Ld Sc-12/r User manual

User’s manual

product code: 991247

SC-12/R

CODE 991247

SCANNER

SC-12/R

INTRODUCTION................................................................................................page 2

SAFETY PRECAUTIONS...................................................................................page 3

TECHNICAL FEATURES...................................................................................page 4

ASSEMBLING...................................................................................................page 5

CONNECTION TO THE POWER SUPPLY.........................................................page 6

MOUNTING AND REPLACING THE LAMP......................................................page 7

FOCUS AND MIRROR ADJUSTMENT.............................................................page 8

GOBOS REPLACEMENT...................................................................................page 8

DMX SIGNAL CONNECTION............................................................................page 9

CONFIGURATION AND CONTROLS................................................................page 10

SWITCH “OPTIONS”.........................................................................................page 11

DMX CHANNELS FUNCTIONS........................................................................page 12

TROUBLESHOOTING.......................................................................................page 13

•TABLE 1 - GENERAL PROBLEMS........................................................page 13

•TABLE 2 - PROBLEMS TO THE CONNECTION DATA LINK...............page 14

•MOTORS PC BOARD...........................................................................page 15

MAINTENANCE................................................................................................page 18

APPENDIX “A” - 8 CHANNELS CONFIGURATION..........................................page 18

INDEXINDEX

INDEX

We thank you for choosing the SC-12/R.

Characterized by an attracting design and an

incredible optic system, the SC-12/R is suitable

for any kind of ambient.

A modern and reliable electric circuit gives

stability and functioning safety for long time.

To make the most of this unit and to make it

work correctly in the years, before connecting

it to its source and using it, we suggest you to

carefully read this manual.

In this way you could be more familiar with

its commands and connections so to easily

use it.

INTRODUCTIONINTRODUCTION

INTRODUCTION

All the sections of this manual have been studied to make as easy and complete as possible the use of the SC-12/R.

To make the manual more clear and easy to consult, we have used the following symbols and conventions:

very important warnings, to be read with the maximum attention;

important parts of the text that give details and/or explanations on the use of

the SC-12/R.

practical advices for an efficient use of the SC-12/R.

IMPORTANT

The safety of the unit is guaranteed only strictly following the instructions, so it is recommended

to accurately preserve them.

SC-12/R

CODE 991247

•PROTECTION AGAINST FIRE

1) This unit has been made to work only with the Lamp: HMI 1200W GS (OSRAM).

!ABSOLUTELY NEVER USE OTHER KIND OF LAMPS.

2) Keep a minimum distance of 0,3 mt. from walls or any inflammable surface.

3) Keep a minimum distance of 1 mt. from lighted objects.

4) Replace the fuses with others of the same kind and value (5x20 250V 10A).

5) Do not install the projector close to heat sources. Do not lay the connection cables on the projector when it is hot.

•PROTECTION AGAINST ELECTRIC SHOCKS

1) This projector must be earthed.

2) Class I equipment. The protection conductor must be part of the power supply cable.

3) For the connection to the main power supply proceed as in fig. 2/a, page 6.

4) Disconnect the power supply before the Lamp replacement or before opening the unit.

5) Do not install the projector outdoors, exposed to rain or moisture.

•PROTECTION AGAINST MECHANICAL HAZARDS

1) When installing the projector use a safety chain.

2) To avoid explosion risks, open the projector only after 5 minutes after the lamp is off.

3) The temperature of the projector can reach high levels. Wait for almost 5 minutes before operating on it.

4) Replace the Lamp if it is damaged or deformed by the heat.

•PROTECTION AGAINST UV RADIATIONS HAZARDS

1) Do not start on the projector without the protecting screen or if the lenses and the ultra-violet filters are

damaged.

2) The protecting screens, the lenses and the ultra-violet filters must be replaced if visibly damaged and if their

efficiency has been reduced, for example by slits or deep cuts.

3) Do not directly look at the Lamp when it is on.

•WARNINGS

1) Do not dismantle and modify the unit.

2) To avoid any inflammable liquids, water or metal objects entering the unit.

SAFETY PRECASAFETY PRECA

SAFETY PRECAUTIONSUTIONS

UTIONSUTIONS

UTIONS

READ ALL CAUTIONS AND WARNINGS PRIOR TO OPERATE THIS EQUIPMENT.

INSTRUCTIONS TO PREVENT INJURIES OR DAMAGES DUE TO FIRE, ELECTRIC SHOCKS, MECHANICAL

HAZARDS AND UV RADIATIONS HAZARDS.

