Lang CSG24 Installation and operating instructions

Star Manufacturing International 10 Sunnen Drive St. Louis, MO 63143
Part Number: 2M-W361 Phone: [phone] Fax: [phone] March 10, 2010
Rev. C WWW.LANGWORLD.COM
Installation
Operation
Maintenance
Troubleshooting
Model: CSG24
Add-on Clamshell® Hood

2
THIS MANUAL MUST BE RETAINED FOR FUTURE REFERENCE. READ,
UNDERSTAND AND FOLLOW THE INSTRUCTIONS AND WARNINGS CONTAINED
IN THIS MANUAL.
FOR YOUR SAFETY
DO NOT STORE OR USE GASOLINE OR OTHER FLAMMABLE VAPORS AND
LIQUIDS IN THE VICINITY OF THIS OR ANY OTHER APPLIANCE.
POST IN A PROMINENT LOCATION
INSTRUCTIONS TO BE FOLLOWED IN THE EVENT USER SMELLS GAS. THIS
INFORMATION SHALL BE OBTAINED BY CONSULTING YOUR LOCAL GAS
SUPPLIER. AS A MINIMUM, TURN OFF THE GAS AND CALL YOUR GAS
COMPANY AND YOUR AUTHORIZED SERVICE AGENT. EVACUATE ALL
PERSONNEL FROM THE AREA.
WARNING: IMPROPER INSTALLATION, ADJUSTMENT, ALTERATION, SERVICE
OR MAINTENANCE CAN CAUSE PROPERTY DAMAGE, INJURY OR DEATH.
READ THE INSTALLATION, OPERATING AND MAINTENANCE INSTRUCTIONS
THOROUGHLY BEFORE INSTALLING OR SERVICING THIS EQUIPMENT.
Model #: Purchased From:
Serial #:
Location:
Date Purchased:
Date Installed:
Purchase Order #:
For Service, Call:

3
TABLE OF CONTENTS
CHAPTER PAGE
1. READ FIRST .................................................................................................................4
2. EQUIPMENT DESCRIPTION........................................................................................6
3. UNPACKING .................................................................................................................7
4. INSTALLATION.............................................................................................................8
5. INITIAL START-UP .......................................................................................................10
6. OPERATION..................................................................................................................11
7. SEQUENCE OF OPERATION .....................................................................................12
8. CLEANING & MAINTENANCE PROCEDURES..........................................................13
9. TROUBLESHOOTING ..................................................................................................14
10. PARTS LISTS................................................................................................................16
11. WIRING DIAGRAMS.....................................................................................................18

