LAVA HQ-ST Link
System Manual
Rev. A00

Rev. A00 HQ-ST System Manual Page i
Table of Contents
Introduction 1
System Design 1
Theory of Operation of the LAVA HQ-ST Link 1
Primary Hardware Components of the HQ-ST System 2
ST Plus 2
HQ Plus 3
Secondary Hardware Components of the HQ-ST System 4
HQ Remote Console 4
HQ Remote Poller 4
Software Components of the HQ-ST Link System 5
HQ Basic Software 5
ST Plus Configuration Console 5
LAVA Ether Link Manager Utility 5
LAVA HQ Plus Install 6
Equipment Needed 6
General 6
METHOD #1: Headquarters Installation using HQ-Basic (recommended method) 6
METHOD#2: Headquarters Installation using Ether Link Manager and the Web Page 9
LAVA ST Plus Install 12
Equipment Needed 12
General 12
Installation of ST Plus Devices at the ECR Equipment Sites 12
ST Configuration Console: Operation 16
Hardware Connection 16
Software Connection 16
HQ Basic: Operation 19
Hardware Connection 19
Software Connection 19
APPENDIX A: Installation Checklist 21
APPENDIX B: Verify Access to the Internet from the LAN 23
APPENDIX C: Check that the LAN Provides DHCP Setting Configurations to Devices on the LAN 24
APPENDIX D: Check that the Selected HQ Site has a STATIC WAN IP Address 25
APPENDIX E: Test that the HQ Site is Properly Set Up and Working: HQ Plus Installed 26
APPENDIX F: Test the End-to-End HQ-ST Link Communications: HQ and ST Installed 27
APPENDIX G: Troubleshooting 28
APPENDIX H: Master Reset to Factory Defaults 30
APPENDIX I: Installing the HQ Plus on the PC as a (TAPI) Modem 31
APPENDIX J: Windows Installation Tools for Use with HQ Plus and ST Plus Devices 32
Web Page Interface on HQ Plus and ST Plus 32
PING Function 32
IPCONFIG Function 32
HyperTerminal 32
TELNET 32

Rev. A00 HQ-ST System Manual Page 1 of 32
Introduction
System Design
The LAVA HQ-ST Link consists of ST Plus devices installed at each store. The ST Plus devices communicate with an
assigned and dedicated HQ-Plus device at the head office. The ST Plus devices are attached to the cash register(s) in
each store, and to the store's Internet connection. Polling software running on a head office computer can poll each
cash register, via the HQ Plus.
The system is supported by the included ST Plus Configuration Console application, which makes configuring ST Plus
units simple, and at the head office by the HQ Basic application, which shows the connection status of ST Plus devices
in stores.
The system is also enhanced by the HQ Plus Remote Console and the HQ Plus Remote Poller, hardware interfaces that
enable an installer or owner to perform head office tasks from other locations.
Theory of Operation of the LAVA HQ-ST Link
A LAVA HQ-ST Link provides reliable "always on-line" communication path between remote/distributed ST Plus
devices and a centrally located HQ Plus device. The ST Plus establishes a TCP/IP connection to the IP address:TCP port
of a designated HQ Plus. This connection then provides the HQ Plus with the current IP address:TCP port of the ST Plus.
Whenever the ST Plus is reset or powered up, the ST Plus establishes this connection, and expects the HQ Plus to send
an "I (HQ Plus) still see You (ST Plus)" packet to the ST Plus once every three minutes at a minimum. If the ST Plus does
not receive this “keep-alive” message from the HQ Plus, the ST Plus will reset and try to re-connect to the HQ Plus.
Similarly, in the event of some change at the ST Plus's site, the ST Plus will re-connect to the HQ Plus. Typical incidents
could be: power cycling off and on, an IP address change of the ST Plus due to dynamic IP address re-assignments , re-
location of the ST Plus, initial installation of the ST Plus, interruption of Internet service, and so on.
The HQ-ST System provides a "telephone modem-like communications environment" to the equipment connected at
both ends. However, the data path between the ST Plus and HQ Plus is over Ethernet using TCP/IP communications.
The Ethernet TCP/IP communications are used only as the communications medium between the HQ Plus and the ST
Plus devices, and are "invisible" to the serial side data I/O activities at the HQ Plus and ST Plus devices.
Figure 1: HQ-ST Layout

