Lawmate HT-18 User manual

V1.0
HT-18
CCD Camera in Sport Cap Design
Operation Manual
Law Enforcement Products Manufacturer
LawMate
User Instruction: HT-18 Connections Illustration
HT-18 mainly uses to capture images. This model improves
acoustic collection with built-in microphone. There are two
application methods to use this device:
HT-18 can connect with a portable DVR:
1. Install the device same as Installation 1 shown above.
2. Insert HT-18 jack into A/V IN DC 5V OUT socket of the portable
DVR device.
3. Press POWER-ON button of portable DVR for 3 seconds and
release the button. Note that HOLD button should switch to left
when press POWER-ON button.
4. A green light will turn on to show that DVR device is turn-on
properly.
5. Press REC button to start recording.
6. Captured images are automatically shown on LCD display.
7. Audio and video signals are automatically collected into
recorded file on DVR.
HT-18 can also output captured audio and video signals
to an external display through AV switching cable:
1. Install the device same as Installation 2 shown above.
2. Slide the back cover of battery holder, BHD-SQ9V, to open the
battery tray.Insert a PP3 (9V) battery with proper cathode/anode
direction into battery tray.Switch to ON indication. PP3
(9V) battery supplies power to the connected camera, HT-18.
3. The yellow and white color cable heads from switching cable,
S-PJ3R, are to connect with the external audio and video jacks
from monitor/television.
4. At the other end of switching cable, S-PJ3R, is a jack socket
connected with jack from HT-18.
5. Captured images are automatically shown on the connected
monitor/television.
6. Audio and video signals are automatically collected into the
recorder connected with monitor/television. Noted that external
monitor/television is required to connect with an audio and
video recording device.Camera does not provide recording
function itself.
HT-18 connects to portable DVR HT-18 AV output connection
CCD Camera
9V Battery Holder
Microphone
Switching Cable
Optional Accessories
Portable DVR- PV-1000Touch
Optional Accessories
Portable DVR- PV-500EVO2/PV-500L2
Installation 1
Installation 2
Microphone
CCD Camera
