Laser SPK-SB100 Owner's manual

QUICK USER MANUAL SPK-SB100
1
IMPORTANT SAFETY INSTRUCTIONS AND PRECAUTIONS
- Read all instructions carefully before use.
- Retain manuals for future reference.
- Use this product only in the manner described.
- Only use a water-dampened soft-cloth to clean the surface of this product.
- The following will damage this product: any liquid such as water or moisture, extreme heat; cold;
humidity, dusty or sandy environments.
- Only place this device onstable surfaces and ensure that any attached cables are secure and will not
cause the device to fall.
- There are no user serviceable parts in this product.
- Un-authorized attempts to dismantle or repair this product will void product warranty
- Using this device near otherelectronic devices may cause interference.

QUICK USER MANUAL SPK-SB100
2
CONNECTIONS
1 Play / Pause (Play or pause music playback. Hold for 3 seconds in Radio
mode to auto scan and save)
2 Input (Aux FM Bluetooth)
3 Select Previous
4 Select Next
A Audio Input (RCA Left (White) Right (Red))
B Stereo Output (for sound bar)
C Power On / Off Switch
D Mains power lead
E FM Antenna
F Adjustable Bass Level
F

QUICK USER MANUAL SPK-SB100
3
THE REMOTE CONTROL
REPLACING THE BATTERIES
1. Open the battery compartment by
sliding the cover back.
2. Insert the new battery as pictured
making you have observed the
correct polarity
3. Close the battery compartment.
Note: the remote control has
a usable angle of 30 degrees from
the speaker IR receiver.
1 Power (Turn On and Off)
2 Number keypad
3 Equaliser (Normal, jazz, rock, pop,
classic and bass)
4 Input (Aux FM Bluetooth)
5 Vol + (Increase volume)
Vol - (Decrease volume)
6 Prev (Select previous)
7 Mute (Mute sound)
8 100+ (Not for model SPK-SB100)
9 Repeat (Not for model SPK-SB100)
10
Next (Select next)
11
Play / Pause (Play or pause music
playback. Hold for 3 seconds in Radio
mode to auto scan and save)

QUICK USER MANUAL SPK-SB100
4
CONNECTING AND TURNING ON
1) Connect the Sound Bar to the Bass unit to the plugs with the white and red labelled
“Output”.
2) Connect the Speaker Cabinet using the RCA cable to your Audio device such as DVD or
Blu-Ray player.
3) Connect the Speaker Cabinet to 240V mains power using the mains cable.
4) Switch the unit on. Note: the default mode is FM radio if no other external audio
device is connected.
5) Adjust the BASS levels using the BASS knob at the back of the speaker cabinet
USING FM RADIO
1) Press the INPUT button to toggle to the RADIO function.
2) For the first time use, press and hold the PLAY/PAUSE to auto search and save the
available channels in your area. These stations will be designated “P 01” through to “P
20”
3) Use the NEXT and PREVIOUS buttons to toggle to your preferred station and adjust
the volume as preferred.
USING BLUETOOTH
1) Press the INPUT button to toggle to the BT function. A BT icon will begin to flash on
screen, which means the Bluetooth “pairing mode” has been activated.
2) Turn the Bluetooth function on, on your device (smart phone or tablet etc).
3) Scan for new devices, and look for SPK-SB100 to pop up on screen.
4) Once found and selected, you will be prompted for a password to complete the
pairing process. The password is 0000 (4 zeros).
5) Once connected and paired, the screen will show a solid BT icon to indicate pairing
has been completed.
6) Youare now ready to listen to music wireless via your sound bar. Open your music
files, select a song and press play.
SPECIFICATIONS
Output Power 16 and 6W x 2
Frequency response 40Hz – 20Khz
Impedance Cabinet 4Ohm, Sound bar 8Ohm
Signal / Noise Ratio >80dB
Isolation sensitivity >45dB
Speaker size (Speaker cabinet) 4”
Speaker size (Speaker bar) 3”
Input power 220 – 240v 60Hz

QUICK USER MANUAL SPK-SB100
5
Warranty Against Defects
Laser Corporation Pty Ltd (“Laser”) warrants your new product to be free from defects in materials and
workmanship for 12 months, from the date of purchase, provided that the product is used in
accordance with accompanying recommendations or instructions where provided. The benefit of this
warranty is in addition to your rights under the Australian Consumer Law and toother rights and
remedies of the consumer under a law inrelation to the goods or services towhichthe warranty
relates.
Through a network of retailers and resellers, Laser will provide you with your choice of a repair,
exchange (where possible) or refund (within Dead onArrival period) forthis product if it becomes
defective within the warranty period.
This warranty will no longer apply where the defect is a result ofalteration, accident, misuse, abuse,
normalwear and tear, neglector improperstorage. Please retainyour receipt as proof of purchase
How to make a product warranty claim:
Step 1: Find your receipt which proves the date of purchase. Where the date of purchase cannot be
verified, your place of purchase or Laser will make an assessment based on the date of manufacture,
the condition of the Laser Product and the type of defect.
Step 2a): Contact your place of purchase. They will assess the nature of the fault and repair, replace or
fund the product as per their store refund or warranty policy.
Step 2b): If your place of purchase cannot be contacted, then you can contact Laser. Customer Service
with details of your defective Laser Product: Phone: [phone]; or Email: [email protected]
or online www.laserco.com.au/warranty (click on “Consumers (End Users)”). Our business address is at
1/6-8 Byfield Street, North Ryde, NSW 2113
Step 3: Laser will issue you with a Return Authorisation (RA) number within 48 hours. When
requested, send us the defective Product and a copy of your receipt. Laser will cover the cost of the
return delivery.
Step 4: Wait for us to contact you. Once we have received your defective Laser Product for
inspection, we will inform you of ourassessment ofyour claim within 7days. When wecontact you, we
will firstly let you know whether you have a valid claim under this Warranty, and if so, we will inform
you whetheryour defective Laser Product will be replaced or repaired, together with the number of
days you can expect to wait to receive your replaced or repaired Laser Product.
Step 5: For further details on warranty cover and returns, please check Terms and Conditions for
Warranty Returns section on http://www.laserco.com.au/warranty
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You
are entitled to a replacement or refund for a major failure and compensation for any other reasonably
foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods
failto be of acceptable quality and the failure does not amount to amajor failure.
