Lang CLG36F Installation and operating instructions

Lang Manufacturing 10 Sunnen Drive St. Louis, MO 63143
Part Number: 2M-W362 Phone: [phone] Fax: [phone]
Rev. B www.langworld.com July 25, 2012
Installation,
Operation, and
Maintenance, & Troubleshooting
Electric Marine & Cruise Line Griddle
Model: CLG36F CLG36THE
CLG48F CLG48THE

2
THIS MANUAL MUST BE RETAINED FOR FUTURE REFERENCE.
READ, UNDERSTAND AND FOLLOW THE INSTRUCTIONS AND
WARNINGS CONTAINED IN THIS MANUAL.
FOR YOUR SAFETY
DO NOT STORE OR USE GASOLINE OR OTHER FLAMMABLE
VAPORS AND LIQUIDS IN THE VICINITY OF THIS OR ANY
OTHER APPLIANCE.
WARNING: IMPROPER INSTALLATION, ADJUSTMENT,
ALTERATION, SERVICE OR MAINTENANCE CAN CAUSE
PROPERTY DAMAGE, INJURY OR DEATH. READ THE
INSTALLATION, OPERATING AND MAINTENANCE
INSTRUCTIONS THOROUGHLY BEFORE INSTALLING OR
SERVICING THIS EQUIPMENT.
NOTICE: THIS EQUIPMENT IS APPROVED FOR INSTALLATION ONLY ON
VESSELS GREATER THAN 65 FEET IN LENGTH, IN
ACCORDANCE WITH USCG REGULATIONS IN TITLE 46 CFR
110-113. ANY WIRING USED IN THE INSTALLATION OF THIS
APPLAINCE MUST BE STRANDED COPPER.
Model #: Purchased From:
Serial #:
Location:
Date Purchased:
Date Installed:
Purchase Order #:
For Service, Call:

3
TABLE OF CONTENTS
CHAPTER PAGE
1. TABLE OF CONTENTS ...............................................................................3
2. READ FIRST .................................................................................................4
3. UNPACKING.................................................................................................6
4. INSTALLATION...........................................................................................7
5. INITIAL START-UP......................................................................................9
6. OPERATION..................................................................................................10
7. MAINTENANCE & CLEANING PROCEDURES......................................11
8. TROUBLESHOOTING .................................................................................12
9. PARTS LISTS................................................................................................14
10. WIRING DIAGRAMS...................................................................................15

4
IMPORTANT READ FIRST IMPORTANT
CAUTION: GRIDDLE IS EXTREMELY HEAVY. FOR SAFE
HANDLING, INSTALLER SHOULD OBTAIN HELP AS
NEEDED, OR EMPLOY APPROPRIATE MATERIALS
HANDLING EQUIPMENT (SUCH AS A FORKLIFT,
DOLLY, OR PALLET JACK) TO REMOVE THE UNIT
FROM THE SKID AND MOVE IT TO THE PLACE OF
INSTALLATION.
CAUTION: ANY STAND, COUNTER OR OTHER DEVICE ON
WHICH GRIDDLE WILL BE LOCATED MUST BE
DESIGNED TO SUPPORT THE WEIGHT OF THE
GRIDDLE.
CAUTION: SHIPPING STRAPS ARE UNDER TENSION AND CAN
SNAP BACK WHEN CUT.
DANGER: THIS APPLIANCE MUST BE GROUNDED AT THE
TERMINAL PROVIDED. FAILURE TO GROUND THE
APPLIANCE COULD RESULT IN ELECTROCUTION
AND DEATH.
WARNING: INSTALLATION OF THE UNIT MUST BE DONE BY
PERSONNEL QUALIFIED TO WORK WITH
ELECTRICITY. IMPROPER INSTALLATION CAN
CAUSE INJURY TO PERSONNEL AND/OR DAMAGE
TO EQUIPMENT. UNIT MUST BE INSTALLED IN
ACCORDANCE WITH ALL APPLICABLE CODES.
NOTICE: The data plate is located behind the access panel in
the back of the griddle. If on a 48” or larger, the data
plate is behind the back left access panel. The
griddle voltage, wattage, serial number, wire size,
and clearance specifications are on the data plate.
This information should be carefully read and
understood before proceeding with the installation.
NOTICE: The installation of any components such as a vent
hood, grease extractors, fire extinguisher systems,
must conform to their applicable National, State and
locally recognized installation standards.
CAUTION: ALWAYS KEEP THE AREA NEAR THE APPLIANCE
FREE FROM COMBUSTIBLE MATERIALS.
CAUTION: KEEP FLOOR IN FRONT OF EQUIPMENT CLEAN
AND DRY. IF SPILLS OCCUR, CLEAN IMMEDIATELY,
TO AVOID THE DANGER OF SLIPS OR FALLS.