IMPORTANT

SC-12/R

CODE 991247

SAFETY PRECASAFETY PRECA

SAFETY PRECAUTIONSUTIONS

UTIONSUTIONS

UTIONS

Make sure that the unit has not been damaged during the transportation.

In case it has happened or in case the unit does not work correctly, immediately contact the Retailer.

If the unit has been directly sent to you , immediately contact the Freight Company.

Only the final receiver (the person or the Company that receive the unit) is in the position to

complain for the above inconveniences.

YOUR REFERENCE

Cite the model and the serial number anytime you contact your retailer to ask for information or assistance.

STANDARD PACKAGE

The standard package of the SC-12/R contains:

1) Projector ON REQUEST:

2) Mains connector * Lamp (code 060268)

3) DMX XLR5 (pc. 2) signal connectors * Flight Case without wheels (code 194979)

4) User’s manual * Black clamp Ø50 (code 194019)

5) Guarantee

IMPORTANT

TECHNICAL FEATECHNICAL FEA

TECHNICAL FEATURESTURES

TURESTURES

TURES

SC-12/R

CODE 991247

PMALPMAL PMAL PMALPMAL

)MARSO(SGW0021IMHpmalegrahcsiD

K°006.5:erutarepmetruoloC

sruoh057:efilpmalegarevA

TNEMEVOMTNEMEVOM TNEMEVOM TNEMEVOMTNEMEVOM

.TLIT°04,NAP°081:.cd2+srotomreppetS6

dnalatnoziroheht,srotomreppetsehtfospets-orcimfometsysdetacitsihposaotsknahT

wolsdnatsafhtobnietaruccadnaraenilylemertxeerarorrimehtfostnemevomlacitrev

.stnemevom

LACITREVLACITREV LACITREV LACITREVLACITREV

TNEMEVOM

°05-/°05+

.noitatneirolaunaM

SRUOLOCSRUOLOC SRUOLOC SRUOLOCSRUOLOC .)7egap,a/3.gif(ETIHW+)elbaegnahcretnilla(SRUOLOC9

.)tceffewobniar(leehwruolocehtfodeepsnoitatorehtetalugerotelbissopsitI

SOBOGGNITATORSOBOGGNITATOR SOBOGGNITATOR SOBOGGNITATORSOBOGGNITATOR .)7egap,a/3.gif(ETIHW+)elbaegnahcretnilla(SOBOGGNITATOR6

.)tceffewobniar(leehwobogehtfodeepsnoitatorehtetalugerotelbissopsitI

SOBOGDEXIFSOBOGDEXIF SOBOGDEXIF SOBOGDEXIFSOBOGDEXIF .)7egap,a/3.gif(ETIHW+)elbaegnahcretnilla(SOBOGDEXIF9

.)tceffewobniar(leehwobogehtfodeepsnoitatorehtetalugerotelbissopsitI

TUOKCALB/OBORTSTUOKCALB/OBORTS TUOKCALB/OBORTS TUOKCALB/OBORTSTUOKCALB/OBORTS .ycneuqerfelbatsujdanahtiwtceffeOBORTS;tceffeTUOKCALB

.).ces/hsalf21.xam,.ces/hsalf1.nim(

MSIRPGNITATORMSIRPGNITATOR MSIRPGNITATOR MSIRPGNITATORMSIRPGNITATOR .deepsnoitatorelbatsujdA.msirPsecaf-eerhtgnitatoR

MAEBTHGILMAEBTHGIL MAEBTHGIL MAEBTHGILMAEBTHGIL

EDUTILPMA

.ecnatsidfo.tm6tarotcejorpehthtiw,)°5,31(.tm3,1.maiD

REWOPTUPNIREWOPTUPNI REWOPTUPNI REWOPTUPNIREWOPTUPNI

.zH05;caV032:egatlovgnitarepolanimoN•

.W0031:ylppusrewopdetaR•

.)caV032(A01:tnerruclanimoN•

GNIKROWGNIKROW GNIKROW GNIKROWGNIKROW

NOITISOP

.noitisopynA

SNOISNEMIDSNOISNEMID SNOISNEMID SNOISNEMIDSNOISNEMID

)HxDxW(

.)5egap,1.giF(593x028x084.mm

THGIEWTHGIEW THGIEW THGIEWTHGIEW 33.gK

YDOBYDOB YDOB YDOBYDOB .muinimuladnaleetS

395mm.

fig. 1

TECHNICAL FEATECHNICAL FEA

TECHNICAL FEATURESTURES

TURESTURES

TURES

BRACKET

MANUAL ORIENTATION

KNOBS

ASSEMBLINGASSEMBLING

ASSEMBLING

!Before installing the SC-12/R, make sure that the carrying structure is safe and able to support the weight of

the unit.