4
IMPORTANT READ FIRST IMPORTANT
NOTICE: If the Clamshell® is to be attached to a griddle/ charbroiler in the
field – it is recommended to complete the installation of mounting adapter
before un-crating the Clamshell®.
CAUTION: UNIT IS EXTREMELY HEAVY. FOR SAFE HANDLING, INSTALLER SHOULD
OBTAIN HELP AS NEEDED, OR EMPLOY APPROPRIATE MATERIALS
HANDLING EQUIPMENT (SUCH AS A FORKLIFT, DOLLY, OR PALLET
JACK) TO REMOVE THE UNIT FROM THE SKID AND MOVE IT TO THE
PLACE OF INSTALLATION.
WARNING: INSTALLATION OF THE UNIT MUST BE DONE BY PERSONNEL QUALIFIED
TO WORK WITH ELECTRICITY AND PLUMBING. IMPROPER
INSTALLATION CAN CAUSE INJURY TO PERSONNEL AND/OR DAMAGE
TO EQUIPMENT. UNIT MUST BE INSTALLED IN ACCORDANCE WITH ALL
APPLICABLE CODES.
NOTICE: The installation of this unit must conform to applicable National, State and
locally recognized installation standards.
CAUTION: SHIPPING STRAPS ARE UNDER TENSION AND CAN SNAP BACK WHEN
CUT.
DANGER: DO NOT REMOVE THE MOUNTING NUTS OFF OF THE MOUNTING PLATE
STUDS WHILE THE UNIT IS IN THE LOWERED POSITION. THE
STANCHION BACK IS UNDER TENSION AND CAN CAUSE BODILY INJURY.
NOTICE: The data plate is located on the inside surface of the hood wrap. The
Clamshell® voltage, wattage, serial number, clearance and gas
specifications are on the data plate. This information should be carefully
read and understood before proceeding with the installation.
NOTICE: This unit is approved to be installed only on equipment which meets NSF
standards, and for which the adapter kit is provided.
WARNING: BEFORE LIGHTING, USE A SOAP AND WATER SOLUTION TO TEST ALL
JOINTS FOR GAS LEAKS.
NOTICE: The installation of any components such as a vent hood, grease extractors,
fire extinguisher systems, must conform to their applicable National, State
and locally recognized installation standards.
WARNING: DURING INITIAL USE, OR USE AFTER SERVICE, IF THE PILOT DOES NOT
IGNITE ON FIRST TRY THE MAIN GAS VALVE MUST BE TURNED OFF FOR
AT LEAST FIVE MINUTES.
CAUTION: ALWAYS KEEP THE AREA NEAR THE APPLIANCE FREE FROM
COMBUSTIBLE MATERIALS.
CAUTION: KEEP FLOOR IN FRONT OF EQUIPMENT CLEAN AND DRY. IF SPILLS
OCCUR, CLEAN IMMEDIATELY, TO AVOID THE DANGER OF SLIPS OR
FALLS.
NOTICE: While cooking, the Clamshell® must be monitored at all times. Do not leave
the Clamshell® unattended while cooking.
NOTICE: Fan in Clamshell® runs continuously. For the safety of the unit, the fan
must run continuously to provide cooling to the electrical components.
Component cooling is required if the base unit is running. If power to the
Clamshell® is turned off, gas to base will be turned off. If it is necessary to
remove power from the Clamshell®, the base unit must be cooled below
200°F first.

5
IMPORTANT READ FIRST IMPORTANT
WARNING: KEEP WATER AND SOLUTIONS OUT OF CONTROLS. NEVER SPRAY OR
HOSE CONTROL CONSOLE, ELECTRICAL CONNECTIONS, ETC.
CAUTION: MOST CLEANERS ARE HARMFUL TO THE SKIN, EYES, MUCOUS
MEMBRANES AND CLOTHING. PRECAUTIONS SHOULD BE TAKEN TO
WEAR RUBBER GLOVES, GOGGLES OR FACE SHIELD AND PROTECTIVE
CLOTHING. CAREFULLY READ THE WARNING AND FOLLOW THE
DIRECTIONS ON THE LABEL OF THE CLEANER TO BE USED.
CAUTION: A COMMERCIAL LIQUID GRIDDLE CLEANER IS NOT RECOMMENDED FOR
CLEANING THE GRIDDLE OR CHARBROILER UNDER THE CLAMSHELL®
AS MOST CONTAIN POTASSIUM HYDROXIDE OR SODIUM HYDROXIDE
WHICH IS HARMFUL TO THE CLAMSHELL® BURNER TILES.
NOTICE: Do not spray any liquids on to the tiles, or wipe the tiles with any materials.
Liquids and direct contact on the tiles can damage them.
CAUTION: DO NOT USE YOUR HAND TO CHECK GRIDDLE/CHARBROILER
TEMPERATURE.
NOTICE: Service on this, or any other, LANG appliance must be performed by
qualified personnel only. Consult your LANG authorized service agent
directory or call the factory at 1-800-438-5264, or WWW.LANGWORLD.COM
for the service agent nearest you.
DANGER: BOTH HIGH AND LOW VOLTAGES ARE PRESENT INSIDE THIS
APPLIANCE WHEN THE UNIT IS PLUGGED/WIRED INTO A LIVE
RECEPTACLE. BEFORE PERFORMING ANY WORK ON INTERNAL
COMPONENTS, DISCONNECT THE APPLIANCE FROM THE ELECTRIC
POWER SUPPLY.
CAUTION: USE OF ANY REPLACEMENT PARTS OTHER THAN THOSE SUPPLIED BY
LANG OR THEIR AUTHORIZED DISTRIBUTORS CAN CAUSE BODILY
INJURY TO THE OPERATOR AND DAMAGE TO THE EQUIPMENT AND
WILL VOID ALL WARRANTIES.
CAUTION: BE SURE ALL OPERATORS READ, UNDERSTAND AND FOLLOW THE
OPERATING INSTRUCTIONS, CAUTIONS AND SAFETY INSTRUCTIONS
CONTAINED IN THIS MANUAL.
WARNING: WHEN MULTIPLE CLAMSHELLS® ARE USED ON A GRIDDLE, ALL THE
CLAMSHELLS MUST BE CONNECTED TO THE SAME 120V SOURCE.

