Lasertec CL2G User manual

INSTRUCTION MANUAL
CL2G
MULTI-LINE LASER

2
SAFETY
Read the following safety instructions
before attempting to operate this product.
Keep these instructions in a safe place or store
in the carry case for future reference.
SAVE ALL WARNINGS AND INSTRUCTIONS FOR
FUTURE REFERENCE.
WARNING: Read and understand all
instructions.
• Use the laser only with the specifically designated
batteries.
• Store the laser out of reach of children and other
untrained persons. Lasers are dangerous in the
hands of untrained users.
• Use only accessories that are recommended for
your model.
• Tool service must be performed only by qualified
repair personnel. Repairs, service or maintenance
performed by unqualified personnel will void the
warranty. Only approved and authorised service
technicians can carry out warranty repairs.
• Do not use optical tools such as a telescope or
transit to view the laser beam. Serious eye injury
could result.
• Do not place the laser in a position which may
cause anyone to intentionally or unintentionally
stare into the laser beam. Serious eye injury could
result.
• Do not position the laser near a reflective surface
which may reflect the laser beam toward anyone’s
eyes. Serious eye injury could result.
• Do not use optical tools to view the laser beam.
• Do not set up the tool at a position where the laser
beam can cross any person at head height.
!

3
• Do not let children come in contact with the laser.
• Turn the laser off when it is not in use. Leaving
the laser on increases the risk of staring into the
laser beam.
• Do not operate the laser around children or allow
children to operate the laser. Serious eye injury
may result.
• Do not remove or deface warning labels.
• Position the laser securely on a level surface.
Damage to the laser or serious injury could result
if the laser falls.
WARNING: DO NOT DISASSEMBLE
THE LASER.
There are no user serviceable parts inside.
Disassembling the laser will void all warranties on
the product. Do not modify the product in any way.
Modifying the tool may result in hazardous laser
radiation exposure.
!
!
CAUTION: Class 2 Laser Product
• Never look into the laser beam directly
and intentionally.
• Do not use optical tools to view the laser beam.
• Do not set up the tool at a position where the
laser beam can cross any person at head height.
• Do not let children come in contact with the laser.
SAFETY (continued)

4
ITEM CHECKLIST
Please ensure the following items are included with your laser level.
If anything is missing please contact your retailer.
Lasertec CL2G
AA alkaline batteries
Laser target
INCHES CM
1
1
2
3
4
5
6
7
2
3
Carry pouch
Magnetic mount

5
LASER OVERVIEW: FRONT
Laser port
Laser port
1/4” tripod thread
Control panel
Locking switch
Battery door cover

6
LASER OVERVIEW: CONTROL PANEL
LED pulse mode indicator
•Power
•Pulsemode(press and hold for 3 seconds)

7
MAGNETIC MOUNT OVERVIEW
1/4” thread
Screw fixing point
Rotating base
Magnet
Magnet
Screw fixing point
5/8” x11 thread
5/8” x 11 thread
1/4” thread
1/4” thread thumb screw

8
POWER SUPPLY
• The instrument is powered by four AA alkaline
batteries.
Battery Replacement
• Remove the battery cover door and the
batteries.
• Insert the batteries according to polarity and
replace the battery cover door.
SET UP
• Select a place as close as practical to the work
site. Ensure the location is clear of traffic.
• Place the instrument on a level surface such as a
bench or mount.
• To mount the instrument onto the supplied
magnetic mount, follow the instructions on page
10.
USING YOUR LASER
OPERATION
Powering on (self levelling)
• To turn the instrument on, slide the locking
switch to the “unlocked” position. Self levelling
will commence and all beams will activate.
• If the instrument is outside the self levelling
range the instrument will not level causing the
laser beam to flash on and off repeatedly. If this
occurs, reposition the instrument onto a level
surface until the instrument can level off.
• Press the power button to cycle through the
active beams.
Powering off
• To turn the instrument off, slide the locking
switch to the “locked” position.
• Press and hold the power button for 3 seconds.

9
Tilt lock function (manual mode)
• Ensure the locking switch is in the “locked”
position.
• Press the power button to activate the laser
beams.
• The instrument can now be tilted to the desired
angle. The beams will flash approximately every
5 seconds to alert the user that the instrument is
in manual mode.
When in tilt lock function (manual mode) the
instrument will not self level and correct for
vibrations and/or disturbances.
Pulse mode cannot be enabled whilst the
instrument is in manual mode.
i
Self-levelling beam position (recommended)
Tilt lock function (manual mode)
i
Always slide the locking switch to the
“locked” position when transporting the
instrument or moving around the job site.
!
USING YOUR LASER (continued)