The SC-12/R is equipped with a bracket with three holes (diam. 10 mm.) to fix clamps and/or screw bolts (fig. 1).

To orientate the unit, follow these instructions:

1) Unscrew the knobs placed at the both sides of the unit (fig. 1);

2) Orientate the unit in the preferred position;

3) Screw the above said knobs.

!Once finished make sure that the unit is correctly fixed and stable.

!Always make sure that you are using a safety chain.

!Do not install the unit outdoor directly exposed to rain or moisture.

!To avoid installing the projector close to heat sources.

!The unit must be at a minimum distance of 30 cm. from the walls or from any inflammable material and 1 mt.

from lighted objects.

!The unit must be placed where it could be easily aerated. To avoid obstructing the in/out air gratings.

SC-12/R

CODE 991247

ITALY

SC-12/R HMI 1200

230

1300

55/02

Amp.

Lamps

Max. Temp.

S.R.L.

SPEC.

50°C

HMI 1200

fig. 2

BEFORE USING THE PROJECTOR

!Carefully read the precautions on page 3 before installing the projector.

In particular read the following points:

1) Disconnect the power supply before replacing the lamp or doing any maintenance job.

2) Do not open the projector if are not passed at least 5 minutes after it went off.

3) Always wear protective gloves and goggles to replace the lamp or to work inside the projector.

4) The protecting screens, the lenses and the ultra-violet filters must be replaced if visibly damaged.

Slits or deep cuts remarkably reduce their efficiency.

5) To avoid any bad performance of the projector or that the lamp breakage could damage its optic,

replace the lamp as soon as it reaches its average life time (750 hrs).

6) Periodically clean the in/out air grates.

7) In case the projector must be held on a structure (truss), make sure that it is well and safely fixed,

even using a safety chain from the projector to the structure.

8) Do not install the projector outdoors, directly exposed to rain and moisture.

9) Before connecting the projector to the main power supply, make sure that the working voltage and

frequency correspond to the values indicated on the label (fig. 2).

The SC-12/R is supplied to work at a working voltage of 230V 50Hz (60Hz on request); 10A.

For being supplied with a voltage of 100-120V it is absolutely necessary an auto-transformer with

the following characteristics:

• Output voltage 230V.

• Output current 11A.

10) The connection of the projector to the mains is described in fig. 2/a:

10 a) Do not install the projector close to heat sources. Do not lay the connection cables on the

projector when it is hot.

10 b) The unit must be placed where it could be easily aerated. To avoid obstructing the in/out air

gratings.

10 c) The projector must be distanced almost 0,3 mt. from walls or any inflammable surface

and almost 1mt. from lighted objects.

The unit must be connected to the earth. The inobservance of these

instructions automatically makes the guarantee expiring.

CONNECTION TCONNECTION T

CONNECTION TO THE POWER SUPPLO THE POWER SUPPL

O THE POWER SUPPLO THE POWER SUPPL

O THE POWER SUPPLYY

IMPORTANT

POWER SUPPLY INPUT

SC-12/R

CODE 991247

fig. 2/a

L = PHASE (Brown)

N = NEUTRAL (Blue)

= EARTH (Green - Yellow)

THREE POLES FEMALE CONNECTOR

FOR THE CONNECTION TO THE MAINS

fig. 3/a

fig. 3

LOCKING BOLT

TOP COVER

LAMP

PROTECTION COVER

OF THE LAMP

LATERAL BUSHES

GOBOS

COLOURS

THERMIC

PROTECTOR

MIRROR

1) Disconnect the projector before replacing the lamp. Wear protective gloves and goggles.

2) Unscrew the locking bolt of the rear panel of the projector (fig. 3).

3) Take out the top cover and disassemble the lamp, pushing it towards its spring clip and rotating it up (fig. 3 and 3/a).

4) Undo the two lateral bushes of the lamp and take it out (fig. 3/a).

Before mounting the new lamp, make sure that into the lamp holder there is not anything that may cause

interruptions to the thermic and electrical conduction.

5) Undo the two lateral bushes of the new lamp and insert it in the lamp holder positioning up the bulb protuberance,

fasten the lamp bushes.