6
2. EQUIPMENT DESCRIPTION
Lang Model: CSG24
ADD-ON CLAMSHELL® HOOD
2.1 Exterior Construction
•The Clamshell® dimensions are 19 1/2” (49.53cm) High in the lowered position, 38 1/3” (97.36cm)
High in the raised position, 36 3/4” (93.35cm) Deep, and width is 24” (60.96cm).
•The stainless steel hood makes for easy cleaning.
•Pivoting heat deflector redirects excess grill heat to either side of the equipment and away from
employees.
2.2 Operation
•By heating only when in the down position, you can conserve energy and save money with a cooler
backroom environment.
•Cook different products at the same time with no height adjustments needed.
2.3 Technical
•Griddle operates on either Natural Gas or Propane. This must be specified when ordering. It is
shipped with a Power Cord and Plug attached.
•Clearances required from non-combustible surfaces: Back: 0 inches, Sides: maintain side clearance
of base appliance or 3 inches which ever is greater, Bottom: 6 inches below the bottom of the
stanchions.
2.4 Griddle Gas and Voltage Specifications
The Lang Clamshell® can be connected to any 120 Volt source. In applications where multiple
clamshells are installed on the same griddle, they all need to be plugged into the same receptacle
circuit.
The gas specifications are listed on the data label located on the inside surface of the hood wrap.
WARNING: WHEN MULTIPLE CLAMSHELLS® ARE USED ON A GRIDDLE, ALL THE
CLAMSHELLS MUST BE CONNECTED TO THE SAME 120V SOURCE.

7
3. UNPACKING
3.1 Receiving the Clamshell®
Upon receipt, check for freight damage, both visible and concealed. Visible damage should be noted
on the freight bill at the time of delivery and signed by the carrier's agent. Concealed loss or damage
means loss or damage which does not become apparent until the merchandise has been unpacked. If
concealed loss or damage is discovered upon unpacking, make a written request for inspection by the
carrier's agent within 15 days of delivery. All packing material should be kept for inspection. Do not
return damaged merchandise to Star Manufacturing International. File your claim with the
carrier.
3.2 Location
Prior to un-crating, move the Clamshell® as near to its intended location as practical. The crating will
help protect the unit from physical damage normally associated with moving it through hallways and
doorways.
NOTICE: If the Clamshell® is to be attached to a griddle/ charbroiler in the field –
it is recommended to complete the installation of mounting adapter
before un-crating the Clamshell®.
3.3 Un-crating the Add-on Clamshell® Hood
If Clamshell® is received already attached to a Griddle/Charbroiler skip to section 3.4.
The Clamshell® will arrive completely assembled inside a wood frame covered by a cardboard box
and bolted to a skid. Remove the cardboard cover, unbolt Clamshell® from the support
brackets. Discard the skid and brackets.
Remove Clamshell® from skid and place in intended location.
There are several parts that are not installed in the unit. Be careful not to misplace the following parts
when un-crating the unit.
Inner Component Cover
Outer Component Cover
Inner Flue
Outer Flue
Insulation
Manual Shut-off Valve
Two 3/8 X 16 Nuts
Note: See Mounting Adapter kit for instructions on installing these parts.
CAUTION: UNIT IS EXTREMELY HEAVY. FOR SAFE HANDLING, INSTALLER
SHOULD OBTAIN HELP AS NEEDED, OR EMPLOY APPROPRIATE
MATERIALS HANDLING EQUIPMENT (SUCH AS A FORKLIFT, DOLLY,
OR PALLET JACK) TO REMOVE THE UNIT FROM THE SKID AND MOVE
IT TO THE PLACE OF INSTALLATION.
3.4 Un-crating Griddle/Charbroiler with Clamshell® Attached
CAUTION: SHIPPING STRAPS ARE UNDER TENSION AND CAN SNAP BACK
WHEN CUT.
The griddle will arrive completely assembled inside a wood frame covered by a cardboard box and
strapped to a skid. Remove the cardboard cover, cut the straps and remove the wood
frame.
Remove griddle from skid and place in intended location. The legs and gas regulator are located in the
grease drawer.

