Owner’s Manual

Congratulations on your purchase of a Lanzar Vibe amplifier. You have purchased a quality product designed and engineered to
give you many years of uncompromised musical service. Vibe amplifiers are designed with the latest technology available,
incorporating a DC to DC Switching Power Supply, which provides headroom for even the most demanding peaks and dynamic
ranges found on modem CD’s and recordings.
TABLE OF CONTENTS
i Table of Contents
Features and Controls
1 vibe 211/221/231/241/251/261
2 vibe 411/421/431
3 vibe 531
4 Specifications
6 Installation
System Wiring
7 2 channel stereo
8 2 channel bridged mode
9 2 channel tri-mode
10 2 channel triamp system
11 4 channel stereo
12 4 channel bridged mode
13 4 channel tri-mode
14 5 channel stereo
15 5 channel bridged mode
i6 5 channel tri-mode
17 Troubleshooting
FEATURES
• MOSFET switches maintain rated power over a wide range of battery voltages
• Stiffly regulated PWM-type power supplies
• 2 Ohm Stable Stereo operation
• Variable input level controls for each pair of channels
• Variable high and low pass crossover controls
• Thermal and speaker short protection circuitry
• Power and Protection LED indicators
• Bass Boost Circuitry
« Stereo, Bridge Mode and Tri-Mode System Application Compatible
• Gold plated power, RCA and speaker connectors
• High-efficiency, heavy aluminum heatsink
• Bass Boost Remote control

Features and Controls
VIBE 211 / 221 / 231 / 241 / 251/261
Input Level Controls
Enables the matching of input levels to the
output levels from the head unit (or other
signal source).
High Pass Filter
When Crossover Mode Selector is in High Pass Mode,
this control limits the frequencies which will be
distributed to the speakers to those above the value to
which this is set within the range 40HZ-3 kHz.
Crossover Mode Selector -
Determines the mode of built-in crossover:
low pass (permits only low frequency signals to
pass to speakers), high pass (permits only high
frequency signals to pass to speakers), or flat.
Power & Protection Indicators
Provide instant information on status of amplifier,
including short-circuit and thermal overload alerts.
l R e m o te Control
Bass Boost Control
Increases sound level in lower frequencies toy i8dB.
■ Low Pass Filter
When Crossover Mode Selector is in Low Pass Mode,
this control limits the frequencies which will be
distributed to the speakers to those below the value
to which this is set within the range 40-350 Hz.
X
cimar VlBE OWNER'S MANUAL - I

Features and Controls
vibe 411 / 421/431
Input Level Controls-'
Enables the matching of input levels to the
output levels from the head unit (or other
signal source).
Bass Boost Control -
Increases sound level in lower frequencies by i8dB.
Power & Protection Indicators
Provide instant information on status of amplifier,
including short-circuit and thermal overload alerts.
Remote Control
Crossover Mode Selectors-
Determine the mode of built-in crossovers:
low pass (permits only low frequency signals to pass
to speakers), high pass (permits only high frequency
signals to pass to speakers), or flat.
Low Pass Filter -
When Crossover Mode Selector is in Low Pass Mode,
this control limits the frequencies which will be
distributed to the speakers to those below the value
to which this is set within the range 40-350 Hz.
High Pass Filter
When Crossover Mode Selector is in High Pass Mode,
this control limits the frequencies which will be
distributed to the speakers to those above the value to
which this is set within the range 40Hz~3kHz.
- JL
Vibe Owner’s Manual

Features and Controls
vise 531
.9TTT Low Input
CHANNEL 1 -f 2
Level Mode ^*9*?
© m ©
( \ | k
Hln Mm Hkjl^
^ Q PWH
Q WOT
A
Input Level Controls-
(all channels)
Enables the matching of input levels
to the output levels from the head unit
(or other signal source)
Power/Protection Indicators
Provide amp power status and short-circuit
and thermal overload alerts. /
Crossover Mode Selectors '
(all channels)
Determine the mode of built-in crossovers:
low pass (permits only low frequency signals to
pass to speakers), high pass (permits only high
frequency signals to pass to speakers), or flat.
High Pass Filters-
When Crossover Mode Selector is in High Pass
Mode, these controls limit the frequencies which
will be distributed to the speakers to those above
the values to which these are set.
Low Input
CHANNEL 3+4
Mode High ^ Boost ££
Mode Level
Min Mum Ok Ott
ft- © ^
mm
Ch4 L -
500
High _ Band _ Low
Pass Pass Pass
± ±
Low Input
Remote Control
Low Pass Filter
When Crossover Mode Selector is in Low Pass
Mode, this control limits the frequencies which
will be distributed to the speakers to those below
the value to which this is set.
4/6 Ch Input Mode Selector
Determines internal circuit routing depending
on whether or not a discrete Channel 5/6 input
signal is available from head unit.
Bass Boost Control
(Channel 5/6 only)
Increases sound level in lower frequencies by i8dB.
Band Pass Crossover Controls
(Channel 3/4 only)
When Ch 3/4 Crossover Mode Switch is in
Band Pass position, these two controls are used
to establish the upper and lower frequency range
limits for the signals which will be distributed
to the Ch 3/4 speakers.
X
anzar Vibe Owner’s Manual - 3

