LauraStar SMART User manual

INSTRUCTIONS MANUAL
BRUKSANVISNING
INSTRUKTIONSMANUAL
BRUGSANVISNING

27
LAURASTAR LAURASTAR LAURASTAR
11
22
33
3
3a
44
55
66
6
6a
77
88
9
10
13
14
15
17
16
20
22
23
24
25
18
19
21
26
26
12
11
11
28
Opt. 3Opt. 2
-2-

-3-
EN
Warning: Failure to comply with this
instruction manual and the safety
instructions may result in serious injury
or damage to property. The manufac-
turer accepts no responsibility for such
injury or damage in the event that these
safety instructions are not followed.
Keep this instruction manual for refer-
ence by any and all persons who may
use the appliance.
WARNING: Your LaurastarTM product generates heat and steam. Various parts of the
appliance may become very hot during operation and can cause burns.
NOTE: This appliance generates heat and can cause burns. Those parts which get very hot
are marked with this symbol.
Table of content
Safety instructions 4
Laurastar Smart App 6
Installation and storage 6
Start up 8
Ironing 9
Filling 11
Maintenance 12
Problems and solutions 14
Technical information 15
Guarantee 16
Dear customer, congratulations! You have just purchased a high-quality Laurastar ironing system that
combines Swiss design and technology. Please read this instruction manual and the safety instructions
carefully before using your appliance for the rst time and retain this instruction manual for future use.
Find all our tutorial videos and suggestions on www.laurastar.com
Overview and features
1. Ironing board
2. Iron
3. Steam Hose
4. Special Laurastar cover
5. Safety storage box
6. Folding iron-rest
7. Adjustable height handles
8. Steam hose holder
9. Steam buttons
10. Vacuum/blower button
11. Water reservoir
12. Small and large water reservoir lid
13. Filter compartment and anti-scale lter
14. Drain tray
15. Steam generator
16. Main ON/OFF button with indicator light
17. Laurastar SenSteam button (option)
18. Pulsed steam button (option)
19. Fan speed button (4 speeds)
20. Empty water indicator light
21. Steam generator cap
22. Drain cap
23. Power plug and Electric cable
24. Fan
25. Fan plug
26. Wheels
27. Protective soleplate
28. Protective soleplate hook

-4-
1. Only use an iron for its intended use.
2. To avoid the risk of electric shock, do not immerse the
iron in water or other liquids.
3. Always turn the iron OFF before plugging or unplugging
the iron from the electrical outlet. Never pull on the cord
to disconnect the iron from the electrical outlet; instead,
grasp the plug and pull on the plug to disconnect the iron.
4. Do not let the cord touch hot surfaces. Let the iron cool
completely before putting the iron away. Coil the cord
loosely around the iron when storing.
5. Always disconnect the iron from the electrical outlet
before lling the iron with water, emptying the water
from the iron, and when the iron is not in use.
6. Do not operate the iron with a damaged cord or in the
event the iron has been dropped or damaged. To avoid the
risk of electric shock, do not disassemble the iron. Take
it to a qualied serviceman for examination and repair.
Incorrect assembly might result in a risk of electric shock
when the iron is used after reassembly.
7. Close supervision is required for any appliance used by
or near children. Do not leave the iron unattended while
the iron is connected or on an ironing board.
8. Burns can occur from touching hot metal parts, hot
water, or steam. Use caution when you turn a STEAM
IRON upside down - there might be hot water in the
reservoir.
9. To avoid a circuit overload, do not operate an iron on
the same circuit with another high wattage appliance.
10. If an extension cord is absolutely necessary, a cord
with an ampere rating equal to or greater than the
maximum rating of the iron shall be used. A cord rated for
less amperage can result in a risk of re or electric shock
due to overheating. Care shall be taken to arrange the
cord so that it cannot be pulled or be tripped over.
• This appliance is intended for private houshold use
only.
• Only use this appliance indoors and for ironing textile
items in accordance with this Operator Manual.
• In an emergency, immediately unplug the plug from the
wall socket.
• The appliance must ONLY be connected to a grounded
wall socket outlet. We recommend FI circuit breakers.
The power plug must be easily accessible in case of
emergency.
• The iron soleplate and steam jet are very hot. DO NOT
iron or apply steam to clothing while it is being worn.
• Do not point steam in the direction of people or pets
during vertical steaming.
• This appliance produces heat. Keep your hands and
body away from the iron soleplate and steam jet while
in use – they will be HOT. Take care when returning the
steam iron to
the iron rest.
• CONTACT WITH STEAM UNDER PRESSURE CAN
RESULT IN SEVERE BURNS.
• DO NOT open the steam generator cap or the drain cap
while operating the appliance.
• Never leave the appliance unattended while switched
on.
• ALWAYS allow the appliance to cool down for at least
2 hours before emptying.
• Keep the iron and its cord out of reach of children
less than 8 years of age when it is energized or
cooling down.
• This appliance is NOT intended for use by children,
or persons with reduced physical, sensory or mental
capacity, or lack of experience, unless they are
supervised by a person
responsible for their safety. This appliance is NOT
intended to be used by children under the age of 8
regardless of supervision or training.
Keep out of reach of children.
Children must be supervised to ensure
that they do not play with the appliance.
DO NOT drink ltered water.
Keep out of reach of children.
DO NOT ingest the demineralization
granules. They may be disposed of with
household waste.
• Always place the iron on a at, stable and re-
resistant surface. NEVER rest the iron on the ironing
board cover or clothes. To avoid risk of re, ensure that
the iron is placed only on the iron rest.
• Take care when removing and setting down the
IMPORTANT SAFETY
INSTRUCTIONS
When using an iron, basic precautions should always be followed, including the following:
READ ALL INSTRUCTIONS BEFORE USING

