the power supply terminal block to
convert the griddle to single phase.
Re-phasing the griddle is not
chargeable to Lang Manufacturing
Company as warranty. To convert
to single-phase have a Lang
Authorized Service Agent, follow
this chart.
MODEL
NUMBER TOTAL K.W.
NOMINALAMPS PER LINE
SINGLE PHASETHREE PHASE
208 Volt 240 Volt 480 Volt
208V 240VL1 L2 L3 L1 L2 L3 L1 L2 L3
24” 12 50 28.8 28.8 43.3 25 25 21.7 12.5 12.5 57.7 50
36” 18 50 50 50 43.3 43.3 43.3 21.7 21.7 21.7 86.5 75
48” 24 75 75 50 65 65 43.3 32.5 32.5 21.7 115.5 100
60”
#1 18 50 50 50 43.3 43.3 43.3 21.7 21.7 21.7 86.5 75
#2 12 50 28.8 28.8 43.3 25 25 21.7 12.5 12.5 57.7 50
72”
#1 18 50 50 50 43.3 43.3 43.3 21.7 21.7 21.7 86.5 75
#2 18 50 50 50 43.3 43.3 43.3 21.7 21.7 21.7 86.5 75
PHASING BY WIRE NUMBER
MODEL
NUMBER THREE PHASE SINGLE PHASE
LINE 1 LINE 2 LINE 3 LINE 1 LINE 2
124T 1,4 2 3 1,3 2,6
136T 1,4 2,5 3,6 1,3,5 2,4,6
148T 1,4,7 2,5,8 3,6,9 1,3,5,7 2,4,6,8
160T #1 1,4 2,5 3,6 1,3,5 2,4,6
160T #2 1,4 2 3 1,3 2,6
172T #1 1,4 2,5 3,6 1,3,5 2,4,6
172T #2 1,4 2,5 3,6 1,3,5 2,4,6

10
INITIAL START UP
Pre-Power On
Before starting the griddle for the first time, clean the griddle body and cooking surface.
Use a mild soap and water solution, then rinse with clear water and dry.
Power On
Set the temperature dials to 200°F (93°C).
Heat the griddle at 200°F (93°C) for 2 hours to evaporate any moisture that may be in the elements.
After 2 hours at 200°F (93°C), turn the temperature up to 350°F (176°C) for ½ hour.
After the griddle reaches 350°F (176°C) for ½ hour, turn the griddle up another 50°F (10°C) for another
½ hour and repeat this until it is at 450°F (232°C) for ½ hour.
The unit may emit a small amount of smoke as the cooking surface passes the 300°F (148°C) point.
Do not be alarmed as the smoke is caused by oils associated with the manufacturing process and will
stop when the griddle reaches 350°F (176°C).
Seasoning Cooking Surface
The cooking surface must be “seasoned” in order to eliminate product sticking during cooking.
To season, heat the griddle to 250°F (121°C).
Once at 250°F (121°C), coat the cooking surface with non-salted vegetable oil.
Allow the griddle to stand at 250°F (121°C) until the cooking surface looks dry then coat it again.
Heat the griddle to 350°F (176°C) and repeat the procedure.
NOTICE: During the first few hours of operation you may notice a small
amount of smoke coming off the griddle, and a faint odor from the
smoke. This is normal for a new griddle and will disappear after the
first few hours of use.

