Using the Lantronix SGX 5150 Serial Device Server
1
Using the Lantronix SGX 5150 Serial Device Server
Application Note #28 - Revision 01/2021
Overview
The Lantronixindustrial wireless device serial servers and Ethernet Bridge/Routers are built for networking
equipment in an array of machine-to-machine (M2M) applications. The SGX 5150 features an industrial
strength enclosure and operates over a wide temperature range (-40° to 70°C) to withstand challenging M2M
environments. Dual port design allows connection of up to 2 devices. Dual-band Wi-Fi supports both 2.4GHz
and 5GHz networking.
Security features include wireless security; network security; and device security (multi-level encryption
capability to protect configuration data).
This Application Note details the configuration steps necessary to use the Lantronix SGX 5150 Device Server
with several Campbell Scientific®data loggers including the CR2XX, CR3XX, CR800, CR1000 and CR6 and
the Canary SystemsMLGPSmodule.
Definitions
Ad-Hoc Network: An ad-hoc network is one of the two types of wireless networks (the other is "Infrastructure")
and is not very common. Ad-hoc networks do not require a wireless network access point and are considered
"de-centralized". Ad-hoc networks are convenient to allow devices and/or PC's to communicate with each other
in the absence of a centralized network.
DHCP: Dynamic Host Configuration Protocol (DHCP) is a mechanism used in computer networks to assign IP
addresses automatically.
Infrastructure Network: An infrastructure network is one of the two types of wireless networks (the other is
"Ad-Hoc") and is the most common. Infrastructure networks require a wireless network access point to manage
and forward traffic to and from the wireless network.
SSID: Service Set Identifier (SSID) is the unique identifier for a wireless network, either infrastructure or ad-
hoc. The SSID is used to configure each device or PC to select the wireless network that you want it to
communicate on.
Wireless Network Access Point (AP): A wireless network access point is a Wi-Fi router that is used to setup
a wireless network. Access Points support "Infrastructure" networks as opposed to "Ad-Hoc" networks. The AP
is responsible for forwarding network to and from connected wireless devices and PC's.
Serial Interface: Typically, the data loggers are connected to one of the serial interface connectors on the
Lantronix SGX 5150. The serial interface port support baud rates up to 921.6Kbps and RS-232 or Multi-
protocol RS-232/422/485. The default serial port settings are 9600 baud, No parity, 8 data bits, 1 stop bit and
no flow control.

Using the Lantronix SGX 5150 Serial Device Server
2
Required Equipment and Software
To configure your SGX 5150 and test its operation you need:
1. SGX 5150 Serial Device Server (normally installed in the data logger enclosure)
2. A USB to Serial Adapter, Lantronix Serial Port adapter cable
3. Computer with a Wi-Fi network adapter (most laptops have built in Wi-Fi and USB Wi-Fi adapters are
readily available to add Wi-Fi capability to a desktop)
4. Data logger (normally installed in the data logger enclosure)
Note − The data logger system should have the serial cable which connects the SGX 5150 serial port to the data
logger serial port already installed.
SGX 5150 Connections
(Figure 1 - Front view of the Lantronix SGX 5150)
(Figure 2 - Rear view of the Lantronix SGX 5150)
Note - Serial 1 and Serial 2 are sometimes referred to as “Line 1” and “Line 2” by Lantronix.

Using the Lantronix SGX 5150 Serial Device Server
3
Configuring the SGX 5150
This Application Note describes how to configure the SGX 5150 to operate in an infrastructure network. It does
not cover configuring for an ad-hoc network.
Gather Information about your Wireless Network
Before you can configure the SGX 5150 you need to understand the wireless network that you are connecting
the SGX 5150 to. Work with your systems administrator to obtain this information, specifically:
SSID
Example: MyNetworkName
Provided by your IT Department
Passphrase
Example: SecretPhrase
Provided by your IT Department
Security Type
Example: WPA2, WEP
Provided by your IT Department
IP ADDRESS
nnn.nnn.nnn.nnn
Assigned by your IT Department
SUBNET MASK
nnn.nnn.nnn.0
Assigned by your IT Department (Typically 255.255.255.0)
Default Gateway
nnn.nnn.nnn.nnn
Assigned by your IT Department
(Table 1 - Note: ‘n’ can be any digit 0 to 9)
Note − The SGX 5150 does include support for DHCP but it is NOT recommended to use this as IP addresses can be
re-assigned which will require MultiLogger