Rev. A00 HQ-ST System Manual Page 2 of 32
Primary Hardware Components of the HQ-ST System
The ST Plus and HQ Plus are the two essential hardware components in an HQ-ST Link. ST Plus devices, attached to
ECRs in stores, connect to their assigned HQ Plus device located at a head office.
ST Plus
The ST Plus is a device operates as a TCP/IP Raw Client, with the intention of providing a store-side serial-to-Ethernet
interface to an ECR or other similar device.
The ST Plus provides a serial port with the I/O characteristics and pin-out of a USR-type modem with a DB-25F
connector. To make a serial-to-serial connection from the HQ Plus's serial port to the ST Plus's serial port the
originating equipment connected to HQ Plus (typically a computer running ECR polling software) sends a dialing
string (ATDT5551234, for example) that causes a connection to be made to the serial port of the specific ST Plus (in this
example, known as 5551234) to which the receiving equipment (the ECR to be polled) is connected.
Figure 2: ST Plus
Figure 3: ST Plus: front connections

Rev. A00 HQ-ST System Manual Page 3 of 32
Figure 4: ST Plus: rear connections
HQ Plus
The HQ Plus operates as a TCP/IP Raw Server, with a known IP:Port address. The HQ Plus is intended to provide a head-
office serial-to-Etherenet interface for a polling application to access remotely located device to be polled.
The HQ Plus provides a modem-like serial interface (US Robotics (USR) command set, DB-25F connector), that is used
by an external device such as a PC to make a "telephone - modem" call (that is, using a conventional modem dialing
string of the format: ATDT5551234).
The HQ Plus comes in versions that support up to 126, 30, or 8 ST sites.
Figure 5: HQ Plus-126, HQ Plus-30, HQ Plus-8
A set of LEDs on the HQ Plus indicates the status of the serial ports of the device, and the number of active ST Plus
connections.
Figure 6: HQ Plus LEDs
The number of active connections has a binary representation. When there are no active connections, the connection
LEDs light and unlight in sequence, creating a “bit walk”. When connections exist, the number of connections is
represented by the sum of the values in each box above. For example, if the “64”, “4”, and “1” LEDs were lit, the number
of active connections would be 69.

Rev. A00 HQ-ST System Manual Page 4 of 32
Secondary Hardware Components of the HQ-ST System
The HQ Remote Console and HQ Remote Poller provide the capability to locate a parallel "HQ site" which can be
readily re-located. The HQ Remote Console and the HQ Remote Poller can be deployed as standalone devices, at the
same or at separate sites. Enabling and disabling of the remote devices is controlled from the main HQ Plus through
the HQ Basic software control to allow or disallow remote console and remote poller functions accesses.
HQ Remote Console
Figure 7: HQ Remote Console: DB-9F serial connector
The HQ Remote Console provides an output of the "current connection status" of the system, via the serial port on the
HQ Remote Console device.
The data output is a "duplicate" of the output from the main HQ Plus, which may be located elsewhere on the WAN,
LAN, or Internet.
The PC that is connected to the serial port of the HQ Remote Console runs the HQ Basic utility. The same control
capabilities exist at the HQ Remote Console site at the main HQ Plus.
The HQ Remote Console can be located anywhere where there is an Internet communication capability available. Only
one HQ Remote Console may be associated with any one HQ Plus, and the site LAN requirements are the same as for
an ST Plus installation.
The HQ Remote Console communicates with the main HQ Plus in a way similar to that used by a standard ST Plus.
HQ Remote Poller
Figure 8: HQ Remote Poller: DB-25F serial connector
The HQ Remote Poller hardware provides the capability to use polling software applications to poll and communicate
with the ST Plus devices that are "connected" to the main HQ Plus.
Only one HQ Remote Poller may be associated with any one HQ Plus.
The site LAN requirements are the same as for an ST Plus installation.