5
IMPORTANT READ FIRST IMPORTANT
WARNING: KEEP WATER AND SOLUTIONS OUT OF CONTROLS.
NEVER SPRAY OR HOSE CONTROL CONSOLE,
ELECTRICAL CONNECTIONS, ETC.
CAUTION: MOST CLEANERS ARE HARMFUL TO THE SKIN, EYES,
MUCOUS MEMBRANES AND CLOTHING.
PRECAUTIONS SHOULD BE TAKEN TO WEAR RUBBER
GLOVES, GOGGLES OR FACE SHIELD AND
PROTECTIVE CLOTHING. CAREFULLY READ THE
WARNING AND FOLLOW THE DIRECTIONS ON THE
LABEL OF THE CLEANER TO BE USED.
NOTICE: Service on this, or any other, LANG appliance must be
performed by qualified personnel only. Consult your
LANG authorized service agent directory or call the
factory at 314-678-6315, or www.langworld.com for the
service agent nearest you.
WARNING: BOTH HIGH AND LOW VOLTAGES ARE PRESENT
INSIDE THIS APPLIANCE WHEN THE UNIT IS
PLUGGED/WIRED INTO A LIVE RECEPTACLE. BEFORE
REPLACING ANY PARTS, DISCONNECT THE UNIT
FROM THE ELECTRIC POWER SUPPLY.
CAUTION: USE OF ANY REPLACEMENT PARTS OTHER THAN
THOSE SUPPLIED BY LANG OR THEIR AUTHORIZED
DISTRIBUTORS CAN CAUSE BODILY INJURY TO THE
OPERATOR AND DAMAGE TO THE EQUIPMENT AND
WILL VOID ALL WARRANTIES.

6
UNPACKING
3.1 Receiving the Griddle
Upon receipt, check for freight damage, both visible and concealed. Visible
damage should be noted on the freight bill at the time of delivery and signed by the
carrier's agent. Concealed loss or damage means loss or damage which does not
become apparent until the merchandise has been unpacked. If concealed loss or
damage is discovered upon unpacking, make a written request for inspection by the
carrier's agent within 15 days of delivery. All packing material should be kept for
inspection. Do not return damaged merchandise to Star Manufacturing
International. File your claim with the carrier.
3.2 Location
Prior to un-crating, move the griddle as near its intended location as practical. The
crating will help protect the unit from the physical damage normally associated
with moving it through hallways and doorways.
3.3 Un-crating
The griddle will arrive completely assembled inside a wood frame covered by
cardboard box and strapped to a skid. Remove the cardboard cover, cut the
straps and remove the wood frame.
Remove griddle from skid and place in intended location.
CAUTION: GRIDDLE IS EXTREMELY HEAVY. FOR SAFE
HANDLING, INSTALLER SHOULD OBTAIN HELP AS
NEEDED, OR EMPLOY APPROPRIATE MATERIALS
HANDLING EQUIPMENT (SUCH AS A FORKLIFT,
DOLLY, OR PALLET JACK) TO REMOVE THE UNIT
FROM THE SKID AND MOVE IT TO THE PLACE OF
INSTALLATION.
CAUTION: ANY STAND, COUNTER OR OTHER DEVICE ON WHICH
GRIDDLE WILL BE LOCATED MUST BE DESIGNED TO
SUPPORT THE WEIGHT OF THE GRIDDLE.
CAUTION: SHIPPING STRAPS ARE UNDER TENSION AND CAN
SNAP BACK WHEN CUT.