!Avoid touching the new lamp with the nude hands; in case it accidentally happens, clean the bulb with the

proper tissue given with the replacement lamp.

6) Make sure the spring clip is back in its place, assemble the top cover and the locking bolt.

MOUNTING AND REPLAMOUNTING AND REPLA

MOUNTING AND REPLACING THE LAMPCING THE LAMP

CING THE LAMPCING THE LAMP

CING THE LAMP

In case of replacement of the Lamp or maintenance, never open the unit

unless are passed at least 5 minutes after it went off.

IMPORTANT

SC-12/R

CODE 991247

FOCUS AND MIRROR ADJUSTMENTFOCUS AND MIRROR ADJUSTMENT

FOCUS AND MIRROR ADJUSTMENT

fig. 4

GOBOS REPLAGOBOS REPLA

GOBOS REPLACEMENTCEMENT

CEMENTCEMENT

CEMENT

To do this operation, it is suggested to use two GOBOS with patterns superinposition (i.e. GOBO B “ROTATING

GOBO wheel” + GOBO B “FIXED GOBO wheel”).

FOCUS ADJUSTMENT

To focus do as follows:

•loosen the knob placed on the objective (fig. 4);

•move the objective forwards/backwards to reach the best focus;

•fasten the knob.

MIRROR ADJUSTMENT

It is possible to orientate the mirror housing, turning it of 180° right/left. To do the above mentioned operation it is

necessary to:

• loosen the two knobs placed on both sides of the objective, using a cross screw driver (fig. 4);

• orientate the mirror housing until the preferred position is reached;

• lock the two knobs.

It is also possible to remove the mirror housing. To do the above mentioned operation it is necessary to:

• unscrew the focus regulation knob;

• loosen the two mirror regulation knobs;

• disconnect the connector, unscrewing the appropriate bush (fig. 4);

!ATTENTION: disconnect/connect the connector only when the projector is Off.

• take off the mirror housing;

• screw the focus regulation knob.

To assemble again the mirror housing, do the above mentioned instructions in the opposite direction.

OBJECTIVE

MIRROR

REGULATION KNOB FOCUS REGULATION

KNOB

BUSH

CONNECTOR

SC-12/R

CODE 991247

To replace the GOBOS is extremely simple:

1) Disconnect the projector from the power supply;

!In case it has been recently used, make sure that has cooled down.

2) Unscrew the locking bolt of the rear panel of the projector and take out the top cover (fig. 3, page 7);

3) Keep stopped the rotor and softly take out the spring using a pointed object;

4) Replace the GOBO and softly take back the spring.

!Never push on the GOBO to take out the spring, to avoid damaging the same GOBO and/or the rotor.

DMX CONTROLLER

LINE TERMINAL

PROJECTOR

LINE TERMINAL

DMX CONTROLLER

LINE TERMINAL

DMX LINE TERMINAL

Do not connect or wrongly connect the DMX line terminal is probably the most common cause of a defective

functioning of a DMX line.

The DMX line terminal is a resistance placed between the two data pin 2 and 3 at the end of the line.

The terminal resistance should ideally have the same value of the impedance of the DMX connecting cable.

It is recommended, for all DMX system, to insert the line terminal into the DMX output connector of the last

connected projector .

EXAMPLES OF CONNECTIONS: DMX CONTROLLER - PROJECTOR

DMX CONTROLLER

DMX SIGNAL CONNECTIONDMX SIGNAL CONNECTION

DMX SIGNAL CONNECTION

It is suggested to use a DMX line terminal with a resistance value of 100/120 Ohm.

We supply, on request, a DMX line terminal with a resistance value of 120 Ohm.

IMPORTANT

PROJECTOR

PROJECTOR PROJECTOR

LAST PROJECTOR

LINE < 100mt. (with microphonic or audio cable)

PROJECTOR

LAST PROJECTOR

SIGNAL

AMPLIFIER

DMX 1 output line

DMX 2 output line

EXAMPLE 1

Controller-projector connection with

only one DMX 512 OUTPUT LINE

SIGNAL

AMPLIFIER

EXAMPLE 2

Controller-projector connection with

two or more DMX 512 OUTPUT LINE

EXAMPLE 3

Controller-projector connection with only one

DMX 512 OUTPUT LINE long more than 150mt.

EXAMPLE 4

Controller-projector connection with only one

DMX 512 OUTPUT LINE long more than 150mt.