Rev. A00 HQ-ST System Manual Page 5 of 32
Software Components of the HQ-ST Link System
While not essential to the main task of polling over IP, the following components supplement the basic HQ-ST Link and
and assist installation or are required for device configuration .
HQ Basic Software
This system management utility, supplied with HQ Plus hardware, provides configuration interfaces for HQ Plus and
ST Plus devices, and presents a tabular view of the state of all ST Plus connections current on a given HQ Plus. It also
provides rudimentary connection logging and debugging information, and a live “chat” interface for HQ-ST system
administrators to communicate with installers in the field.
HQ Basic resides on the host PC, which is connected to the Console port of the HQ Plus. It is loaded from the LAVA
Installation CD.
See “HQ Basic: Operation” on page 19.
ST Plus Configuration Console
This application, supplied with ST Plus hardware, provides a configuration interface for ST Plus devices, and a live
“chat” interface for installers to communicate with a head office.
This utility resides on a PC host and is used via the serial port of the ST Plus. It is loaded from the LAVA Installation CD.
Connect the serial port of the host PC to the serial port of the ST Plus, start the utility, select the COM port, then cycle
the power to the ST Plus. The ST Plus Configuration Console communicates with and is ready to configure the ST Plus.
Note: there is a five second access-to-start window, after ST Plus power-up.
See “ST Configuration Console: Operation” on page 16.
LAVA Ether Link Manager Utility
This device management utility is used to locate, display, and configure the current network settings of the LAVA HQ
Plus and ST Plus devices, and to indicate the network settings of the Host PC that is connected to the LAN. The Host PC
network settings can be used to assist in selecting the static IP settings that may be required by the HQ Plus and ST
Plus (if DHCP is not available) for operation on the LAN.
This utility operates on a LAN only. The LAN must not block UDP broadcast packets. Network security programs/
firewall may need to be disabled or edited to allow the UDP broadcast packets on the LAN.
The Host PC may be connected directly to the HQ Plus or ST Plus via a standard Ethernet cross-over cable, in order to
bypass using the LAN environment.
The utility is downloaded from www.lavalink.com.

Rev. A00 HQ-ST System Manual Page 6 of 32
LAVA HQ Plus Install
Equipment Needed
To set up an HQ Plus for polling you will need:
• polling software [not supplied]
• LAVA HQ Basic software (See “HQ Basic: Operation” on page 19.)
• LAVA HQ Plus with power supply (do not confuse power supply with that of ST Plus)
• Windows-based PC with 2 available COM ports (2 x DB-9) [not supplied] (two separate computers could also be
used for polling software and HQ Basic software if desired)
• one Ethernet cable (CAT-5 UTP with RJ-45 connectors) [not supplied]
• one straight-through serial cable (DB-25M to DB-9F) [not supplied]
• one straight-through serial cable (DB-9M to DB-9F) [not supplied]
General
HQ Plus devices communicate over Ethernet LAN/WAN facilities. The devices must be configured with the appropriate
IP addresses and port numbers for the specific LAN onto which these devices are to be connected.
The installer must know the correct network parameters to configure HQ Plus devices for operation.
METHOD #1: Headquarters Installation using HQ-Basic (recommended method)
Before Proceeding: Complete the relevant network parameters checklists on the LAN
• See “Verify Access to the Internet from the LAN” on page 23.
• See “Check that the LAN Provides DHCP Setting Configurations to Devices on the LAN” on page 24.
• See “Check that the Selected HQ Site has a STATIC WAN IP Address” on page 25.
Important: The headquarters site requires static IP addresses — the HQ LAN IP address must be static, AND the WAN
address of the HQ LAN site device must be static.
The WAN/Internet IP address must be a known STATIC IP address (or an assigned DNS name). Use Internet Explorer to
access www.whatismyip.com to verify the address. Also verify that this is so by accessing the setup parameters of the
gateway/router that is to be used to provide the access to the Internet for the LAN.
Note: The HQ site may (as an option) have a DNS name, which can be used by Internet users instead of the STATIC IP, to
connect to the HQ site.
Important: Port forward the two port numbers associated with each HQ Plus on the LAN.
1. Connect the HQ Plus “Console” port to a PC’s COM port using the DB-9M to DB-9F cable. Supply power to the HQ
Plus.
2. Install and run the HQ Basic management software on the computer attached to the HQ Plus.
3. Choose the COM port to which the HQ Plus is attached and click “Connect”.