Speci fications
MODEL
vibe 2 ii amp h E el
vibe221 a 2 mp h ffi el Vibe 231 amplifier 6 * Vibe 241 amplifier 6 '
RMS at 4 Ohms
2X90W 2 x 150W 2 X 200 W 2 X 250 W
MAX at 4 Ohms
2 X IgoW 2 x 300W 2X40OW 2 X 500 W
At 4 Ohms Bridged
1X360W 1 x 600W IX800W 1 x 1000W
RMS at 2 Ohms
2XI50W 2 x 250W 2X350W
2X420W
Min. Speaker Impedance
2 Ohm 2 Ohm 2 Ohm 2 Ohm
T.H.D
0.04%
0.04%
<9.04%
0.04%
Frequency Response
i5Hz-35kHz, - ldB 15HZ-35ICHZ, - ldB i5Hz-35kHz, - ldB i5Hz-35kHz, - ldB
Input Sensitivity
ioomV-40oomV ioomV-40oomV ioomV-40oomV ioomV-40oomV
Input Impedance
22 kOhm 22 kOhm 22 kOhm 22 kOhm
S/N Ratio
> 90 dB >90dB >90dB
Channel Separation
>65dB
>65dB
>65dB
>65dB
Crossover Filters
Low Pass
High Pass
Bandpass
4oHz-350kHz
40HZ-3 kHz
n/a
40Hz-350kHz
40HZ-3 kHz
n/a
40Hz~350kHz
40HZ-3 kHz
m/a
40Hz~350kHz
40HZ-3 kHz
n/a
Bass Boost
+i8dB +i8dB +i8dB +i8dB
Dimensions (Inches)
10.25 x 2 x 8 (WxHxL) 10.25 x 2 x 10 (WxHxL) 10.25 x 2 x 12 (WxHxL) 10.25 x 2 x 15 (WxHxL)
Fuse(s)
15A
20A 25A 15AX2
4 - cManzar Vibe Owner’s Manual

vibe25 1ampufier 61 vibe26 1 fnfpE 61 \dbe411 ? m c p h i!fi n e n r el vibe42i? m c p h S el vibe43i? m c p h E el vibe53i a 5 m c P h E el
2X400W 2 x 600W
4 X 75 W
4 x 125W 4 x 150W 4 x 100W +1 x 200W
2X800W
2 X1200W
4 x 150W 4 x 250W 4X300W 4 x 200W +1 x 400W
1 x 1600W 1 x 2400W 2X300W 2 x 500W 2x6ooW 2 x 400W +1 x 600W
2X650W
2 x 1000W
4 x 125W 4 x 200W 4 x 250W
4X175W+IX375W
2 Ohm
2 Ohm 2 Ohm 2 Ohm 2 Ohm 2 Ohm
0.04% 0.04% 0.04% 0.04% 0.04% 0.04%
i5Hz~35kHz, - ldB i5Hz-35kHz, - ldB
! 5 Hz- 35 kHz, - ldB
i5Hz~35kHz, - ldB *5Hz-35kHz, - ldB
15I Iz~35kHz, -ldB
ioomV-40oomV ioomV-40oomV
lOOmV -4000111V
ioomV-40oomV
lOOmV ~ 4 O 00 mV
ioomV-40oomV
22 kOhm 22 kOhm
22 kOhm
22 kOhm
22 kOhm
22 kOhm
>90dB
>9odB > 90 dB > 90 dB > 90 dB > 90 dB
>6gdB >65dB >65dB >65dB >&5dB
>65dB
4oHz-35okHz
8oHz-2.5okHz
n/a
40Hz-350kHz
40HZ-3 kHz
n/a
4oHz-35okHz
4oHz-3kHz
n/a
40Hz-350kHz
4oHz-3kHz
n/a
40Hz-350kHz
4oHz-3kHz
n/a
40HZ-500HZ
40Hz-4kHz
variable, 40Hz-4kHz(HPF)
40HZ-500H4LPF)
+i8dB +i8dB +i8dB +i8dB +i8dB +12dB
10.25 x 2 x 19 (WxHxL) 10.25 x 2 x 21 (WxHxL) 10.25 x 2 x 12 (WxHxL) 10.25 x 2 x 14 (WxHxL) 10.25 x 2 x 17 (WxHxL) 10.25 X 2 x 24 (WxHxL)
25AX2 40Ax2 15AX2 20Ax 2 25 Ax 2 30Ax 2
oCanzar Vibe Owner’s Manual - 5