-5-
protective soleplate after use. Place the hot soleplate
on the heat-resistant iron rest.
• Cleaning, repairs, and maintenance on the
appliance should ONLY be performed when the iron
is switched off, cold and allowed to cool down for
at least 2 hours. Unscrew the caps with care: any
pressurized steam present will begin to escape after
a few turns, posing a risk of burns.
• Allow the iron to cool down completely before
storing.
• DO NOT operate the appliance without water.
• Clean the exterior of the appliance with a soft,
damp cloth. DO NOT use solvents, oil or petrol.
• DO NOT attempt to insert objects into the openings
of the appliance. If water or a foreign body enters the
appliance, immediately unplug the iron from the wall
socket. Contact an authorized Laurastar Customer
Service representative for information on repair.
• To avoid risk of electric shock, DO NOT pull the
electric cable from the wall socket – take a rm hold
of the plug and remove it.
• Position the electric cable and the steam hose
so that they cannot be pulled or caught to avoid a
tripping hazard.
• The lling, or decalcifying, or rinsing, or inspection
apertures that are under pressure, shall not be
opened during use.
• Do not use the appliance if it has been damaged
in a fall, shows visible signs of damage, or has a
faulty steam hose or electric cable. To avoid the risk
of electric shock, do not open or disassemble the
appliance. Contact an authorized Laurastar Customer
Service representative for information on repair.
Incorrect reassembly can cause a risk of electric
shock when the appliance is used.
• Environmental information and waste disposal
measures : DO NOT dispose of the used appliance
with normal household waste ! Ask your municipal or
local authorities about appropriate environmentally-
friendly disposal facilities.
SAVE THESE INSTRUCTIONS
FCC Statement
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
Caution: The user is cautioned that changes or
modications not expressly approved by the party
responsible for compliance could void the user’s
authority to operate the equipment.
Note: This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there
is no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment
off and on, the user is encouraged to try to correct
the interference by one or more of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and
receiver.
- Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV
technician for help.
This equipment complies with FCC radiation exposure
limits set forth for uncontrolled equipment and meets
the FCC RF exposure guidelines. This equipment
has very low levels of RF energy that are deemed to
comply without testing of specic absorption ration.
ISED statements
This device complies with Industry Canada license-
exempt RSS standard(s). Operation is subject to the
following two conditions: (1) this device may not
cause interference, and (2) this device must accept
any interference, including interference that may
cause undesired operation of the device.
This equipment complies with Canada radiation
exposure limits set forth for uncontrolled
environments. This transmitter must not be co-
located or operating in conjunction with any other
antenna or transmitter.
EN