7
INSTALLATION
DANGER: THIS APPLIANCE MUST BE GROUNDED AT THE
TERMINAL PROVIDED. FAILURE TO GROUND THE
APPLIANCE COULD RESULT IN ELECTROCUTION AND
DEATH.
WARNING: INSTALLATION OF THE UNIT MUST BE DONE BY
PERSONNEL QUALIFIED TO WORK WITH ELECTRICITY.
IMPROPER INSTALLATION CAN CAUSE INJURY TO
PERSONNEL AND/OR DAMAGE TO EQUIPMENT. UNIT
MUST BE INSTALLED IN ACCORDANCE WITH ALL
APPLICABLE CODES.
NOTICE: The data plate is located behind the access panel in the
back of the grill. If on a 48” or larger, the data plate is
behind the back left access panel. The griddle voltage,
wattage, serial number, wire size, and clearance
specifications are on the data plate. This information
should be carefully read and understood before
proceeding with the installation.
NOTICE: The installation of any components such as a vent hood,
grease extractors, fire extinguisher systems, must
conform to their applicable National, State and locally
recognized installation standards.
4.1 Electrical Connection
There is one power supply connection on 2, 3 and 4 foot griddles. There are two
power supply connections on 5 and 6 foot griddles. Refer to the power supply
chart on the next page for proper power supply size.
There is (1) one 1 1/4 inch conduit knockout on 2, 3, and 4 foot griddles located at
the rear of the griddle, through the back and the bottom of the griddle body. There
are (2) two 1 1/4 inch conduit knockouts provided on the 5 and 6 foot griddles.
Use a supply wire suitable for at least 90C.
4.2 Griddle Voltage
This griddle is shipped from the factory wired for 208/240 or 480 volts. The
208/240 griddle is a dual voltage design. Jumper wires on terminal strip next to the
main power supply connection determine the griddle voltage. For a 208 volt power
supply, leave the jumpers in place. For a 240 volt power supply disconnect the
jumpers as indicated on the tag to the terminal strip. The 480 volt griddle can be
operated on 480 volts only.
4.3 Phasing
All griddles are shipped from the factory set up for a three phase service.
Rearrange the wires in the power supply terminal block to convert the griddle to
single phase. Rephasing the griddle is not chargeable to Star Manufacturing
International as warranty. To convert to single phase follow the chart located on
the next page.

8
INSTALLATION CONT’D
GRIDDLE SPECIFICATIONS
MODLE
NUMBER TOTAL
KW
NOMINAL AMPS PER LINE
WEIGHT
THREE PHASE SINGLE PHASE
208 VOLT 240 VOLT 480 VOLT 208V 240V
LINE 1 LINE 2 LINE 3 LINE 1 LINE 2 LINE 3 LINE 1 LINE 2 LINE 3
CLG24F 12.0 50.0 28.8 28.8 43.3 25.0 25.0 21.7 12.5 12.5 57.7 50.0 210 CLG36F 18.0 50.0 50.0 43.3 43.3 43.3 43.3 21.7 21.7 21.7 86.5 75.0 405 CLG48F 24.0 75.0 75.0 50.0 65.5 65.5 43.3 32.5 32.5 21.7 115.2 100.0 515
CLG60F #1 18.0 50.0 50.0 50.0 43.3 43.3 43.3 21.7 21.7 21.7 86.5 75.0 625 CLG60F #2 12.0 50.0 28.8 28.8 43.3 25.0 25.0 21.7 12.5 12.5 57.7 50.0 625 CLG72F #1 18.0 50.0 50.0 43.3 43.3 43.3 43.3 21.7 21.7 21.7 86.5 75.0 735 CLG72F #2 18.0 50.0 50.0 43.3 43.3 43.3 43.3 21.7 21.7 21.7 86.5 75.0 735
PHASING BY WIRE NUMBER
MODEL NUMBER THREE PHASE SINGLE PHASE
LINE 1 LINE 2 LINE 3 LINE 1 LINE 2
CLG24F 1,4 2 3 1,3 2,6 CLG36F 1,4 2,5 3,6 1,3,5 2,4,6 CLG48F 1,4,7 2,5,8 3,6,9 1,3,5,7 2,4,6,8
CLG60F #1 1,4 2,5 3,6 1,3,5 2,4,6 CLG60F #2 1,4 2 3 1,3 2,6 CLG72F #1 1,4 2,5 3,6 1,3,5 2,4,6 CLG72F #2 1,4 2,5 3,6 1,3,5 2,4,6