11
OPERATION
General
The suggested time and temperature chart (below) is provided as a guide for the products listed only.
If different temperature settings are to be used, select one side of the griddle and operate at the lowest
temperature. Adjoining sections should be set at progressively higher temperatures. Do not try to
operate the end sections hot and the center sections cool.
ALWAYS KEEP THE AREA NEAR THE APPLIANCE FREE FROM
COMBUSTIBLE MATERIALS.
KEEP FLOOR IN FRONT OF EQUIPMENT CLEAN AND DRY. IF
SPILLS OCCUR, CLEAN IMMEDIATELY, TO AVOID THE DANGER OF
SLIPS OR FALLS.
Loading the Griddle
An understanding of how the griddle sections are controlled will be a valuable aid in loading product on
your unit.
Each 12-inch section of your griddle is independently controlled by a temperature controller.
The temperature control sensor is mounted in the center of each cooking section under the griddle plate.
If the product is loaded directly over the temperature sensor, that section will turn on and the burner will
heat the entire cooking section. If the product is loaded to the side, front or back of the temperature
sensor, the thermostat will react to the temperature change much slower.
During slow periods with minimal
loads, do not load directly over
the thermostat sensors as this will
unnecessarily turn the burners on and
overheat the remainder of the section
not being utilized.
Turn the product and continue
cooking until it has reached its
desired degree of doneness.
Remove the product from the griddle.
When reloading the griddle, first
use the griddle surface on which a
previous load was not placed.
This will help insure the proper griddle
temperature.
SUGGESTED TIMESAND TEMPERATURES
PRODUCTS TEMPERATURE
F / C TIME (MIN)
HAMBURGER
350°F / 176°C
2 patties per LB 6 to 8
4 patties per LB 4 to 6
6 patties per LB 3 to 4
STEAKS
1/2 to 3/4 inch thick, cooked medium 375°F / 190°C 5 to 7
3/4 to 1 inch thick, cooked medium 8 to 10
Lamb Chops 350°F / 176°C 6 to 8
Pork Chops 6 to 8
Salmon 350°F / 176°C 6 to 8
Halibut 325°F / 162°C 6 to 8
Snapper 6 to 8
Hash Brown Potatoes 375°F / 190°C 3 to 4
Bacon 350°F / 176°C 3 to 4
Sausage Links or Patties 3 to 4
Ham (Pre-cooked) 375°F / 190°C 2
Eggs 275°F / 135°C 2 to 4
Note: The times and temperatures in this chart are intended as a general guide and starting point.
Your actual times and temperatures may vary from this chart.
CAUTION

12
MAINTENANCE & CLEANING
Cleaning
• Always start with a cold griddle.
• The stainless exterior can easily be cleaned using a good non-abrasive cleaner.
• Always follow the cleaner manufacturer’s instructions when using any cleaner.
• Always apply these cleaners when the griddle is cold and rub in the direction of the metal’s grain.
Griddle Surface Care (non-chromium surfaces)
It takes very little time and effort to keep the griddle attractive and performing at top efficiency.
If grease is permitted to accumulate, it will form a gummy cake and then carbonize into a hard
substance which is extremely difficult to remove. To prevent this condition, the following suggestions
for cleanliness should be followed:
• After each use, scrape the griddle with a scraper or flexible spatula to remove excess grease
and food. A waste drawer is provided for the scrapings. If there is an accumulation of burned
on grease and food, the griddle should be thoroughly scoured and re-seasoned. Use pumice
or griddle stone while the griddle is warm.
Do not use steel wool because of the danger of steel slivers getting into the food.
Daily Cleaning
Empty the grease drawer or whenever it is 3/4 full. It is easily removed for washing.
USE CAUTION WHEN REMOVING THE RELEASE DRAWER
AS IT CONTAINS HOT GREASE.
Clean the exterior of the appliance with hot water and mild detergent to maintain a gleaming
appearance.
Keep the griddle surface clean. After each cooking load scrape the griddle surface to remove any
carbonized grease.
Weekly Cleaning
Once a week or when necessary the griddle surface should be cleaned and seasoned. Use a
griddle stone, griddle pad, or liquid cleaner. Rub with the grain of the metal, being careful not to
scrape the splash guard.
A mild detergent with water or one of the many commercial griddle cleaners may be used.
Be sure to rinse thoroughly and coat the cooking surface with a thin film of oil to prevent rusting.
Season the griddle plate after each cleaning.
CAUTION

13
GRIDDLE CARE (CHROME SURFACES)
(Chrome surface griddles are marked with “CHS” at the end of the model number designation on the nameplate.)
It takes very little time and effort to keep this Industrial Chrome griddle surface sparkling clean and performing at top
efficiency. DO NOT allow grease to accumulate as it will carbonize and become difficult to remove.
To prevent this condition, the following cleaning suggestions should be followed:
1. Remove excess oil and food regularly with a 4” (100mm) wide razor sharp type scraper and wipe surface with
a damp cloth if desired.
2. Following the scraping, for end of the day cleaning, a damp cloth and a non-silicated,non-abrasive, non-
chlorinated cleaner such as Bon-Ami may be used to wipe surface clean, followed by wiping with clean wet
cloth.
3. Follow daily cleaning steps for Non-Chrome Surfaces.
CAUTION
ON CROME SURFACES:
1. Never use pumice, griddle stones, or abrasives on the surface.
2. Never strike the griddle surface with a sharp instrument or spatula edge.
3. Never use steel wool.
4. Never use commercial liquid grill cleaner on the griddle surface.
5. Abusing the surface voids the warranty.
KEEP WATER AND SOLUTIONS OUT OF CONTROLS. NEVER SPRAY OR
HOSE CONTROL CONSOLE.
MOST CLEANERS ARE HARMFUL TO THE SKIN, EYES, MUCOUS
MEMBRANES AND CLOTHING. PRECAUTIONS SHOULD BE TAKEN TO
WEAR RUBBER GLOVES, GOGGLES OR FACE SHIELD AND PROTECTIVE
CLOTHING. CAREFULLY READ THE WARNING AND FOLLOW THE
DIRECTIONS ON THE LABEL OF THE CLEANER TO BE USED.
NOTICE: Never leave a chlorine sanitizer in contact with stainless steel surfaces longer
than 10 minutes. Longer contact can cause corrosion.
CAUTION

