Lanzar LQ24CAP Original operating instructions

WIRING DIAGRAM
Lanzar 2.4 Farad
Power Capacitor
(Supplied)
Power Source(Battery)
2.4 FARAD DIGITAL POWER CAPACITOR WITH INSTALL KIT
1. Disconnect vehicle's battery.
2. Select mounting location for capacitor
3. Select a convenient location for installation of the distribution block.
4. Cut power and ground wires to existing amp or route wires to block for a new install.
5. Connect the wires so they continue through the distribution block on to the amp.
6. Connect ring terminals on power and ground wires to capacitor and route wires to
distribution block.
7. Cut wires to length and make connection.
8. Reconnect battery and enjoy a better sounding ystem!
QUICK & EASY INSTALLATION
Power to Amplifier
Your Amplifier
www.lanzar.com
FARADFARAD
PowerPower
2.4
2.4 LQ24CAP
High Performance
Car Audio Accessory
High Performance
Car Audio Accessory
4ft of 4 ga Power &
Ground Wire (Supplied)
0/4 ga Main Power & Ground wire
Distribution Block(Supplied)