9
INITIAL START UP
5.1 Initial Start Up
Before starting the griddle for the first time, clean the griddle body and cooking
surface with a mild soap and water solution then rinse with clear water and dry.
Set the main power switch, located at the far left of the control panel, to the "ON"
(up) position (there are 2 "ON" switches on 5 and 6 foot griddles).
Set the temperature dials to 200°F (93°C) degrees.
Heat the griddle at 200°F (93°C) degrees for 2 hours to evaporate any moisture that
may be in the elements.
After 2 hours at 200°F (93°C) degrees, proceed with "SEASON THE COOKING
SURFACE".
5.2 Season the Grill
The cooking surface must be "seasoned" in order to reduce product sticking.
To season, heat the griddle to 250°F (121°C) degrees.
Once at 250°F (121°C) degrees, coat the cooking surface with a non-salted
vegetable oil.
Allow the griddle to stand at 250°F (121°C) degrees until the cooking surface looks
dry then coat it again.
Heat the griddle to 350°F (176°C) degrees and repeat the procedure.
The griddle may emit a small amount of smoke as the cooking surface passes the
350F (176°C) point. Do not be alarmed as oils associated with the manufacturing
process may cause smoke and will stop when the griddle reaches 350°F (176°C)
degrees.

10
OPERATION
CAUTION: ALWAYS KEEP THE AREA NEAR THE APPLIANCE
FREE FROM COMBUSTIBLE MATERIALS.
CAUTION: KEEP FLOOR IN FRONT OF EQUIPMENT CLEAN AND
DRY. IF SPILLS OCCUR, CLEAN IMMEDIATELY, TO
AVOID THE DANGER OF SLIPS OR FALLS.
6.1 Setting the Temperature
If different temperature settings across the same griddle are to be used, select one
side of the griddle and run that at the lowest temperature. Adjoining sections
should be set at progressively higher temperatures.
Do not try to run end sections hot and center sections cool.
6.2 Loading the Grill
An understanding of how the griddle sections are controlled will be a valuable aid
in loading your griddle.
A thermostat independently controls each 12-inch section. Sensors are mounted
under the griddle plate in the center of each cooking section.
If product is loaded directly over the temperature sensor, that section will turn on
and the element will heat the entire cooking section. If the product is loaded to the
side, front or back of the temperature sensor, the controller will react to the
temperature change of the entire section instead of just one product.
During slow periods minimal loads, do not load directly over the temperature
sensors as this will unnecessarily turn the elements on and over heat the reminder
of the section not being utilized.
During busy periods, a systematic approach should be utilized in loading the
griddle. Load the entire section from rear to front and continue cooking to the next
section if necessary.
Turn the product and continue cooking until it has reached its desired degree of
doneness.
Remove the product from the griddle.
When reloading the griddle, first use the griddle surface on which a previous load
was not placed. This will ensure the proper griddle temperature.