Rev. A00 HQ-ST System Manual Page 7 of 32
4. Once connected, double-click on the last entry in the table (the entry is named “CONSOLE LOCAL” and denotes
the HQ Plus that is currently connected).
5. In the Network Settings screen that appears, enter at least the following: the IP address of this HQ Plus (factory
default is 192.168.0.35) and an Identification Key matching that used by ST Plus units targeting this HQ Plus
(factory default is a string of zeros). LAVA recommends changing the Identification Key from this factory default to
one personalized to your system for full security.

Rev. A00 HQ-ST System Manual Page 8 of 32
6. The default values in the Serial Settings tab are for display only and cannot be changed.
7. The serial settings in the “Modem Settings” tab must be set to match those used in the polling generally (that is,
those of the ECR, ST Plus, and polling software).

Rev. A00 HQ-ST System Manual Page 9 of 32
8. The modem settings on the right hand side of this tab may not need to be changed, depending on the particular
modem requirements of the polling software. LAVA suggests starting with them at their default values.
9. Connect the HQ Plus “Modem” port to the PC’s second COM port using the DB-9F to DB-25M serial cable.
10. Connect the HQ Plus’s Ethernet port to the store LAN on which the “Default Gateway” is located.
11. Map a TCP port nnnn (default port number is 4098) on the headquarter’s gateway to allow control and
negotiation data to pass to remote units. Consult your router's documentation for this step.
12. Map a TCP port nnnn+1 (default port number is 4099) on the headquarter’s gateway to allow modem data to pass
to remote units. Consult your router's documentation for this step.
13. Test the link.
See “Test that the HQ Site is Properly Set Up and Working: HQ Plus Installed” on page 26.
See “Test the End-to-End HQ-ST Link Communications: HQ and ST Installed” on page 27.
14. Attach the PC that will host the polling software. The serial port of the polling host PC should be connected to the
“Modem” port of the HQ Plus. In general, it is most trouble-free to configure the serial port of the polling host PC
to match the serial port of the HQ Plus, and to ensure that serial settings and connections end-to-end (from
polling software to polled device) are consistent.
15. If necessary, troubleshoot the link using the troubleshooting chart:
See “Troubleshooting” on page 28.
16. POLL AWAY!
METHOD#2: Headquarters Installation using Ether Link Manager and the Web Page
Before Proceeding: Complete the relevant network parameters checklists on the LAN
• See “Verify Access to the Internet from the LAN” on page 23.
• See “Check that the LAN Provides DHCP Setting Configurations to Devices on the LAN” on page 24.
• See “Check that the Selected HQ Site has a STATIC WAN IP Address” on page 25.

