Larson Electronics SPLED-STL-600W-12V-M1 User manual

SPLED-STL-600W-12V-M1
600W Solar LED Street Light
100W Solar Panel, 45000 lms Dimmable - Pole Mount/IP67
Instruction Manual
IMPORTANT
READ CAREFULLY BEFORE INSTALLING THIS FIXTURE. SAVE THESE INSTRUCTIONS FOR FUTURE
REFERENCE. THE SPLED-STL-600W-12V-M1 MUST BE WIRED IN ACCORDANCE WITH NATIONAL
ELECTRICAL CODE AND ALL APPLICABLE LOCAL CODES. PROPER GROUNDING IS REQUIRED FOR SAFETY.
WE STRONGLY ENCOURAGE ONLY A LICENSED ELECTRICIAN INSTALL, OPERATE AND MAINTAIN
THIS PRODUCT. IF YOU ARE NOT QUALIFIED OR UNFAMILIAR WITH ANY ASPECT OF THIS INSTRUCTION
SHEET, CONSULT AN ELECTRICIAN. THERE ARE NO SERVICEABLE PARTS INSIDE.
WARNING: MAKE SURE POWER ISTURNED OFF BEFORE STARTING
THE INSTALLATION OR PERFORMING ANY MAINTENANCE.
RISK OF FIRE/ELECTRIC SHOCK –DISCONNECT POWER AT BREAKER BEFORE INSTALLING OR SERVICING.
RISK OF PERSONAL INJURY –FIXTURE MAY BECOME UNSTABLE OR DAMAGED IF NOTINSTALLED
PROPERLY. RISK OF BURN –ALLOW FIXTURE TO COOL BEFORE SERVICING.
The SPLED-STL-600W-12V-M1 from Larson Electronics is a Solar LED Street Light for sustainable, outdoor illumination.
Equipped with a wireless remote, this eco-friendly solar street light can operate for 3 days without sunlight on a full battery
charge. The IP67-rated dimmable unit is compatible with pole-mounting installations.
Parts
Installation
The SPLED-STL-600W-12V-M1 is compatible with pole mounting installations. For best results, install at a height of
13`-26`.
Larson Electronics, LLC Phone: [phone] Fax: [phone] www.larsonelectronics.com 1of 2
Pole Mount:
Wall Mount:

SPLED-STL-600W-12V-M1
Larson Electronics, LLC Phone: [phone] Fax: [phone] www.larsonelectronics.com 2of 2
For best results, ensure solar panel is free of overhead obstructions, and positioned so that it will receive the most
amount of sunlight possible. We recommend setting the panel at a 45 degree angle using the adjustable bracket, and
facing it towards the area in the sky where the sun is during peak daytime hours.
Remote









 

 .
4 1% 

MAINTENANCE
There are no serviceable parts inside the fixture. However, it is good practice to routinely clean and check the
fixture for proper function.
•Disconnect power running to the lamp and panel and be sure the fixture iscool to the touch.
•Use a non-abrasive glass cleaning solution to clean the lens or solar panel if they should become dirty.
Note: It is not necessary to open the fixture and clean or touch the LED’s.
USE AND CARE
Unauthorized modification may impair the function and/or safety of this device and could affect the life of the equipment.
Always check for damaged or worn out parts before using the device. Store it in a secure place out of the reach of
children when not in use.Inspect for good working condition prior to storage and before re-use.
REPLACEMENT PARTS
The SPLED-STL-600W-12V-M1 is designed to provide years of reliable performance. Should the need for replacement
parts arise, please contact Larson Electronics.
THESE INSTRUCTIONS MAY NOT COVER ALL DETAILS OR VARIATIONS OF THIS PRODUCT FOR YOUR EQUIPMENT OR INSTALLATION REQUIREMENTS.
SHOULD FURTHER INFORMATION NOT COVERED BY THESE INSTRUCTIONS BE REQUIRED, PLEASE CONTACT LARSON ELECTRONICS BY EMAIL AT
SAL[email protected] OR BY PHONE AT 1-877-348-9680 FOR FURTHER ASSISTANCE.
PLEASE VISIT LARSONELECTRONICS.COM FOR WARRANTY AND RETURN INFORMATION.