configuration to be updated. Names can be assigned to an IP address,
and MultiLogger

does support name resolution of IP addresses, however this requires additional configuration that is
beyond the scope of this Application Note.
Configuration over a Serial Port
The following steps are for configuration of the SGX 5150 over the serial port. This configuration method does
not require extra software or network access. If you have access to the network you want to configure for,
please see Appendix D for an alternative method.
1. In order to start the configuration, first set SGX 5150 to Factory Defaults; See Appendix A.
2. Turn off power to the SGX 5150.
3. Open the terminal program HyperTerminal (or similar program like PuTTY) and set serial communications
to: (9600, 8, N, 1, No Flow)
▪Baud rate: 9600
▪Data bits: 8
▪Parity bit: None
▪Stop bit: 1
▪Flow control: None
4. Set your terminal program to the proper COM port (Check Device Manager).
5. Connect the USB-Serial Adapter to a Null-Modem cable. Plug the Serial Cable adapter into Serial 2 (use
Serial 1 if configuring for an MLGPS) on the SGX 5150 and the DB-9 end to the Null-Modem cable.
6. In the terminal window, Hold down the “!” key (shift + 1).
7. Turn on the power to the SGX 5150.
8. Keep holding the “!” key for about 10 seconds until a “!” character appears in the terminal window.
9. Release the “!” key and type “xyz” within 5 seconds.

Using the Lantronix SGX 5150 Serial Device Server
4
10. The SGX 5150 prompt should appear in the window:
(Figure 3 - Terminal Window)
Enter the commands as shown below. Black text is the command prompt. The red text indicates commands
you enter. Blue text indicates command responses from the SXG 5150. For brevity, not all SGX 5150
responses are shown.
Connection is complete once WLAN and SIGNAL lights on the SGX 5150 turn on, this may take a few minutes.

Using the Lantronix SGX 5150 Serial Device Server
5
Confirm Connection
The SGX 5150 should now be configured for your wireless network. This can be tested by opening a web
browser and typing the SGX 5150 IP address into the address bar. When prompted for a username, enter
"admin". The password, for devices manufactured after January 1, 2020, is the last 8 characters of the Device
ID, or for older units use “PASS”. Once the user name and password have been entered click OK. If you see
the SGX 5150 homepage (shown below), you have correctly configured your SGX 5150.
(Figure 4 - SGX homepage that displays when connected and properly configured)

Using the Lantronix SGX 5150 Serial Device Server
6
Testing SGX 5150 Configuration
To test the operation of the Serial Device Server with a CR300 (or similar) Control Module, open MultiLogger
and update the IP:Port configuration for the new device, CR300 example shown below.
Connect the datalogger’s Serial Port to Line 1 on the SGX 5150.
Note − Be sure to use the settings utilized with your infrastructure.
The ports for the Serial Ports are as follows:
▪Serial Port 1: 10001 (Serial Port 1 is Line 1 on the SGX 5150)
▪Serial Port 2: 10002 (Serial Port 2 is Line 2 on the SGX 5150)
Press Save in MultiLoggerwhen settings are updated.
(Figure 5)
Double-click the node, CR300_1 in the example above, or select it and press the Logger button, to open the
Logger form.

