KB-BT288 USER MANUAL
1
Please read carefully before use
TABLE OF CONTENTS
IMPORTANT SAFETY INSTRUCTIONS AND PRECAUTIONS...................................................................2
WHAT’S IN THE BOX..........................................................................................................................2
OVERVIEW.........................................................................................................................................2
PC, TABLET OR SMARTPHONE PAIRING..............................................................................................2
APPLE IPHONE/IPAD® PAIRING..........................................................................................................3
SONY PLAYSTATION 3® PAIRING........................................................................................................3
MAC INSTALLATION (OS X 10)............................................................................................................4
USING THE MULTIMEDIA KEYS...........................................................................................................5
USING THE TOUCHPAD......................................................................................................................6
USING THE FUNCTION KEYS...............................................................................................................7
SYSTEM REQUIREMENTS...................................................................................................................8
SPECIFICATIONS ................................................................................................................................ 8
TROUBLE SHOOTING / Q & A.............................................................................................................8

KB-BT288 USER MANUAL
2
IMPORTANT SAFETY INSTRUCTIONS AND PRECAUTIONS
- Please read these instructions carefully before use.
- Please retain this user manual for future reference.
- Use this product only in the manner described.
- Only use a water-dampened soft-cloth to clean the surface of this product.
- Only recommended batteries and accessories should be used with thisproduct.
- The following will damage this product: any liquid such as water or moisture, extreme heat; cold;
humidity, dusty or sandy environments.
- This product has re-moveable batteries, remove them before long periods of in-active use, to
prevent damage due to leakage. Always insert batteries according to the + and - signs and
replace the batteries with the same type at the same time.
- There are no user serviceable parts in this product.
- Unauthorized attempts to dismantleor repair this product will void product warranty
WHAT’S IN THE BOX
1 x Bluetooth keyboard with touch pad,1 x User Manual
OVERVIEW
Bluetooth technology range up to 10-15 meters
Compact size with built-in high sensitivity touch pad
Multimedia and Internet hot keys
Right and left click mouse buttons

KB-BT288 USER MANUAL
3
PC, TABLET OR SMARTPHONE PAIRING
Before installing this product, please make sure your PC or device supports Bluetooth, that the feature
is enabled or that the Bluetooth dongle has been installedcorrectly.
1) Insert the batteries intothe battery compartment noting the + and – orientation signs
2) Turn the uniton by sliding the power switch toON
3) Open the Bluetooth program of your PC or device Activate Bluetooth connectivity and begin the
“SEARCH NEW DEVICE” function; then
4) Press the CONNECT button at the back of the keyboard
5) After a short scanning period, your PC or Device will indicate that your BT288 keyboard has
been discovered and is ready for connection/pairing
6) Double click the Bluetooth keyboard icon.
7) If you are prompted to enter a pin-code, a random code will automatically be generated for
you (usually 8 numerical digits long) Enter this code as directed to complete the installation.
Note: If the above pairing process has failed, please ensure your Bluetooth receiver or software has
been installed correctly and then repeat the above steps.
APPLE IPHONE/IPAD® PAIRING
1) Insert batteries into the keyboard and switch the Keyboard ON
2) In the iPhone/iPad home screen, select settings，then general，then Bluetooth
3) Swipe the on/off switch to “on” The message “Now Discoverable” will appear
4) Press the CONNECT button on the back of keyboard, the keyboard LED light will flash
5) The BT288 should be identified by your iPhone/iPad. Select it to complete the pairing
Note: If you are prompted to enter a pin-code, a random code will automatically be generated for
you (usually 8 numerical digits long) Enter this code as directed to complete the installation.
SONY PLAYSTATION 3® PAIRING
1) Insert batteries into the keyboard and switch the Keyboard ON
2) In the PS3 menu，go to the settings section，select accessory settings，then go to Manage
Bluetooth Devices
3) Select REGISTER NEW DEVICE
4) Press the CONNECT button on the back of keyboard, the keyboard LED light will flash
5) Your PS3 will searchfor Bluetooth devices. When the BT288 has been identified, select“Bluetooth
keyboard"
6) If you are prompted to enter apin-code, a random code will automatically be generated for
you (usually 8 numerical digits long) Enter this code as directed to complete the installation.

KB-BT288 USER MANUAL
4
MAC INSTALLATION (OS X 10)
Go to System Preferences and click the Bluetooth icon
Click the “+” sign to add new BT keyboard (bottom left of screen)
The “Bluetooth Setup Assistant” program will then open. Make sure your KB288 is turned on, then
press the CONNECT button at the back of the keyboard. Once the keyboard is detected, it will appear
on the hardware list. Click the keyboard icon and then press “Continue”. If you areprompted to enter
a pin-code, a random code will automatically be generated for you (usually 8 numerical digits long).
An example only is providedbelow. This number is an example number only) Type the generated
digits in the required fields then click the Return button to finish the setup.
Note: All function keys may not be available when using your Mac OS

KB-BT288 USER MANUAL
5
USING THE MULTIMEDIA KEYS
Multimedia keys Multimedia Keys Description
Play/Pause
Switches between Play and Pause
of DVD/VCD/MP3/Audio device.
Once pause is pressed, pressing
this button again resumes play.
Mute Mute's the sound. Press it again to
turn the sound back on
V+ Increases the volume. Hold the button down to increase volume
quickly
V- Decreases the volume. Hold the button down to decrease volume
quickly

