Laser NRGVAULT PV1500 User manual

PWR-PV1500-PS
User Manual

INTRODUCTION
This product is a portable energy storage power generator. It
can be used as a power source for emergency relief, outdoor
camping, oce equipment, entertainment and much more.
It is compact enough for portability but capable enough to
power small to large appliances.
MAINTENANCE
• Clean with a soft dry cloth only. DO NOT use any water
or liquids as this could lead to damage of internal
components and electric shock.
• When not using the unit for extended periods, disconnect
from the power outlet and any connected devices, then
power o the unit.
• Charge the unit to approx. 80% battery every 3 – 6
months during extended periods of storage.
• Indoor storage only.
• Recommended storage temperature: 0 - 25°C.

GENERAL SAFETY
The NRGVault range of portable power stations has been made to the
highest standards for safety and reliability. Please retain the user manual for
important safety information about your device. This manual will help you
learn the features and specications of the device to assist with operability
and satisfaction during use. Failure to follow these guidelines for proper
use and care of your device may result in damage to the unit, or injury to
yourself and others.
• NEVER use a damaged
device or a device with a
damaged battery with this
unit. This may lead to re, uid
leaks, overheating, or
explosion.
• Use approved accessories
only. Improper use or
incompatible accessories
may result in re, explosion,
or other safety hazards.
• DO NOT place other objects
on top of the unit during use
or storage.
• DO NOT attempt to modify,
repair, or replace any internal
components of the unit. If
necessary, please contact the
manufacturer.
• Turn o immediately in case
of malfunction or smoke.
• Use dry powder re
extinguisher in case of re.
• Keep children and pets away
from the device.
• DO NOT expose the unit to
re, liquids, dirt, or other
contaminants as this could
lead to re or electric shock.
• DO NOT place the unit on an
unstable, uneven, or slippery
surface.
• Always use the unit in a well
ventilated and spacious area.
• DO NOT dismantle, crush,
puncture, or squeeze the unit.
• DO NOT insert any foreign
objects into the vents, ports,
or other openings.
• Always operate or store the
device in accordance with
the specied temperature
range.
• DO NOT ignore warnings
from other manufacturers
when using this device.

TIPS FOR SAFE
CHARGING
1. AVOID OVERCHARGING.
Disconnect power stations and devices after the battery
reaches a full charge. Leaving devices on a power station
too long may cause them to overheat and can reduce
battery life.
2. PICK THE RIGHT POWER OUTPUT.
Take special care to match the correct voltage and amp
values your device requires when using a power station.
Some power stations have multiple output ports so check
which one might be the most suitable for your device.
3. CHARGE ONLY ON NON-FLAMMABLE SURFACES.
Devices and power stations can get warm or sometimes
even hot during charging. Make sure to always place the
device and power station on a non-ammable surface when
charging. Do not place on beds, pillows, paper, or near any
fabric such as curtains or clothing under any circumstances.
4. AVOID EXTREME ENVIRONMENTS.
Do not recharge your devices or leave a power station in
environments where extreme temperatures can occur.
On particularly hot days do not charge or leave your power
station in places such as the inside of a car, or an
unairconditioned room. If it’s possible, try and wait till
the evening when temperatures are a bit cooler.
5. MONITOR CHARGING.
Recharge your devices while you are nearby, preferably in
the same room or another room close by. This way when
there is a defective battery or power station, you are able to
disconnect it immediately.

WHAT’S IN THE BOX
• PWR-PV1500-PS Portable
Power Station
• AC Charging Cable
• User Manual

PRODUCT SPECIFICATIONS
No. Item Description
1 Battery Cell Battery Cell Type: LiFePO4
Model: 32700 3.2V/6000mAh x 64
2 Rated Capacity 1228Wh (25.6V/48Ah)
3 Lifecycle 2000 cycles to 80%
4
Battery
Management
System
Under/Over Voltage Protection, Over Current Protection,
Short Circuit Protection, Overcharging Voltage Protection,
Over Temperature Protection, Overload Protection.
5 MPPT Supports Solar Power MPPT charging
6 Housing ABS+PC
7 Input Options
Wall charge 220-240V/50Hz Max 1000W
Vehicle charge DC port:
12-30V, 7A 200W
Solar charge XT60 port:
12-30V, 10A 300W
8Output
Options
2 x USB-C
PD 100W [1]
(5V/9V/12V/
15V/3A,20V/5A,
Max 100W)
PD [1]
4 x USB-A
QC3.0 [2]
(5V/3A,9V/2A,
12V/1.5A,
Max 18W
QC3.0 [2]
2 x DC5521 13.6V/8A Max
108.8 W Total share 8A
12V Car Socket
Connector
13.6V/8A Max
108.8 W
4 x 4 AC
AC: 220-240V~ 50Hz
Rated Power: 1500W
Peak Power: 2000W 1s
9 Dimensions 350 x 220 x 313mm
10 Weight 15.8kg
1. PD 100W = USB-C Power Delivery can deliver up to 100W of power.
2. QC3.0 = Quick Charge 3.0 can charge devices up to 4 times faster than
conventional charging.

