Lasermet Audio Alert AA-04 User manual

01379-53-000 Page 1 of 14 Issue 2 25th February 2014
LASERMET
AA-04
Audio Alert
Recorded Message Playback Device

AA-04 Audio Alert Instruction Manual
01379-53-000 Page 2 of 14 Issue 2 25th February 2014
AA-04
Audio Alert
Instruction Manual
Contents
Introduction ...................................................................................................................4
Recording a Message ...................................................................................................5
Wiring............................................................................................................................8
Adjusting Volume ..........................................................................................................9
Installation...................................................................................................................10
Attaching the AA-04 to the Backplate..........................................................................12
Removing the AA-04 from the wall..............................................................................13
Specifications..............................................................................................................14
Contact Details............................................................................................................14

AA-04 Audio Alert Instruction Manual
01379-53-000 Page 3 of 14 Issue 2 25th February 2014
CE Declaration of Conformity
Manufacturer: Lasermet Ltd.
Lasermet House, 137 Hankinson Road,
Bournemouth BH9 1HR U.K.
Equipment: AA-04 Audio Alert
01156-00-000 Standard
Applicable Directives: Low Voltage Directive 73/23/EEC
CE Directive 93/68/EEC
EMC Directive 2004/108/EC
European Standards to which conformity is declared:
EN 60598-1: 2008
EN 62471:2008
EN 55015:2006
EN 61547:1995 inc. A1:2000
EN 61547:2009
I hereby declare that the above listed products conform to the relevant sections of
73/23/EEC, 93/68/EEC and 2004/108/EC.
Signed:
Name: K. Bowers
Position: Quality Assurance Manager
Date: 25 February 2014

AA-04 Audio Alert Instruction Manual
01379-53-000 Page 4 of 14 Issue 2 25th February 2014
Introduction
The AA-04 Audio Alert device is intended to be used in conjunction with Lasermet’s
Laser Interlock systems for the purpose of audibly warning personnel of hazards by
playing back a message recorded on the device. However, the devices can be
readily used independently from Lasermet Interlock systems.
The AA-04 plays back a recorded message up to 40 seconds long (13 seconds
default) when a supply voltage of +6VDC to +24VDC is applied.
The message is generally recorded at factory and can be any audio whether it be
speech, music or other. The repetition rate and the number of repetitions of the
message are factory settable to end-user requirements.
The AA-04 incorporate adjustable volume control and line-out features to allow audio
output to external devices such as amplifiers, speakers and PA systems.
Lasermet provides a full range of laser interlock equipment including control
systems, interlock switches, illuminated warning signs, laser shutters, door locks,
external power supplies etc. which can be connected to provide a complete laser
interlock system. Full support, design and installation is available from Lasermet,
please contact us for any queries. Contact details are given at the end of this
manual.

AA-04 Audio Alert Instruction Manual
01379-53-000 Page 5 of 14 Issue 2 25th February 2014
Recording a Message
Generally, the customer can provide Lasermet with a digital audio file when ordering
an AA-04 and Lasermet will upload the file onto the device for the customer prior to
delivery. Lasermet also has an in-house vocalist who can record written messages
onto the AA-04 prior to delivery.
If the customer wishes to record their own messages, then optional Lasermet part
AA-MIC can be purchased. AA-MIC is special microphone with custom connections
specifically for the Audio Alert range. The following steps indicate how recording with
the AA-MIC is performed.
Step 1 –Remove Rear of Case
Figure 1: Removing Highlighted Screws
Remove the two screws circled in red, and remove the rear half of the case
exposing the circuit board below.

AA-04 Audio Alert Instruction Manual
01379-53-000 Page 6 of 14 Issue 2 25th February 2014
Step 2 –Connect Power & AA-MIC
Figure 2: Connecting Power and AA-MIC Cables
Connect +6VDC to +24VDC to J1. (Refer to “Wiring” section if in doubt)
Connect the AA-MIC to J3, making sure Pin 1 of the AA-MIC is aligned with
Pin 1 of J3.

AA-04 Audio Alert Instruction Manual
01379-53-000 Page 7 of 14 Issue 2 25th February 2014
Step 3 –Record Message
Figure 3: Recording the Message using AA-MIC
Ensure power is on to the AA-04
Slide the switch on the AA-MIC to on and record your message, speaking
clearly into the microphone.
Immediately after you finish speaking, slide the switch on the AA-MIC back to
the off position.
Switch off power to the AA-04.
When power is reapplied to the AA-04, your recorded message should be
heard.
Repeat this process until you are satisfied with the message.
When satisfied, remove power and AA-MIC from the AA-04 and screw the
rear of the case back on.