8
4. INSTALLATION
WARNING: INSTALLATION OF THE UNIT MUST BE DONE BY PERSONNEL
QUALIFIED TO WORK WITH ELECTRICITY AND PLUMBING.
IMPROPER INSTALLATION CAN CAUSE INJURY TO PERSONNEL
AND/OR DAMAGE TO EQUIPMENT. UNIT MUST BE INSTALLED IN
ACCORDANCE WITH ALL APPLICABLE CODES.
NOTICE: The data plate is located on the inside of the hood wrap. The
Clamshell® voltage, wattage, serial number, clearance and gas
specifications are on the data plate. This information should be
carefully read and understood before proceeding with the installation.
NOTICE: This unit is approved to be installed only on equipment which meets
NSF standards, and for which the adapter kit is provided.
WARNING: WHEN MULTIPLE CLAMSHELLS® ARE USED ON A GRIDDLE, ALL THE
CLAMSHELLS MUST BE CONNECTED TO THE SAME 120V SOURCE.
4.1 Electrical Connection
The Clamshell® is supplied with a cord and plug. The receptacle is not provided with the Clamshell®.
Follow the receptacle manufacturer’s instructions when connecting the receptacle to the power supply.
When multiple Clamshells are installed on the same griddle, you must plug them into the same
electrical circuit (receptacle) to prevent from doing damage to the units transformers.
4.2 Gas Connection
WARNING: BEFORE LIGHTING, USE A SOAP AND WATER SOLUTION TO TEST
ALL JOINTS FOR GAS LEAKS.
This Clamshell® is manufactured for use with the type of gas indicated on the nameplate.
Contact the factory if your type of gas does not match the nameplate data.
All gas connectors must be in accordance with local codes and comply with the National Fuel
Federal Gas Codes ANSI Z223.1 latest edition.
There are two gas connections involved in the installation of the Clamshell®:
The first is the gas supply to the Clamshell® itself. This connection should be made positioning
the manual shut-off valve supplied with the Clamshell® to isolate the appliance from the kitchens
main gas supply during any future service activity (See figure 1). (A service agent should be able
to shutoff and disconnect the gas supply to the Clamshell® without affecting the main gas supply
to the kitchen.) Use gas lines that have a minimum diameter of at least 1/2 an inch.
The second is the gas supply to the base appliance (the appliance to which the Clamshell® is
mounted). The Clamshell® has an external solenoid valve (the Automatic Cutoff Valve (ACV))
at the end of a flexible conduit. The ACV must be installed in line with the gas supply to the base
appliance in a location, which will ensure the ACV is not exposed to temperatures above 175°F
(See figure 1). Remove the cover to the ACV to ensure the correct flow direction through the
valve when making the connections. Replace the cover after the connections are complete. Use
gas lines that have a minimum diameter of at least 1/2 an inch.
NOTE: If this Clamshell® is received already mounted on a Lang griddle no further installation is
required. If this Clamshell® is a separate unit proceed to section 4.3 below.
NOTICE: The installation of any components such as a vent hood, grease
extractors, fire extinguisher systems, must conform to their applicable
National, State and locally recognized installation standards.