I NSTALLATION
1. Find a suitable location in the vehicle to mount the amplifier.
2. Make sure there is sufficient air flow around the intended mounting location.
3. Bolt the amplifier to the mounting surface.
4. Connect the power ground terminal to the nearest point on the chassis of the car. Keep
this ground wire less than one meter (39") in length. Use 8 gauge wire.
5. Connect the remote terminal to the remote output of the head unit using 14 gauge wire.
6. Connect an empty fuse holder within 300 mm (12") of the battery and run 8 gauge or
larger high quality cable from this fuse to the amplifier location.
7. Make sure there is no fuse in this fuse holder. Then make the connection to the "BATT"
connection on the amplifier.
8. If multiple amplifiers are being used, use cables (each with its own fuse at the battery)
or a #0 or #2 cable from the fuse holder at the battery to a distribution block at or near
the amplifier's location.
9. Connect all line inputs and outputs using high-quality RCA-RCA cables.
10. Insert fuse(s) at the battery fuse holder(s).
11. Recheck all connections before powering up.
12. Set all level controls to their least sensitive positions and set all crossover controls,
switches, etc. to the desired frequency or position.
13. Once the system is powered up, set the volume control on the head unit to about the
2 o'clock position, and then set all the amplifiers' level controls for maximum output level.
14. Further fine tuning of the various controls may be necessary to obtain the desired results.
PRECAUTIONS
• Before you drill or cut any holes, investigate your
car’s layout veiy carefully. Take care when you work
near the gas tank, fuel lines, hydraulic lines and
electrical wiring.
• Do not operate the amplifier when it is unmounted.
Attach all audio system components securely within
the automobile to prevent damage, especially in an
accident.
• Do not mount this amplifier so that the wire
connections are unprotected or in a pinched
condition, or likely to be damaged by nearby objects.
Be sure to select a location inside your vehicle which
has adequate ventilation.
• Before making or breaking power connections in
your system, disconnect the vehicle battery. Confirm
that your head unit or other equipment is turned
off while connecting the input jacks and speaker
terminals.
• If you need to replace the power fuse, only replace
it with a fuse identical to that supplied with the
system. Using a fuse of a different ty pe or rating
may result in damage to your system which isn’t
covered by the manufacturer’s warranty.
- JL
Vibe Owner's Manual

vibe2ll/221/231/241/251/261
_ System Wiring
2 CHANNEL STEREO CONFIGURATION
FRONT
REAR
to REMOTE OUTPUT
FROM HEAD UNIT
~ LEFT RIGHT +
SPEAKER SPEAKER
Speaker Impedance
2*4 OHM
anzar VlBE OWNER'S MANUAL - 7

System Wiring _
2 CHANNEL BRIDGED MODE CONFIGURATION
vibe2ii/22i/23i/24i/251/261
]
FRONT
Xu
Vibe Owner’s Manual

to REMOTE OUTPUT
from HEAD UNIT
SUBWOOFER J an2a , v, B E Owne r’s Manual - 9

System Wiring _
TRIAMP SYSTEM USING THREE 2 CHANNEL AMPLIFIERS vibe21l/22l/23l/24l/25l/26l
Master Amp Front (Woofers) Master Amp Rear
- oCanzar Vibe Owner's Manual
10

vibe4ii /421/431
_ System Wiring
4 CHANNEL STEREO CONFIGURATION
to REMOTE SUBWOOFER
LEVEL CONTROL
Y ADAPTOR
Y ADAPTOR
TO OUTPUT FROM HEAD UNIT
FRONT
11

vibe4ii /421/431
_ System Wiring
4 CHANNEL TRI-MODE CONFIGURATION
to REMOTE OUTPUT
FROM HEAD UNIT

System Wiring _
5 CHANNEL STEREO CONFIGURATION vibe 531

vibe53i
_ System Wiring
5 CHANNEL BRIDGED MODE CONFIGURATION
IS

System Wiring _
5 CHANNEL TRI-MODE CONFIGURATION
vibe 53 i
16 -
FRONT

Troubleshooting
Amplifier will not power up.
• Check for good ground connection.
• Check that remote DC terminal has at least 3v DC.
• Check that there is battery power on the + terminal.
• Check all fuses.
• Check that Protection LED is not lit. If it is lit, shut off amplifier briefly and then repower it.
High hiss or engine noise (alternator whine) in speakers.
• Disconnect all RCA inputs to the amplifier(s) - if hiss/noise disappears, then plug in the component
driving the amplifier and unplug its inputs. If hiss/noise disappears, go on until the faulty/noisy
component is found.
• It is best to set the amplifier's input level as low as possible. The best subjective S/N ratio
is obtainable this way. Try to drive as high a signal level from the head unit as possible.
Protection LED comes on when the amplifier is powered up.
• Check for shorts on speaker leads.
• Check that the volume control on the head unit is turned down low.
• Remove speaker leads, and reset the amplifier. If the Protection LED still comes
on, then the amplifier is faulty.
Amplifier(s) gets very hot.
• Check that the minimum speaker impedance for that model is correct.
• Check for speaker shorts.
• Check that there is good airflow around the amplifier. In some
applications, an external cooling fan may be required.
Distorted sound
• Check that the Level controls) is set to match the signal level of the
head unit.
• Check that all crossover frequencies have been properly set.
• Check for shorts on the speaker leads.
High squeal noise from speakers.
• This is almost always caused by a poorly-grounded RCA patch cord.
dCanzar VlBE Owner’s MANUAL • 17

mzttir
Lanzar Audio Inc.
1600 63rd Street, Brooklyn, NY 11204
[phone]
www.lanzar.com
PRINTED IN KOREA