KB-BT288 USER MANUAL
6
USING THE TOUCHPAD FINGER GESTURES
Touchpad Function
Comparable Mouse
Function Finger Gesture Finger Action
Moving Moving Cursor Slide Finger
Click ( Tap) Left Button Click Tap 1 finger
Middle Button Click Middle Button Click Tap 2 fingers
Right Button Click Right Button Click Tap 3 Fingers
Double Click Double Click Double Tap 1 Finger
Drag Drag Tap and Drag
Vertical 2 Finger
Scroll Middle Button Vertical Scroll
Slide 2 fingers
vertically

KB-BT288 USER MANUAL
7
USING THE FUNCTION KEYS
Using a combination of theFn key (function) and Num Lock key (Number) set to either the
ON and/or OFF positions, keys which are otherwise absent from the keyboard can be
enabled eg. The HOME and END button can be enabled (as tabled below) in place of the
number 7location key by switching ON the Fn key and switching OFF the Num Lock key.
Note: the ON and OFF positions of the Fn and Num Lock keys are indicated by an illuminated
light on the keyboard
Fn and Num Lock key sequences
Key
Location Fn
Num
Lock Fn
Num
Lock Fn
Num
Lock Fn
Num
Lock
OFF
OFF
ON
OFF
OFF
ON
ON
ON
7
&7
Home
7
7
8
*8
↑
8
8
9
(9
Pg
Up
9
9
0 )0 * * 0
U
U
←
4
U
I
I
5
I
O
O
→
6
O
P
P
-
-
P
J J End 1 J
K
K
↓
2
K
L
L
Pg
Dn
3
L
:;
:;
+
+
:;
M
M
Ins
0
M
>.
>.
Del
.
>.
?/
?/
/
/
?/
Enter
Enter (L)
Enter(R)
Enter(R)
Enter(L)
F1/F11
F1
F11
F1
F11
F2/F12 F2 F12 F2 F12
F10/ Scr Lock F10 Scr Lock F10 Scr Lock
↑/Pg
Up
↑
Page Up
↑
Page Up
↓/Pg
Dn
↓
Page Down
↓
Page Down
←/Home
←
Home
←
Home
→/End
→
End
→
End

KB-BT288 USER MANUAL
8
SYSTEM REQUIREMENTS
Windows Vista, XP, 2000, Win7
Mac OS X 10
iPad 1 & Pad 2
iPhone 3X , 4X
PlayStation 3
Note: some keys might not function with the Mac OS
SPECIFICATIONS
Dimension: 280 (L) x 112 (W) x 17 (H) mm
Weight: 280g
Expected Battery life (using 2 Alkaline AAA type batteries): Up to 150 hours
Transmission Distance: 10-15 meters (line of sight)
TROUBLE SHOOTING / Q & A
Why do I only get a few hours battery life?
We recommend new Alkaline batteries for
this unit. Heavy duty and Super Heavy
duty batteries by there design, do not last
as long. Sliding the power switch to theoff
position will also help when not in use for
long periods.
I always find configuring Bluetooth
software to be very difficult. Do you have
any tips to make this easier?
For the first time user,
we recommend
that you read these instructions carefully
before connecting your first device.
Bluetooth technology is thepreferred
wireless technology, with the set up steps
simply repeated for any Bluetooth device.
For further productinformation and instruction please visit our product web
page at www.laserco.netor email [e-mail]
Please note: As continual improvements are made to this product, slight operational differences may
occur. For the most up-to-date user manual, please visit our web site.

KB-BT288 USER MANUAL
9
Warranty Against Defects
Laser Corporation Pty Ltd (“Laser”) warrants your new product to be free from defects in
materials and workmanship for 12 months, from the date of purchase, provided that the
product is used in accordance with accompanying recommendations or instructions where
provided. The benefit of this warranty is in addition to your rights under the Australian
Consumer Law and to other rights and remedies of the consumer under a law in relation to
the goods or services to which the warranty relates.
Through a network of retailers and resellers, Laser will provide you with your choice of a
refund, repair or exchange (where possible) for this product if it becomes defective within the
warranty period. This warranty will no longer apply where the defect is a result of alteration,
accident, misuse, abuse, normal wear and tear, neglect or improper storage.
Please retain your receipt as proof of purchase
How to make a product warranty claim:
Step 1: Find your receipt which proves the date of purchase. Where the date of purchase
cannot be verified, your place of purchase or Laser will make an assessment based on the
date of manufacture, the condition of the Laser Product and the type of defect.
Step 2a): Contact your place of purchase. They will assess the nature of the fault and
refund or replace the product as per their store refund or warranty policy.
Step 2b): If your place of purchase cannot be contacted, then you can contact Laser .
Customer Service with details of your defective Laser Product: Phone: [phone]; or
Email: [e-mail] or online www.laserco.net/support/warranty (click on
“Consumers (End Users)”). Our business address is at 1/6-8 Byfield Street, North Ryde,
NSW 2113
Step 3: Laser . will issue you with a Return Authorisation (RA) number within 48 hours.
When requested, send us the defective Product and a copy of your receipt. Laser will cover
the cost of the return delivery.
Step 4: Wait for us to contact you. Once we have received your defective Laser Product for
inspection, we will inform you of our assessment of your claim within 7 days. When we
contact you, we will firstly let you know whether you have a valid claim under this Warranty,
and if so, we will inform you whether your defective Laser Product will be replaced or
repaired, together with the number of days you can expect to wait to receive your replaced or
repaired Laser Product.
Our goods come with guarantees that cannot be excluded under the Australian Consumer
Law. You are entitled to a replacement or refund for a major failure and compensation for
any other reasonably foreseeable loss or damage. You are also entitled to have the goods
repaired or replaced if the goods fail to be of acceptable quality and the failure does not
amount to a major failure.