GENERAL SPECIFICATIONS
No. Item Parameter
1Battery Cell Standard
Voltage 3.2V
2Cells Conguration 8S8P
3 Battery Pack Voltage 25.6V
4 Output Waveform Pure Sine Wave
5 Operating Environment 0~40°C
6 Working Humidity 20%~90%
No condensation at 20-90% of humidity
7 Storage Temperature
Normal indoor storage temperature.
Recommended storage temperature:
0 ~ 25°C (Range)
8 Standby Time Recommend: Recharge every 3 months.
Required: Must be recharged every 6 months.

USE CASE
(approximations only)
Table Lamp
220 hours
iPhone 12
40+ Charges
Tablet
30+ Charges
Laptop
10-15 Charges
Camera
30+ Charges
Drone
20+ Charges
Mini Fridge
10 - 15 hours
Cordless Drill
15+ Charges
Fan
20 hours
CPAP Device
5 – 6 hours
TV
9 hours
Bluetooth Speaker
90+ Charges

PRODUCT DIAGRAM
1. DC on/o Switch
2. DC Output Port
3. Car Socket
4. DC Input Port
5. AC Input Port
6. Solar Input Port
7. AC on/o Switch
8. AC Output Ports
9. LCD Display
10. USB on/o Switch
11. QC3.0 USB-A Ports X 4
12. PS100W USB-C Ports X 2
13. Main Power Button
14. Ground Connection

LCD DISPLAY
Battery Information
Indicator
Battery Power Level % Battery failure/low
voltage indicator
Battery Lock Protection
USB Output Indicators Output power
Hours
Solar Input Input Power
Over Temperature
Indicator
Over Temperature
Protection Indicator
System Failure Indicator Overload Protection
Indicator
Battery Power Level Battery high/low
temperature indicator
AC Input DC Input
Remaining discharge/
charge time
AC Output Indicators DC/Car Outlet Output
Minutes
Low Temperature
Indicator
Input Indicator
Remaining time
Indicator
Output Indicator
Protection Indicator
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21

CHARGING
AC CHARGING
• Please charge the PWR-PV1500-PS before using.
• Charge the battery to 80% before extended storage. Check
the PWR-PV1500-PS remaining power level every 3-6 months
and charge again.
• There are 3 input ports on the PWR-PV1500-PS:
1 x AC input port.
1 x Solar input port.
1 x DC5521 port.
• AC Charging: AC power supply (such as a wall socket)
can be used to charge the PWR-PV1500-PS with a maximum
power of 1000W through the AC charging port (gure 5
in Product Diagram).
• A full charge via AC charging takes approx. 80 minutes.
Note: When charging the
PWR-PV1500-PS by AC input, the
AC output ports cannot be used
and will stop supplying power to
any AC connected devices
AC

• The PWR-PV1500-PS supports Solar Panel charging rated
at 90W.
• Solar power can be used to charge the PWR-PV1500-PS
with a maximum power of 300W through the XT60 port
(gure 6 in Product Diagram)
• A full charge from a 300W Solar Panel will take between
5-10 hours (dependant on sunlight intensity).
SOLAR CHARGING
Solar Panel and XT60 cable not
included
CAUTION:
• The maximum voltage of solar panels that the
PWR-PV1500-PS can support is 30V, and the maximum current
is 10A.
• The PWR-PV1500-PS must be charged by solar panels with a
voltage lower than 30V.
• If the input voltage exceeds 30V it has a risk of damaging the
product.