14
WARNING
TROUBLESHOOTING
Symptoms
What follows is a chart of Symptoms and Possible Causes to aid in diagnosing faults with the griddle.
Refer to the Symptoms column to locate the type of failure then to the Possible Cause for the items
to be checked.
To test for a possible causes refer to the TEST section and locate the Possible Cause then refer
to test to identify test procedures.
NOTICE: Service on this, or any other, LANG appliance must be performed
by qualified personnel only. Consult your Lang Authorized Service
Agent Directory or call the factory at 1-800-807-9054, or WWW.STAR-
MFG.COM For the service agent nearest you.
BOTH HIGH AND LOW VOLTAGES ARE PRESENT INSIDE THIS
APPLIANCE WHEN THE UNIT IS PLUGGED/WIRED INTO A LIVE
RECEPTACLE. BEFORE REPLACING ANY PARTS, DISCONNECT
THE UNIT FROM THE ELECTRIC POWER SUPPLY.
If an item on the list is followed by an asterisk (*), the work should be done by a factory authorized
service representative.
SYMPTOM POSSIBLE CAUSE
Whole Griddle will not heat •No Power to Griddle
One Section will not heat •Failed contactor
•Failed Element.
Product Burning •Product left on griddle too long
•Out of Calibration
Product Under cooked •Product removed too soon
•Out of Calibration
POSSIBLE CAUSE TEST
Product is cooked too long •No test available, operational condition
Failed Contactor •Remove the wires from the contactor coil and check
for continuity across the contactor coil connection*
•Ensure the contactor moveable points move freely up
and down*
Failed Element •Confirm that Elements are getting correct voltage and
have continuity*

15
TROUBLESHOOTING continued
USE OF ANY REPLACEMENT PARTS OTHER THAN THOSE SUPPLIED BY
LANG OR THEIR AUTHORIZED DISTRIBUTORS CAN CAUSE BODILY INJURY
TO THE OPERATOR AND DAMAGE TO THE EQUIPMENT AND WILL VOID ALL
WARRANTIES.
CAUTION