LINE > 150mt. (with microphonic or data transmission cable)

LINE < 100mt. (with microphonic or audio cable)

SC-12/R

CODE 991247

fig. 5

fig. 5/a

On the rear panel of the SC-12/R (fig. 6) there are some led and some switches to correctly configure the projector.

LEDLED

LED

• Led “POWER” (green) on: the main pc board receives the right power supply;

off: the main pc board is not supplied.

• Led “DMX” (yellow) flashing: the DMX input signal is on;

off: the dmx input signal is out.

• Led “CONTROL” (red) on: the ROTATING GOBO and the COLOUR wheels have not been

properly settled;

flashing: the DMX address is incorrect;

off: the settling has been correctly executed.

fig. 6

NIPNIP NIP NIPNIP ERIWERIW ERIW ERIWERIW LANGISLANGIS LANGIS LANGISLANGIS

1DLEIHSVO/NRUTER/DNUORG

2ROTCUDNOCRENNI)DETREVNI,-(TNEMELPMOCATAD

3ROTCUDNOCRENNI)DETREVNINON,+(EURTATAD

4.C.N

5.C.N

SWITSWIT

SWITCHCH

CHCH

• START ADDRESS to fix the DMX addresses.

• OPTIONS to activate/not activate

optional functions.

DMX SIGNAL CONNECTIONDMX SIGNAL CONNECTION

DMX SIGNAL CONNECTION

The DMX signal connection to the SC-12/R must be done through the input signal connectors XLR 5 pins, placed on

the rear panel of the projector (fig. 5).

The nomenclature of the pins of the DMX input connectors is listed in the table reported in fig. 5/a.

To avoid any problem in the transmission of the signal it is recommended to use a cable for very fast data

transmissions.

A normal audio cable is suitable only for lines long not more than 100mt.

The best performances and the maximum stability are obtained using a shielded microphonic cable which section

must be of at least 2x0,25mm, or, a data transmission cable.

In case of lines long more than 150/200mt. it is recommended to use a DMX Repeater Amplifier.

CONFIGURACONFIGURA

CONFIGURATION AND CONTROLSTION AND CONTROLS

TION AND CONTROLSTION AND CONTROLS

TION AND CONTROLS

SC-12/R

CODE 991247

On the rear panel of the projector there are some switches - switch “OPTIONS” (fig. 7) - to be used to activate or not

activate the following options:

• COLOURS NORMAL/BLACKOUT ON: to change colours (COLOUR wheel) obscuring the light beam;

(DIP-SW “2”) OFF: to change colours (COLOUR wheel) not obscuring the light beam.

• GOBOS NORMAL/BLACKOUT ON: to change gobos (ROTATING GOBO wheel) obscuring the light

(DIP-SW “3”) beam;

OFF: to change gobos (ROTATING GOBO wheel) not obscuring the

light beam.

• REVERSE PAN&TILT CHANNELS ON: to reverse the PAN/TILT channels,

(DIP-SW “4”) OFF: normal.

• REVERSE PAN ON: to reverse the PAN movement;

(DIP-SW “5”) OFF: normal.

• REVERSE TILT ON: to reverse the TILT movement;

(DIP-SW “6”) OFF: normal.

• RESERVED FOR CHECKING ON: to execute the projector setting;

(DIP-SW “7”) OFF: normal.

• TEST ON: to execute the self-setting;

(DIP-SW “8”) OFF: normal.

SWITCH “OPTIONS”SWITCH “OPTIONS”

SWITCH “OPTIONS”

fig. 7

SWITCH “OPTIONS”

SWITCH “START ADDRESS”

SC-12/R

CODE 991247

°NLENNAHC°NLENNAHC °NLENNAHC °NLENNAHC°NLENNAHC NOITCNUFROTCEJORPNOITCNUFROTCEJORP NOITCNUFROTCEJORP NOITCNUFROTCEJORPNOITCNUFROTCEJORP

1MSIRP

2WOBNIAR+SRUOLOC

3WOBNIAR+SOBOGGNITATOR

4DEEPSEBORTS/RETTUHS

5ESRAOCNAP

6ESRAOCTLIT

7SOBOG.TOR

8WOBNIAR+SOBOGDEXIF

ROTCEJORPROTCEJORP ROTCEJORP ROTCEJORPROTCEJORP

REBMUN SLENNAHCSLENNAHC SLENNAHC SLENNAHCSLENNAHC

"SSERDDATRATS"HCTIWS"SSERDDATRATS"HCTIWS "SSERDDATRATS"HCTIWS "SSERDDATRATS"HCTIWS"SSERDDATRATS"HCTIWS