9
4. INSTALLATION CONT’D
4.3 Installation Instructions
Refer to the Installation instructions provided with the adapter kit, on how to connect this Clamshell®
to the griddle/charbroiler.
Figure 1
Griddle / Charbroiler
ACV
ACV
Manual Shut-off
Valve
Regulator
Legend:
ACV = Automatic Cut-off Valve
A = 1” Pipe
B = Reduction to 3/4” Pipe
C = Reduction to 1/2” Pipe
D = Increase to 3/4” Pipe
O = Optional second AGC Parts
CSG24 CSG24

10
5. INITIAL START UP
5.1 Initial Lighting Procedure for an Clamshell®
WARNING: DURING INITIAL USE, OR USE AFTER SERVICE, IF THE PILOT DOES
NOT IGNITE ON FIRST TRY THE MAIN GAS VALVE MUST BE TURNED
OFF FOR AT LEAST FIVE MINUTES.
NOTICE: While cooking, the Clamshell® must be monitored at all times.
DO NOT leave the Clamshell® unattended while cooking.
NOTICE: Fan in Clamshell® runs continuously. For the safety of the unit, the fan
must run continuously to provide cooling to the electrical components.
Component cooling is required if the base unit is running. If power to
the Clamshell® is turned off, gas to base will be turned off. If it is
necessary to remove power from the Clamshell®, the base unit must be
cooled below 200°F first.
•The Clamshell® has two positions, the lowered position for cooking and the raised position for griddle
loading, cleaning, or griddle only use.
•No thermostats are provided for temperature control. The Clamshell® is a radiant cooking device,
which operates only in the lowered position.
•Ignition is automatic and occurs as the Clamshell® is lowered.
•Raising the Clamshell® turns the gas burner off.
5.2 Initial Lighting Procedure for the Griddle/Charbroiler
See Operator manual for the griddle/charbroiler.

11
6. OPERATION
6.1 Clamshell® Operation
CAUTION: ALWAYS KEEP THE AREA NEAR THE APPLIANCE FREE FROM
COMBUSTIBLE MATERIALS.
CAUTION: KEEP FLOOR IN FRONT OF EQUIPMENT CLEAN AND DRY. IF SPILLS
OCCUR, CLEAN IMMEDIATELY, TO AVOID THE DANGER OF SLIPS OR
FALLS.
NOTICE: While cooking, the Clamshell® must be monitored at all times. Do not
leave the Clamshell® unattended while cooking.
•The Clamshell® has two positions, the lowered position for cooking and the raised position for
griddle loading, cleaning, or griddle only use.
•No thermostats are provided for temperature control. The Clamshell® is a radiant cooking device,
which operates only in the lowered position.
•Ignition is automatic and occurs as the Clamshell® is lowered.
•Raising the Clamshell® turns the gas burner off.
•Place food on griddle/charbroiler and immediately lower the Clamshell®. The tiles will glow
reddish-orange in approximately 30-45 seconds. The radiant heat from the Clamshell® will cook
from the top while the griddle/charbroiler cooks the product from the bottom.
•Load product under the Clamshell® following the normal loading procedures for the
griddle/charbroiler to which it is attached.
6.2 Operation When Attached to a Griddle/Charbroiler
See Operator’s Manual for the base unit.

12
7. SEQUENCE OF OPERATION
7.1 Power On
•When the Clamshell® is plugged in, 115 Volts is applied to the blower motor. The Clamshell® is
designed to have a constantly running blower motor.
•The air switch then senses the blower motor, closes, and applies the 115 Volts to a 24 VAC transformer.
•The transformer then supplies 24 VAC to the tilt switch, and to the automatic cutoff valve.
•The 24 VAC to the automatic cutoff valve opens the gas valve to the griddle/charbroiler, thus allowing the
base unit to operate.
•When the Clamshell® is lowered, the tilt switch allows 24 VAC to go to the spark module.
•The spark module then supplies 24 VAC to open the Clamshell® gas valve, and high voltage to the spark
igniter.
•When the burner ignites, the sense probe senses the flame is ignited and the spark module turns off the high
voltage to the spark igniter.
•When the Clamshell® is raised the tilt switch opens the 24 VAC to the spark module, which removes the
24 VAC to the gas valve, turning off the Clamshell®.