11
MAINTENANCE & CLEANING
7.1 Daily Cleaning
WARNING: KEEP WATER AND SOLUTIONS OUT OF CONTROLS.
NEVER SPRAY OR HOSE CONTROL CONSOLE,
ELECTRICAL CONNECTIONS, ETC.
CAUTION: MOST CLEANERS ARE HARMFUL TO THE SKIN,
EYES, MUCOUS MEMBRANES AND CLOTHING.
PRECAUTIONS SHOULD BE TAKEN TO WEAR
RUBBER GLOVES, GOGGLES OR FACE SHIELD AND
PROTECTIVE CLOTHING. CAREFULLY READ THE
WARNING AND FOLLOW THE DIRECTIONS ON THE
LABEL OF THE CLEANER TO BE USED.
Empty the grease drawer often or whenever it is 3/4 full. It is easily removed for
washing.
Clean the exterior of the appliance with hot water and mild detergent to maintain a
gleaming appearance.
Keep the griddle surface clean. After each cooking load, scrape the griddle surface
with a griddle scraper to remove any carbonized grease.
7.2 Weekly or as Required
Once a week or when necessary the griddle surface should be cleaned and
re-seasoned. Use a griddle stone, griddle pad, or liquid cleaner. Rub with the grain
of the metal, being careful not to scrape the splashguard.
A mild detergent with water or one of the many commercial griddle cleaners may
be used.
Be sure to rinse thoroughly and coat the cooking surface with a thin film of oil to
prevent rusting.
Re-season the griddle plate after each cleaning (refer to section 5.2 on page 9).

12
TROUBLESHOOTING
9.1 Symptoms
What follows is a chart of Symptoms and Possible Causes to aid in diagnosing
faults with the oven.
Refer to the Symptoms column to locate the type of failure then to the Possible
Cause for the items to be checked.
To test for a possible cause, refer to the TEST section and locate the Possible Cause
then refer to test to identify test procedures.
SYMPTOM POSSIBLE CAUSE
Griddle will not heat Failed element
Failed thermostat
No power to cord outlet
Open wire
Product burning Product is cooked too long
Failed thermostat
Product under done Failed thermostat

13
TROUBLESHOOTING CONT’D
9.2 TESTS
NOTICE: Service on this, or any other, LANG appliance must be
performed by qualified personnel only. Consult your
LANG authorized service agent directory or call the
factory at 314-678-6315 or www.langworld.com For
the service agent nearest you.
WARNING: BOTH HIGH AND LOW VOLTAGES ARE PRESENT
INSIDE THIS APPLIANCE WHEN THE UNIT IS
PLUGGED/WIRED INTO A LIVE RECEPTACLE.
BEFORE REPLACING ANY PARTS, DISCONNECT THE
UNIT FROM THE ELECTRIC POWER SUPPLY.
If an item on the list is followed by an asterisk (*), the work should be done by a factory
authorized service representative.
Possible Cause TEST
Product is cooked too long No test available, operational condition
Failed thermostat Check thermostat for continuity, or that it is
cycling on & off
Failed element Remove the wires and check for proper
resistance across the element
CAUTION: USE OF ANY REPLACEMENT PARTS OTHER THAN
THOSE SUPPLIED BY LANG OR THEIR AUTHORIZED
DISTRIBUTORS CAN CAUSE BODILY INJURY TO THE
OPERATOR AND DAMAGE TO THE EQUIPMENT AND
WILL VOID ALL WARRANTIES.

