LCI CORRECT TRACK HANGER Use and care manual

Rev: 01.14.19 Page 1 CCD-0001695
TI-300
AXLES AND SUSPENSION
CORRECT TRACK™ HANGER REPLACEMENT
The "WARNING" symbol above is a sign that the installation procedure has a safety risk involved and
may cause death, serious personal injury and/or product or property damage if not performed safely and
within the parameters set forth in this instruction sheet.
Introduction
This document details the steps to remove a damaged Correct Track™ hanger and replace it with a new hanger.
Safety
Always lift trailer by the frame, never the axle or suspension. Do not go under the trailer unless it is
properly supported by jack stands. Unsupported trailers can fall causing death or serious injury. This
repair should only be completed by an authorized service technician.
Always wear eye protection when performing service or maintenance to the trailer. Other safety
equipment to consider would be hearing protection, gloves and possibly a full face shield,
depending on the nature of the service.
• New hangers (PNs
303917 or 303918)
• Jack stands
• Floor jacks
• Welder
• Torque wrench
• Personal protective
equipment (PPE)
for welding
• Die grinder with
cutting wheel
attachment
• Cordless or electric
drill or screw gun
• Appropriate drive
bits
• Tape measure
• Marker
• Fire blankets
or other heat
protective devices
• Black spray paint
• Lint-free wipes
• Mineral spirits
Failure to remove ammable objects, obstructions, tires, axles or additional suspension components
may result in death, serious personal injury and/or severe product or property damage.
Resources Required
Instructions
Preparation
NOTE: Solid orange lines in this instruction sheet refer to using a grinder to remove components. Solid red/
black lines refer to using a welder to add frame components.
1. Lift front and rear of frame with floor jacks and stabilize with jack stands.
2. Support framework in accordance with the manufacturer's recommendation.
3. Remove tires.
4. Remove underbelly material, if applicable.
5. Remove any gas lines, flammable items and/or obstructions that may be damaged during the repair or
that may present a danger when welding.
Moving parts can pinch, crush or cut. Keep clear and use caution.
Rev: 01.14.19 Page 2 CCD-0001695
TI-300
AXLES AND SUSPENSION
CORRECT TRACK™ HANGER REPLACEMENT
Failure to remove flammable objects, obstructions, tires, axles or additional suspension components
may result in death, serious injury and/or severe product or property damage.
6. Using heat-resistant material, cover any remaining components within the welding area that could not
be removed or relocated.
7. Stabilize axles with floor jacks.
8. Measure the distance between the axle hanger to be replaced and the adjacent hanger (Fig. 1). Record
the measurements.
Fig. 1
Fig. 2
9. Remove cam and bolt assembly from the hanger (Fig. 2) and set aside.
NOTE: I-beam removed for clarity.
NOTE: Record position of cam for later use.
10. Lower axle and spring nearest the hanger to be replaced.
Measure
and
Record
Measure
and
Record
11. Using a die grinder with a cutting wheel, cut through each weld on all four sides of the hanger (Fig 3).
Make sure not to cut into the frame.
12. Grind off any excess welding material until the surface of the frame is smooth. Make sure not to grind
into the frame.
Measure and Record
Rev: 01.14.19 Page 3 CCD-0001695
As a supplier of components to the RV industry, safety, education and customer satisfaction are our primary concerns. Should you
have any questions, please do not hesitate to contact us at (574) 537-8900 or by email at [email protected]. Self-help tips,
technical documents, product videos and a training class schedule are available at lci1.com or by downloading the MyLCI app.
TI-300
AXLES AND SUSPENSION
CORRECT TRACK™ HANGER REPLACEMENT
Fig. 3 Fig. 4
Cut Through
Welds
¼" Continuous
Weld
Installation
1. Measure and mark the frame where the new hanger will be mounted (refer to Preparation section).
Make sure the new hanger is properly aligned.
2. Weld the new hanger into place using a 1/4" continuous weld bead on all four sides (Fig. 4).
Post-Weld Cleanup
1. Allow welded areas to cool completely.
Overspray or dripping of paint and solvents onto an unprotected oor can create a slipping hazard.
Slipping on wet surfaces can causes personal injury. Use a drop cloth or other similar protective
material on the work area to prevent slipping.
2. Chip off any flux from the welds and inspect the welds for completeness.
3. Paint over the welded areas with rust inhibitor spray paint or brushed-on paint.
NOTE: Spray and brush applications will have uniquely different appearances.
4. Let painted areas on the chassis/frame dry completely.
5. Reinstall all previously removed or relocated components (steps 3-5 of the Preparation section) to their
original location.
6. Raise axle and spring to align the spring holes with the hanger.
7. Reinstall Correct Track cams on front and back sides of the hanger in their original positions (step 9 of
the Preparation section).
8. Insert shoulder bolt from the back side of the hanger and extend bolt through the cams and hanger.
9. Torque shoulder bolt nut to 30-50 ft-lbs.
10. Reinstall axle, tire and other components previously removed.
11. Lower the trailer to the ground.