13
8. MAINTENANCE & CLEANING
WARNING: KEEP WATER AND SOLUTIONS OUT OF CONTROLS. NEVER SPRAY OR
HOSE CONTROL CONSOLE, ELECTRICAL CONNECTIONS, ETC.
CAUTION: MOST CLEANERS ARE HARMFUL TO THE SKIN, EYES, MUCOUS
MEMBRANES AND CLOTHING. PRECAUTIONS SHOULD BE TAKEN TO
WEAR RUBBER GLOVES, GOGGLES OR FACE SHIELD AND PROTECTIVE
CLOTHING. CAREFULLY READ THE WARNING AND FOLLOW THE
DIRECTIONS ON THE LABEL OF THE CLEANER TO BE USED.
CAUTION: A COMMERCIAL LIQUID GRIDDLE CLEANER IS NOT RECOMMENDED FOR
CLEANING THE GRIDDLE OR CHARBROILER UNDER THE CLAMSHELL®
AS MOST CONTAIN POTASSIUM HYDROXIDE OR SODIUM HYDROXIDE
WHICH IS HARMFUL TO THE CLAMSHELL® BURNER TILES.
NOTICE: Do not spray any liquids on to the tiles, or wipe the tiles with any materials.
Liquids and direct contact on the tiles can damage them.
8.1 Weekly Cleaning
•The Clamshell® tiles are self cleaning, which is accomplished by leaving the Clamshell® on with no
product being cooked, thus allowing the heat of the broiler to burn debris from the tiles.
•To clean the Clamshell®, start with a clean griddle plate.
•Turn off the griddle/charbroiler thermostats and wait until the griddle/charbroiler is cool.
CAUTION: DO NOT USE YOUR HAND TO CHECK GRIDDLE/CHARBROILER
TEMPERATURE.
•Lower the Clamshell® and let it run for 45 minutes, then raise the Clamshell® and ensure the blower motor
continues to blow cooling air through the burner tiles (Do not unplug or turn off Clamshell® power).
•Once the Clamshell® has cooled, wipe ash from around the burner tiles. Take care not to touch the burner
tiles with the cleaning rag.
NOTICE: Do not spray any liquids on to the tiles, or wipe the tiles with any materials.
Liquids and direct contact on the tiles can damage them.
8.2 Burner Air Shutter Adjustment
•The air shutters are pre-set at the factory, and should not need adjustment. However, if adjustments are
being required, contact your local authorized service station for instructions.
8.3 Disconnecting Power from Blower Motor
If power is to be removed from the blower motor, the following must be completed:
The gas to the base unit and the gas to the Clamshell® must be turned off.
The base unit must be cooled below 200°F.

14
8. MAINTENANCE & CLEANING CONTINUED
CAUTION: DO NOT REMOVE THE REAR DRIP SHIELD. THE DRIP SHIELD SHOULD
ONLY BE REMOVED DURING SPECIFIC REPAIRS BY A TRAINED SERVICE
PROFESSIONAL.
Do not remove the drip shields. The drip shields should only be removed during
specific repairs by a trained service professional. Check the screws on your unit
during your periodic inspection.
• If you cannot turn a screw to the left or counter-clockwise, then do not do anything further
with that screw.
• If you can turn a screw to the left or counter-clockwise, then use the Lang kit,
part number PS-60101-W8, provided to you at no charge to rework the screw.

15
9. TROUBLESHOOTING
9.1 Symptoms
What follows is a chart of Symptoms and Possible Causes to aid in diagnosing faults with the Clamshell®.
Refer to the Symptoms column to locate the type of failure then to the Possible Cause for the items to be
checked.
To test for a possible cause, refer to the TEST section and locate the Possible Cause then refer to test to
identify test procedures.
SYMPTON POSSIBLE CAUSE
Igniter not sparking •Failed spark module
•Failed tilt switch
•Failed air switch
•Failed motor blower
•Failed transformer
•Failed spark electrode
Spark but no ignition •Failed spark controller
•Failed gas solenoid valve
•Clamshell® gas valve turned off
•Plugged orifice
Clamshell® turns off after extended use •Incorrectly adjusted sense electrode
Taking too long to light •Incorrectly adjusted spark electrode
•Plugged enrichment orifice
•Plugged burner tiles
Hazy blue flame on tile face •Incorrectly adjusted air shutter
•Leak in air path to burner face
•Incorrectly adjusted gas regulator
Not hot enough •Incorrectly adjusted gas regulator
•Plugged main burner orifice
•Plugged burner tiles
Clamshell® not turning off •Failed tilt switch
•Failed gas solenoid valve
Blower runs continuously •Normal operation

