Lawson Hammock BLUE RIDGE CAMPING HAMMOCK User manual

!!!!!!!Lawson! Hammock!
!!!!!!!!! BLUE RIDGE CAMPING H A MM OC K !
!!!!!!!!!!!!!!! These parts are inside your stuff sack, ready to assemble:!
!
!
!
!
H A M M O C K W / C O L L A P S E D S P R E A D E R B A R S
!
!
!
!
A R C H P O L E S R A I N F L Y / T A R P
!
!!!!!
1!!!!!!At each end of the unrolled hammock, join spreader bar halves.!
Make sure ropes are not tangled or twisted. Check all knots on ropes
attached to hammock bed for tightness. Ropes may stretch with use,
requiring occasional re-tightening.!
!
!
!
B
!
!
!
!
!
T Y I N G A B O W L I N E
!
!
!
!
!
A
!
!
!
2Hang hammock between two trees or sturdy upright objects using!
Tree Huggers (sold on our website), other straps or rope/webbing
as shown. Attach hanging rope at hammock end loop with a
bowline or other strong knot, and wrap rope at least once around
tree before re- attaching to hammock end loop with another
bowline (see detail above). NOTE: Tie 3–4’ off ground, keeping
rope & hammock taut.!
3
!!
Once hammock is hung, fit together the two shock-corded aluminum
arch poles and slide one through each sleeve on top of hammock.
Insert end of each pole through grommet as shown (detail A). Attach
snap hooks on elastic cords at ends of hammock to tops of arch
poles (detail B). Shorten elastic if necessary to keep canopy tight.!
!
!
!
!
!
A
!
!
!
!
!
B
W R A P
U N D E R
R O P E S
& C L I P
BIVY SETUP: Follow above instructions, but do not hang (#2). Instead, use
stakes to stretch & secure both ends of hammock to ground as shown.
Continue with steps #3–4.
!
!
4!!!!
To use rainfly, extend over hammock, attaching hooks at each end
to hammock end loops (detail A). Attach snap hooks at rainfly
corners to adjacent hammock ropes (B). Fit elastic loops on rainfly
sides around bottoms of arch poles (C). Attach Velcro® tabs on
rainfly sides to Velcro® tabs on hammock bottom. Rainfly will
appear loose when hammock is empty. If tightening is necessary,
attach snap hooks from B farther in on hammock ropes, or knot
elastic cord from A.!
!
!
!
!
!
!
!
!
SEE REVERSE FOR NOTES & CARE

N O TES/TIPS:
!
Always open net door completely before entering. Sit in the middle of the
hammock with both feet on ground. Carefully swi ng feet in and lie down.
Reverse steps to exit. Never step or jump in.
The bowline knots recommended for tying your hammock ropes tighten
with use, but may be slightly loosen when hammock is new or hasn’t been
used recently. Before you enter the hammock, always check knots and
tighten ropes as necessary.
One person at a time in the hammock — weight limit 275 lbs.
Don’t leave children unattended in the hammock. This is not a toy;
children should use the hammock only with adult supervision.
Keep hammock away from fire or flame. Parts of the hammock have been
treated with fire retardant, but the hammock & rainfl y will burn if kept in
contact with flame or high heat source.
If using the hammock in colder temperatures, attach the rain fly
to help contain body heat. For added insulation, secure a sleeping bag or
emergency blanket to the hammock floor or an under-quilt beneath the
hammock.
To protect trees, wrap your hanging rope around several times
For lounging without bug netting, take arch poles out (flip hammock
over if desired).
Tie off/stake down the four corners with cord (attach cord to the
black, webbing loop tabs where arch poles connect to grommets)
for increased stability.
CARE:
!
Your Blue Ridge Camping Hammock has been seam sealed, and the rainfly,
buffer zone and bottom are urethane coated. Check every season that the
seams are still sealed; apply additional sealer if necessary. Seam sealing is
made easier by hanging the hammock to reach all inside seams. Be sure to
liberally coat all areas of higher stress, such as the head and foot of
hamm ock.
Before putting away, be sure that both the hammock and rainfly are dry
and free of debris. Store in a dry place away from heat . Do not store on
concrete, which contains chemicals that can harm the hammock fabric
and its finish.
Avoid contact with substances that can compromise the fabric & coating,
such as solvents, hair & insect spray, fruit juices, etc.
To clean, hand wash with mild soap and rinse well with clean water. Do not
use strong detergents or wash in a machine.
Lubricate the zipper with silicone if necessary. Do not attempt to force a
jammed zipper — this could ruin the zipper tab as well as the fabric. Keep
the tab clean and free of dirt or sand.
If the material should rip, use a rip-stop/tent repair tape to patch.
Seam sealer will close small holes. Discontinue use if grommets come out
— hammock bed could rip.
Do not hang gear from, sit on, or otherwise add weight or stres s to the
spreader bars, as they may break.
!!!
!
LAWSON HAMMOCK LIMITED WARRANTY !
!
Lawson Hammock Co. warrants to the original purchaser that its products are free from defects in material and workmanship for the period of one (1) year from date
of purchase. The product must be returned, freight prepaid, and with proof of the date of purchase, to the Lawson Hammock dealer from whom this product was
purchased . If purchased direct from Lawson Hammock, please contact us via email or phone.
If after inspection we find that the product was defective in material or workmanship we shall at our option either repair or replace it without charge. We are not
responsible for normal wear and tear or for defects caused by accident, abuse, alteration, misuse, or improper care.
There are no other express warranties beyond the terms of this limited warranty. In no event shall any implied warranties, including merchantability and fitness for a
particular purpose, extend beyond the duration of the express warranty contained herein. In no event shall Lawson Hammock Co. be liable for incidental or
consequential damages.
Some States do not allow limitations on how long an implied warranty lasts or the exclusion or limitation of incidental or consequential damages, so the above
limitations may not apply to you.
If you have any questions regarding your Blue Ridge Camping Hammock please contact us at [phone] or
[e-mail] . We welcome feedback of any kind that will help us evaluate our products.
!
Thank you,
Lawson Hammock Company
Please follow @LawsonHammock on Instagram, Facebook and Twitter for additional information, photos and updates.
We love receiving your hammock photos! Please email to i[email protected] and we may post them on our website and/or
social media pages.
Fabric Composition: Hammock, rainfly & net – 100% Nylon/Polyester. Covered under US patent.
Lawson Hammock • 1217 Pierce St. • Raleigh, NC 27605 • [phone] • www.lawsonhammock.com