16
JUMPER
GRIDDLE ELEMENTS
1
2
3
4
5
GRIDDLE PILOT LAMP
GRIDDLE THERMOSTAT
TERMINAL BLOCK
L2 5
L3L1
4
*
18
26
25
CONN #2 USE LG36
DLG
2
2
3
4
10
17
2
3
12-13-02
LG72: CONN #1 USE LG36
5
2
3
4
5
2
3
4
5
1
1
1
16 15
23
*
31
LG48
LG36 LG24
22
32
8765
29
30
22
*
14
21
13
43
27
28
20
*
12
19
11
5
1
NOTES:
LG60 & LG72 HAVE TWO POWER SUPPLY CONNECTIONS
LG60: CONN #1 USE LG36
CONN #2 USE LG24
1
9
11
A
B
C
D
DWG. NO: SHEET OF
DWN. DATE :
DWN. BY : CHK. BY :
DESCRIPTION: LANG GRIDDLE 208-240/220VAC
1
Company
Manufacturing 61114-01 REV:
1G
1
CAD FILE :FROM ACAD
CHK. DATE :
REV. BY : REV. DATE :
E
F
G
HH
G
F
E
D
C
B
A
2
34
5
6
7
8
9
10
11
12
1
2
3
4
5
6
7
8
9
10
12
2 POLE THERMOSTAT.
9
17
10
*
18
26
25
1
2
2
1
54
3
NOTE: TYPICAL WIRING FOR EACH
SECTION ON UNITS THAT HAVE A
TYPICAL
208-220 V 240V
INSTALL REMOVE
JUMPER JUMPER
ELEMENT HOOKUP
(ITEM 4) (ITEM 4)
AMPS 1
L1-L2L2-L3L1-L3TOTALL1L2L3PHASEL1L2L3L1L2
208 6.0 6.0 12.0 50.0 28.9 28.9 57.7
220 6.7 6.7 13.4 52.9 30.5 30.5 60.9
240 6.0 6.0 12.0 43.3 25.0 25.0 50
208 6.0 6.0 6.0 18.0 50.0 50.0 50.0 86.5
220 6.7 6.7 6.7 20.1 52.9 52.9 52.9 91.4
240 6.0 6.0 6.0 18.0 43.3 43.3 43.3 75
208 12.0 6.0 6.0 24.0 76.0 76.3 50.0 115.4
220 13.4 6.7 6.7 26.8 80.6 80.6 52.9 121.8
240 12.0 6.0 6.0 24.0 66.1 66.1 43.3 100 3,6 1,3,5,7
1,3,5 2,4,6
2,4,6,8
2,4
1,4 2,5 3,6
LG48
LG36
1,4 2
1,4,7 2,5,8
MODEL
LG24
Kw SERVICE CONNECTIONS AMP TOTALS
VOLT THREE PHASE SINGLE PHASE
31,3
Revision Block
REV ECN NO. DESCRIPTION DR. MFG. ENG. DATE
E REVISED AND REDRAWN CDS 10/15/2002
F ADDED 220VAC FOR LGCL DLG 12/13/2002
G6170
ADDED WIRING FOR 2 POLE
TSTAT DJS 10/1/2007

17
15
31
1
LG48 / 148T
LG36 / 136T LG24 / 124T
L1 L2 L3 4
NOTE: LG60 & LG72 HAVE TWO POWER SUPPLY CONNECTIONS
LG60: CONN # 1 USE LG36
CONN # 2 USE LG24
LG72: CONN # 1 USE LG36
CONN # 2 USE LG36
1 GRIDDLE ELEMENTS
2 GRIDDLE PILOT LAMP
3 GRIDDLE THERMOSTAT
4 TERMINAL BLOCK
3
2
32
87
* NUMBER
***
**
6
*
5
*
13
3
29
2
30
** *
1
4
*
3
*
11
3
27
2
28
** *
1
2
*
1
*
9
3
25
2
26
** *
1
MODELS:
48OV, 3PH Electric Thermostatic Griddles
2M-61114-02 Rev B 11/7/1997
SERVICE CONNECTIONS
MODEL
24
36
48
2,51,4
1,4,7 2,5,8
1,4
L2
2
3,6
3,6
L3
3
L1
THREE PHASE

18
SK2397 Rev. - 8/15/08
1
2
3
4
5
6
7
8
9
14 10
17
15
16
18
19
20
21
10
24
23
25
26
27
10
10
10
29
32
30
22
22
12
13
10
31 10
11
28
Model: Electric Thermostatic Griddle