16
9. TROUBLESHOOTING CONT’D
9.2 TESTS
NOTICE: Service on this, or any other, LANG appliance must be performed by
qualified personnel only. Consult your LANG authorized service agent
directory or call the factory at 1-800-807-9054, or WWW.STAR-MFG.COM
For the service agent nearest you.
WARNING: BOTH HIGH AND LOW VOLTAGES ARE PRESENT INSIDE THIS
APPLIANCE WHEN THE UNIT IS PLUGGED/WIRED INTO A LIVE
RECEPTACLE. BEFORE REPLACING ANY PARTS, DISCONNECT THE
UNIT FROM THE ELECTRIC POWER SUPPLY AND CLOSE THE MAIN GAS
VALVE. ALLOW FIVE MINUTES FOR UNBURNED GAS TO VENT.
If an item on the list is followed by an asterisk (*), the work should be done by a factory
authorized service representative.
Possible Cause TEST
Failed tilt switch •Unplug switch and test for continuity while raising/lowering
the hood
Failed gas valve •Remove the wires and check for continuity across the valve
coil
Failed spark module •Check for 24 VAC on TH*
•Observe spark
Failed air switch •Unplug switch and test for continuity while blower motor is
running*
Failed combustion blower •Check for proper voltage to unit/blower*
•Check for continuity across the motor’s windings
Improper gas pressure •Ensure gas pressure is adjusted properly*
Failed transformer •Check for proper voltage*
CAUTION: USE OF ANY REPLACEMENT PARTS OTHER THAN THOSE SUPPLIED BY
LANG OR THEIR AUTHORIZED DISTRIBUTORS CAN CAUSE BODILY
INJURY TO THE OPERATOR AND DAMAGE TO THE EQUIPMENT AND
WILL VOID ALL WARRANTIES.

1
2
3
78
9
10
11
16
15 14 13
12 29
30
31
32
33
34
19 17
20
21
22
24
25
26
27
28
23
4
6
5
NOTE: 2H-60106-66
must be sold with Item #21
SK2476, Rev. -
Model: CSG24 GAS 24” CLAMSHELL

PARTS LIST October 29, 2012, Rev. -
Gas Clamshell Hood Parts List
Fig No Part No Qty Description Application
1 K9-60101-851 1 HOOD WRAP ASSY, w/DIE CAST LOGOS
2 2M-60301-W2 1 LANG CLAMSHELL LOGO
3 K9-70603-24 1 AGC HOOD HANDLE ASSY COMPLETE
4 K9-60301-43-1 1 SATIN CHRM-LANG DIE CAST
5 2K-70801-19 1 BUSHING HEYCO 5/8#2077
6
7 2P-51002-11 2 HOOD SPRING
8 2P-51002-05 2 SPRING GAS HOOD
9 2K-70101-50 2 BRAS TBE TEE 3/8CC-3/8CC-1/4CC
10 K9-50312-40 2 SPRING PISTON / WASHER
11 2C-20104-37 2 SCRW 3/8-16X12 H/H CAP 2 THD
12 2V-80502-03 1SOLENOID VALVE 24VAC 1/2PIPE CSG24
2 CSG24B
13 K9-30307-01 1 SWT MERC TLT W/250°C 18GA
14 2J-80300-10 1 SPRK IGN CNTRL
15 2V-80501-03 1 GAS REG 1/2X1/2CLSIISET10 LP
2V-80501-10 1 GAS REG 1/8X1/2 CLS I NAT
16
Y9-80403-04 190 DEG FITING W/#29 DRL NAT
2A-80400-26 ORIFICE HOOD .1360 #29
Y9-80403-05 190 DEG FITING W/#44DRL LP
2A-80400-27 ORIFICE HOOD .0860 #44
17 2E-103-232 1 HARNESS, AGC HOOD #1
19 2J-80302-06 1 IGNITOR/SENSOR CHANNEL
20 K9-103-3 1 SPARK COVER
21 K9-51100-59 1 BURNER TILE ASSY, GLUED
22 2U-103-193 1 LEFT SKIRT
23 2V-103-194 1 RIGHT SKIRT
24 2V-103-197 1 FRONT SKIRT w/HINGE
25 K9-60102-1964 1 FRONT SKIRT INNER WALL w/SCREWS
26 2C-20103-02 3 SCRW SM PLT 10 X .5 PHLSL
27 K9-103-A88 1 FLAPPER ASSY
28 2B-50201-08 1 WIRE GUARD ADD-ON-BROILER
29 2K-70101-51 1 BRAS TBE ELBOW 1/4CC X 1/4CC
30 K9-103-4 1 TOP SEAL PLATE
31 K9-103-89 1 TOP PLATE SEAL
32 2C-20201-03 1 WSHR FLT AN960-716
33 K9-103-71 1 TUBE #5
34 2A-80401-04 1PILOT BURNER ORIFICE, .021DRL NAT
2A-80401-05 PILOT BURNER ORIFICE, .010DRL LP
NI 2H-103-124 1 COMPONENT COVER INSULATION
IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED PAGE
INCLUDE MODEL AND SERIAL NUMBER OF
Some items are included for illustrative purposes only and in certain instances may not be available.
1
1
R