Using the Lantronix SGX 5150 Serial Device Server
7
Press the Monitor button on the Logger toolbar to start the Monitor mode.
This initiates a socket connection to the device and attempts to start the Monitor mode.
If successful, the Datalogger Clock starts updating to indicate successful communication.
(Figure 6)

Using the Lantronix SGX 5150 Serial Device Server
8
Appendix A –SGX 5150 Reset
To reset the SGX 5150 and restore the manufacturer default settings: Press the Reset button as shown in the
figure below for 6 seconds. The SGX 5150 configuration automatically reboots as the button is released.
(Figure 7)

Using the Lantronix SGX 5150 Serial Device Server
9
Appendix B –Troubleshooting PC Wireless
If your PC’s wireless adapter will not connect to the SGX 5150, then these steps may help resolve the lack of
connectivity:
1. After the device connects, go to the PC’s Network and Internet settings.
(Figure 8)
2. Right-click on your Wi-Fi adaptor and select Properties.
(Figure 9)
3. In the Wi-Fi Properties, select Internet Protocol and select Properties again.
(Figure 10)

Using the Lantronix SGX 5150 Serial Device Server
10
If Use the following IP address is selected, then select Obtain an IP address automatically and skip to step
5. If Obtain an IP address automatically is selected, then proceed to the following step.
(Figure 11)
4. Select Use the following IP address and enter a Default gateway, Subnet mask and unique IP address
for your network. (Example shown in Figure 11)
(Figure 12)
5. Then click on OK.

Using the Lantronix SGX 5150 Serial Device Server
11
Appendix C –Diagnostic Lights
The lights on the front of the SGX 5150 can be used for basic network troubleshooting:
WPS Status
Blink Pattern
WPS is enabled and on
Short, continuous
WPS has a profile error
Long, long, long, short, short, 2 seconds off, continuous
WPS has a timeout error
Long, long, long, short, short, short, short, 2 seconds off, continuous
(Table 2)
Note - For the above table, a “long” blink is 0.7 seconds of light followed by 0.3 seconds of no light. A “short” blink is a
light that is on for only 0.2 seconds and followed by 0.2 seconds of no light.
The diagnostic blink patterns reflect the highest priority fault condition. Also, the Diagnostic LED gives an
initial, identifying blink pattern to indicate the type of diagnostic information it will display. All power and other
non-network related diagnostic patterns begin with one long blink. All wired LAN related diagnostics patterns
begin with two long blinks. All WLAN-related diagnostics patterns begin with three long blinks.

Using the Lantronix SGX 5150 Serial Device Server
12
Appendix D –GUI Based Configuration via Wi-Fi
If the network this is to be installed on is available, this may be a more convenient method of configuration.
1. Connect the SGX 5150 to a PC with a Web Browser.
The following steps assume the SGX 5150 is new and has not been configured. (If the unit has been
configured a wireless network, please see Appendix A for instructions to reset the device.)
2. Power up the SGX 5150 with the AC adapter or a DC power source per the device instructions.
3. After a minute or two, check the Wi-Fi networks available on your computer. You will see a network titled
"sgx5150_SERIALNUMBER" where SERIALNUMBER is the serial number of the specific device you are
using. Press Connect.
(Figure 13)
4. In a browser such a Google Chrome or Microsoft Edge, type into the address bar: 192.168.0.1.
(Figure 14)
5. A requester pops up asking for a Username and Password. Enter the information as shown: (default
Username and Password from Lantronix)
(Figure 15)
Note - If there is no connectivity at this step, please check Appendix B.
6. Then press Sign In. This gives you full access to configure the SGX 5150 for your specific network.

Using the Lantronix SGX 5150 Serial Device Server
13
7. On the Quick Setup status page in your browser, set the following options:
▪DHCP Client OFF
▪Enter the desired IP address for the SGX 5150 (example indicated)
▪Enter the Default Gateway address (example indicated)
▪IPv6 State Disabled
▪IPv6 DHCP Client OFF
▪IPv6 Auto Configuration OFF
(Figure 16)
(Figure 17 - Near the bottom of the status page, the available networks are shown.)