Rev. A00 HQ-ST System Manual Page 10 of 32
Important: The headquarters site requires static IP addresses — the HQ LAN IP address must be static, AND the WAN
address of the HQ LAN site device must be static.
The WAN/Internet IP address must be a known STATIC IP address (or an assigned DNS name). Use Internet Explorer to
access www.whatismyip.com to verify the address. Also verify that this is so by accessing the setup parameters of the
gateway/router that is to be used to provide the access to the Internet for the LAN.
Note: The HQ site may (as an option) have a DNS name, which can be used by Internet users instead of the STATIC IP, to
connect to the HQ site.
Important: Port forward the two port numbers associated with each HQ Plus on the LAN.
1. Assign STATIC Network IP parameters to each HQ Plus
Use the LAVA Ether Link Manager utility (See “LAVA Ether Link Manager Utility” on page 5.) to configure the LAN
NETWORK settings of the HQ Plus, then (on knowing the IP address of the HQ Plus) use the web page (See “Web
Page Interface on HQ Plus and ST Plus” on page 32.) to configure any parameters on the HQ Plus.
2. Confirm that two TCP socket ports are assigned to each HQ Plus
The default ports are 4098 and 4099, (that is, a base port and a base+1 port). Use the web page interface to the HQ
Plus to configure the base port number of the HQ Plus. The second port number is computed automatically based
on this first value.
3. Forward the HQ Plus IP address base and base+1 ports
Port Forward the HQ Plus IP address base and base+1 ports, through the gateway to allow access to the HQ Plus's
IP address:ports from the Internet. Use the information provided on www.portforward.com to accomplish the
"port forwarding" procedure on your particular installed gateway/router.
4. Configure the serial I/O parameters
Configure the serial port of the HQ Plus to match the requirements of the equipment that is to be connected to
the serial port of the HQ Plus.
SPECIAL NOTE: Some application software programs that communicate with a serial modem expect that the
"modem" is installed as a TAPI device under Windows. In this case follow the procedure to install the HQ Plus as a
Generic 56K Modem on a selected Com:n port, set the baud rate as required for the equipment, and set the option to
operate WITHOUT waiting for Dial Tone. Once the device is "installed", re-boot the PC then do a test by querying the
modem to verify the correctness of the "modem installation". See “Installing the HQ Plus on the PC as a (TAPI) Modem”
on page 31.
Some application software programs only expect that an external modem is connected to a serial port on the PC. In
this case connect the HQ Plus to the appropriate Com:n serial port. The application program will send AT commands
through the serial (com:n) port to the HQ Plus.
5. Record important settings
Information to be noted: Keep this information on hand for reference when setting up the ST Plus devices, and for
test/troubleshooting purposes.
Internet (WAN) IP address of the HQ site. This is the "call home" IP address that will be entered into all ST Plus devices
that are to communicate with this HQ Plus on IP(WAN):port/s.
Base and Base+1 Ports assigned. The Base Port number will be entered into all ST Plus devices, as part of the unique
"call home" IP address information, of the HQ Plus. Note several HQ Plus devices can be located at the site, but each HQ
Plus will be uniquely identified by its assigned Base Port number.
6. Test the link.
See “Test that the HQ Site is Properly Set Up and Working: HQ Plus Installed” on page 26.
See “Test the End-to-End HQ-ST Link Communications: HQ and ST Installed” on page 27.

Rev. A00 HQ-ST System Manual Page 11 of 32
7. Attach the PC that will host the polling software. The serial port of the polling host PC should be connected to the
“Modem” port of the HQ Plus. In general, it is most trouble-free to configure the serial port of the polling host PC
to match the serial port of the HQ Plus, and to ensure that serial settings and connections end-to-end (from
polling software to polled device) are consistent.
8. If necessary, troubleshoot the link using the troubleshooting chart:
See “Troubleshooting” on page 28.