AA-04 Audio Alert Instruction Manual
01379-53-000 Page 8 of 14 Issue 2 25th February 2014
Wiring
Figure 4: Terminal Identification
+6 to +24VDC should be applied to J1 (Power) in order to activate the unit and start
the speech routine. Positive should be connected to a +24V terminal and negative to
a 0V terminal.
If the audio signal is required to be outputted to an external amplifier or other audio
device, then the positive and negative terminals of J5 should be connected to the
positive and negative terminals of the external audio device.

AA-04 Audio Alert Instruction Manual
01379-53-000 Page 9 of 14 Issue 2 25th February 2014
Adjusting Volume
Figure 5: Volume Adjuster
In order to adjust the volume of the playback, a small screwdriver should be used to
turn the volume adjuster (pictured above) clockwise to increase volume or counter-
clockwise to decrease the volume. Depending on the screwdriver you are using, you
may or may not have to remove the rear of the case as shown the “Recording a
Message” section of this manual. The volume adjuster is placed within the unit to
prevent unauthorised changes to the volume of the device.

AA-04 Audio Alert Instruction Manual
01379-53-000 Page 10 of 14 Issue 2 25th February 2014
Installation
The AA-04 is designed to be permanently attached to a wall or other fixed vertical
surface.
Positioning
The AA-04 should be mounted in a convenient position for use and wiring.
During installation, wired connections will need to be made and allowance should be
made for the installation of electrical conduit or trunking if required to make entry to
the unit.
Ideally the AA-04 should be attached directly to the wall with the cables being fed
from within the wall. For hollow walls this should be straightforward. For solid walls it
may be easiest and neatest to feed the cables right through the wall from the other
side.
Alternatively the AA-04 may be attached to a round conduit box which may be buried
or surface-mounted, though this last option will result in the unit projecting further
from the wall, making it less stable and more vulnerable.
It is recommended that there must be a flat unobstructed area of wall extending at
least 70mm above and 110mm below the mounting centre to allow fitment and
removal.
If a Lasermet Miniature Warning Sign is being fitted above the AA-04 the centres
should be at least 140mm apart vertically.
Refer to Figure 6 for details of the fixing holes and cable entry. The wallplate and
locking plate are secured using preferably four screws on a 35.4mm square around
the cable entry point. The locking plate and plastic wallplate disk are pre-drilled and
may be used as a marking template. If using a round conduit box, the holes will align
with the cover fixing holes.
Once all the holes have been made, secure the wallplate and the locking plate as
shown in figure 6 with the plastic wallplate against the wall. Check that the plastic
wallplate and locking plate are aligned as shown.
Feed the cables through the hole in the centre of the locking plate.
NOTE: Make the electrical connections before attaching the unit to the wallplate, see
the Wiring section.

AA-04 Audio Alert Instruction Manual
01379-53-000 Page 11 of 14 Issue 2 25th February 2014
35.4
35.4
16.6
At least 100mm
Ø20
Ø4.5
Figure 6: Wall Drilling Details

AA-04 Audio Alert Instruction Manual
01379-53-000 Page 12 of 14 Issue 2 25th February 2014
Attaching the AA-04 to the Backplate
Once all the wiring connections
have been made, attach the AA-
04 to the backplate by hooking
the top of the AA-04 onto the
backplate and swinging the
bottom against the wall. Press
the AA-04 firmly until it clicks into
place.
Figure 7: Locking Case onto Backplate
Click!

AA-04 Audio Alert Instruction Manual
01379-53-000 Page 13 of 14 Issue 2 25th February 2014
Removing the AA-04 from the wall
Once the AA-04 has been locked to the wall, a 5mm flat screwdriver is required to
release the locking latch before it can be removed, see figure 8.
Ensure that the supply is turned off.
Insert the screwdriver into the recess in the
bottom of the AA-04 at the back and push the
latch upwards to disengage it from the case.
Note that the latch is quite secure and some
force may be needed before it releases.
When the latch is released it will be possible
to tilt the bottom of the AA-04 forwards and
then lift it off the backplate.
Use a 3mm flat screwdriver to disconnect the
wires from the terminals.
Figure 8: Releasing
Locking Pin

AA-04 Audio Alert Instruction Manual
01379-53-000 Page 14 of 14 Issue 2 25th February 2014
Specifications
Dimensions:
160 mm wide X 108mm high X 38.5mm deep.
Weight:
250g.
Operating Voltage:
+6 to +24VDC.
Power Consumption:
0.48W standby, 3.8W activated.
All figures quoted are approximate. Lasermet reserve the right to alter specifications
without prior notice.
Contact Details
For sales and technical support::
Lasermet Ltd.
Lasermet House,
137 Hankinson Road,
Bournemouth
BH9 1HR
United Kingdom.
Tel.: +44 (0) 1202 770740
Fax: +44 (0) 1202 770730
E-mail: sales@lasermet.com
Website: www.lasermet.com
