Laser SPK-F220 Instruction manual

QUICK USER GUIDE
CONTROL PANEL
SPK-F220
1
Status Display
2
Mode SelectButton
3
Previous Track / FM Station Button
4
Play / Pause Button
5
Next
Track /
FM Station
B
utton
6
Recording
and P
layback
Function Keys
7
Mic
rophone Sound Priority (over music)
8
Charging
Indicator Light. Red = Charging, Blue = Charge Complete.
Playback via Battery = 2 to 5 hours depending on volume.
Charge Time = 4 to 6 hours.
9
Power Adapter Charger Input
10
Wired
Microphone Input
11
Aux
iliary Audio Input (3.5mm socket)
12
Micro SD
Card Socket
13
USB
Storage Input
14
Karaoke
Microphone Echo Effect
15
Karaoke
Microphone Volume
16
Main
Volume
17
ON
/
OFF
Switch
18
LED Light
Show Switch
19
12V
External DC Power Input

LINE IN
JACK
1. Connect a 3.5mm Audio Cable(notincluded) to the LINEIN JACK of your SPK-F220
and to your external audio devices eg. MP3 player or Discman etc
2. Then select the LINE feature by pressing the MODE button.
3. Then press PLAY / PAUSE button to begin playback
FM RADIO
1. Select FM (mode) feature by pressing the MODE / SELECT button.
2. Press the PLAY / PAUSE button to begin automatically searching and saving available
radio stations.
3. Press PREVIOUS / NEXT button to select a specific radio station.
NOTE: PLEASE MOVE YOUR SPEAKER, TOENSURE BESTRECEPTION
USB / SD JACK
1. Insert USB drive or Micro SD card for playback
2. Playback will begin automatically
3. Press the PLAY / PAUSE button to pause and play
4. Press PREVIOUS / NEXT button to select a specific track for playback.
BLUETOOTH
1. Select the BT (Bluetooth) feature by pressing the MODE / SELECT button
2. Turn the Bluetooth feature on, on your portable device
3. Find and pair with your SPK-F220 speaker
4. Press the PLAY / PAUSE buttonto begin playback
MIC IN JACK
Plug in the microphone. The microphone is then ready to use.
RECORDER FUNCTION
1. Insert a USB Drive (Thumb Drive) and plug in your microphone
2. Long press the REC/REPLAY button
3. The speaker will then display REC and begin recording.
4. To stop recording, short press the REC/REPLAY button again
5. To playback a recorded file, press the REC/REPLAY
button (while your thumb drive is inserted)
then press the PREVIOUS and NEXT buttonsto select a track for playback.
SPECIFICATIONS
Power Output: 10W x 2
Frequency Response: 100Hz-20KHz
Power input: 100 – 240V AC
CHARGING INDICATOR LAMPS
During charging, the charging indicator lamp will turn RED.
When charging is complete, the charging indicator lamp will turn BLUE.
CONNECTING THE WALL CHARGER
1. Connect the wall charger toyour speaker
2. When the battery is fully charged,disconnect the charger from the speaker
first, then the wall charger from the wall.
Note: The speaker can beused normally during charging
ON / OFF SWITCH
Press andhold the ON /OFFSwitch toturn the speaker ONand again to turn
the speaker off.
VOLUME
Turn thevolume knob anti-clockwise to decrease thevolume and clockwise to
increase the volume.
PREVIOUS / NEXT BUTTON
To search for a specific song to playback, press thePREVIOUS / NEXT button to
either go forward or backwards through track lists.
1. Mute ON/OFF Button
2. Mode SelectButton
3. Power ON/OFF Button
4. Next Track/FMStation
5. Previous Track/FM Station
6. Play/Pause Button(FM
Auto Search Button
7. Master Volume knob
8. Equalizer knob
9. USB/SD card Playback
10. Repeatbutton
11. Keypad (select audio
tracks)

Warranty Against Defects
Laser Corporation Pty Ltd (“Laser”) warrants your new product to be free from defects in materials
and workmanshipfor 12months, from the date of purchase,provided that the productis usedin
accordance with accompanying recommendations or instructions where provided. The benefit of
this warranty is in addition to your rights under the Australian Consumer Law and to other rights
and remedies of the consumer under a law in relation to the goods or services to which the
warranty relates.
Through a network of retailers and resellers, Laser will provide you with your choice of a repair,
exchange (where possible) or refund (within Dead on Arrival period) for this product if it becomes
defective within the warranty period.
This warranty will no longer apply where the defect is a result of alteration, accident,misuse,
abuse, normal wear and tear, neglect orimproper storage. Please retain yourreceipt asproof of
purchase
How to make a product warranty claim:
Step 1: Find your receipt which proves the date of purchase. Where the date of purchase cannot
be verified, your place of purchase or Laser will make an assessment based on the date of
manufacture, the condition of the Laser Product and the type of defect.
Step 2a): Contact your place of purchase. They will assess the nature of the fault and repair,
replace or fund the product as per their store refund or warranty policy.
Step 2b): If your place of purchase cannot be contacted, then you can contact Laser. Customer
Service with details of your defective Laser Product:Phone:[phone]; or Email:
[e-mail] or online www.laserco.com.au/warranty (click on “Consumers (End
Users)”). Our business address is at 1/6-8 Byfield Street, North Ryde, NSW 2113
Step 3: Laser will issueyou witha Return Authorisation(RA) number within 48 hours. When
requested, send us the defective Product and a copy of your receipt. Laser will cover the cost of
the return delivery.
Step 4: Wait for us to contact you. Once we have received your defective Laser Product for
inspection, we will inform you of our assessment of your claim within 7 days. When we contact
you, we will firstly let you know whether you have a valid claim under this Warranty, and if so, we
will inform you whether your defective Laser Product will be replaced or repaired, together with
the number of days you can expect to wait to receive your replaced or repaired Laser Product.
Step 5: For further details on warranty cover and returns, please check Terms and Conditions for
Warranty Returns section on http://www.laserco.com.au/warranty
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law.
You areentitled toa replacement or refund fora majorfailure and compensation for any other
reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or
replaced if the goods fail to be of acceptable quality and the failure does not amount to a major
failure.
(