10
USING THE MAGNETIC MOUNT
Mounting onto a magnetic surface
• Attach the instrument to the mount using the 1/4”
thumb screw.
• Attach the mount to a metal surface, ensuring that
the mount has a strong hold before releasing your
hands.
• To rotate the instrument on the mount, twist the
mount platform. This can be rotated up to 180°.
Mounting via screw fixing points
• Attach the instrument to the mount using the 1/4”
thumb screw.
• Fix a screw into a secure surface and hook the
mount over the screw. Ensuring that the mount has
a strong hold before releasing your hands.
• To rotate the instrument on the mount, twist the
mount platform. This can be rotated up to 180°.
Mounting onto a tripod
• Attach the mount onto the tripod via the 1/4” or
5/8” x11 thread.
• Attach the instrument to the mount using the 1/4”
thumb screw.
• To rotate the instrument on the mount, twist the
mount platform. This can be rotated up to 180°.
The tripod is an optional accessory which can
be purchased from your retailer.
i
USING YOUR LASER (continued)

11
i
*Detector image shown is for illustrative purposes only.
Actual model may vary.
USING AN OPTIONAL DETECTOR
• Press and hold the power button for 3 seconds
to enter into pulse mode. The LED pulse mode
indicator will illuminate to show pulse mode is active.
• Switch the detector on by pressing the power
button. The speaker will beep indicating the
instrument is operating.
• Move the detector into the path of the laser beam.
• Hold the detector upright for horizontal beams.
Rotate the detector 90° for vertical beams.
• The LED direction indicators will indicate the
position of the laser beam. The centre LED will
indicate alignment with the beam.
• To exit pulse mode, press and hold the power
button for 3 seconds. The LED pulse mode indicator
will turn off to show pulse mode is not active.
The detector is an optional accessory which
can be purchased from your retailer.
USING YOUR LASER (continued)
Detector position for horizontal beams*
Detector position for vertical beams*

12
TROUBLE SHOOTING
Error Cause & Solution
Laser does not turn on
• Check the batteries. They may be in the wrong way or need
replacing.
• Check the battery compartment for signs of damage.
Ensure they are clean and not bent.
Laser does not remain on
for long periods of use.
• Check the batteries.
• Check the battery compartment for signs of damage.
Ensure they are clean and not bent.
Laser does not level off
• Instrument may be outside its self levelling range.
Adjust the instrument or tripod so it is level.
• Instrument may have impact damage.

13
CARE AND MAINTENANCE
• This is a precision measuring instrument
and should always be handled with care and
transported within the carry pouch provided.
• Always slide the locking switch to the “locked”
position when transporting the instrument or
moving around the job site.
• Whenever possible, store the instrument in a dry,
shady location.
• Calibration of the instrument is recommended:
every six months, if ongoing accurate levelling is
required, or an impact has occurred.
• The operator should check the accuracy of the
instrument before precision levelling is attempted.
Failure to do so may result in inaccurate
measurements.
• Clean the instrument with a dry, soft cloth after
use in dusty, damp or wet conditions before
storing.
• Smudges and fingerprints may be removed with a
damp tissue or a soft, lint-free cloth.

14
WARRANTY
3 YEAR STANDARD WARRANTY PERIOD
1. The warranty period for your tool is 3 years from
the date of purchase.
2. The warranty period for batteries, battery packs
and chargers is 1 year from the date of purchase.
3. Calibrations are not covered under warranty as
they are deemed wear and tear.
4. All products have a standard warranty period, you
do not have to register your products to obtain the
standard warranty period.
5. To claim under this warranty, the date of purchase
of the tool must be documented by an invoice/
receipt.
7 YEAR EXTENDED WARRANTY PERIOD
1. The extended warranty is available on selected
tools only.
2. You may extend the warranty period for your
tool to 7 years from the date of purchase. This
excludes batteries, battery packs and chargers.
3. Calibrations are not covered under warranty as
they are deemed wear and tear.
4. To obtain the extended warranty, the registration
process must be completed within 30 days from
the date of purchase.
5. Failure to register your product online and/or
submission of a valid invoice/receipt will void the
warranty extension.
6. Please ensure ALL information submitted/
uploaded is correct.
7. Extended warranty is ONLY available via online
registration, offline (mailing in of warranty
registration) will not be accepted.

15
AUSTRALIA
“Our goods come with guarantees that cannot be
excluded under the Australian Consumer Law. You
are entitled to a replacement or refund for a major
failure and for compensation for any other reasonably
foreseeable loss or damage. You are also entitled to
have the goods repaired or replaced if the goods fail
to be of acceptable quality and the failure does not
amount to a major failure.”
For more information please visit consumerlaw.gov.au
NEW ZEALAND
For more information please visit
consumerprotection.govt.nz
WARRANTY (continued)

16
To assist you with any queries or technical questions
please contact customer support
Australia: 1300 658 338
New Zealand: 0800 367 527
CUSTOMER SUPPORT

17
SPECIFICATIONS
Specications Lasertec CL2G
Product code 91280
Warranty 7 Years*
Accuracy ±2mm at 10m
Operating range 50m (with optional detector)
Levelling range ±4°
Laser class 2 Green
Battery life 5 hours
Battery type 4x 1.5v AA
Vertical lines 1
Horizontal lines 1
IP rating 54
Weight (kg) 0.45 (inc. batteries)
Dimensions (mm) 92 x 63 x 103
*With online registration (3 years without registration). Please refer to page 14 for details.

18
NOTES

19
NOTES (continued)

www.spoton.com.au