-6-
Installation and storage
Installing your ironing system
• Remove the appliance from the box and position it vertically on the
ground in a closed position.
• Hold the table with one hand on the iron rest side (6). Hold the middle
of the table (1) with the other hand and pivot it to a horizontal position
(maximum height). AB
• Unfold the iron-rest to the open position.
• Fit the ironing board cover (4), securing it from the side of the iron rest
to the tip of the ironing board, then adjust. The cover supplied with this
product is specially designed to ensure uniform distribution of air over
the whole board in vacuum or blower mode. Use only a Laurastar ap-
proved cover to ensure that its effectiveness is not impaired. The cover
is washable at 30°C (warm water); do not spin dry.
• Take the iron (2) out of its safety storage box (5) and place it on the iron-
rest (6).
• You can fold the iron-rest into the close position (6a) if you desire.
• Insert the steam hose holder (8) in one of the two holes beside the
iron-rest(6), x the steam hose on the steam hose holder (3a). Insert
the protective soleplate hook (28) in the other hole.
• You can lower the table height by clamping the handles (7). There are six
levels. To lift the table, simply pull it up without using the handles.
• To move your Laurastar, simply raise the tip of the board and roll.
A B
C
C
LAURASTAR SMART APP
DOWNLOAD the Laurastar App
If you have it already, make sure that the App is up to date.
LAUNCH the App
Launch the Laurastar App and follow the
instructions on your smartphone or tablet.
CONNECT your smartphone to your Laurastar
Insert the power plug of your Laurastar into the wall socket.
Activate Bluetooth on your smartphone or tablet.
On your Laurastar, push the fan speed button (19),
keep it pressed and push the main ON/OFF button (16).
Release the 2 buttons. All the user interface LEDs will
flash during 20 seconds.
This process can be repeated if the time available is not
sufficient. Once the connection established, it is not
necessary to reconnect the same smartphone or tablet.
user interface
1 2 3 LAURASTAR
user interface
1 2 3 LAURASTAR
user interface
1 2 3 LAURASTAR
user interface
1 2 3 LAURASTAR
user interface
1 2 3 LAURASTAR
user interface
1 2 3 LAURASTAR
user interface
1 2 3 LAURASTAR
user interface
1 2 3 LAURASTAR
user interface
1 2 3
LAURASTAR
user interface
1 2 3 LAURASTAR
user interface
1 2 3 LAURASTAR

-7-
Which water should be used?
Your Laurastar has been designed for use with tap water. It is
still absolutely necessary to use the supplied anti-scale lter
(13) in order to benet fully and longer from your Laurastar.
NOTICE: Never use additives (e.g. per-
fumed water), water containing chemical
products or water from tumble dryers as
these products will have a detrimental
effect on the function of your Laurastar.
Storing your system
• To turn your appliance off, press the main ON/OFF button (16).
• Remove the power plug (23) and roll the electric cable around the
feet of the table. If your model has the automatic rewind, pull on the
cable in order to activate the rewind.
• Place the steam hose holder (8) horizontally in the hole designed for
this purpose.
• Place the iron in the iron safety storage box (5). Fold the iron-rest into
the “close” position on top of the table. Hold the table with one hand
on the iron rest side (6). With the other hand grasp the ironing board
(1), tilt the table into the vertical position. HI
• Store your system in a vertical position. You can leave the water in
the reservoir until the next usage.
• NOTE: if you store your system in a horizontal position, you
must empty the water reservoir (11).
EN
MAX
MAX
E
F
D
G
H
I
Preparing the appliance
We recommend that you rinse out the steam generator (15) before us-
ing it for the rst time:
• Check that the plug (23) is disconnected from the mains socket.
• Set the ironing board (1) to its highest position, then remove the
water reservoir (11).
• Place the drain tray(14) beneath the drain cap (22).
• First unscrew the steam generator cap (21), then unscrew the drain
cap (22). D
• Remove the small and the large lid (12) from the water reservoir.
Remove the lter compartment with the lter (13). E
• Fill the water reservoir with warm tap water up to the MAX level. F
• Position the large funnel shaped lid (12) at the place of the water res-
ervoir (11) on top of the steam generator (15) and place the water res-
ervoir above it. G
• Once all the water has own through and the reservoir is empty, screw
the two caps in place again.
• Dispose of the water.

-8-
LAURASTAR
ON/OFF
SenSteam
Pulse
Fan speed
Water
MAX
10 min.
3-5 min.
A
B
C
LauraStar Auto Steam Picto 01/09/16
LauraStar Auto Picto 01/09/16
Start up
CAUTION: ALWAYS ll the water reservoir (11) completely be-
fore turning on your Laurastar. Operating the appliance with-
out water could damage the appliance.
PLEASE NOTE: Operating the appliance without water will
void any limited warranties provided with your appliance.
Installation of the anti-scale cartridge and lling
• Check that the power plug is disconnected from the mains socket.
• Set the ironing board to its highest position.
• Take the water reservoir (11) out. Take off the water reservoir lids.
Install the anti-scale lter(13). A
• Fill the reservoir with tap water. The ltered water has to reach the MAX
level. B
• Close the water reservoir with the lids and put the reservoir back on the
steam generator (15).
• If the water does not ow, soak the anti-scale lter in cold water for 3
minutes.
User interface
• ON/OFF = the green indicator light ashes until the appliance is ready to
be used.
• = Option Laurastar SenSteam. If your appliance is equipped with the
Laurastar SenSteam option (17), the white indicator light signals that the
function is on.
• = Option Pulsed Steam. If your appliance is equipped with the Pulsed
Steam option (18), the white indicator light signals that the function is ON.
Fan speed button (19) = choice of four speeds. The white indicator light
signals the intensity chosen.
• Empty water light (20) = the red drop shaped indicator light signals that
there is no more water in the reservoir (11).
Switching on your appliance
• Insert the power plug (23) in the socket. If your model is equipped with the
automatic rewinder, rst pull the electric cable untill the end-of-cable mark is
visible at the rewinder opening.
• Press the main ON/OFF button (16), the green indicator light will ash for
3-5 minutes. C
• When the green indicator light stops ashing and stays on, the appliance is
ready. You can start ironing.
• NOTE: For your comfort and safety, your Laurastar system will
switch off after 10 minutes of non-use.

