9040
For Boys And Girls
Ages 5 And Up
SAMURAI
8 Models+
Any creation you can build
LIGHTED
CONSTRUCTION SET INCLUDES:
• 14 Laser Pegs®
• 42 Construction Parts
• Triangle Power Base
• Instruction Manual
Requires 3 AA Batteries
Batteries NOT
Included
www.LaserPegs.com
Laser Pegs® Parts List
There is No LED In The 90° Peg
STRAIGHT
T-PEG
Y PEG
Please read manual before you
begin! Failure to follow this manual’s
instructions may result in damage to
the Triangle Power Base, AC Adapter
and/or Laser Pegs®. Not adhering
to these directions will void the
manufacturer’s warranty.
Packing has to be kept since it
contains important information.
This manual is copyright and cannot be reproduced or used online without Laser
Pegs®Ventures LLC permission. Copyright 2013 © All Rights Reserved US Patent
#7,731,558 Additional Global & Multiple Patents Pending. Laser Pegs® Ventures
1. Remove screws.
2. Place three AA batteries in the correct
position - as displayed inside the Triangle Power Base.
3. Push RED button to turn on!
4. Do not mix old and new batteries.
5. Do not mix alkaline, standard (carbon-
zinc), or rechargeable (nickel-cadmium) batteries!
6. Exhausted batteries are to be removed
from the power base.
7. Never connect more than 200 Laser Pegs®
8. Non-rechargeable batteries are not to be recharged.
9. Rechargeable batteries are only to be charged under
adult supervision.
10. Rechargeable batteries are to be removed from the
toy before being charged.
11. Batteries are to be inserted with the correct polarity.
12. The supply terminals are not to be short-circuited.
WARNING! Each Laser Peg® draws current from the batteries. Therefore,
the more pegs you use, the quicker you will deplete your battery power! As
the power weakens, the current will slowly fail and some Laser Pegs® will
illuminate (typically the reds and yellows) and some won’t. When the Laser
Pegs® dim the Laser Pegs® are not broken, they just need stronger batteries
or an AC adapter.
You have 3 simple options...
1. Use a 5 volt AC Adapter –available from www.LaserPegs.com.
2. Change the batteries.
3. Use high quality batteries. They will last a little longer, but they will still
deplete rapidly the more Laser Pegs® you connect!
Compatible with other
construction kits
Each Laser Peg® is color coded on the circuit board inside
each shape. There is No LED In The 90 Degree Peg.
Laser Pegs® link that allows you to
connect to other construction kits. Triangle Power Base
Color
Code
Press button to
turn on/o
Push button to cycle
through 3 dierent
light settings.
Power Button
Peg Holes
AC Adapter Connection
Remove the three Philips
head screws with a 4mm
screw driver.
Requires (3AA) Batteries
Using an
AC Adapter
Remove all batteries from Laser Pegs®
power base before using the 5 volt AC
Adapter.
When using an AC Adapter,
NEVER place the adapter
plug into the Triangle Power
Base top peg holes.
CHOKING HAZARD-Small parts.
Not for children under 3 yrs.
Do not submerge in water.
Construction Compatible
Laser Pegs
®
Stackable
*To avoid short-circuits, keep metal objects and other
un-authorized materials from obstructing the peg holes.
The AC adapter used with the power base are to be regularly
examined for damage to the cord, plug, enclosure and other
parts, and in the event of such damage, they must not be used
until the damage has been repaired.
When Using Batteries
EN71, RoHS COMPLIANT
x4
This product complies to all safety
requirements of ASTM F 963
STACKABLE
Never connect more than 200 Laser Pegs®
when using a 5 volt (2000mA) AC Adapter.
45° PEG SQUARE
M-M PEG
Construction Parts List x6
x1
90° PEG
MODEL INSTRUCTIONS
All additional model instructions can be
downloaded at www.LaserPegs.com
SQUARE
PEG TRIANGLE
PEG
x1
x2 x1
x1 x2
x2
x2
x2
x2
x2
x6
x7 x2
x2
x2
x2
4
x4
x2
x2
x1
To construct with Laser Pegs®, slide two pieces together to form
a connection. Slide each piece on and o smoothly. The 90° pegs
are essential to construction but they DO NOT ILLUMINATE.
Connecting Pegs
A
B
1
STEP
2
STEP
3
STEP
4
STEP
5
STEP
6
STEP
7
STEP
8
STEP
9
STEP
Model
Diculty
Level
TURBO PROP PLANE
TURBO PROP PLANE - A high-performance, short-ight aircraft
which uses a turbine engine to drive its propeller.
