Larson Electronics VPLHL-7WLED-PC-GR50 User manual

VPLHL-7WLED-PC-GR50
Larson Electronics, LLC Phone: [phone] Fax: [phone] www.larsonelectronics.com
1of 2
10W Vapor Proof (Waterproof) LED Hand Lamp w/Cord Reel
Lexan Globe
Instruction Manual
Do not attempt operation until you are familiar with all warnings, precautions, and procedures outlined within this
instruction sheet. Read carefully before operating. Retain these instructions for future reference.
WARNING:
USER SHOULD BE TRAINED IN THE PROPER USE AND MAINTENANCE OF THIS DEVICE.
PERIODIC INSPECTION OF THE HANDLAMP AND CORD IS NECESSARY.
IT IS RECOMMENDED THAT THE CORD BE ROUTINELY CHECKED FOR CUTS, BREAKS, OR ANY SEVERE ABRASIONS, AND IF ANY ARE
FOUND, THE CORD BE REPLACED BEFORE RESUMING USE OF THE HANDLAMP.
MOUNTING CORD REEL
1. Unpack and inspect reel for damage. Turn by hand to check for smooth
operation. Check for completeness.
2. Position reel on floor, wall, or ceiling. Secure into place, using four (customer
supplied) screws or bolts.
3. Attach power cord from reel to Voltage on Product Label compatible
receptacle.
WARNING: Check product label for correct voltage! Failure to comply could
result in damage to the fixture which may not be covered by warranty.
CAUTION: Unless the reel was specified differently when ordering, the maximum installation height is 16 feet. Do
not exceed this distance.
WARNING: Ensure that the power supply voltage does not exceed maximum voltage rating of reel. Observe applicable
NEC. OSHA, and local electrical codes.
WARNING: Pull electrical cord from reel by grasping the electrical cord itself, not the work device.
OPERATION
Reel hand lamp and position in desired location using stainless steel swivel hook. Grasp cord stop to begin reeling cord,
not hand lamp. The lamp will illuminate once power is supplied.
Do not exceed the voltage or ampere rating of the cable. Do not exceed the voltage or ampere rating of the reel.
Overheating, fire, damage to equipment or personal injury could result.
Do not allow cable to retract without restraining the retraction speed.
Operate the reel within the cable size and length and spring tensioning limits for which it was intended.
Two wraps of cable should remain on the reel at maximum extension to avoid excessive tension on the cable
entrance watertight.
The spring should not be wound to its last two turns at maximum payout to avoid over-stressing the spring, thus
reducing its life or damaging the reel.
Keep the reel and cable clean to avoid excessive wear and damage.
Arrange for maintenance service if damage is found on the cable or reel.
Cable should be fully retracted when not in service to maximize spring life.

VPLHL-7WLED-PC-GR50
Larson Electronics, LLC Phone: [phone] Fax: [phone] www.larsonelectronics.com
2of 2
LAMP REPLACEMENT
1. Loosen (4) set screws holding Globe Guard.
2. Remove Globe Guard assembly from handle.
3. Unscrew Globe from handle.
4. Replace with 10 watt LED compatible lamp.
5. Screw Globe completely onto lamp base.
6. Replace Globe Guard.
7. Tighten (4) set screws securely.
Note: Over tightening can deform threads.
USE AND CARE
Unauthorized modification may impair the function and/or safety of the work
light and could affect the life of the equipment. Always check damaged or worn
out parts before using the work light. When work light is not in use, store it in a
secure place out of the reach of children. Inspect for good working condition
prior to storage and before re-use.
REPLACEMENT PARTS
The VPLHL-7WLED-PC-GR50 is designed to provide years of reliable lighting performance. Should the need for
replacement parts arise, please contact Larson Electronics at the contact information below.
Should further information not covered by these instructions be required, please contact Larson Electronics at
1-800-369-6671 or [email protected] for further assistance.
Please visit LarsonElectronics.com for Warranty and Return information.