Rev. A00 HQ-ST System Manual Page 12 of 32
LAVA ST Plus Install
Equipment Needed
To set up an ST Plus for polling you will need:
• LAVA ST Plus Configuration Console software
• LAVA ST Plus with power supply (do not confuse power supply with that of HQ Plus)
• Windows-based PC with 1 available COM port (1 x DB-9) [not supplied]
• one Ethernet cable (CAT-5 UTP with RJ-45 connectors) [not supplied]
• one straight-through serial cable (DB-25M to DB-9F) [not supplied]
General
ST Plus devices communicate over Ethernet LAN/WAN facilities. The devices must be configured with the appropriate
IP addresses and port numbers for the specific LAN onto which these devices are to be connected.
The installer must know the correct network parameters to configure ST Plus devices for operation.
In general the ST Plus is very easy to install on a LAN that has DHCP support. If the LAN does not provide DHCP, then
determine or obtain the set of static IP addresses that are to be used by the ST Plus on the LAN:
• IP address of the ST Plus
•NetMaskIP
•GatewayIP
• DNS IP (required if DNS is used to contact HQ site)
Make a note of these IP addresses. They will be entered as part of the network settings of the ST Plus.
The essential operating parameters will typically be pre-configured before installation at the remote location.
1. Use the ST Configuration Console or web page interface to set up the ST Plus for the HQ-ST Link operating
requirements. The essential parameters are:
• Network settings - either DHCP or static IP settings
• Call Home IP address and port - these are the IP:(base) port of HQ Plus
2. Use the ST Configuration Console or web page interface to set up the ST Plus optional parameters.
Optional parameters include:
• Device Name: for location identification
• Store Telephone: ID, "tel" number used by the polling software
Installation of ST Plus Devices at the ECR Equipment Sites
Before Proceeding: Complete the relevant network parameters checklists on the LAN
• Complete the site Installation Checklist. See “Installation Checklist” on page 21.
• See “Verify Access to the Internet from the LAN” on page 23.
• See “Check that the LAN Provides DHCP Setting Configurations to Devices on the LAN” on page 24.
1. Install the ST Plus Configuration Console software on the computer and open the application.
2. Connect a straight-through serial cable to the serial port of the ST Plus and to the computer with the ST Plus
Configuration Console software. Choose the COM port to which the ST Plus is attached and click “Connect”.
3. Cycle power on the ST Plus. On ST Plus boot-up, the data fields of the ST Plus Configuration Console will be
populated with the settings of the ST Plus.

Rev. A00 HQ-ST System Manual Page 13 of 32
4. In the screen that appears, DHCP should be checked on (unless you are manually configuring network settings).
5. The fields “Home IP/Port” and “Device Tel No.” must be completed.

Rev. A00 HQ-ST System Manual Page 14 of 32
6. The Identification Key must match that of the HQ Plus to which you are connecting.
7. Set the correct serial port settings. They should match the settings of the polling software, the ECR's
communications port, and the HQ Plus modem port.
8. Connect the Ethernet port of the ST Plus to the store's LAN. Click "Write" and then click “Run”. You should see a
time stamp and a “Connected to Unit: [device name]” message in the Message dialog window.
9. Select the mode of ST Plus operation: STOP, RUN, ACTIVATED.
Operating modes are as follows:
STOP. In this mode the ST Plus is not communicating to an HQ Plus. The ST Plus can be fully re-configured using the ST
Config utility or the web page interface, and LAVA Ether Link Manager.