19
1 K9-XL-722-2 1 PLATE ASY 2’ ACU 124T
K9-XL-722-21 1 PLATE ASY 2’ACU 4.5 124T-480VSJ, 124TSS, 124TSS-480V
K9-XL-722-211 1 PLATE ASSY 2’ACU WITH 4.5 124T-PE, 124T-PE-480V
K9-XL-722-24 1 PLATE ASY 2’ACU W/XLH12 124THE, 124THE2L
K9-XL-724-2 1 PLATE ASSY 2’ TALL CHROME 124TC
K9-XL-724-W24 1 PLTE ASY 2’ACU CHRME 3/4H 124TC-TE
2 2N-11030-30 2 ELMNT GRID 208V 1257W 124T
3 2N-11030-04 2 ELMNT GRID 380V 5991W 124T-380V
2N-11030-29 2 ELE GRD 208/240V4.5KW/6KW 124T
2N-11030-31 2 ELMNT GRID 480V 5991W 124T-480V/M, 124T-480VSJ, 124T-PE-480V,
124TSS-480V
4 K9-XL-426 2 ELEMENT PAN PLATE 124T
5 K9-XL-435 2 ELEMENT PAN Z 124T
6 2H-XL-424 2 ELEMENT PAN INSULATION 124T
7 K9-XL-425 2 ELEMENT PAN 124T
8 2C-20201-04 12 WSHR FLT 3/8 USS PLTD 124T
9 2C-20103-06 2 SCRW SM PLT 6 X 3/8 PHL
10 2C-20103-02 16 SCRW SM PLT 10 X .5 PHLSL 124T
11 K9-XL-227 1 SUPPLY WIRE BAFFLE 124T
12 Y9-31200-02-1 1 GROUNDING LUG/+LABEL
13 2C-20202-06 1 WSHR LOCK #10 INT STAR
14 2E-30500-07 1 TRM BLOCK 3PLELRGE 125AMP 124T
15 2C-20103-01 4 SCRW SM PLT 10X7/8 PHIL
17 K9-XL-507 1 REAR COVER
18 2C-20104-04 3 SCRW PHD ST 8-32X.5 PLTD PHILP 124T
19 2P-70903-08 1 PLG BTN PLTD MTL 5/16 124T
2P-70903-09 1 PLG BTN PLTD MTL 7/16 124T
2P-70903-09 4 PLG BTN PLTD MTL 7/16 124T
20 2A-72500-05 4 LEG 4 W/BOLT DOWN ADJ 124T-380VM, 124T-440VM
2A-Z0314 4 FOOT, 4” DIE CAST 124T
21 2K-70801-02 2 SNAP BUSH 1 3/8 SB1375-16 124T
22 2T-30402-07 2 STAT ADJ 550° 48 C/T 124T, 124T-220V, 124THE2L
2T-30402-09 2 STAT ADJ 550° 72 C/T 124T-220VCW, 124T-480V, 124T-PE,
124T-PE-480V, 124TC-TE, 124TSS, 124TSS-480V
2T-30401-30 1 STAT FXD 550° DEG OPEN 124THE2L
23 2C-20101-77 4 SCRW MS PLT 6-32 X .25 PHD
24 K9-XL-524-1 1 ELECT BOX COVER SPOT 2’ 124T
25 2J-31601-01 2 PILOT LT 250V 6LEAD BLK 124T, 124T-220V
2J-31601-01 3 PILOT LT 250V 6LEAD BLK 124THE2L
2J-31601-02 3 PILOT LT 480V 6LEAD BLK 124T-380V/M, 124T-480V/M, 124T-480VSJ,
124T-PE-480V, 124TSS-480V
26 Y9-70701-14-1 2 KNOB 550° C PHANTOM 124T-220VCW, 124T-480VSJ, 124T-PE,
124T-PE-480V, 124TSS, 124TSS-480V
Y9-70701-15-1 2 KNOB 550o D PHANTOM 124T, 124T-220V, 124T-480V
27 K9-XL-725-04 1 ELECT BOX ASY 2’ XL\LG 124T, 124T-220V
K9-XL-725-041 1 ELECT BOXASY 2’ XL\LG 124T-220VCW, 124T-480VSJ, 124T-PE,
124TC-TE, 124TSS
K9-XL-725-W13 1 ELECT BOX ASSY 2’ XL/LG 124THE2L
28 K9-XL-422-1 1 ACCESS PANELASSY 2’ 124T
29 K9-XL-235-1 1 GREASE BUCKET ASSY S/S 124T
30 K9-XL-228 1 BUCKET SLIDE ASSY 124T
31 K9-XL-504 2 STAT HOLDER 124T
NI K9-50302-14 1 2’ GRAB BAR ASSY 124T-MARINE
NI K9-LGCL-234-1 1 DRAWER STOP 124T-MARINE
NI K9-WTGC-24 1 WORK TABLE GRIDDLE COVER 124T-BK
NI 2E-30900-30 2 FUSE, 60 AMP 124THE2L
NI 2E-30901-14 1 FUSE BLOCK 2 POLE 60AMP 124THE2L
NI 2E-30705-01 2 CONTC 2-SPD MTR COIL 240 124THE2L
Model No: 124T, 124TC, 124THE, 124TSS
Selectronic Electric Griddle
PARTS LIST September 10, 2008, Rev F
IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED PAGE
INCLUDE MODEL AND SERIAL NUMBER OF
Some items are included for illustrative purposes only and in certain instances may not be available.
Description
Part
Number
Key
Number
1
1
Qty
Per

