LCG LCG-WIDMX-RCB User manual

www.lc-group.ca LCG-WIDMX-RCB User manual
LCG-WIDMX-RCB
Wireless DMX512 Receiver (Lithium
Battery)
Built-in rechargeable lithium battery,
plug and play
FHSS with 79 Channels,
interference-free operation.
32-bit ARM Processor, DMA transfer
without delay
Standard DMX512 3-pin XLR,
Through XLR power supply design
One-touch operation with a Tri-color
status indicator
Built-in Wireless Solution Compatibility
Mode
Automatically learning of various
parameters of controller, just like DMX
transfer via cable
Group Mode, easy plug-and-play operation; Pairing Mode, supports more
transmitter universes
Overview
LCG-WDMX-RCB is unique in its use of advance radio technologies that are
also used in military communication and mobile phones. That is 2.4GHz ISM
Band (license-free worldwide) and GFSK Modulation (more efficient
transitions).Its user-friendly operation that simplifies all the complex
communication protocols makes it possible for the users to just plug and play.

www.lc-group.ca LCG-WDMX-RCB User manual
Multiple Communication Protocol, There are no upgrading troubles
LCG-WDMX-RCB is now compatible with the world's leading wireless
communication protocols like the Sweden’s protocol or the GZ protocols. There
are no upgrading troubles.
Application
Stage lighting applies to the Grand Variety Show, Gymnasium, Temporary
Set-up Stage, TV Station, Centers Conference, Theaters, Opera, Theme
Parks, Dance Halls, and Bars, or any lighting equipment with standard
DMX512 XLR etc.
Appearance

www.lc-group.ca LCG-WDMX-RCB User manual
Description of Status Indicator
1）In the Set-up mode, different colors mean different communication
protocols:
1. Red ----------------- WIDMX Protocol
2. Green -------------- W-DMX Receive Protocol
3.Yellow ------------- Guangzhou(GZ) Protocol
2）In the User mode, Description of Status Indicator:
Protocol
Action
Status Description
WIDMX or
GZ Protocol
Red, Green, Blue,Yellow,
Cyan, Purple (, White)
6 / 7 Different Wireless
Groups
Flashing Red
Transmitting DMX Signal
Flashing Green
Receiving DMX Signal
W-DMX
Receive
Protocol
White
Connection is not
Established
Red
Deleting Connection
Red(Fast-Flash)
Connection is Lost
Green(Fast-Flash)
Connecting to Transmitter
Green(Slow-Flash)
Connected, Without DMX
Signal
Green
Connected, Receiving
DMX Signal
Description of the Battery Level Indicator Status
1) In Charging:
1. Red -------------- Level < 40%
2. Flashing Green -------------- 40% <= Level <70%
3. Flashing Blue -------------- 70% <= Level <100%
4. Blue -------------- Level = 100% (full charge)

www.lc-group.ca LCG-WDMX-RCB User manual
2) In Discharge: (Except for low battery, the battery level display will go out
after 5 seconds. Press the button to display the battery level again for 5
seconds.)
1. Blue -------------- 70% <= Level
2. Green -------------- 40% <= Level <70%
3. Red -------------- 10% <= Level <40%
4. Flashing Red -------------- Level < 10% (low battery)
Operation Guide
1. Set-up mode:
Press and hold the button before you power up. When you see status indicator
turns into the white light, release the button to enter the Set-up mode. In this mode
you can select different transmission protocols. Each time you press the button,
you would see the status indicator changes in follow order: red, green, blue and
yellow. Choose one of the protocols, then press and hold the button (> 1S), when
you see the white light, release it to enter the use mode.
2. Use mode:
1) Powered up and enter the Use mode;
2) If it is in Set-up mode, press and hold the button (> 1S) until you see the white
light, then release it to enter the Use mode.
2.1. In WIDMX protocol or GZ protocol, you could select different DMX
Group:
1) The first time when you press the button, it will not change the color but show
you the group that you are in.
2) If you press it again it will switch to other group.
2.2. In W-DMX Receive protocol:
Press and hold (> 3S) the receiver’s button until the indicator turns white. The
device would disconnect with the transmitter.

www.lc-group.ca LCG-WDMX-RCB User manual
Specifications
Form Factor
Type: stand-alone installation
Size: 85 x 18 x 18 mm
Weight: 110 g
System Information
CPU: 32-bit ARM Core (Cortex-M4)
Radio Parameters
Range: 600 meters (line-of-sight)
Frequency: 2.402 - 2.480GHz, ISM, 79 channels
Spread Spectrum: FHSS, 1100 hops / sec
Modulation: GFSK
Maximum Transmit Power: 23dBm
Receiver Sensitivity: -94dBm
DMX Signal Interface
3-pin female XLR
Environmental Limits
Operating Temperature: -40 ~ 85 °C
Storage Temperature: -65 ~ 150 °C
Ambient Relative Humidity: 5 to 95% (non-condensing) Power
Requirements
Charging input: 500 mA@5V DC
Charging time: 90% @ 50 minutes, 70 minutes full charge
Discharge time: 20 hours max.
Reliability
Automatic Reboot Trigger: Built-in WDT (watchdog timer)