2
1
3
4
57
10
11
12 13 14
17
9
8
19
24
25
26
23
22
18
20
21
15 16
6
SK2477, Rev. -
Model: CSG24 GAS 24” CLAMSHELL, FRAME ASSY

PARTS LIST October 29, 2012, Rev. -
Gas Clamshell Frame Parts List
Fig No Part No Qty Description Application
1K9-103-702-W2 1LEFT OUTER STANCHION - ASSY CSG24
K9-103-702-1 LEFT OUTER STANCHION CSG24B
2 K9-103-701 1 BLOWER DUCT - SPOT
3 2U-30200-44 1 MOTOR & BLOWER ASSY FOR AGC
4 OB-60102-194 1 OBS AGC BLOWER HOUSE ASSY
5K9-103-301 1 STANCHION COVER LH CSG24
K9-103-301-2 CSG24B
6K9-103-303 1 INNER DRIP EDGE CSG24
K9-103-303-2 CSG24B
7 K9-103-304 1 BAFFLE CLIP RH
8 K9-103-305-1 1 BAFFLE CLIP LH
9K9-103-300 1STANCHION COVER RH CSG24
K9-103-300-2 STANCHION COVER RH CSG24B
10 K9-103-323 1 HOODWRAP DRIP CATCHER
11 K9-103-164 1 REAR ACCESS COVER
12 2C-20104-08 2 SCRW HXHD CAP PLT 1/4-20
13 2C-20202-05 2 WSHR PLT 1/4 LOCK SPLIT
14 2C-20201-05 2 WSHR LFT 1/4 USS PLTD
15 2P-70201-07 4 BRNZ BR FLN 5/8IDX3/4ODX1
16 K9-60102-1911 2 HOOD PIVOT SHAFT ASSY
17 K9-103-115-W3 1RIGHT OUTER STANCHION CSG24
K9-103-115-3 RH OUTER STANCHION CSG24B
18 2C-20109-04 16 SCREW THD MS SS 10-32X
19 K9-103-102 1 FIXED BOTTOM
20 2E-30501-02 1 TRM STRP 3 POLE W/PUSH ON TRM
21 2E-31200-01 1 BOX CONNECTOR 3/8
22 2E-30600-11 1RELAY 120V SPDT FLANGE MNT used w/Envirozone Griddles
2E-30600-04 RLAY 24VAC 2FRMC DPDT FLNG MNT
23 2E-31400-07 1 XFRMR, 120-208-240/24V,40V
24 K9-103-101 1 COMPONENT TRAY
25 2E-70505-07 1 CONDUIT CNNCTR 3/8 90° FLEX
26 2E-31107-06 1 CORD SET 14/3 X 6’ 15A
NI 2E-30308-01 1 SWITCH AIR 10WC 1/4
NI K9-103-95 1 AIR SWITCH HOSE
NI 2E-40704-04 1 CAP - BLOWER START FOR
IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED PAGE
INCLUDE MODEL AND SERIAL NUMBER OF
Some items are included for illustrative purposes only and in certain instances may not be available.
1
1
R