14
PARTS LIST July 25, 2012, Rev. B
CLG36F, CLG36THE Electric Marine & Cruise Line Griddle
Part No. Description QTY Application
2A-72500-05 LEG 4 W/BOLT DOWN ADJ 4 ALL
2D-73800-01 WATER PAN 1/3 HOTEL 1 ALL
2E-30500-11 TRM BLOCK 2 PLE LG 175AMP 2 ALL
2F-50404-07-1 LG PLT 1X35 7/8X22 15/16 1 ALL
2H-XL-424 ELEMENT PAN INSULATION 3 ALL
2N-11030-48 ELE GRD 440V 5991W XL/LG 3 ALL
2R-70701-28 KNB BLK 1/4BUSH2SETSCW@90 3 ALL
2T-30402-07 STAT ADJ 550o 48 C/T 3 ALL
K9-LGCL-425 ELEMENT PAN 3 ALL
K9-LGCL-723-31 GRDL PLT WELD 3' ACU PB 1 CL36GF-440V
K9-LGCL-723-W33 GRID PLT ASY-3' ACU CSE12 1 CLG36THE-440
CLG48F, CLG48THE Electric Marine & Cruise Line Griddle
Model: CL48GF, Electric Marine & Cruise Line Griddle
Part No. Description QTY Application
2A-72500-05 LEG 4 W/BOLT DOWN ADJ 4 ALL
2D-73800-01 WATER PAN 1/3 HOTEL 1 ALL
2E-30500-11 TRM BLOCK 2 PLE LG 175AMP 2 ALL
2F-50404-08-1 LG PLT 1X47 7/8X22 15/16 1 ALL
2H-XL-424 ELEMENT PAN INSULATION 4 ALL
2N-11030-12 ELE GRD SPECL 240V 5991W 4 240V
2N-11030-48 ELE GRD 440V 5991W XL/LG 440V
2R-70701-28 KNB BLK 1/4BUSH2SETSCW@90 4 ALL
2T-30402-07 STAT ADJ 550o 48 C/T 4 ALL
K9-LGCL-425 ELEMENT PAN 4 ALL
K9-LGCL-0723-41 PLATE ASSY WELD 4’ ACU 1 CLG48G-440V
K9-LGCL-0723-44 PLATE ASSY WELD 4’ ACCU 1 CLG48THE-440
Wiring Diagram
2M-61114-W53 WD 4' ACU ELE GRID w/CSE12 CLG48THE-240V
2M-61114-44 WD 4' 440VAC 3 PHASE 440V

15
WIRING DIAGRAM

16
WARRANTY
Lang Manufacturing Limited Warranty
to Cruise Line Purchasers
Lang Manufacturing Equipment (“Lang
Equipment”) has been skillfully manufactured,
carefully inspected and packaged to meet rigid
standards of excellence. Lang warrants its
Equipment to be free from defects in material and
material-related workmanship for (13) thirteen
consecutive months from the date of initial
shipboard installation or (18) eighteen consecutive
months from date of initial factory shipment, which
ever comes first. The aforementioned warranty
statement is subject to the following conditions and
limitations.
I. This warranty is limited to the provision of
replacement components for Product sold by Lang to
a joiner company for installation aboard a cruise
ship, or a cruise ship company for installation aboard
its own ship. The provision of replacement
components to affect Product repairs will be on a no-
charge basis during the term of the warranty.
Replacement components will be sent to the address
required within 48 hours of Lang receiving written
notification of the description of the defect and the
model and serial number of the Product affected by
the repair.
Quartz elements are warranted for ninety (90) days
from the date of installation.
II. Damage during shipment is to be reported to the
carrier, is not covered under this warranty, and is the
sole responsibility of purchaser/user.
III. Replacement components will be shipped
F.O.B. factory with freight prepaid.
Replacement component damage related to
shipment is not covered under this warranty.
IV. This warranty does not cover consumable
parts such as quartz elements, and does not
cover defects caused by improper installation,
abuse, careless operation, or improper
maintenance of Product.
V. All warranties are conditioned upon Lang’s
receipt of written notice of any defect prior to the
end of the applicable warranty period.
VI. THIS WARRANTY IS EXCLUSIVE AND IS
IN LIEU OF ALL OTHER WARRANTIES,
EXPRESSED OR IMPLIED, INCLUDING ANY
IMPLIED WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE, EACH OF WHICH IS
HEREBY EXPRESSLY DISCLAIMED. THE
REMEDIES DESCRIBED ABOVE ARE
EXCLUSIVE AND IN NO EVENT SHALL LANG
BE LIABLE FOR SPECIAL, CONSEQUENTIAL
OR INCIDENTAL DAMAGES FOR THE
BREACH OR DELAY IN PERFORMANCE OF
THIS WARRANTY.
VII. Lang Equipment is for cruise line use only. If
sold as a component of another (OEM)
manufacturer’s equipment, or if used as a consumer
product, such Equipment is sold AS IS and without
any warranty.