Rev. A00 HQ-ST System Manual Page 15 of 32
RUN. Enter this mode after the ST Plus is set up, to test if it can open a connection to the designated "call home"
IP:port of an HQ Plus. In this mode the ST Plus will connect to the HQ Plus, and remain connected and fully operating,
until the ST Plus is reset or power cycled . After a reset or power cycling, the ST Plus will revert to STOP mode.
Run mode is typically used for testing the setup configuration or re-configuration, prior to placing the ST Plus into fully
operational mode.
Access the web page of the ST Plus to check its connection status.
When the ST Plus is in Run mode the LAVA Ether Link Manager will not "locate/find" the ST Plus.
ACTIVATED. This mode is the normal operating mode for the ST Plus. The device will always attempt to re-connect to
the HQ Plus's IP:port as designated by the “Home IP” entry of the ST Plus.
Select this mode only if all ST parameters are set, and correct.
Access the web page of the ST Plus to check its connection status.
When the ST Plus is in Activated mode, the LAVA Ether Link Manager will not "locate/find" the device. In this case, use
the ST Configuration Console to make any changes. The user may also make changes to the ST Plus's configuration by
using the HQ Basic software utility running at the head office site, or by using an HQ Remote Console device at any
location.
NOTE: As an option, the basic network parameters can be set using the ST Configuration Console, and STOP mode
selected, thereby allowing the installer to access the web page interface of the ST Plus to complete configuring the ST
Plus for operation.
10. Test the link.
See “Test the End-to-End HQ-ST Link Communications: HQ and ST Installed” on page 27.
11. Attach the device to be polled (ECR or POS station). In general, it is most trouble-free to configure the serial port of
the ST Plus to match the serial port of the ECR or POS station.
12. If necessary, troubleshoot the link using the troubleshooting chart:
See “Troubleshooting” on page 28.
13. POLL AWAY!

Rev. A00 HQ-ST System Manual Page 16 of 32
ST Configuration Console: Operation
The ST Configuration Console provides a Windows-based interface for users to configure the network and serial port
settings of an ST Plus device. These settings are required for the operation of the ST Plus in an HQ-ST Link.
It also provides an interface for supplying store-specific information for storing in an ST Plus. These details are not used
for connectivity, but may be used as contact information or for store identification from the head office.
Hardware Connection
The ST Configuration Console software runs on a host PC that has a serial port connected to the serial port of the ST
Plus device, using a straight-through serial cable. The ST Plus end of the cable will need a DB-25 male connector; the
host PC end of the cable will probably need a DB-9 female connector (depending on the serial port connector being
used on the host PC).
Software Connection
NOTE: The ST Plus Configuration Console software can only establish a connection to the attached ST Plus in the five
second interval following the powering on of the ST Plus device. The serial port of an ST Plus device is designed to fall
back to an operational mode after this five-second window.
To establish a connection between the ST Plus and the ST Plus Configuration Console, follow the following steps:
1. Connect the serial port of the ST Plus to the serial port of the host PC that the ST Plus Configuration Console will
use.
2. Start the ST Plus Configuration Console software.
3. Ensure that the serial port selected in the dialog box at the bottom left of the ST Configuration Console screen
matches the physical port that is cabled to the ST Plus device.
4. Click on the “Connect” button.
5. Cycle the power on the ST Plus device. The ST Plus Configuration Console will detect that an ST Plus is attached
and available, and query the device.
6. Data from the ST Plus will populate the fields of the ST Plus Configuration Console, and the word “Connected” will
appear at the top of the ST Plus Configuration Console screen (see below).

Rev. A00 HQ-ST System Manual Page 17 of 32
Figure 9: ST Configuration Console: Network configuration screen
7. At a minimum, you will need to set up the network connectivity, the home IP/port, and the identification key.
• LAVA recommends using DHCP at the store, to simplify connectivity. If you are configuring the network manually,
you wil need to supply the ST Plus with an IP address (IP Address) , a subnet mask (Subnet Mask), and an address
for the network’s gateway (Default Gateway).
• The “Home IP/Port” settings are the IP address and port for the HQ unit that will be used to poll this ST Plus.
• The Identification Key is a user-configurable security value that ensures that only HQ Plus devices and ST Plus
devices with matching identification keys will communicate with each other.
8. Optionally, you can supply the device telephone number (Device Tel No), which is the number that the polling
software will use when “dialing” to the ST Plus.
9. Screens are available to configure the ST Plus serial port to the requirements of the ECR and polling software that
will be used, and to input store-specific information.

Rev. A00 HQ-ST System Manual Page 18 of 32
Figure 10: ST Configuration Console screens: Serial Settings, Store Info, Manager Info
Figure 11: ST Configuration Console screens: Technical Info, Security Info