• PWR-PV1500-PS supports car charging rated at 200W.
• The 12V socket in a car can be used to charge the
PWR-PV1500-PS with a maximum power of 200W through
the DC port (gure 4 in Product Diagram).
• A full charge via a 12V car charger will take approx. 14-16 hours.
Note: A 12V DC5521 cable (sold seperately) is required.
CAR CHARGING
CAUTION:
• The maximum voltage of car charging the PWR-PV1500-PS
can support is 30V, and the maximum current is 7A.
• The PWR-PV1500-PS must be charged by car with a voltage
lower than 30V.
• If the input voltage exceeds 30V it has a risk of damaging
the product.

HOW TO USE AC
OUTPUT
Under the condition that the total power does not exceed
1500W, all AC outlets can work together at the same time.
1. Make sure there is no device connected to the AC input,
then long press the main power button 3 seconds to turn on.
The main power indicator and the screen lights up, then enters
the standby state.
2. Plug in AC appliances.
3. Tap the AC on/o switch to turn on the AC output function.
The product starts to supply power to external AC appliances.
4. Long press the AC power on/o switch to turn o the AC
output.
5. When not using the product for a long time, please long
press the main power switch for 3 seconds to turn o to save
power.

HOW TO USE AC
OUTPUT
NOTE:
• When the AC out function is turned on, the AC icon on the
LCD display will light up, then perform a system power check
for approx 8-10 seconds. After the checks are complete, AC
power output will be available.
• When charging the PWR-PV1500-PS by AC input, the AC
output ports cannot be used and will stop supplying power
to any AC connected devices.
continued...

HOW TO USE DC
OUTPUT
1. Long press the main power button to turn on. The main
power indicator and the screen light up, then enters the
standby state.
2. Plug in the DC device.
3. Tap the DC on/o switch to turn on the DC function.
4. After use, tap the DC on/o switch to turn o the DC
output.
5. When not using the product for a long time, please long
press the main power switch for 3 seconds to turn o to save
power.
CAUTION:
When using the PWR-PV1500-PS, please do not plug the DC
input cable into the DC output connector. This could damage
the product.

HOW TO USE USB
OUTPUT
1. Long press the main power button to turn on. The main
power indicator and the screen light up, then enters the
standby state.
2. Tap the USB on/o switch to turn on the USB function.
3. Plug in the USB device.

TROUBLESHOOTING
DEVICE NOT CHARGING:
• Power o/on your device and try charging again.
• Try using another charging cable from your device to the
PWR-PV1500-PS.
• If using AC or DC output, make sure their respective switches are
set to ON.
• Check the device you are trying to charge does not exceed the
power rating for the output port being used.
• Check battery levels on the PWR-PV1500-PS
DEVICE OR POWER STATION GETS HOT DURING CHARGING:
• It is normal for a device and the power station to generate heat
during charging. If you feel that either are too hot, then unplug the
device from the power station and wait till it has cooled down.
THE POWER STATION IS NOISY:
• The power station uses an air-cooled system with built-in fans
working to help dissipate heat. The fans may spin faster or slower
depending on workload.
CAN I TAKE THE PWR-PV1500-PS ON A PLANE?
- No, the battery in the unit exceeds the 160Wh regulation.

TROUBLESHOOTING
continued...
HOW DO I CHARGE THE PWR-PV1500-PS?
- The PWR-PV1500-PS has 3 charging inputs. AC (Wall Socket), XT60
(Solar Panel) and DC (Car). An AC cable is included for charging via a
wall socket. The XT60 and DC cables are not
included.
HOW DO I KNOW IF THE PWR-PV1500-PS IS FULLY CHARGED?
- Check the LCD display. The power level is indicated as a
battery icon and a % number.
HOW DO I KNOW HOW MUCH POWER THE PWR-PV1500-PS IS
SUPPLYING TO A CONNECTED DEVICE?
- Check the LCD display. The estimated time a connected
device can run for will be indicated on the display.
CAN THE PWR-PV1500-PS OUTPUT POWER TO ANOTHER DEVICE
WHILE IT IS BEING CHARGED?
- Yes, the PWR-PV1500-PS can output power (except to the AC
output ports) while it is being charged. When charging the
PWR-PV1500-PS the AC output ports cannot be used.
CAN THE PWR-PV1500-PS SIMULTANEOUSLY CHARGE MULTIPLE
DEVICES?
- Yes, all the output ports on the PWR-PV1500-PS can be used at
the same time as long as the total power output does not exceed
1500W.

Thank you
for your purchase!
To get the most out of your product please read
the user manual carefully and keep for future use.
For specic information relating to your product
such as Spare Parts, FAQs, Warranty claims, and
more, please scan the following QR code:
