Laser KB-BT500 User manual

KB-BT500
1
QUICK START GUIDE
Please read carefully before use
TABLE OF CONTENTS
IMPORTANT SAFETY INSTRUCTIONS AND PRECAUTIONS ................................................................... 2
WHAT’S IN THE BOX .......................................................................................................................... 2
OVERVIEW.........................................................................................................................................
............................................................................................................................
2
2
KEYBOARD MED
INDICATOR LIGHTS
IA KEYS .................................................................................................................... 3
SHORTCUT COMBINATION KEYS ........................................................................................................ 3
PC, TABLET OR SMARTPHONE PAIRING.............................................................................................. 4
APPLE IPHONE/IPAD® PAIRING.......................................................................................................... 4
SONY PLAYSTATION 3® PAIRING ........................................................................................................ 4
MAC INSTALLATION (OS X 10)............................................................................................................ 5
SYSTEM REQUIREMENTS ................................................................................................................... 6
SPECIFICATIONS ................................................................................................................................ 6
TROUBLE SHOOTING / Q & A ............................................................................................................. 6

KB-BT500
2
QUICK START GUIDE
IMPORTANT SAFETY INSTRUCTIONS AND PRECAUTIONS
- Please read these instruc ons carefully before use.
- Please retain this user manual for future reference.
- Use this product only in the manner described.
- Only use a water-dampened so -cloth to clean the surface of this product.
- The following will damage this product: any liquid such as water or moisture, extreme heat; cold;
humidity, dusty or sandy environments.
- There are no user serviceable parts in this product.
- Unauthorized a empts to dismantle or repair this product will void product warranty
WHAT’S IN THE BOX
1 x Bluetooth keyboard, 1 x User Manual
OVERVIEW
Bluetooth technology range up to 10-15 meters
Fold up stand and protec ve case
Mul media and Internet hot keys (via key combina on)
INDICATOR LIGHTS
This unit is equipped with three indicator lights;
Capital Le ers: Signifies when Caps Lock is engaged
Charging: Blinks yellow for low power, solid red for charging and green for fully charged.
Bluetooth: Con nuous blink while in pairing mode un l pairing has been completed.

KB-BT500
3
QUICK START GUIDE
KEYBOARD MEDIA KEYS
To access Media Keys, first you need to set up your keyboard to suit your device;
Note: Some keys may not function with your Apple iOS device.
For Android Devices Press Fn + “Q”
For Windows Devices Press Fn + “W”
For Apple iOS Devices Press Fn + “E”
Home
Back
Search
Select all
Copy
Paste
Cut Play/Puse
Volume Down
Volume Up
Music Backward Music Forward
SUITS OPERATING SYSTEMS
Mute
Touch Screen Keyboard
Key Funcon Android Windows IOS
Control + Space Bar Change Language Y - -
Windows Key + Space Bar Change Language - Y Y
Control + C Copy Y Y -
Control + V Paste Y Y -
Control + X Cut Y Y -
Control + Z Undo Y Y -
Control + "UP Arrow" Goto Top of Text Y Y -
Control + "DOWN Arrow" Goto Boom of Text Y Y -
Control + Delete Delete whole Line Y Y -
Shi+ "RIGHT Arrow" Select Text to the Right Y Y Y
Shi+ "LEFT Arrow" Select Text to the LeY Y Y
Shi+ "UP Arrow" Select Text Upwards Y Y Y
Shi+ "DOWN Arrow" Select Text Downwards Y Y Y

QUICK START GUIDE KB-BT500
4
PC, TABLET OR SMARTPHONE PAIRING
Before installing this product, please make sure your PC or device supports Bluetooth, that the feature
is enabled or that the Bluetooth dongle has been installed correctly.
1) Turn the unit on by sliding the power switch to ON
2) Open the Bluetooth program of your PC or device and acvate Bluetooth connecvity. Then
begin the “SEARCH NEW DEVICE” funcon.
3) Press the CONNECT buon at the f of the keyboard
4) Aer a short scanning period, your PC or Device will indicate that your BT500 keyboard has
been discovered and is ready for connecon/pairing
5) Double click the icon for the Bluetooth keyboard.
6) If you are prompted to enter a pin-code, a random code will automacally be generated for
you (usually 8 numerical digits long) Enter this code as directed to complete the installaon.
Note: If the above pairing process has failed, please ensure your Bluetooth receiver or soware has
been installed correctly and then repeat the above steps.
APPLE IPHONE/IPAD® PAIRING
1) In the iPhone/iPad home screen, select sengs,then general,then Bluetooth
2) Swipe the on/offswitch to “on” The message “Now Discoverable” will appear
3) Press the CONNECT buon on the front of keyboard, the keyboard LED light will flash
4) The BT500 should be idenfied by your iPhone/iPad. Select it to complete the pairing
Note: If you are prompted to enter a pin-code, a random code will automacally be generated for you
(usually 8 numerical digits long) Enter this code as directed to complete the installaon.
SONY PLAYSTATION 3® PAIRING
1) Turn the unit on by sliding the power switch to ON
2) In the PS3 menu,go to the sengs secon,select accessory sengs,then go to
Manage Bluetooth Devices
3) Select REGISTER NEW DEVICE
4) Press the CONNECT buon on the front of keyboard, the keyboard LED light will flash
5) Your PS3 will search for Bluetooth devices. When the BT500 has been idenfied, select
“Bluetooth keyboard"
Note: If you are prompted to enter a pin-code, a random code will automacally be generated for you
(usually 8 numerical digits long) Enter this code as directed to complete the installaon.

QUICK START GUIDE KB-BT500
5
MAC INSTALLATION (OS X 10)
Go to System Preferences and click the Bluetooth icon
Click the “+” sign to add new BT keyboard (boom leof screen)
The “Bluetooth Setup Assistant” program will then open. Make sure your KB500 is turned on, then
press the CONNECT buon at the front of the keyboard. Once the keyboard is detected, it will appear
on the hardware list. Click the keyboard icon and then press “Connue”. If you are prompted to enter
a pin-code, a random code will automacally be generated for you (usually 8 numerical digits long).
An example only is provided below. This number is an example number only) Type the generated
digits in the required fields then click the Return buon to finish the setup.
Note: All funcon keys may not be available when using your Mac OS

QUICK START GUIDE KB-BT500
6
SYSTEM REQUIREMENTS
Windows Vista, XP, 2000, Win7
Mac OS X 10
iPad 1 & Pad 2
iPhone 3
iPad air &iPadmini
,4 and 4S
SPECIFICATIONS
Expected Baery: Up to 120 hours
Transmission Distance: 10-15 meters (line of sight)
Bluetooth Specificaon:Version 3.0
Operaon Current:<5mA
Standby Current: 1.2mA
Baery Type: Lithium
Charging period:Up to 4hours (For the first me, please charge for 12 hours)
TROUBLE SHOOTING / Q & A
Why do I only get a few hours baery life?
Try sliding the power switch to the off
posion when not in use.
I always find configuring Bluetooth
soware to be very difficult. Do you have
any ps to make this easier?
For the first me user, we recommend
that you read these instrucons carefully
before connecng your first device.
Bluetooth technology is the preferred
wireless technology, with the set up steps
simply repeated for any Bluetooth device.
For further product informaon and instrucon please visit our product web
page at www.laserco.net or email supp[email protected].au
Please note: As connual improvements are made to this product, slight operaonal differences may
occur. For the most up-to-date user manual, please visit our web site.

QUICK START GUIDE KB-BT500
7
Warranty Against Defects
Laser Corporation Pty Ltd (“Laser”) warrants your new product to be free from defects in materials
and workmanship for 12 months, from the date of purchase, provided that the product is used in
accordance with accompanying recommendations or instructions where provided. The benefit of this
warranty is in addition to your rights under the Australian Consumer Law and to other rights and
remedies of the consumer under a law in relation to the goods or services to which the warranty
relates.
Through a network of retailers and resellers, Laser will provide you with your choice of a refund, repair
or exchange (where possible) for this product if it becomes defective within the warranty period. This
warranty will no longer apply where the defect is a result of alteration, accident, misuse, abuse,
normal wear and tear, neglect or improper storage.
Please retain your receipt as proof of purchase
How to make a product warranty claim:
Step 1: Find your receipt which proves the date of purchase. Where the date of purchase cannot be
verified, your place of purchase or Laser will make an assessment based on the date of manufacture,
the condition of the Laser Product and the type of defect.
Step 2a): Contact your place of purchase. They will assess the nature of the fault and refund or
replace the product as per their store refund or warranty policy.
Step 2b): If your place of purchase cannot be contacted, then you can contact Laser . Customer
Service with details of your defective Laser Product: Phone: (02) 9870 3355; or Email:
service@laserco.com.au or online www.laserco.net/support/warranty (click on “Consumers (End
Users)”). Our business address is at 1/6-8 Byfield Street, North Ryde, NSW 2113
Step 3: Laser . will issue you with a Return Authorisation (RA) number within 48 hours. When
requested, send us the defective Product and a copy of your receipt. Laser will cover the cost of the
return delivery.
Step 4: Wait for us to contact you. Once we have received your defective Laser Product for
inspection, we will inform you of our assessment of your claim within 7 days. When we contact you,
we will firstly let you know whether you have a valid claim under this Warranty, and if so, we will
inform you whether your defective Laser Product will be replaced or repaired, together with the
number of days you can expect to wait to receive your replaced or repaired Laser Product.
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You
are entitled to a replacement or refund for a major failure and compensation for any other reasonably
foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the
goods fail to be of acceptable quality and the failure does not amount to a major failure.