20
Model No: 136T, 136TC, 136TNTS
Thermostatic Electric Griddle Commercial & Marine
PARTS LIST October 1, 2008, Rev. F
IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED PAGE
INCLUDE MODEL AND SERIAL NUMBER OF
Some items are included for illustrative purposes only and in certain instances may not be available.
Description
Part
Number
Key
Number
1 K9-XL-722-3 1 PLATE ASY 3’ACU 136T, 136T-440VM, 136T-480V
K9-XL-724-34 1 PLATE ASSY 3’ ACU W/6.75 136TC-TE
K9-XL-722-W35 1 PLATE ASY 3’ACU-NO TAPER 136TNTS
2 2N-11030-30 3 ELMNT GRID 208V 1257W ALL
3 2N-11030-29 3 ELE GRD 208/240V4.5KW/6KW 136T
2N-11030-31 3 ELMNT GRID 480V 5991W 136T-480V
2N-11030-48 3 ELE GRD 440V 5991W 136T-440VM
2N-11030-04 3 ELMNT GRID 380V 5991W 136TC-TE-380
4 K9-XL-426 3 ELEMENT PAN PLATE 136T
5 K9-XL-435 3 ELEMENT PAN Z ALL
6 2H-XL-424 3 ELEMENT PAN INSULATION ALL
7 K9-XL-425 3 ELEMENT PAN ALL
8 2C-20201-04 18 WSHR FLT 3/8 USS PLTD ALL
9 2C-20103-06 2 SCRW SM PLT 6 X 3/8 PHL ALL
9 2C-20301-06 18 NUT HEX 5/16-18 PLTD ALL
10 2C-20103-02 18 SCRW SM PLT 10 X .5 PHLSL ALL
11 K9-XL-227 1 SUPPLY WIRE BAFFLE ALL
12 Y9-31200-02-1 1 GROUNDING LUG/+LABEL ALL
13 2C-20202-06 1 WSHR LOCK #10 INT STAR ALL
14 2E-30500-07 1 TRM BLOCK 3PLELRGE 125AMP ALL
15 2C-20103-01 4 SCRW SM PLT 10X7/8 PHIL ALL
16 2E-30500-22 1 TRMINL STRP 8POLE 50A250V 136T
17 K9-XL-507 1 REAR COVER ALL
18 2C-20104-04 3 SCRW PHD ST 8-32X.5 PLTD PHILP ALL
19 2P-70903-08 1 PLG BTN PLTD MTL 5/16 ALL
2P-70903-09 1 PLG BTN PLTD MTL 7/16 ALL
2P-70903-09 4 PLG BTN PLTD MTL 7/16 ALL
20 2A-72500-05 4 LEG 4 W/BOLT DOWN ADJ MARINE
2A-Z0314 4 FOOT, 4” DIE CAST COMMERCIAL
21 2K-70801-02 2 SNAP BUSH 1 3/8 SB1375-16 ALL
22 2T-30402-07 3 STAT ADJ 550o 48 C/T 136T
2T-30402-09 3 STAT ADJ 550° 72 C/T 136TC-TE, 136TC-TE-380
23 2C-20101-77 6 SCRW MS PLT 6-32 X .25 PHD ALL
24 K9-XL-502 1 ELECT. BOX COVER 3’ & 4’ ALL
25 2J-31601-01 3 PILOT LT 250V 6LEAD BLK 136T
2J-31601-02 3 PILOT LT 480V 6LEAD BLK 136T-440VM, 136T-480V/M, 136TC-TE-380
26 Y9-70701-15-1 3 KNOB 550o D PHANTOM 136T
26 Y9-70701-14-1 3 KNOB 550° D PHANTOM 136TC-TE, 136TC-TE-380
27 K9-XL-725-08 1 ELECT BOX ASY 3’ XL\LG 136T
K9-XL-725-081 1 ELECT BOX ASY 3’ XL\LG 136TC-TE
28 K9-XL-422-2 1 ACCESS PANELASSY 3’ 136T
29 K9-XL-235-1 1 GREASE BUCKET ASSY S/S 136T
30 K9-XL-228 1 BUCKET SLIDE ASSY 136T
31 K9-XL-504 3 STAT HOLDER 136T
NI K9-50302-15 1 3’ GRAB BAR ASSY 136T-440VM
NI K9-LGCL-234-1 1 DRAWER STOP 136T-440VM
1
1
Qty
Per