-9-
• NOTE: Before ironing, or after an extended break, press the
iron’s steam button (9) 2 or 3 times, while pointing it away
from the clothes. This will release any condensation from the
iron and prevent water marks on the clothes.
CAUTION: Do not point the iron at people or pets while
using vertical steam.
Ironing
Two ironing modes
For the best possible steam ironing result, we offer two modes of ironing :
• Blower mode: Pressing the vacuum/blower button (10) on the
iron activates the fan (24) in blower mode. this blows air into the fabric
from below, helping to reduce unwanted creases.
• Vacuum mode: Pressing the vacuum/blower button (10) again,
activates the fan (24) in vacuum mode. This draws in air, holding the
garment in place on the board to facilitate perfect pleats.
Press the vacuum/blower button (10) to switch from blower to vacuum
mode and vice versa. You can adjust the intensity (4 speeds) pressing
the fan speed button (19) on the user interface of the steam generator.
LAURASTAR SENSTEAM (17) (certain models only)
Laurastar SenSteam (17) allows you to obtain an automatic steam diffu-
sion without pressing the steam button (9). The steam is automatically
activated when the iron moves forward and stops when the iron rests or
moves back C.
To switch back to regular mode, press the Laurastar SenSteambutton
(17) again.
PULSE(18) (certain models only)
Press the pulsed steam button (18) to activate the pulse function. Then
press the steam button (9) to automatically generate small and regular
steam jets D. To switch back to regular mode, press the pulsed steam
button again (18).
Steam principle
Perfect ironing requires diffusion of steam across the fabric, in order to
relax the bres, and drying to x them in place. Creases can only be
completely removed if these conditions are present.
Advice: For best results, rst iron the item with steam and then iron it
again without steam, thereby enabling the iron to dry the fabric.
EN
2-3 x
A
B
C
D
B
A

-10-
Protective soleplate(27)
The protective soleplate is indispensable for dark-coloured fabrics which can
become shiny, for delicate fabric like silk and synthetic fabrics which have a
tendency to stick to the iron.
Using the protective soleplate (27):
• First place the tip of the iron (2) at the front of the protective soleplate
(27) and lower the iron to x it in place in the soleplate.
• Wait approximately 2 minutes for the soleplate to reach the correct
temperature.
• To remove the protective soleplate, pull on the tab and remove the iron
while it is still hot.
WARNING: The protective soleplate is hot! Use caution
when you remove the protective soleplate.
NOTICE: ALWAYS remove the protective soleplate after use.
Advice: For mohair, cashmere, velvet and angora: do not allow the fabric to
come into contact with the protective soleplate (27). Iron the fabric at a dis-
tance of approximately 10 cm (4 in) while diffusing steam, so that the fabric
does not become felted. Then take the item of clothing in your hand and
shake it to restore its volume.
For velvet, corduroy and jersey, we recommend steaming without the pro-
tective soleplate (27) at around 2-3 cm (1-2 in) from the fabric, then level-
ling out by hand.
Vertical smoothing out
Suspend the item of clothing on a hanger or on the vertical support brack-
et (available on www.laurastar.com or at your approved Laurastar retailer).
Moving the iron from top to bottom, lightly touch the fabric using short bursts
of steam. Note: almost all fabrics smooth out easily, with the exception of
cotton, linen and certain silks. H
If a fabric is difcult to smooth out, place it on the ironing board and iron it
normally.
WARNING: Do not iron or vertical steam clothes that are
being worn. Do not point vertical steam in the direction of
people or pets.
10 cm / 4
in
E
F
G
E
F
G
H