Using the Lantronix SGX 5150 Serial Device Server
14
8. Click on the network of choice and then the page extends with connectivity options. Enter the Passphrase
and click on Submit.
(Figure 18)
9. Select the Network tab on the top menu, expand Wireless Network and Link on the left side menu and
select Configuration. In this window choose "Antenna 1" from the Antenna Diversity.
(Figure 19)
10. At the bottom of the SGX 5150 Wireless Network page, click the Submit button.
(Figure 20)

Using the Lantronix SGX 5150 Serial Device Server
15
11. Select the Administration tab on the top menu, expand Line and Line1 from the left side and select
Configuration. Here make sure that Protocol is set to “Tunnel” and the Baud Rate is set per the Baud
Rate Setting matrix below in Table 3.
(Figure 21)
Follow the matrix below for the proper setting for your system:
Datalogger
Baud Rate Setting
CR2xx
9600
CR300/CR800/CR1000/CR6/
MLGPS/TM50 & TM30 Robots
115200
SlideMinder
38400
(Table 3)
12. Press Submit at the bottom of the page.
(Figure 22)

Using the Lantronix SGX 5150 Serial Device Server
16
13. Now reboot the device by going to the Status tab on the top menu and click on the Reboot button outlined
in Figure 22.
(Figure 23)
Wait 2 or 3 minutes for the device to reboot and access your chosen wireless network at the new IP address.
Note - Most likely you will have to reconnect to your PC to the chosen network to connect to the SX 5150.

Using the Lantronix SGX 5150 Serial Device Server
17
Appendix E –GUI Based Configuration via Ethernet
When reset, the SGX 5150 randomly assigns a random IP address for the Ethernet port 169.254.xxx.xxx
where x = random number (subnet mask is /16 or 255.255.0.0). The best way to find this random address is to
use Device Installer - a free program from Lantronix. This program is available at
www.lantronix.com/support/downloads
1. Connect the Ethernet port of the SGX 5150 to a network adapter to a local PC. Make sure the adapter is
set to DHCP (see Appendix B).
2. Once the software is installed, run Device Installer.
3. Click on Options.
(Figure 24)
4. Select the correct network adapter (example shown in Figure 24).
(Figure 25)
5. Click on Search.
(Figure 26)
6. The randomly generated IP address appears as indicated below.
(Figure 27)
7. Type the IP address you see into a browser (as shown in Appendix D –Step 4) and follow the Appendix D
steps thereafter.

Using the Lantronix SGX 5150 Serial Device Server
18
Appendix F –Switched Power Control for Campbell Dataloggers
Campbell Scientific dataloggers include programmable power outputs, such as Switch 12 (SW12), which can
be used to control power to connected devices, such as the Lantronix SGX 5150.
(Figure 28)
SW12 provides a programmable output of 12 volts to the connected device and by doing so, the following can
be achieved:
•Power cycle the connected device, allowing a reconnection to the local Wi-Fi network.
•Reducing the power consumption of an entire unit by turning power on at specified times rather than
being continuously powered.
To use switch power control, the datalogger program must be updated and the device’s power inputs must be
rewired to connect to SW12 instead of the charge regulator.
Note − Devices that requires more than 1 amp of power cannot be powered through SW12. If a device
requires more than 1 amp of power,contact Canary Systems.

Using the Lantronix SGX 5150 Serial Device Server
19
SW12 Program Changes
The datalogger requires programming changes to activate SW12 as a power output. These changes can be
made through MultiLoggerand MLWebHardware.
MLWebHardware Configuration
The following section explains how to update the datalogger program using MLWebHardware.
1. Navigate to the dataloggers Program Configuration. Programming for SW12 is done on the Configuration
Card. See the MLWebHardware Users Guide for details on navigation MLWebHardware and configuring
new dataloggers.
(Figure 29)
2. Select Port Set as the Code Insert.
3. Select the Power Port, either SW12-1 or SW12-2, depending on which port the connected device is wired
into.
4. Using the other fields on this card, select at which point in the program power will be turned on, for how
long, and with what delay.
(Figure 30)
5. Save the Program Configuration once the desired functionality is selected and return to the Device
Configuration form.
6. To push the updated program to the datalogger, first verify the program, then Update .

Using the Lantronix SGX 5150 Serial Device Server
20
MultiLogger Configuration
The following section shows how to configure SW12 Power Control via MultiLogger.
1. Open the logger form for the datalogger and navigate to the Program tab.
2. SW12 power configuration is enabled by selecting an Output Device from the drop-down menu, highlighted
in the figure below.
a. For a CR300 select “Turn On Cell Modem”
(Figure 31)
